Serial-Port 16-Bit

SoundComm Codec

AD1843

FEATURES
Single Chip Integrated Speech, Audio, Fax and Modem

Codec

Highly Configurable Stereo

ADCs and Quad

DACs

Supports V.34, V.32bis, and Fallback Modem Standards

As Well As Voice Over Data

Dual Digital Resamplers with Programmable Input and

Output Phase and Frequency

Three On-Chip Phase Lock Loops for Synchronization to

External Signals, Including Video

Thirteen Analog Inputs and Seven Analog Outputs
Advanced Analog and Digital Signal Mixing and Digital-

to-Digital Sample Rate Conversion

Programmable Gain, Attenuation and Mute
On-Chip Signal Filters

Digital Interpolation and Decimation
Analog Output Low Pass

1 Hz Resolution Programmable Sample Rates from 4 kHz

to 54 kHz Derived from a Single Clock Input

80-Lead PQFP and 100-Lead TQFP Packages
Operation from +5 V or Mixed +5 V/+3 V Supplies
FIFO-Buffered Serial Digital Interface Compatible with

ADSP-21xx Fixed-Point DSPs

Advanced Power Management
VHDL Model of Serial Port Available; Evaluation Board

and MAFE Board Available

GENERAL PRODUCT DESCRIPTION

The AD1843 SoundCommTM Codec is a complete analog front
end for high performance DSP-based telephony and audio ap-
plications. The device integrates the real-world analog I/O re-
quirements for many popular functions thereby reducing size,
power consumption, and system complexity. The AD1843
SoundComm is the world's first codec which can support four
different sample rates simultaneously, without any beat fre-
quency noise issues. This is essential for highly integrated audio/
modem/fax products since the sample rates associated with au-
dio are very much distinct from the sample rates associated with
telephony-oriented data communication. It is also the first codec
to offer on-chip digital phase lock loops for sample rate synchro-
nization to external clock signals. This sample rate flexibility is
enabled through Analog Devices' Continuous Time Oversampling
(CTO) technology.

The main elements of the AD1843 are its extensive input and mix-
ing section, its two channels of sigma-delta (

) analog-to-digital

conversion, its four channels of

digital-to-analog conversion, its

digital filters, and the clock and control circuitry for implementing
the device's different modes. The AD1843 permits flexible sample-
rate selection through programming and external synchronization,
many input and output options, and many mixing options.

(continued on page 11)

SoundComm is a trademark of Analog Devices, Inc.

REV. 0

Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 617/329-4700

Fax: 617/326-8703

SIMPLIFIED FUNCTIONAL BLOCK DIAGRAM

20 dB

GNDA

ADC

GAM = GAIN
ATTENUATION
MUTE

GAM

FIFO

ADC

DAC1

DAC2

T
A
L

N
T
E
R
F
A
C
E

CONTROL

REGISTERS

LEFT AND

RIGHT CHANNELS

LEFT AND

RIGHT CHANNELS

GNDD

FILTL

CMOUT

REF

FILTR

HPOUTR

HPOUTC

HPOUTL

LOUT1

MOUT

MIN

AUX3

AUX2

AUX1

MIC

LIN

SYNC

XTAL

CONV

BIT

CLKOUT

LOUT2

AAFILTL AAFILTR

SUM

RESET

PWRDWN

PDMNFT

MUTE

GAM

MUTE

ATTN

MUTE

S
E
L
E
C
T
O
R

MUTE

SCLK

SDFS

SDI

SDO

TSO

TSI

XCTL [1:0]

µ/A

LAW

CLOCK GENERATION

ATTN

U
T

MUTE

DRIVER

µ/A

LAW

FIFO

µ/A

LAW

S
E
L
E
C
T
O
R

PGA

DAC

MUTE

U
T

ATTN

VOLTAGE REFERENCE

AD1843

ANALOG INPUT

Min

Typ

Max

Units

Full-Scale Input Voltage (RMS Values Assume Sine Wave Input)

All Inputs with ADRFLT & ADLFLT = 0 and LINLSD & LINRSD = 0

V rms

(LINLP, LINRP, AUX1L, AUX1R, AUX2L,

2.55

2.828

3.1

V p-p

AUX2R, AUX3L, AUX3R, MIN)
All Inputs with ADRFLT & ADLFLT = 0 and LINLSD & LINRSD = 1

V rms

(LINLP & LINLN, LINRP & LINRN)

5.1

5.656

6.2

V p-p

All Inputs with ADRFLT & ADLFLT = 1 and LINLSD & LINRSD = 0

1.127

V rms

(LINLP, LINRP, AUX1L, AUX1R, AUX2L, AUX2R, AUX3L,

2.8

3.156

3.5

V p-p

AUX3R, MIN)
All Inputs with ADRFLT & ADLFLT = 1 and LINLSD & LINRSD = 1

2.254

V rms

(LINLP & LINLN, LINRP & LINRN)

5.6

6.312

7.0

V p-p

MIC with +20 dB Gain (LMGE & RMGE = 1

and ADRFLT & ADLFLT = 0)

0.1

V rms

(MICL, MICR)

0.25

0.2828

0.31

V p-p

MIC with 0 dB Gain (LMGE & RMGE = 0

and ADRFLT & ADLFLT = 0)

V rms

(MICL, MICR)

2.55

2.828

3.1

V p-p

AUX, SUM and MIN Input Impedance*

10K

(AUX1L, AUX1R, AUX2L, AUX2R, AUX3L, AUX3R, SUML,
SUMR, MIN)

LIN Input Impedance* (LINLP, LINLN, LINRP, LINRN)

40K

MIC Input Impedance* (MICL, MICR)

20K

Input Capacitance* (All Inputs)

PROGRAMMABLE GAIN AMPLIFIERADC

Min

Typ

Max

Units

Step Size (0 dB to 22.5 dB) (All Steps Tested)

1.3

1.5

1.7

PGA Gain Range Span*

21.5

22.5

23.5

INPUT (AUX1, AUX2, AUX3, MIN, MIC)
ANALOG AMPLIFIERS/ATTENUATORS

Min

Typ

Max

Units

Step Size (+12.0 dB to 30 dB) (All Steps Tested)

1.25

1.5

1.75

Step Size (31.5 dB to 34.5 dB) (All Steps Tested)

1.1

1.5

1.9

Input Gain/Attenuation Range*

45.5

46.5

47.5

Mute Attenuation*

80.0

AD1843SPECIFICATIONS

REV. 0

STANDARD TEST CONDITIONS UNLESS OTHERWISE NOTED

Temperature

Digital Supply (V

)

5.0

Analog Supply (V

)

5.0

Sample Rate (F

)

kHz

Input Signal

1008

Analog Output Passband

20 Hz to 20 kHz

ADC FFT Size

2048

DAC FFT Size

8192

2.0

0.8

2.4

0.4

ADC Input Conditions

Mic 20 dB Gain Disabled
LIN Single-Ended

(LINLSD & LINRSD = 0)

Autocalibrated
0 dB PGA Gain
1.0 dB Relative to Full Scale
Line Input
16-Bit Linear Mode

DAC Conditions

Autocalibrated
0 dB Attenuation
0 dB Relative to Full Scale
16-Bit Linear Mode
No Output Load
Mute Off
DAC1 Single-Ended
DAC2 Differential

AD1843

REV. 0

DIGITAL DECIMATION AND INTERPOLATION FILTERSAUDIO MODE*

Min

Max

Units

Passband

0.40

Passband Ripple

0.016

Transition Band

0.4

0.6

Stopband

0.6

Stopband Rejection

91.8

Group Delay

15/F

Group Delay Variation Over Passband

0.0

DIGITAL DECIMATION AND INTERPOLATION FILTERSMODEM MODE*

Min

Max

Units

Passband

0.442

Passband Ripple

0.220

Transition Band

0.442

0.542

Stopband

0.542

Stopband Rejection

75.7

Group Delay

19/F

Group Delay Variation Over Passband

0.0

Sample Rate

kHz

DIGITAL DECIMATION AND INTERPOLATION FILTERSRESAMPLER MODE*

Min

Max

Units

Passband

0.4

Passband Ripple

0.035

Transition Band

0.4

0.5

Stopband

0.5

Stopband Rejection

92.2

Group Delay

25/F

Group Delay Variation Over Passband

0.0

ANALOG-TO-DIGITAL CONVERTERS

Min

Typ

Max

Units

Audio Dynamic Range (60 dB Input, THD+N Referenced to Full Scale,

A-Weighted, ADRFLT & ADLFLT = 0)

Modem Dynamic Range (60 dB Input, THD+N Referenced to Full Scale,

300 Hz to 4 kHz Analog Output Passband, LINRSD & LINLSD = 1,
ADRFLT & ADLFLT = 1, F

= 12.8 kHz)

Audio THD+N (Referenced to Full Scale)

0.03

Modem THD+N (3.0 dB Referenced to Full Scale,

300 Hz to 4 kHz Analog Output Passband, LINRSD & LINLSD = 1,
ADRFLT & ADLFLT = 1, F

= 12.8 kHz)

0.02

78.5

Audio Signal-to-Intermodulation Distortion* (CCIF Method)

ADC Crosstalk*

LIN Inputs (Input L, Ground R, Read R; Input R, Ground L, Read L)

Line to MIC (Input LIN, Ground and Select MIC, Read Both Channels)

Line to AUX1, AUX2, AUX3, MIN

Interchannel Gain Mismatch (Difference of Gain Errors)

0.5

ADC Offset Error

REV. 0

AD1843

DAC1 DIGITAL-TO-ANALOG CONVERTERS

Min

Typ

Max

Units

Audio Dynamic Range (60 dB Input, THD+N Referenced to Full Scale,

A-Weighted, DA1FLT = 0)

Audio THD+N (Referenced to Full Scale, DA1FLT = 0)

0.03

Audio Signal-to-Intermodulation Distortion* (CCIF Method)

Interchannel Gain Mismatch (Difference of Gain Errors)

0.5

DAC Crosstalk* (Input L, Zero R, Measure LOUT1R; Input R, Zero L,

Measure LOUT1L)

Total Out-of-Band Energy*

(Measured from 0.6

to 100 kHz in Audio Mode)

Audible Out-of-Band Energy*

(Measured from 0.6

to 22 kHz in Audio Mode,

Tested at F

= 8.0 kHz)

DAC2 DIGITAL-TO-ANALOG CONVERTERS

Min

Typ

Max

Units

Audio Dynamic Range (60 dB Input, THD+N Referenced to Full Scale,

A-Weighted, DA2FLT = 0)

Modem Dynamic Range (60 dB Input, THD+N Referenced to Full Scale,

300 Hz to 4 kHz Analog Output Passband, DA2FLT = 1, RDA2G5:0
& LDA2G5:0 = 000101 [4.5 dB], F

= 12.8 kHz)

Audio THD+N (Referenced to Full Scale, DA2FLT = 0)

0.03

Modem THD+N (3.0 dB Referenced to Full Scale,

300 Hz to 4 kHz Analog Output Passband, DA2FLT = 1, RDA2G5:0
& LDA2G5:0 = 000101 [4.5 dB], F

= 12.8 kHz)

0.016

Audio Signal-to-Intermodulation Distortion* (CCIF Method)

Interchannel Gain Mismatch (Difference of Gain Errors)

0.5

DAC Crosstalk* (Input L, Zero R, Measure LOUT2R; Input R, Zero L,

Measure LOUT2L)

Total Out-of-Band Energy*

(Measured from 0.6

to 100 kHz in Audio Mode)

Audible Out-of-Band Energy*

(Measured from 0.6

to 22 kHz in Audio Mode,

Tested at F

= 8.0 kHz)

DC Offset

DAC1 AND DAC2 ANALOG AMPLIFIERS/ATTENUATORS

Min

Typ

Max

Units

Step Size (+12.0 dB to 30.0 dB) (All Steps Tested)

