MICROPROCESSOR CRYSTALS SURFACE MOUNT
CERAMIC LOW PROFILE
ABMM3
Frequency Range
3.5 MHz - 25 MHz
Operation Mode
Fundamental, AT
Operating Temperature
-10C to + 60 C
(See Options)
Storage Temperature
-55C to + 125 C
Frequency Tolerance
@
25C
50 ppm max.
(See Options)
Frequency Stability over Temp.
50 ppm max.
(See Options)
Equivalent Series Resistance
200 W for 3.5 MHz < F < 4.0 MHz
(ESR) Maximum
150 W for 4.0 MHz < F < 6.0 MHz
100 W for 6.0 MHz < F < 10.0 MHz
80 W for 10 MHz < F < 14.0 MHz
50 W for 14 MHz < F <_ 25 MHz
Shunt Capacitance C
0
7 pF max.
Load Capacitance C
L
16pF
(See Option)
Drive Level
100W max.
Aging
@
25 C First Year
5 ppm max.
Insulation Resistance
500
M
W
min. at 100 Vdc 15V
S
S
T
T
A
A
N
N
D
D
A
A
R
R
D
D
S
S
P
P
E
E
C
C
I
I
F
F
I
I
C
C
A
A
T
T
I
I
O
O
N
N
S
S
Frequency Range
13.0MHz - 120.0MHz
Operation Mode
13.00MHz ~ 40MHz
(Fundamental)
40.01MHz ~ 120MHz
(3rd overtone)
Operating Temperature
-10C to +60C (See Options)
Storage Temperature
-40C to +85C
Frequency Tolerance @ 25C
50ppm max. (See Options)
Frequency Stability over Temp.
50ppm max. (See Options)
Equivalent Series Resistance 80 W max. for 13.00MHz < F < 20.0MHz
(ESR) Fundamental
50 W max. for 20.0MHz < F < 40.0MHz
3rd Overtone
100 W max. for 40.0MHz < F < 120.0MHz
Shunt Capacitance C
0
7pF max.
Load Capacitance C
L
18pF (See Options)
Drive Level
100W max
Aging
@
25C per Year
5ppm max.
Insulation Resistance:
500M W min. at 100Vdc 15V
APPLICATIONS:
PCMCIA applications.
Suitable for thin equipment.
FEATURES:
Low in height; (1.3 mm) suitable for thin equipment.
Wide frequency range.
Superior heat-resistant glass sealing
Suitable for solder reflow.
Environmental, and mechanical specifications, see appendix C. Group 2.
Marking, see appendix G.
Tape and Reel, see appendix H.(1,000 pcs/reel)
Reflow profile, see appendix E.
Recommended handling, see appendix F.
Application notes see appendix A.
ABMM3 - Frequency - CL - ESR - Temperature - Tolerance - Stability - Packaging
XX.XXXX MHz
RXXX
(value in
W
)
-2 for 20ppm
-3 for 25ppm
-4 for 30ppm
- T
(Tape
&
Reel)
-X for 20ppm
-W for 25ppm
-Y for 30ppm
-H for 35ppm
-Z for 100ppm
-E for 0C to + 70C
-B for -20C to + 70C
-C for -30C to + 70C
-N for -35C to + 85C
-D for -40C to + 85C
ORDERING
OPTIONS
Load cap. in pF
or -S for Series
Dimensions: Inches (mm)
6.0 x 3.5 x 1.3 mm
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
NOTE: Left blank if standard
All specifications and markings subject to change without notice
29 Journey Aliso Viejo, CA 92656 USA
(949) 448-7070 F
AX
: (949) 448-8484
E-
MAIL
:
abinfo
@
abracon.com
I
NTERNET
A
DDRESS
:
www.abracon.com
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
ABRACON
C O R P O R A T I O N