1.25

1.5

1.75

Step Size (31.5 dB to 34.5 dB) (All Steps Tested)

1.1

1.5

1.9

Step Size (36.0 dB to 82.5 dB)*

1.3

1.5

1.7

Output Attenuation Span*

81.5

82.5

83.5

Mute Attenuation*

DIGITAL MIX ATTENUATORS

Min

Typ

Max

Units

Step Size (0 dB to 94.5 dB)* (All Steps Tested)

1.3

1.5

1.7

Output Attenuation Span*

93.5

94.5

95.5

Mute Attenuation*

AD1843

REV. 0

Figure 1. Timing Diagrams

ANALOG OUTPUT

Min

Typ

Max

Units

LOUT1 Full-Scale Output Voltage

0.707

V rms

(RMS Values Assume Sine Wave Input)

1.8

2.0

2.2

V p-p

LOUT2 Full-Scale Single-Ended Output Voltage

0.707

V rms

(RMS Values Assume Sine Wave Input)

1.8

2.0

2.2

V p-p

LOUT2 Full-Scale Differential Output Voltage

1.414

V rms

(RMS Values Assume Sine Wave Input)

3.6

4.0

4.4

V p-p

LOUT1 Output Impedance*

600

LOUT2 Output Impedance*

LOUT1 External Load Impedance*

LOUT2 External Load Impedance*

MOUT External Load Impedance*

HPOUT External Load Impedance*

HPOUT THD+N (Referenced to Full Scale, 32

External Load Impedance)

0.10

Output Capacitance*

External Load Capacitance*

100

CMOUT

2.10

2.25

2.40

External CMOUT Load Current*

CMOUT Output Impedance*

Mute Click* (Muted Output Minus Unmuted Midscale DAC1 and DAC2 Outputs)

SYSTEM SPECIFICATIONS

Max

Units

System Frequency Response Ripple* (Line-In to Line-Out)

1.0

Differential Nonlinearity*

Bit

Phase Linearity Deviation*

Degrees

STATIC DIGITAL SPECIFICATIONS

Min

Max

Units

High-Level Input Voltage (V

)

Digital Inputs, Except SCLK

2.0

+ 0.3

XTALI and SCLK

2.4

+ 0.3

Low-Level Input Voltage (V

)

0.3

0.8

High-Level Output Voltage (V

)

2.4

Low-Level Output Voltage (V

)

0.4

Input Leakage Current (GO/NOGO Tested)

Output Leakage Current (GO/NOGO Tested)

TIMING PARAMETERS (GUARANTEED OVER OPERATING TEMPERATURE AND DIGITAL SUPPLY RANGE)

Min

Typ

Max

Units

Serial Data Frame Sync [SDFS] Period (t

)

(Master Mode, FRS = 1 [16 Slots per Frame], SCF = 0 [SCLK = 12.288 MHz])

20.833

Frame Sync [SDFS] HI Pulse Width (t

)

Clock [SCLK] to Frame Sync [SDFS] Propagation Delay (t

PD1

)

Data [SDI] Input Setup Time to SCLK (t

)

Data [SDI] Input Hold Time from SCLK (t

)

Clock [SCLK] to Output Data [SDO] Valid (t

)

Clock [SCLK] to Output Data [SDO] Three-State [High-Z] (t

)

Clock [SCLK] to Time Slot Output [TSO] Propagation Delay (t

PD2

)

RESET

and PWRDWN LO Pulse Width (t

RPWL

)

100

BIT 0

BIT 14

BIT 15

BIT 14

BIT 0

PD1

SCLK

SDFS

SDI

SDO

RESET

PWRDWN

RPWL

15 14 13

3 2 1 0 15 14 13

PD2

PD1

SCLK

SDFS

SDI OR SDO

TSO

LAST
VALID

TIME SLOT

15 1413

REV. 0

AD1843

POWER SUPPLY (33

HPOUT LOAD)

Min

Typ

Max

Units

Power Supply Range--Analog V

4.75

5.25

Power Supply Range--Digital V

2.85

5.25

Total Power Supply Current--5.0 V

and V

Operating

(5.0 V

and V

Supplies)

210

250

Total Power Supply Current--5.0 V

/3.0 V

Operating*

(5.0 V

Analog/3.0 V

Digital Supplies)

150

175

Analog Supply Current--5.0 V

Operating

Digital Supply Current--5.0 V

Operating

150

175

Digital Supply Current--3.0 V

Operating*

100

Digital Power Supply Current--V

Power Down (PWRDWN LO)

Analog Power Supply Current--V

Power Down (PWRDWN LO)

0.5

Power Dissipation--5.0 V

and V

Operating (Current

Nominal Supply)

1250

Power Dissipation--5.0 V

/3.0 V

Operating* (Current

Nominal Supply)

875

Power Dissipation--5.0 V

and V

Power Down (PWRDWN LO)

(Current

Nominal Supply)

7.5

Power Dissipation--5.0 V

/3.0 V

Power Down* (PWRDWN LO)

(Current

Nominal Supply)

Power Supply Rejection (100 mV p-p Signal @ 1 kHz)*

(At Both Analog and Digital Supply Pins, for ADC, DAC1 and DAC2)

CLOCK SPECIFICATIONS*

Min

Typ

Max

Units

Input Crystal/Clock Frequency

24.576

MHz

Input Clock Duty Cycle (When an External Clock Is Used Instead of a Crystal)

25/75

75/25

Initialization Sample Rate Change Time

PACKAGE CHARACTERISTICS

Typ

Units

PQFP

(Thermal Resistance [Junction-to-Ambient])

C/W

PQFP

(Thermal Resistance [Junction-to-Case])

8.75

C/W

TQFP

(Thermal Resistance [Junction-to-Ambient])

30.6

C/W

TQFP

(Thermal Resistance [Junction-to-Case])

4.6

C/W

NOTES

The stopband repeats itself at multiples of 64

, where F

is the sampling frequency. Thus the audio mode digital filter will attenuate to 91.8 dB or better across

the frequency spectrum except for a range of

0.6

wide at multiples of 64

The stopband repeats itself at multiples of 64

, where F

is the sampling frequency. Thus the modem mode digital filter will attenuate to 75.7 dB or better across

the frequency spectrum except for a range of

0.542

wide at multiples of 64

The stopband repeats itself at multiples of 64

, where F

is the sampling frequency. Thus the resampler mode digital filter will attenuate to 92.2 dB or better

across the frequency spectrum except for a range of

0.5

wide at multiples of 64

*Guaranteed, not tested.
Specifications subject to change without notice.

ABSOLUTE MAXIMUM RATINGS*

Min

Max

Units

Power Supplies

Digital (V

)

0.3

6.0

Analog (V

)

0.3

6.0

Input Current

(Except Supply Pins)

10.0

Analog Input Voltage (Signal Pins) 0.3

+ 0.3

Digital Input Voltage (Signal Pins) 0.3

+ 0.3

Ambient Temperature (Operating) 0

+70

Storage Temperature

+150

ESD Tolerance (Human Body

1000

Model per Method 3015.2
of MIL-STD-883B)

WARNING!

ESD SENSITIVE DEVICE

CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD1843 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.

*Stresses greater than those listed under "Absolute Maximum Ratings" may cause

permanent damage to the device. This is a stress rating only and functional
operation of the device at these or any other conditions above those indicated in the
operational section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.

ORDERING INFORMATION

Temperature

Package

Model

Range

Description

Option

AD1843JS

C to +70

80-Lead PQFP

S-80

AD1843JST

C to +70

100-Lead TQFP ST-100

AD1843

REV. 0

PIN CONFIGURATIONS

80-Lead PQFP

AD1843

TOP VIEW

(Not to Scale)

SDI

SCLK

GNDD

CLKOUT

CONV3

BIT3

GNDD

CONV2

CONV1

BIT2

GNDD

BIT1

XTALO

XTALI

GNDD

XCTL1

XCTL0

SYNC3

SYNC2

SYNC1

GNDD

RESET

PWRDWN

PDMNFT

GNDA

HPOUTL

HPOUTC

HPOUTR

SUML

SUMR

SDO

SDFS

GNDD

TSI

TSO

GNDD

AUX3R

AUX3L

AUX2R

AUX2L

AUX1R

AUX1L

MICR

MICL

MIN

GNDA

AAFILTR

FILTR

AAFILTL

FILTL

LINRP

LINRN

LINLP

LINLN

LOUT2RP

LOUT2RN

LOUT2LP

LOUT2LN

MOUT

LOUT1L

GNDA

CMOUT

REF

GNDA

LOUT1R

PIN DESCRIPTION
Serial Interface

Pin Name

PQFP

TQFP

I/O

Description

SCLK

I/O

Serial Clock. SCLK is a bidirectional signal that supplies the clock as an output
to the serial bus when the Bus Master (BM) pin is driven HI and accepts the clock
as an input when the BM pin is driven LO. When the AD1843 is configured in
master mode, the SCLK frequency may be set to either 12.288 MHz or 16.384 MHz
with the SCF bit in Control Register Address 26.

SDFS

I/O

Serial Data Frame Sync. SDFS is a bidirectional signal that supplies the frame
synchronization signal as an output to the serial bus when the Bus Master (BM)
pin is driven HI and accepts the frame synchronization signal as an input when
the BM pin is driven LO.

SDI

100

Serial Data Input. SDI is used by peripheral devices such as the host CPU or a
DSP to supply control and playback data information to the AD1843. All control
and playback transfers are 16 bits long, MSB first.

SDO

Serial Data Output. SDO is used to supply status/control register readback and
capture data information to peripheral devices such as the host CPU or a DSP.
All status/control register readback and capture data transfers are 16 bits long,
MSB first. A three-state output driver is used on this pin.

Bus Master. When BM is tied HI the AD1843 is the serial bus master. The
AD1843 will then supply the serial clock (SCLK) and the frame sync (SDFS)
signals for the serial bus. No more than one device (AD1843/CPU/DSP) should
be configured as the serial bus master. When BM is tied LO, the AD1843 is con-
figured as a bus slave, and will accept the SCLK and SDFS signals as inputs. The
logic level on this pin must not be changed once RESET is deasserted (driven HI).

REV. 0

AD1843

100

AD1843

TOP VIEW

(Not to Scale)

SDI

SCLK

GNDD

CLKOUT

CONV3

BIT3

GNDD

CONV2

CONV1

BIT2

GNDD

BIT1

XTALO

XTALI

GNDD

XCTL1

XCTL0

SYNC3

SYNC2

SYNC1

GNDD

RESET

PWRDWN

PDMNFT

GNDA

HPOUTL

HPOUTC

HPOUTR

SUML

SUMR

GNDA

AAFILTR

FILTR

AAFILTL

FILTL

LINRP

LINRN

LINLP

LINLN

LOUT2RP

LOUT2RN

LOUT2LP

LOUT2LN

LOUT1R

MOUT

LOUT1L

GNDA

CMOUT

REF

GNDA

SDO

SDFS

GNDD

TSI

TSO

GNDD

AUX3R

AUX3L

AUX2R

AUX2L

AUX1R

AUX1L

MICL

MICR

MIN

NC = NO CONNECT

Serial Interface (Continued)

Pin Name

PQFP

TQFP

I/O

Description

Chip Select. When CS is set HI, the serial interface I/O pins will be in their normal
active states. When CS is reset LO, SCLK, SDFS, and SDO are three-
stated; SCLK, SDFS and SDI inputs are ignored; and TSO drives out the logic
level received on TSI.

TSO

Time Slot Output. TSO is asserted HI by the AD1843 simultaneously with the LSB
of the last time slot used by the AD1843. It is used to daisy-chain multiple AD1843s
on a common TDM serial bus. If the power-down (PWRDWN) pin is asserted or if
the chip select pin (CS) is deasserted, TSO is set to the logic level on the TSI pin,
allowing powered-down or unselected AD1843s on a daisy-chain to be skipped.

TSI

Time Slot Input. Asserting TSI HI indicates to the AD1843 that it should use
the next six time slots beginning on the next SCLK period. It also enables TSO
to be asserted at the end of these six time slots. TSI is ignored (but should be tied
LO) when the AD1843 is the bus master since the bus master uses the first time
slots in a TDM frame.

XCTL[1:0]

59, 58

72, 74

I/O

External Control. These signals reflect the status of bits (Data 8 and 9) in Control
Register Address 28 of the AD1843. They may be used for signaling or controlling
external logic.

PIN CONFIGURATIONS

100-Lead TQFP

AD1843

REV. 0

Analog Signals

Pin Name

PQFP

TQFP

I/O

Description

LINLP

Line Input Left Channel Positive Differential Signal.

LINLN

Line Input Left Channel Negative Differential Signal.

LINRP

Line Input Right Channel Positive Differential Signal.

LINRN

Line Input Right Channel Negative Differential Signal.

MICL

Microphone Input Left Channel. Microphone input for the left channel. This
signal can be either line level or 20 dB from line level.

MICR

Microphone Input Right Channel. Microphone input for the right channel.
This signal can be either line level or 20 dB from line level.

AUX1L

Auxiliary #1 Left Channel Line Input.

AUX1R

Auxiliary #1 Right Channel Line Input.

AUX2L

Auxiliary #2 Left Channel Line Input.

AUX2R

Auxiliary #2 Right Channel Line Input.

AUX3L

Auxiliary #3 Left Channel Line Input.

AUX3R

Auxiliary #3 Right Channel Line Input.

MIN

Monaural (Mono) Line Input.

MOUT

Monaural (Mono) Line Output.

LOUT1L

Line Output #1 Left Channel.

LOUT1R

Line Output #1 Right Channel.

HPOUTL

Headphone Output Left Channel.

HPOUTC

Headphone Common Return.

HPOUTR

Headphone Output Right Channel.

LOUT2LP

Line Output #2 Left Channel Positive Differential Signal.

LOUT2LN

Line Output #2 Left Channel Negative Differential Signal.

LOUT2RP

Line Output #2 Right Channel Positive Differential Signal.

LOUT2RN

Line Output #2 Right Channel Negative Differential Signal.

SUML

Mixer Line Input Left Channel.

SUMR

Mixer Line Input Right Channel.

Clocks

Pin Name

PQFP

TQFP

I/O

Description

CLKOUT

Clock Output. This signal is a buffered version of XTALO (with a duty cycle
restored to at least 60%/40%), the crystal clock output. This pin is enabled by
default but can be three-stated by programming a bit in Control Register
Address 28. The CLKOUT frequency is 24.576 MHz.

SYNC[3:1]

57, 56, 55

71, 70, 69

Sync Inputs. These SYNC signals are used as the clock source inputs to three
receptive PLLs in the AD1843. These pins accept a clock at, or at a multiple of,
the desired sample rate for A-to-D and D-to-A conversions. These inputs are
ignored if a sample rate is programmed directly, but should never be left floating.

CONV[3:1]

75, 71, 67

94, 89, 84

Conversion Clock Outputs. These output clocks have an average period equal to (or 128
times) the internal sample rates of the AD1843. These clock outputs are three-stated
by default but can be enabled by programming bits in Control Register Address 28.

BIT[3:1]

74, 70, 66

92, 87, 82

Bit Clock Outputs. These output clocks can be individually programmed to
multiples of the sample rates. Support for V.34 or V.32 bit rates is available.
These clock outputs are three-stated by default but can be enabled by
programming bits in Control Register Address 28.

REV. 0

AD1843

Miscellaneous

Pin Name

PQFP

TQFP

I/O

Description

XTALI

24.576 MHz Crystal Input. When using a crystal as the clock source, the crystal
should be connected between the XTALI and XTALO pins. This crystal should
be 24.576 MHz for the normal sampling rate range, i.e., 4 kHz to 54 kHz. A
clock input (perhaps the CLKOUT of another AD1843) may be driven into
XTALI in place of a crystal. The external clock input must be greater than or equal
to 512 times the maximum desired AD1843 sampling frequency.

XTALO

24.576 MHz Crystal Output. When using a crystal as the clock source, the crystal
should be connected between the XTALI and XTALO pins. If a clock is driven
directly into XTALI, then XTALO should be left unconnected.

PWRDWN

Power Down. PWRDWN is active LO. The assertion of this signal will initialize
the on-chip Control Registers to their default values, and will completely and
quietly power down the AD1843. If a crystal is not connected between XTALI
and XTALO, there must be a 24.576 MHz clock input on XTALI for at least
5 ms after this signal is asserted LO for proper operation. The AD1843 will not
be completely powered down until after this 5 ms period elapses. The AD1843
always finishes an in-progress power-up sequence before initiating a power-down
sequence, and vice versa. If the PWRDWN pin is asserted while a power-up sequence
is in progress, the 24.576 MHz clock signal on XTALI must persist for a worst
case maximum of 479 ms (power up = 470 ms, autocalibration = 4 ms, power
down = 5 ms) after PWRDWN is asserted. When INIT (Control Register
Address 0, Bit 15) is set to a "1," the power-down sequence is complete. See
the "Power Management" section for important additional details.

RESET

Reset. RESET is active LO. The assertion of this signal will initialize the on-chip
registers to their default values, and will completely power down the AD1843.
RESET

is similar to PWRDWN, except that when PWRDWN is asserted, power

down is "quiet" and performed synchronously to the internal clocks. When RESET
is asserted, power down is "noisy" and performed asynchronously to the internal
clocks.

PDMNFT 49

Power-Down Mono Feedthrough. When the AD1843 mixer is powered down,
and PDMNFT is asserted HI, the Mono Input (MIN, PQFP Pin 19) is routed to
the Mono Output (MOUT, PQFP Pin 35), and the signal applied to MIN will
feedthrough to MOUT. When the AD1843 mixer is powered down and
PDMNFT is deasserted LO, the feedthrough of MIN to MOUT will be muted.
When the AD1843 mixer is not powered down, and MIN to MOUT feedthrough
is desired, the Mono Input Mix Mute (Control Register Address 8, Bit 15) and the
Mono Output Mute (Control Register Address 8, Bit 6) must be unmuted. During
power-down feedthrough, the signal applied to the MIN input appears only at
the MOUT output. During normal operation, the signal applied to the MIN
input appears at both the MOUT and the LOUT1 outputs. The state of the
PDMNFT pin should be changed when the AD1843 mixer is powered up. If the
state of PDMNFT is changed when the AD1843 is in total power-down, audible
pops and clicks will likely result.

CMOUT

Common-Mode Voltage Output. Nominal 2.25 volt reference available externally
for dc-coupling and level-shifting. CMOUT should not be used where it will sink
or source current.

REF

Voltage Reference Filter. Voltage reference filter point for external bypassing only.

FILTL

Left Channel Filter. This pin requires a 1.0

F capacitor to analog ground for

proper operation.

FILTR

Right Channel Filter. This pin requires a 1.0

F capacitor to analog ground for

proper operation.

AAFILTL 24

Left Channel Antialias Filter. This pin requires a 1000 pF capacitor to analog
ground for proper operation.

AAFILTR 22

Right Channel Antialias Filter. This pin requires a 1000 pF capacitor to analog
ground for proper operation.

AD1843

REV. 0

POWER SUPPLIES

Pin Name PQFP

TQFP

I/O

Description

20, 41, 44

25, 51, 55

Analog Supply Voltage (+5 V).

GNDA

21, 37, 40, 48

27, 46, 49, 59 O

Analog Ground.

4, 8, 50, 53,

5, 10, 62, 66,

Digital Supply Voltage (+5/3 V).

63, 64, 68, 72, 79, 80, 85, 90,
77

GNDD

3, 7, 54, 60,

4, 9, 67, 75,

Digital Ground.

65, 69, 73, 78

81, 86, 91, 97

3, 8, 13, 14,

No Connect. May be left floating.

24, 26, 32, 37,
42, 50, 52, 60,
63, 68, 73, 78,
83, 88, 93, 98

(continued from page 1)

The versatility of the device is shown by the following examples
of functions it can perform:

· Stereo audio input and/or quad output, simultaneously at dif-

ferent sample rates

· Stereo audio output with simultaneous full duplex modem or

fax operation with frequency and phase resampling

· Mono audio input and stereo audio output with simultaneous

modem receive and transmit for simultaneous voice and data
communications

· Dual independent audio inputs with audio output for echo-

cancelling speakerphones

Audio Functional Description

The AD1843 SoundComm codec provides a complete audio so-
lution with very few external components required. Dynamic
range of the device exceeds 80 dB over the 20 kHz audio band
and sample rates from 4 kHz to 49 kHz are supported (up to
54 kHz for a single channel if other channels are powered
down). The audio functionality of this device is a superset of
that found in the Analog Devices AD1848 SoundPort

device

which has set the business audio standard throughout the com-
puter industry.

Inputs to the device include a stereo microphone pair, a stereo
line pair, a stereo CD input pair (AUX1), a stereo synthesized
music input pair (AUX2), a dual phone line input (AUX3), a
mono input, and a stereo input from an FM synthesizer (SUM).
All of these inputs (except SUM) are multiplexed to the two

A/D converters and are mixable directly as analog signals with
the outputs of the D/A converters. All analog input signals (ex-
cept SUM) can be amplified, attenuated or muted before mix-
ing with the outputs of the D/A converters.

The device has two pairs of

DACs which accept 8- or 16-bit

digital data from the serial port. Each DAC pair's independent
sampling rate can either be programmed by Control Register
(with 1 Hz resolution) or synchronized to an external input.
The second pair of DACs can be used to replace the music syn-
thesis DAC pair found on many audio products for PCs. Out-
puts from the AD1843 include a line output, a mono output, a
stereo headphone output with its own current return path, and a

SoundPort is a registered trademark of Analog Devices, Inc.

differential stereo output for connection to a DAA. The line and
differential outputs are looped back to the ADC input selector.

The AD1843's mixing and routing capabilities are extensive.
The digital data from both DAC channels after interpolation
can be routed back to the ADC decimators, to support digital-
to-digital sample rate conversion (digital resampling). Digital
data from the ADC can also be routed to the two stereo DAC
pairs, for a digital loopback mode which is helpful for device-
level and board-level test. Digital data from either stereo DAC
can be mixed with the digital data feeding the other DAC, and
the analog signal from DAC2 can be mixed with the analog out-
put from DAC1.

Sample rates are independently programmable in the range of
4 kHz to 54 kHz to a 1 Hz resolution or sample rates can be
synchronized to an external source. Up to three different signals
can be applied to the device's three digital phase lock loop
SYNC inputs for external synchronization.

These SYNC inputs can also be used in a special mode for au-
dio/video synchronization. In this mode, an NTSC or PAL de-
rived clock signal (approximately 15 kHz) is applied to the
SYNC inputs and the device produces one of a variety of stan-
dard audio sample rates (32 kHz, 44.056 kHz, 44.1 kHz and
48 kHz, and most of these divided by the integers 1 through 8).
In this manner, video and audio sample rates which are math-
ematically unrelated can be locked together.

Data Communications/Telephony Functional Description

The AD1843 includes all data conversion, filtering, and clock
generation circuitry needed to implement an echo-cancelling
modem with a companion digital signal processor. Software-
programmable sample rates and clocking modes support all
established modem standards including those for the V.34
standard.

The AD1843 utilizes advanced

technology to move the

entire echo-cancelling modem implementation into the digital
domain. The device maintains 90 dB typical dynamic range
throughout all filtering and data conversion across a 9.6 kHz
passband. Purely DSP-based echo cancellation algorithms can
maintain robust bit error rates under worst-case signal attenua-
tion and echo amplitude conditions. The AD1843's on-chip
interpolation filter resamples (both frequency and phase) the re-
ceived signal after echo cancellation in the DSP, freeing the pro-
cessor for other voice or data communications tasks.

AD1843

REV. 0

On-chip bit and baud clock generation circuitry allows either
synchronous or asynchronous operation of the transmit (DAC)
and receive (ADC) paths. Each path features independent
phase advance and retard adjustments via software control. The
AD1843 can also synchronize modem operation to an external
terminal band clock. Because the device has multiple input and
output channels and converters, it is well suited for telephony
applications requiring multiple channels for voice and modem.

A detailed block diagram of the AD1843 is shown in Figure 2.

DETAILED PRODUCT DESCRIPTION

The Serial-Port AD1843 SoundComm Codec integrates the key
audio and PSTN data conversion and control functions into a
single integrated circuit. The AD1843 is intended to provide a
complete, single-chip audio and fax/modem solution for PC
multimedia applications.

External circuit requirements are limited to a minimal number
of low cost support components. Dynamic range exceeds 80 dB
over the 20 kHz audio band. Sample rates from 4 kHz to
54 kHz with 1 Hz resolution are supported from a single exter-
nal crystal or clock source.

The AD1843 SoundComm Codec is intended to be interfaced
through a DSP chip or an ASIC to a host bus such as ISA,
EISA or PCI. A general system architecture is shown in
Figure 3.

S
Y
S
T
E
M

B
U
S

ASIC

ADSP-21xx

ANALOG I/O

AD1843

Figure 3. AD1843 System Diagram

The SoundComm codec includes a stereo pair of

analog-to-

digital converters and two stereo pairs of

digital-to-analog

converters. Inputs to the ADC can be selected from eight
sources of analog signals: stereo line (LIN), stereo microphone
(MIC), stereo auxiliary line #1 (AUX1), stereo auxiliary line #2
(AUX2), stereo auxiliary line #3 (AUX3), mono line (MIN),
mixer output, and DAC2 output. A mono output and a stereo
headphone driver are included on-chip. A stereo line level input
(SUM) can be mixed into the output summer. A software-con-
trolled programmable gain stage allows independent gain for
each ADC channel. The ADCs' output can be digitally mixed
with both the DAC1 and DAC2 inputs. The left and right
ADC channels can be configured for different sample rates and
digital filter function (audio, modem or resampling).

The pair of 16-bit outputs from the ADCs is available over a se-
rial interface that also supports 16-bit digital input to the DACs
and control/status information. The AD1843 can accept and
generate 16-bit twos-complement PCM linear digital data, 8-bit
unsigned magnitude PCM linear data, and 8-bit

-law or A-law

companded digital data. The data format is defined indepen-
dently for each conversion resource on the AD1843.

The

DACs are preceded by a four sample deep FIFO buffer

and a digital interpolation filter. The DAC1 and DAC2 outputs
can be mixed in the digital domain. Digital and analog attenua-
tors provide independent user volume control (plus mute) over
each DAC channel. Nyquist images and shaped quantized

noise are removed from the DACs' analog stereo output by on-
chip switched-capacitor and continuous-time filters. All of the
analog inputs (except the stereo line input) can be mixed with
the DAC1 output in the analog domain. The DAC2 output can
also be mixed with the DAC1 output in the analog domain.
The DAC1 and DAC2 digital data can be fed back to the digital
half of the ADC to enable digital resampling operation. DAC1
and DAC2 can be run at different sample rates and with differ-
ent digital filter functions, without any beat frequency problems.

FUNCTIONAL DESCRIPTION

This section overviews the functionality of the AD1843 and is
intended as a general introduction to the capabilities of the de-
vice. As much as possible, detailed reference information has
been placed in "Control Registers" and other sections. The
user is not expected to refer repeatedly to this section.

Analog Inputs

The AD1843 SoundComm Codec accepts stereo line-level and
mic-level inputs. The mono MIN analog signal input, and LIN
(differential), MIC, AUX1, AUX2, AUX3 and post-mixed
DAC output analog stereo signals are multiplexed to the inter-
nal programmable gain amplifier stage (PGA).

The PGA following the input multiplexer allows left and right
independent selectable gains for each channel from 0 dB to
22.5 dB in +1.5 dB steps. The Codec can operate either in a
global stereo mode or in a global mono mode with left-channel
inputs appearing at both channel outputs.

Analog Mixing

The MIN analog mono signal, and the MIC, AUX1, AUX2,
AUX3 and SUM analog stereo signals can be mixed in the ana-
log domain with the DAC1 output. Each channel of each auxil-
iary analog input can be independently gained/attenuated from
+12 dB to 34.5 dB in 1.5 dB steps or completely muted. The
mixer output is available on LOUT1 externally and as an input
to the ADCs. Even if the AD1843 is not playing back data from
its DACs, the analog mix function can still be active.

MIN allows the analog signal intended for the PC speaker to be
passed through, attenuated or mixed in the AD1843's analog
domain. MIN can be used to accept other mono input sources.
A digital control signal pin PDMNFT (Power Down Mono
Feed Through) enables the mono input signal to be fed through
to the mono output when the AD1843 mixer is powered down.

Analog-to-Digital Datapath

The AD1843

ADCs incorporate a fourth-order modulator.

A single pole of passive filtering is all that is required for
antialiasing the analog input because of the ADC's high over-
sampling ratio. The ADCs include linear-phase digital decima-
tion filters that low-pass filter the input. ADC input overrange
conditions will cause bits to be set that can be read.

Each channel of the mic inputs can be amplified in the analog
domain by +20 dB to compensate for the voltage swing differ-
ence between line levels and typical condenser microphone levels.

Digital-to-Analog Datapath

The

DACs are preceded by a programmable attenuator and

a low-pass digital interpolation filter. The anti-imaging interpo-
lation filter oversamples and digitally filters the higher frequency
images. The attenuator allows independent control of each
DAC channel from +12.0 dB to 82.5 dB in 1.5 dB steps plus
full mute. The DACs'

noise shapers oversample and con-

vert the signal to a single-bit stream. The DAC outputs are then

REV. 0

AD1843

representations in all four formats correspond to equivalent full-
scale signals. The eight least-significant bit positions of 8-bit
data in 16-bit fields are ignored on input and zeroed on output.

The 16-bit PCM data format is capable of representing 96 dB of
dynamic range. Eight-bit PCM can represent 48 dB of dynamic
range. Companded

-law and A-law data formats use nonlinear

coding with less precision for large-amplitude signals. The loss
of precision is compensated for by an increase in dynamic range
to 64 dB and 72 dB, respectively.

On input, 8-bit companded data is expanded to an internal lin-
ear representation, according to whether

-law or A-law was

specified in the Codec's internal registers. Note that when

law compressed data is expanded to a linear format, it requires
14 bits. A-law data expanded requires 13 bits.

MSB

LSB

COMPRESSED

INPUT DATA

8 7

MSB

LSB

3/2 2/1

EXPANSION

MSB

LSB

3/2 2/1

DAC INPUT

0 0 0 / 0 0

Figure 4.

-Law or A-Law Expansion

When 8-bit companding is specified, the ADCs' linear output is
compressed to the format specified.

MSB

LSB

ADC OUTPUT

MSB

LSB

3/2 2/1

TRUNCATION

MSB

LSB

8 7

COMPRESSION

0 0 0 0 0 0 0 0

Figure 5.

-Law or A-Law Compression

Note that all format conversions take place at input or output.

Power Supplies and Voltage Reference

The AD1843 operates from either +5.0 V analog (V

) and

digital (V

) power supplies or +5.0 V analog and +3.0 V digi-

tal supplies. Independent analog and digital supplies are recom-
mended for optimal performance though excellent results can be
obtained in single-supply systems. A voltage reference is included
on the Codec and its +2.25 V buffered output is available on an
external pin (CMOUT). The reference output can be used for
biasing op amps used in single supply systems. The internal ref-
erence is externally bypassed to analog ground at the V

REF

pin.

Clocks and Sample Rates

The AD1843 operates from a single external clock or crystal
source. From a single clock, a wide range of sample rates can be
generated. When supplied with a single 24.576 MHz clock, the
AD1843 can be programmed to generate any sample frequency
between 4 kHz and 54 kHz with 1 Hz resolution. For modem
sample rate support, the frequency programmed can also be in-
creased by 8/7 using a control bit. All sample rate changes can
be made "on the fly."

The AD1843's SYNC inputs can be used to synchronize the
sampling activity of the four on-chip conversion resources to ex-
ternal clock signals, such as video HSYNC or an ISDN network
clock. The SYNC inputs are used by three on-chip digital phase

filtered in the analog domain by a combination of switched-capaci-
tor and continuous-time filters. They remove the very high fre-
quency components of the DAC bitstream output. No external
components are required. Phase linearity at the analog output is
achieved by internally compensating for the group delay varia-
tion of the analog output filters.

Changes in DAC output attenuation may be programmed to
take effect immediately, or only on zero crossings of the digital
signal, thereby eliminating "zipper" noise on playback. Each
channel has its own independent zero-crossing detector and at-
tenuator change control circuitry. A timer guarantees that re-
quested volume changes will occur even in the absence of an
input signal that changes sign. The time-out period is 8 milli-
seconds at a 48 kHz sampling rate and 48 milliseconds at an
8 kHz sampling rate. (Time-out [ms]

384

[kHz]).

Digital Mixing

Stereo digital output from the ADCs can be mixed digitally with
the input to the DACs. Digital output from the ADCs going
out of the serial port is unaffected by this digital mix. Along the
digital mix datapath, the 16-bit linear output from the ADCs is
attenuated by an amount specified with Control Register bits.
The level of attenuation applied to the left and right channels is
independently programmable. (Note that internally the AD1843
always works with 16-bit PCM linear data, digital mixing in-
cluded; format conversions take place at the input and output.)

Sixty-four steps of 1.5 dB attenuation are supported to 94.5 dB.
The digital mix datapath can also be completely muted, pre-
venting any mixing of the analog input with the analog output.
Note that the level of the mixed signal is also a function of the
input PGA settings, since they affect the ADCs' output. The
sample rate of the ADCs and the selected DAC pair must be the
same for the digital mix function to operate properly.

The attenuated digital mix data is digitally summed with the
DAC input data prior to the DACs' datapath attenuators. The
digital sum of digital mix data and DAC input data is clipped at
plus or minus full scale and does not wrap around. Because
both stereo signals are mixed before the output attenuators,
mix data is attenuated a second time by the DACs' datapath
attenuators. In case the AD1843 is playing back data but input
digital DAC data fails to arrive in time ("DAC underrun"), then
a midscale zero will be added to the digital mix data in place of
the unavailable DAC data.

Analog Outputs

The two mixer line-level outputs are available at external pins.
Each output channel can be independently muted. When
muted, the outputs will settle to a dc value near CMOUT, the
midscale reference voltage. The two DAC2 stereo outputs are
available at external pins differentially. The full-scale level on
these pins is established by programming bits in a Control Reg-
ister. In addition, there is stereo headphone output (with a cur-
rent return), and a mono output. Both the headphone output
and the mono output have a single mute control.

Digital Data Types

The AD1843 supports four data types: 16-bit twos-complement
linear PCM, 8-bit unsigned linear PCM, 8-bit companded

-law,

and 8-bit companded A-law, as specified by control register bits.
The data type is independently assignable for each conversion
resource (i.e., ADCL, ADCR, DAC1 and DAC2). Data in all
four formats is always transferred MSB first. Eight-bit data is al-
ways left-justified in 16-bit fields; said in other words, the MSBs
of all data types are always aligned; in yet other words, full-scale

AD1843

REV. 0

lock loops, which can be arbitrarily assigned to the conversion
resources. The lock range of these digital PLLs is 4 kHz to
54 kHz, which is the same range supported by the register-
controlled clock generators.

If a SYNC input stops after its associated phase lock loop has
had a chance to initially lock, the AD1843 will continue to gen-
erate a sample clock (as well as BIT clock and CONV clock)
very similar to the initial frequency, but off by at most

1%.

The three SYNC inputs feed three on-chip Digital Phase Lock
Loops (DPLLs) which utilize a first-order loop filter with a
20 Hz corner frequency. Jitter frequencies above 20 Hz are
attenuated, and jitter frequencies below 20 Hz are interpreted as
time base drift, and are tracked. The DPLL provides 12 dB per
octave of jitter rejection. The DPLLs have been designed to tol-
erate at least 2% Unit Interval (UI) of SYNC clock jitter. The
DPLLs are critically damped at all input frequencies.

Power Management

The AD1843 SoundComm codec has extensive power manage-
ment capabilities. Hardware power down is performed using the
PWRDWN

pin. Software power management is programmed us-

ing Control Register Address 27 and 28. Several elements of the
AD1843 can be powered down on a selective basis. These blocks
include: the DAC2 to DAC1 analog mixer; the entire DAC1 con-
version channel; the entire DAC2 conversion channel; the analog
half of the ADC, DAC1 and DAC2; the headphone driver; the en-
tire analog mixer; the right ADC channel; the left ADC channel; all

four conversion channels; clock generator 1; clock generator 2;
clock generator 3; conversion clock outputs 1 through 3; bit clock
outputs 1 through 3; and the nominal 24.576 MHz clock output.
Refer to the descriptions of Control Register Address 27 and 28 for
further information.

For proper operation, the AD1843 must be calibrated following
power-up. This initial calibration occurs automatically without any
user intervention or programming. Subsequent to this initial
power-up autocalibration, there is no requirement to recalibrate the
SoundComm codec following software power-down sequences.
The entire AD1843 or selected portions of the device may be
powered down, allowed to idle indefinitely, then powered up
and used immediately, without the need for repeated auto-
calibration. The digital information obtained during the initial
power-up calibration is retained and valid unless the RESET or
PWRDWN

pin is asserted, forcing a hardware reset. (If desired,

the user can specify that a calibration cycle occur when leaving
the software power-down state by setting ACEN (Control Reg-
ister Address 28, Bit 14) to "1.") A hardware reset or power-
down clears the calibration information, and therefore a fresh
autocalibration cycle is performed by the AD1843 following this
event. Autocalibration takes approximately 4 ms to complete.

The following table provides an indication of the power savings
associated with powering-down the various resources in the
AD1843. Note that the power savings is somewhat order-

Table I. AD1843 Power-Down Savings

+5 V Digital, +5 V Analog Supplies

Total Active Operation Current: 200 mA

Average, Typical

Absolute I

Normalized

Software Power Down

Control Register Bit(s)

Current

Power Savings

CLKOUT Output

ENCLKO Bit = 0

8 mA

All Bit Clocks and

ENBT3, ENBT2, ENBT1 Bits = 0

All Conversion Clocks

ENCV3, ENCV2, ENCV1 Bits = 0

2 mA

Clock Generator 1

C1EN Bit = 0

6 mA

Clock Generator 2

C2EN Bit = 0

6 mA

Clock Generator 3

C3EN Bit = 0

6 mA

All Clock Generators

C1EN, C2EN, C3EN Bits = 0

20 mA

10%

Headphone Driver

HPEN Bit = 0

8 mA

DAC2 to DAC1 Mix

DDMEN Bit = 0

2 mA

Analog Input to Analog Output Mix

AAMEN Bit = 0

8 mA

ADC Left Channel

ADLEN Bit = 0

8 mA

ADC Right Channel

ADREN Bit = 0

8 mA

ADC Left and Right Channels

ADLEN, ADREN Bits = 0

38 mA

17%

DAC2 (Left and Right Channels)

DA2EN Bit = 0

30 mA

15%

DAC1 (Left and Right Channels)

DA1EN Bit = 0

24 mA

12%

DAC2 AND DAC1 (Left and Right Chs)

DA2EN, DA1EN Bits = 0

60 mA

30%

ADC and DAC2 and DAC1

ADLEN, ADREN,
DA2EN, DA1EN Bits = 0

108 mA

54%

Analog Channel

ANAEN Bit = 0

54 mA

27%

All Control Register 27

HPEN, DDMEN, AAMEN, ADLEN,
ADREN, DA2EN, DA1EN, ANAEN Bits = 0

134 mA

67%

Converter

PDNI Bit = 1

140 mA

70%

All of the Above (Register 27 and

ENCLKO, ENBT3, ENBT2, ENBT1, ENCV3,

Clocks and PDNI)

ENCV2, ENCV1, C1EN, C2EN, C3EN, HPEN,
DDMEN, AAMEN, ADLEN, ADREN, DA2EN,
DA1EN, ANAEN Bits = 0, PDNI Bit = 1

176 mA

88%

REV. 0

AD1843

dependent; depending upon the sequence in which the hardware
resources are powered down, the savings may be more or less
than the typical numbers given.

Mode Changing

In general, there are very few restrictions with respect to chang-
ing the operating mode of the AD1843. Because of the advanced
Continuous Time Oversampling technology, the waiting period
associated with changes to the sample rate of the data converters
("Mode Change Enable" resynchronization delay) is eliminated.
The only waiting periods associated with the AD1843 occur at
start-up, and are documented in the "START-UP SEQUENCE"
section below. Following the start-up sequence, the sample rate
of the four data conversion resources on the AD1843 may be
changed at any time, on-the-fly (presuming that they are
enabled). All gain, mute and attenuation settings of enabled
resources may also be changed at any time.

Channel Synchronization

If multiple AD1843s are used in a daisy-chained system, and it
is desired to synchronize data conversion activity among the
multiple codecs, the clock generator blocks of the AD1843s
must be enabled on the same frame (see step 5 in the "START-
UP SEQUENCE" section below).

A DAC channel does not actually start processing samples until
the first rising edge of the conversion clock (CONV pin) after
the sixth rising edge of frame sync (SDFS pin) after the channel
is enabled (via a write to DA1EN or DA2EN in Control Regis-
ter Address 27). The wait until the sixth rising edge of frame
sync is necessary to allow the four deep DAC FIFO to be filled
before conversion commences. The subsequent wait until the
rising edge of the conversion clock is necessary to synchronize
the serial interface based DAC channel enable command with a
conversion clock that is potentially already running (which is
particularly likely if the SYNC pin inputs and lock mode are
in use).

The ADC channels behave very similarly to the DAC channels.
An ADC channel does not actually start taking samples until the
first rising edge of the conversion clock (CONV pin) after the
sixth rising edge of frame sync (SDFS pin) after the channel is
enabled (via a write to ADLEN or ADREN in Control Register
Address 27). The wait until the sixth rising edge of frame sync is
present so that the ADC startup is similar to that of the DAC
startup, as well as to allow some time for stale ADC data inside
the AD1843 to be cleared. The subsequent wait until the rising
edge of the conversion clock is necessary to synchronize the
serial interface based ADC channel enable command with a
conversion clock that it potentially already running (which is par-
ticularly likely if the SYNC pin inputs and lock mode are in use).

Supported Conversion Rates

With all conversion channels operating (i.e., ADC left, ADC
right, DAC1 and DAC2), the AD1843 is able to support sam-
pling rates up to 49 kHz, which 2.1% higher than the nominal
maximum audio standard of 48 kHz, to accommodate timebase
drift while configured in slave mode. If either one DAC (i.e.,
either DAC1 or DAC2) or both ADC channels (i.e., ADC left
and ADC right) are shut down, then the AD1843 can support
sampling up to 54 kHz on all channels of the remaining conver-

sion resources, as long as the DFREE bit (Control Register Ad-
dress 27) is asserted (i.e., set to "1"). If DFREE is not asserted,
then the maximum sampling rate for the remaining conversion
resources is 49 kHz.

Digital Filter Selection

The operative digital filter modes for the four conversion re-
sources on the AD1843 SoundComm are programmed using
Control Register Address 25. ADLFLT (Bit 0) selects the digi-
tal filter mode for the ADC left channel and ADRFLT (Bit 1)
selects the digital filter mode for the ADC right channel. Note
that these bits also establish the full-scale input voltage range for
these channels as well. DA1FLT (Bit 8) selects the DAC1 digi-
tal filter mode, and DA2FLT (Bit 9) selects the DAC2 digital
filter mode. Note that these bits also establish the full-scale out-
put voltage for these channels as well.

The three digital filter modes are audio, modem and resampler.
The specifications for these modes are given in the description
of Control Register Address 25, as well as in the "SPECIFICA-
TIONS" section of this data sheet. The specifications have been
made to satisfy the demands of the applications which the
AD1843 can serve. The audio mode provides decimation and
interpolation characteristics sufficient for high quality cap-
ture and playback of material from 20 Hz to 20 kHz. The mo-
dem mode provides characteristics sufficient for modulation
standards up to V.34 quality. The resampling mode provides
optimal characteristics for high quality sample rate conversion.
While in the resampling mode, all images in the resampled data
stream (including those in the transition band) are attenuated to
below the quantization noise floor. Note that the maximum
sample rate for modem mode is 24 kHz.

Digital Resampling

Digital resampling is best achieved by routing the digital output
of one of the DACs back to the digital input of one of the
ADCs. This bypasses the analog portion of the DAC and ADC,
eliminating their noise and signal delay contributions. This fea-
ture is enabled by bits DAADR1:0 (Digital ADC Right Channel
Source Select) and DAADL1:0 (Digital ADC Left Channel
Source Select) in Control Register Address 25.

If the "Digital Resampler Filter Mode" (DRSFLT bit = "1,"
Control Register Address 25) is enabled, the DAC2 pair is sacri-
ficed, but the remaining four channels (ADC left and right,
DAC1 left and right) can still be used in any way they could
have been when not in "Digital Resampler Filter Mode." When
in this mode, internal AD1843 hardware normally devoted to
DAC2 is reallocated to the other four channels, allowing these
channels to realize superior digital filtering. Note that the
AD1843 DOES NOT actually have to be in digital resampler
filter mode to perform digital resampling, however the superior
digital filters in this mode allow for a much higher quality digital
resampling.

Using the AD1843 in a Modem Application

The AD1843 analog performance is sufficient to support the
modem Analog Front End (AFE) function, for data modulation
standards up to and including the 28.8 kbps V.34 ITU stan-
dard. The data pump function is performed in a companion
DSP, such as the ADSP-2181, for which several V.34 algo-
rithms (from third party Independent Algorithm Vendors) exist.

AD1843

REV. 0

LINE IN

MIC IN RIGHT

MIC IN LEFT

AUX1 IN

AUX2 IN

AUX3 IN

MONO IN

SUM IN

LINE1 OUT

HEADPHONE OUT

LINE2 OUT RIGHT

LINE2 OUT LEFT

MONO OUT

SYNC2

CONV1

BIT1

SERIAL

INTERFACE

DAA

SERIAL
INTERFACE

ADSP-21xx

DSP OR ASIC

AD1843 SOUNDCOMM

CODEC

IDMA PORT

OR PARALLEL

PORT

NTSC

HORIZONTAL

SYNC SIGNAL

HOST BUS

ISA OR PCI

EXTERNAL POWERED

MULTIMEDIA SPEAKERS

SPEAKERPHONE

AUDIO FROM DAT

OR CASSETTE

PC SPEAKER

PSTN

AUDIO FROM

EXTERNAL MPEG

DECODER

PC ATTENTION

"BEEPER" SIGNAL

AUDIO FROM

CD-ROM

EXTERNAL

WAVEFORM

SYNTHESIZER

Figure 6. Typical Configurations

15 14 13 12

512 BITS

MSB

512 BITS

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SLOT 31

SLOT 16

256 BITS

SAMPLE PERIOD N

SAMPLE PERIOD N+1

SAMPLE PERIOD N+2

SAMPLE
PERIOD N+3

FRAME M

FRAME M+1

SDI OR SDO

SCLK

SDFS

FRS = 0 [DEFAULT 32 SLOTS PER FRAME, 2 SAMPLES PER FRAME SYNC]

MASTER MODE

NOTE THAT AD1843 FRAME RATE IS NOT RELATED TO SAMPLE RATES

Figure 7. FRS = 0, Master Mode Timing

15 14 13 12

256 BITS

MSB

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SAMPLE PERIOD N

SAMPLE PERIOD N+1

SAMPLE PERIOD N+2

SAMPLE
PERIOD N+3

FRAME M

SDI OR SDO

SCLK

SDFS

FRS = 1 [16 SLOTS PER FRAME, 1 SAMPLE PER FRAME SYNC]

MASTER MODE

NOTE THAT SCLK CAN BE PROGRAMMED FOR EITHER 12.288 MHz

OR 16.384 MHz WHEN IN MASTER MODE

256 BITS

FRAME M+1

FRAME M+2

FRAME M+3

Figure 8. FRS = 1, Master Mode Timing

REV. 0

AD1843

15 14 13 12

512 BITS

MSB

512 BITS

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SLOT 31

SLOT 16

256 BITS

SAMPLE PERIOD N

SAMPLE PERIOD N+1

SAMPLE PERIOD N+2

FRAME M

FRAME M+1

SDI OR SDO

SCLK

TSI

FRS = 0 [DEFAULT 32 SLOTS PER FRAME, 2 SAMPLES PER FRAME SYNC]

EXAMPLE SHOWING GAPS BETWEEN FRAMES

SLAVE MODE

GAP

Figure 9a. FRS = 0, Slave Mode Timing

15 14 13 12

512 BITS

MSB

512 BITS

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SLOT 31

SLOT 16

256 BITS

SAMPLE PERIOD N

SAMPLE PERIOD N+1

SAMPLE PERIOD N+2

FRAME M

FRAME M+1

SDI OR SDO

SCLK

TSI

FRS = 0 [DEFAULT 32 SLOTS PER FRAME, 2 SAMPLES PER FRAME SYNC]

EXAMPLE SHOWING NO GAPS BETWEEN FRAMES

SLAVE MODE

15 14 13 12

15 14

Figure 9b. FRS = 0, Slave Mode Timing

FRS = 1 [16 SLOTS PER FRAME, 1 SAMPLES PER FRAME SYNC]

EXAMPLE SHOWING GAPS BETWEEN FRAMES

SLAVE MODE

GAP

15 14 13 12

256 BITS

MSB

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SAMPLE PERIOD N

SAMPLE PERIOD N+1

FRAME M

FRAME M+1

SDI OR SDO

SCLK

TSI

GAP

Figure 10a. FRS = 1, Slave Mode Timing

FRS = 1 [16 SLOTS PER FRAME, 1 SAMPLES PER FRAME SYNC]

EXAMPLE SHOWING NO GAPS BETWEEN FRAMES

SLAVE MODE

15 14 13 12

256 BITS

MSB

256 BITS

SLOT 15

SLOT 0

SLOT 15

SLOT 0

SAMPLE PERIOD N

SAMPLE PERIOD N+1

FRAME M

FRAME M+1

SDI OR SDO

SCLK

TSI

15 14 13 12

MSB

Figure 10b. FRS = 1, Slave Mode Timing

AD1843

REV. 0

Modem Data Access Arrangement (DAA) devices are generally
differential on the transmit side, and single-ended on the receive
side. The DAA transmit input (generally differential) should be
connected to the DAC2 output, pins LOUT2LP and LOUT2LN,
or LOUT2RP and LOUT2RN. The DAA receive output
(generally single-ended) should be connected to one of the
ADC line inputs, LINLP or LINRP. See the "APPLICATION
CIRCUITS" section below for more detail on the electrical
connections. There are several software driver steps that are re-
quired to configure the SoundComm codec for use as a modem
AFE.

Configure DAC2

1. Set the DA2FLT bit (Control Register Address 25, Bit 9) to

"1," to select the digital modem filter mode. The DAC2 out-
puts can be used either as differential outputs or single-ended
outputs depending on how the pins are connected electrically;
no Control Register writes are required to configure the DAC2
outputs as either differential or single-ended.

2. Program LDA2G5:0 (Control Register Address 10, Bits 8

through 13) to "00 0101" (i.e., +4.5 dB) or RDA2G5:0
(Control Register 10, Bits 0 through 5) to "00 0101" (i.e.,
+4.5 dB), depending on whether the DAA transmit input is
connected to the left channel DAC2 output (use LDA2G5:0)
or the right channel DAC2 output (use RDA2G5:0). This
code establishes the DAC2 nominal analog output swing at
3.156 V p-p single-ended, or 6.312 V p-p differentially. The
3.156 V p-p level is equivalent to 3.17 dBm.

Configure ADC

1. Set the ADLFLT bit (Control Register Address 25, Bit 0) to

"1," or the ADRFLT bit (Control Register Address 25, Bit 1)
to "1," to select the digital modem filter mode. Set ADLFLT
if the DAA receive output is connected to the AD1843
LINLP input; set ADRFLT if the DAA receive output is
connected to the AD1843 LINRP input. Set the LINLSD bit
(Control Register Address 28, Bit 0) to "1" if the DAA is
connected to the AD1843 LINLP input; set the LINRSD bit
(Control Register Address 28, Bit 1) to "1" if the DAA is
connected to the AD1843 LINRP input.

2. Program LIG3:0 (Control Register Address 2, Bits 8 through

11) to "0000" (i.e., 0.0 dB) or RIG3:0 (Control Register
Address 2, Bits 0 through 3) to "0000" (i.e., 0.0 dB) de-
pending on whether the left or right ADC input channel is
being used for the modem function. This code maps an ana-
log input swing of 3.156 V p-p to the full dynamic range of
the 16-bit digital sample (i.e.,

). The 3.156 V p-p level is

equivalent to 3.17 dBm.

Note that if the AD1843 is to be reconfigured dynamically, the
affected converter must be powered down before its associated
digital filter can be changed. In other words, if the digital filter
for the ADC left channel is being changed from audio mode to
modem mode, the ADC left channel must be powered down
first (using the ADLEN bit in Control Register Address 27).

Use the ADREN bit in Control Register Address 27 for the
ADC right channel, the DAC1EN bit in Control Register
Address 27 for DAC1, and the DAC2EN bit in Control Regis-
ter Address 27 for DAC2.

Typical Configurations

Figure 6 below illustrates example connections between the
AD1843 SoundComm codec and other system resources. The
rich analog input and output connectivity of the AD1843 allows
a wide variety of configuration possibilities. Note that the level
of modem, speakerphone and external speaker concurrency is
application and DSP resource dependent.

SERIAL INTERFACE

The AD1843 SoundComm Codec transmits and receives both
data and control/status information through its serial port.

The AD1843 can be configured as either master or slave of the
serial interface. This is selected by using the BM pin. When
BM is tied HI, the AD1843 serves as bus master and supplies
the frame sync and the serial clock. When BM is tied LO, the
AD1843 serves as bus slave and receives the frame sync and the
serial clock. The level on BM should not be altered unless the
reset pin (RESET) is asserted.

The AD1843 has six pins devoted to the serial interface: SDI,
SDO, SCLK, SDFS, TSI and TSO. The SDI pin is for serial
data input to the AD1843 and the SDO pin is for serial data
output from the AD1843. The SCLK pin is the serial interface
clock. Communication in and out of the AD1843 requires bits
of data to be transmitted after a rising edge of SCLK, and
sampled on a falling edge of SCLK. When the AD1843 is bus
master (BM pin tied HI), the SCLK frequency driven by the
AD1843 will be 12.288 MHz by default, but this can be in-
creased to 16.384 MHz by setting the SCF bit in Control Regis-
ter 26. When the AD1843 is bus slave (BM pin tied LO), the
SCLK frequency driven to the AD1843 may be as high as
24.576 MHz, but must not be any higher than the frequency on
the XTALI pin.

The SDFS pin is for the serial interface frame sync. When bus
master, new frames are marked by a HI pulse driven out on
SDFS one serial clock period before the frame begins. When
bus slave, new frames must be marked by a LO to HI transition
driven in on SDFS one serial clock period before the frame be-
gins, but the transition back from HI to LO may occur at any
time provided the HI and LO times of SDFS are at least one
SCLK period in duration each.

When the AD1843 is bus master, frame size is controlled by the
FRS bit in Control Register 26. When FRS is set to "1," each
frame is divided into 16 slots of 16 bits. When FRS is reset to
"0," each frame is divided into 32 slots of 16 bits. In 32 slot
configuration, the second 16 slots of a frame must have slot as-
signments that are identical to the first 16 slots of the frame; 32
slot configuration is essentially 16 slot configuration with every
other SDFS pulse missing. Although these are the frame sizes

REV. 0

AD1843

for Control Register write data input and read data output. The
remaining slots are used for playback (DAC) data input and
capture (ADC) data output, where each channel has an assigned
slot. Table II and Figure 11 illustrate these slot assignments.

Since the conversion channels of the AD1843 can be pro-
grammed to run at different sample rates, a communication
mechanism indicates when playback channels request data,
when playback data is actually sent to the AD1843, and when
transmission of capture data from the AD1843 becomes neces-
sary. This is facilitated by the Control and Status Words lo-
cated in the first slot. The Control Word indicates which slots
in the current frame contain valid playback data. The Status
Word indicates if playback data can be sent to the AD1843 dur-
ing the next frame, and which slots in the current frame contain
valid capture data. See the descriptions of the Control Word
and the Status Word below for additional detail.

Four word FIFO buffers are used on the inputs of each of the
DACs to allow data to be transferred in small bursts. This re-
duces the required response time to playback data requests, and
also buffers differences between the frame sync rate and the
channel sample rate. The Status Word indicates that playback
data can be sent if there is any room in the buffers, thus tending
to keep the input buffers full. Underrun flags are available in
Control Register 1, which indicate if an input buffer ran out of
data. If an underrun occurs, a zero is used in place of the un-
available data. To ensure underruns do not occur, playback data
must be sent to the AD1843 within two sample periods after the
status word indicates that the DAC FIFO is not full.

Note that the DAC Not Full status bits (DA2RQ and DA1RQ
in the Status Word Output) are updated immediately (i.e., in
the same frame as a valid write to the DAC FIFOs). If the DAC
Input Valid Flags (DA2V and DA1V in the Control Word
Input) are set (i.e., DAC data is valid) and only one location in
the DAC1 and DAC2 input FIFOs is available, then the
DA2RQ and DA1RQ status bits will reflect this valid write, and
will be reset to "0." This is possible because the DA2V and
DA1V bits are in the most significant bits of the Control Word
and the DA2RQ and DA1RQ bits are in the least significant bits
of the Status Word, and the AD1843 uses this intervening time

Table II. AD1843 Slot Assignment

32 Slot Mode (FRS Reset to "0")

Slot

SDI Pin

SDO Pin

0 & 16

Control Word Input

Status Word Output

1 & 17

Control Register Data Input

Control Register Data Output

2 & 18

Playback Data Input--DAC1 Left

Capture Data Output--ADC Left

3 & 19

Playback Data Input--DAC1 Right

Capture Data Output--ADC Right

4 & 20

Playback Data Input--DAC2 Left

Reserved (Unused)

5 & 21

Playback Data Input--DAC2 Right

Reserved (Unused)

16 Slot Mode (FRS Set to "1")

Slot

SDI Pin

SDO Pin

Control Word Input

Status Word Output

Control Register Data Input

Control Register Data Output

Playback Data Input--DAC1 Left

Capture Data Output--ADC Left

Playback Data Input--DAC1 Right

Capture Data Output--ADC Right

Playback Data Input--DAC2 Left

Reserved (Unused)

Playback Data Input--DAC2 Right

Reserved (Unused)

produced by an AD1843 serving as bus master, an AD1843
serving as bus slave does not actually require these frame sizes.
When FRS is set to "1," a slave will operate correctly with any
number or fraction of slots, provided there are enough slots for
it to complete its necessary communication (see below). When
FRS is reset to "0," a slave can also operate correctly with a
wide range in the number of slots per frame, however it will au-
tomatically retake ownership of the serial interface bus 16 slots
after it is first given ownership of the bus in a frame.

The nominal minimum number of slots when the AD1843 is
configured in slave mode is six. The codec must be supplied
with at least 6

16 = 96 SCLK periods (both rising and falling

edges); SCLK may be gated (i.e., no need to be continuous)
between valid slots.

While SDFS marks the beginning of frames, AD1843 bus own-
ership during a frame is controlled by the TSI (Time Slot In)
and TSO (Time Slot Out) pins. When bus slave, a level HI on
TSI grants the AD1843 bus ownership beginning with the next
SCLK period. The TSI pin is monitored only when an AD1843
does not already own the bus; once an AD1843 is given owner-
ship of the bus, the level on TSI is ignored until one SCLK
period before bus ownership is relinquished. Bus ownership will
last for six slots. Coincident with the final SCLK period of the
final slot owned, the AD1843 asserts TSO HI. This allows
chaining of AD1843s onto a common serial bus by connecting
the TSO pin of one AD1843 to the TSI pin on the next later
AD1843 in a chain. In single codec systems where the
SoundComm is configured as bus slave, connect the AD1843
SDFS and TSI signals together. When an AD1843 is bus mas-
ter, its function is identical to that just described for the slave,
except a bus master always owns the first six slots and its TSI
pin is ignored (but should be tied LO).

Whenever an AD1843 does not own the bus, its SDO pin will
be three-stated and its SDI pin is ignored. Figures 7 through 10
illustrate the signal, slot, sample and frame relationships for the
four basic operating modes of the AD1843 serial interface.

The AD1843 requires slots of communication each time it takes
ownership of the serial bus. The first slot is used for a Control
Word input and a Status Word output. The second slot is used

AD1843

REV. 0

interval to update the DAC Not Full status bits. Therefore
driver software does not have to make provision for frame-to-
frame delays between control and status information; the infor-
mation in each frame is always up to date.

The AD1843 supports locking to an external clock which may
result in a sample rate that is marginally higher than the nominal
audio standard maximum sample rate of 48 kHz. This is neces-
sary since two crystal-based clock sources are never perfectly
matched to one another. One is always at a slightly higher fre-
quency. The AD1843 conversion channels have been designed
to support sample rates that are up to 2.1% higher than 48 kHz
(i.e., 49 kHz), referenced to the AD1843's clock input on
XTALI, when all conversion channels are simultaneously run-
ning. Even higher rates can be supported when all channels are
not running simultaneously. See the "Conversion Rates" sec-
tion above for additional details. The serial interface must also
allow for this higher sample rate with a frame sync (SDFS) rate
that is at least as high as the sample rate in 16 slot per frame

mode, or half as high as the sample rate in 32 slot per frame
mode. When the AD1843 is bus master, the SCLK frequency
is either 12.288 MHz or 16.384 MHz, which allows for up to
48 kHz or 64 kHz sampling rates, respectively.

The AD1843 Control Registers are read and written by trans-
mitting a read/write request bit along with the Control Register
address in the slot 0 Control Word. When a read is requested,
the contents of the Control Register addressed is transmitted
out during slot 1 of the following frame. When a write is re-
quested, data to be written must be transmitted to the AD1843
in slot 1, and the former contents of the control register are
transmitted out during slot 1 of the following frame. Unless oth-
erwise noted, Control Register writes do not take effect until the
current round of six communication TDM time slots concludes.
Equivalently, unless otherwise noted, Control Register writes do
not take effect until the subsequent falling edge of the TSO signal.

The following sections describe the bit assignments for all time
slots.

IGNORED

3-STATED

CONTROL WORD

STATUS WORD

REGISTER DATA

DAC1 LEFT

ADC LEFT

DAC1 RIGHT

ADC RIGHT

DAC2 LEFT

DAC2 RIGHT

IGNORED

3-STATED

SDI

SDO

16-BIT

STEREO

DON'T

CARE

IGNORED

3-STATED

CONTROL WORD

STATUS WORD

REGISTER DATA

IGNORED

3-STATED

DAC1R

DON'T

CARE

DAC2L

DAC2R

DON'T

CARE

DAC1L

DON'T

CARE

ADCL

ADCR

SDI

SDO

8-BIT

STEREO

IGNORED

3-STATED

CONTROL WORD

STATUS WORD

REGISTER DATA

DAC1

ADC LEFT

DON'T CARE

ADC RIGHT

DAC2

DON'T CARE

IGNORED

3-STATED

SDI

SDO

16-BIT
MONO

DAC1, DAC2

IGNORED

3-STATED

CONTROL WORD

STATUS WORD

REGISTER DATA

DON'T CARE

DAC2

DON'T

CARE

DON'T

CARE

DAC1

ADCL

ADCR

IGNORED

3-STATED

SDI

SDO

8-BIT

MONO

DAC1, DAC2

THE DIAGRAM ABOVE IS INTENDED TO BE ILLUSTRATIVE OF THE MORE COMMONLY USED CONFIGURATIONS. ADC LEFT, ADC RIGHT, DAC1
AND DAC2 CAN BE INDIVIDUALLY ASSIGNED TO 8-BIT OR 16-BIT SAMPLE WIDTH, AND DAC1 AND DAC2 CAN BE INDIVIDUALLY ASSIGNED
TO STEREO OR MONO MODE. EACH AD1843 CONSUMES 6 TMD SLOTS (REQUIRING 96 SCLK PERIODS), LEAVING 10 TDM SLOTS
UNUSED IN A 16 SLOT FRAME.

NOTE THAT BECAUSE THE SERIAL INTERFACE AND THE ADC AND DACS ARE IN GENERAL ASYNCHRONOUS, NOT EVERY CAPTURE OR
PLAYBACK TIME SLOT WILL CONTAIN VALID DATA. THE HOST PROCESSOR MUST POLL THE STATUS WORD TO DETERMINE WHETHER
THE ADC DATA IS VALID AND WHETHER THE DAC IS REQUESTING ADDITIONAL SAMPLES.

TIME

SLOT 0

TIME

SLOT 1

TIME

SLOT 2

TIME

SLOT 3

TIME

SLOT 4

TIME

SLOT 5

SCLK

SDFS

16 BITS

Figure 11. AD1843 Slot Assignments

REV. 0

AD1843

SERIAL INTERFACE INPUT

Note that the references to slot numbers are valid only when the AD1843 is configured in master mode. For slave mode, bus owner-
ship does not necessarily start on Slot 0.

Control Word Input (Slot 0 or 16)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

DA2V

DA1V

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

R/W

res

IA4

IA3

IA2

IA1

IA0

DA2V

DAC2 Input Valid Flag. When in DAC2 stereo mode, setting this bit to "1" indicates that slots 4 and 5
contain valid playback data for the left and right channels of DAC2, respectively. When in DAC2 mono
mode, setting this bit to "1" indicates that slot 4 contains valid playback data for both left and right channels
of DAC2. Slot 5 is ignored in DAC2 mono mode. When this bit is reset to "0," data in slots 4 and 5 is
ignored. This bit is ignored if the AD1843 did not request data for DAC2 in the last frame (see the DA2RQ
bit in the Status Word Output).

DA1V

DAC1 Input Valid Flag. When in DAC1 stereo mode, setting this bit to "1" indicates that slots 2 and 3
contain valid playback data for the left and right channels of DAC1, respectively. When in DAC1 mono
mode, setting this bit to "1" indicates that slot 2 contains valid playback data for both left and right channels
of DAC1. Slot 3 is ignored in DAC1 mono mode. When this bit is reset to "0," data in slots 2 and 3 is
ignored. This bit is ignored if the AD1843 did not request data for DAC1 in the last frame (see the DA1RQ
bit in the Status Word Output).

R/W

Read/Write Request. Either a read from or a write to a Control Register occurs every frame. Setting this bit
to "1" indicates a Control Register read while resetting this bit to "0" initiates a Control Register write. Bits
IA4:0 define the Control Register address. When reading, the contents of the Control Register addressed are
transmitted during slot 1 of the following frame. When writing, the data to be written is taken from slot 1
and the former contents of the Control Register are transmitted during slot 1 of the following frame.

IA4:0

Control Register address for read or write.

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Control Register Write Data Input (Slot 1 or 17)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DATA7

DATA6

DATA5

DATA4

DATA3

DATA2

DATA1

DATA0

Format for the input data to written to the addressed Control Register. MSB is first.

DAC1 Left Sample Input (Slot 2 or 18)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DATA7

DATA6

DATA5

DATA4

DATA3

DATA2

DATA1

DATA0

Data format may be 8-bit unsigned linear PCM, 16-bit signed linear PCM, 8-bit

-Law companded, or 8-bit A-Law companded.

MSB is first. DATA7:0 are ignored in 8-bit linear or 8-bit companded modes.

REV. 0

AD1843

SERIAL INTERFACE OUTPUT

Status Word Output (Slot 0 or 16)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

ADRV

ADLV

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

DA2RQ

DA1RQ

ADRV

Right ADC Channel Output Valid Flag. Set to "1" if slot 3 (or 19) contains valid right ADC capture data.

ADLV

Left ADC Channel Output Valid Flag. Set to "1" if slot 2 (or 18) contains valid left ADC capture data.

DA2RQ

DAC2 Input Request Flag. Set to "1" if DAC2 is enabled and its four word stereo input buffer is not full.

DA1RQ

DAC1 Input Request Flag. Set to "1" if DAC1 is enabled and its four word stereo input buffer is not full.

res

Reserved for future expansion. Read back as "0." Should be ignored to ensure future compatibility.

Control Register Data Output (Slots 1 or 17)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DATA7

DATA6

DATA5

DATA4

DATA3

DATA2

DATA1

DATA0

Contents of Control Register addressed in previous frame.

ADC Left Sample Output (Slots 2 or 18)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DATA7

DATA6

DATA5

DATA4

DATA3

DATA2

DATA1

DATA0

Data format may be 8-bit unsigned linear PCM, 16-bit signed linear PCM, 8-bit

-Law companded, or 8-bit A-Law companded.

MSB is first. DATA7:0 are ignored in 8-bit linear or 8-bit companded modes.

ADC Right Sample Output (Slots 3 or 19)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DATA7

DATA6

DATA5

DATA4

DATA3

DATA2

DATA1

DATA0

Data format may be 8-bit unsigned linear PCM, 16-bit signed linear PCM, 8-bit

-Law companded, or 8-bit A-Law companded.

MSB is first. DATA7:0 are ignored in 8-bit linear or 8-bit companded modes.

AD1843

REV. 0

Reserved Output (Slots 4 or 20)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

Reserved for future expansion. Read back as "0." Should be ignored to ensure future compatibility.

Reserved Output (Slots 5 or 21)

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

Reserved for future expansion. Read back as "0." Should be ignored to ensure future compatibility.

CONTROL REGISTERS
Control Register Architecture

All Control Registers are cleared to their default state when either the RESET pin or the PWRDWN pin is asserted. All conversion
related Control Registers (Addresses 115, 25 and 27) are cleared to defaults when the conversion resources of the AD1843 are pow-
ered down through the PDNI bit in Control Register Address 28. Control Registers which manage analog DAC gain/attenuation
(Addresses 310) are cleared to defaults whenever the resource they manage is powered down. Finally, the three clock generator
sample phase shift Control Registers (Addresses 18, 21 and 24) are cleared to defaults whenever their associated clock generator is
powered down. Writes to Control Registers are blocked until a clearing condition no longer exists. Writes to Control Registers are
also blocked immediately after the RESET pin or the PWRDWN pin is asserted until the AD1843's internal clocks have settled,
which is indicated by the INIT bit in Control Register Address 0. Control Registers may always be read.

Figures 12 and 13 associate the Control Registers to the AD1843 Block Diagram.

REV. 0

AD1843

Address 0

Codec Status and Revision Identification

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

INIT

PDNO

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

ID3

ID2

ID1

ID0

This register is read only.

INIT

Clock Initialization Flag. This bit is set to "1" if the AD1843's internal clocks generated from the crystal input pin
XTALI have not yet stabilized. When set to "1," Control Registers may be read if the AD1843 is configured as a Bus
Slave (see the definition for the BM pin), but Control Register writes will be blocked. This bit is set to a "1" after the
RESET

pin is asserted, or when the power-down sequence (initiated by asserting the PWRDWN pin) has completed.

The bit is reset to "0" usually within 400 to 800

sec after the RESET or the PWRDWN pin is deasserted, depending

upon parasitic capacitance on the XTALI and XTALO pins outside the AD1843. Because these parasitics are a func-
tion of the board design and layout, the exact amount of time required for the crystal to start to oscillate, and the in-
ternal clocks to stabilize cannot be known exactly in advance.

PDNO

Converter Power-Down Flag. This bit is set to "1" if the AD1843 conversion resources are powered down, or are in
the process of entering or exiting power down. Conversion resources are all resources in the AD1843 with the excep-
tion of the three clock generators and the serial interface. Conversion power-down is entered if either the power-down
pin (PWRDWN) is driven LO, or if the PDNI (Converter Power Down) bit in Control Register Address 28 is as-
serted. Power down is exited only if both pin (PWRDWN) and bit (PDNI) are deasserted. When this bit is set to
"1," Control Registers may still be read, but only Control Registers 1624, 26 and 28 which do not manage conver-
sion resources may be written. See the "Power Management" section for further details. This bit is set to "1" imme-
diately after a reset since the PDNI bit is initially asserted after a reset.

ID3:0

Revision Identification. These bits define the revision level of the AD1843. The first version of the AD1843 is
"0001."

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1100 0000 0000 0001 (C001 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

Address 1

Channel Status Flags

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

SU2

SU1

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

OVR1

OVR0

OVL1

OVL0

This register is cleared to all "0" after any read or write access.

SU2

DAC2 Sample Underrun. When set to "1," this bit indicates that the four word stereo input buffer for DAC pair 2
ran out of samples. If this occurs, zeros are used in place of the unavailable data. This bit is "sticky" and is cleared
after any write to this register. It is also cleared by powering down DAC2 (see the DA2EN bit in Control Register
Address 27).

SU1

DAC1 Sample Underrun. When set to "1," this bit indicates that the four word stereo input buffer for DAC pair 1

ran out of samples. If this occurs, zeros are used in place of the unavailable data. This bit is "sticky" and is cleared
after any write to this register. It is also cleared by powering down DAC1 (see the DA1EN bit in Control Register
Address 27).

OVR1:0

ADC Right Overrange Detect. These bits record the largest output magnitude on the ADC right channel and are

cleared to "00" after any write to this register. The peak amplitude as recorded by these bits is "sticky," i.e., the larg-
est output magnitude recorded by these bits will persist until these bits are explicitly cleared. They are also cleared by
powering down the ADC right channel (see the ADREN bit in Control Register Address 27).

00 = Greater than 1.0 dB underrange

01 = Between 1.0 dB and 0 dB underrange

10 = Between 0 dB and 1 dB overrange

11 = Greater than 1.0 dB overrange

AD1843

REV. 0

OVL1:0

ADC Left Overrange Detect. These bits record the largest output magnitude on the ADC left channel and are

cleared to "00" after any write to this register. The peak amplitude as recorded by these bits is "sticky," i.e., the larg-
est output magnitude recorded by these bits will persist until these bits are explicitly cleared. They are also cleared by
powering down the ADC left channel (see the ADLEN bit in Control Register Address 27).

00 = Greater than 1.0 dB underrange

01 = Between 1.0 dB and 0 dB underrange

10 = Between 0 dB and 1 dB overrange

11 = Greater than 1.0 dB overrange

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default when: the RESET pin is asserted

LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register Address 0 is set to "1" (all
conversions disabled).

Address 2

Input Control--ADC Source and Gain/Attenuation

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LSS2

LSS1

LSS0

LMGE

LIG3

LIG2

LIG1

LIG0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RSS2

RSS1

RSS0

RMGE

RIG3

RIG2

RIG1

RIG0

LSS2:0

Left ADC Source Select
000 = Left Line Input
001 = Left Mic Input
010 = Left Auxiliary 1 Input
011 = Left Auxiliary 2 Input
100 = Left Auxiliary 3 Input
101 = Mono Input
110 = Left DAC1 Output
111 = Left DAC2 Output

LMGE

Left ADC Microphone Gain Enable
0 = 0 dB Gain
1 = +20 dB Gain

LIG3:0

Left ADC Input Gain. Least significant bit represents +1.5 dB.
0000 = 0.0 dB Gain
1111 = +22.5 dB Gain

RSS2:0

Right ADC Source Select
000 = Right Line Input
001 = Right Mic Input
010 = Right Auxiliary 1 Input
011 = Right Auxiliary 2 Input
100 = Right Auxiliary 3 Input
101 = Mono Input
110 = Right DAC1 Output
111 = Right DAC2 Output

RMGE

Right ADC Microphone Gain Enable
0 = 0 dB Gain
1 = +20 dB Gain

RIG3:0

Right ADC Input Gain. Least significant bit represents +1.5 dB.
0000 = 0.0 dB Gain
1111 = +22.5 dB Gain

Initial Default State after Reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register 0
is set to "1" (all conversions disabled).

REV. 0

AD1843

Address 3

Mix Control--DAC2 to Mixer

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LD2MM

res

LD2M4

LD2M3

LD2M2

LD2M1

LD2M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RD2MM

res

RD2M4

RD2M3

RD2M2

RD2M1

RD2M0

LD2MM

Left DAC2 Mix Mute
0 = Mix Enabled
1 = Mix Muted

LD2M4:0

Left DAC2 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p DAC2
output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

RD2MM

Right DAC2 Mix Mute
0 = Mix Enabled
1 = Mix Muted

RD2M4:0

Right DAC2 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p DAC2
output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled); or when the DDMEN bit (DAC2 to DAC1 analog mix disabled),
the DA2EN bit (DAC2 powered down), or the ANAEN bit (analog channels powered down) in Control Register Ad-
dress 27 is reset to "0."

Address 4

Mix Control--Auxiliary 1 to DAC1

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LX1MM

res

LX1M4

LX1M3

LX1M2

LX1M1

LX1M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RX1MM

res

RX1M4

RX1M3

RX1M2

RX1M1

RX1M0

LX1MM

Left Auxiliary 1 Mix Mute
0 = Mix Enabled
1 = Mix Muted

LX1M4:0

Left Auxiliary 1 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p DAC1
output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

RX1MM

Right Auxiliary 1 Mix Mute
0 = Mix Enabled
1 = Mix Muted

RX1M4:0

Right Auxiliary 1 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p DAC1
output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

AD1843

REV. 0

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written
to when: the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in
Control Register Address 0 is set to "1" (all conversions disabled); or when the AAMEN bit (analog input to
analog mix disabled), or the ANAEN bit (analog channels powered down) in Control Register Address 27 is
reset to "0."

Address 5

Mix Control--Auxiliary 2 to Mixer

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LX2MM

res

LX2M4

LX2M3

LX2M2

LX2M1

LX2M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RX2MM

res

RX2M4

RX2M3

RX2M2

RX2M1

RX2M0

LX2MM

Left Auxiliary 2 Mix Mute
0 = Mix Enabled
1 = Mix Muted

LX2M4:0

Left Auxiliary 2 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to
2.0 V p-p DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

RX2MM

Right Auxiliary 2 Mix Mute
0 = Mix Enabled
1 = Mix Muted

RX2M4:0

Right Auxiliary 2 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to
2.0 V p-p DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register Ad-
dress 0 is set to "1" (all conversions disabled); or when the AAMEN bit (analog input to analog mix disabled), or the
ANAEN bit (analog channels powered down) in Control Register Address 27 is reset to "0."

Address 6

Mix Control--Auxiliary 3 to Mixer

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LX3MM

res

LX3M4

LX3M3

LX3M2

LX3M1

LX3M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RX3MM

res

RX3M4

RX3M3

RX3M2

RX3M1

RX3M0

LX3MM

Left Auxiliary 3 Mix Mute
0 = Mix Enabled
1 = Mix Muted

LX3M4:0

Left Auxiliary 3 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to
2.0 V p-p DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

REV. 0

AD1843

RX3MM

Right Auxiliary 3 Mix Mute
0 = Mix Enabled
1 = Mix Muted

RX3M4:0

Right Auxiliary 3 Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to
2.0 V p-p DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled); or when the AAMEN bit (analog input to analog mix disabled), or
the ANAEN bit (analog channels powered down) in Control Register Address 27 is reset to "0."

Address 7

Mix Control--Mic to Mixer

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LMCMM

res

LMCM4

LMCM3

LMCM2

LMCM1

LMCM0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RMCMM

res

RMCM4

RMCM3

RMCM2

RMCM1

RMCM0

LMCMM

Left Microphone Mix Mute
0 = Mix Enabled
1 = Mix Muted

LMCM4:0

Left Microphone Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p
DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

RMCMM

Right Microphone Mix Mute
0 = Mix Enabled
1 = Mix Muted

RMCM4:0

Right Microphone Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB. Referred to 2.0 V p-p
DAC1 output level.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled); or when the AAMEN bit (analog input to analog mix disabled), or
the ANAEN bit (analog channels powered down) in Control Register Address 27 is reset to "0."

Address 8

Mix/Miscellaneous Control--Mono In to Mixer and Miscellaneous Settings

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

MNMM

res

MNM4

MNM3

MNM2

MNM1

MNM0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

ALLMM

MNOM

HPOM

HPOS

SUMM

res

DAC2T

DAC1T

MNMM

Mono Input Mix Mute
0 = Mix Enabled
1 = Mix Muted

AD1843

REV. 0

MNM4:0

Left and Right Mono Mix Gain/Attenuation Select. Least significant bit represents 1.5 dB.
00000 = +12.0 dB Gain
01000 = 0.0 dB
11111 = 34.5 dB Attenuation

ALLMM

All Mix Mute. Mutes all mixing (MIC, AUX1, AUX2, AUX3, and DAC2) to left and right DAC1, overriding the
independent mute control bits in Control Register Addresses 3 through 8.
0 = Mix to DAC1 Enabled
1 = Mix to DAC1 Muted

MNOM

Mono Output Mute
0 = Mono Output Enabled
1 = Mono Output Muted

HPOM

Headphone Output Mute (Left and Right)
0 = Headphone Output Enabled
1 = Headphone Output Muted

HPOS

Headphone Output Voltage Swing (Left and Right)
0 = 2 volts peak-to-peak
1 = 4 volts peak-to-peak

SUMM

Sum Left and Right Mute. Mutes mixing from SUML and SUMR pins to DAC1.
0 = SUML and SUMR Mix to DAC1 Enabled
1 = SUML and SUMR Mix to DAC1 Muted

DAC2T

DAC2 Gain/Attenuation Change Timing. This bit controls when changes to the DAC2 gain/attenuation setting
(Control Register 10) take effect. When set to "1," changes take effect immediately. When reset to "0," changes are
delayed until either the output level on DAC2 crosses zero (midscale), or until after a 10 to 12 ms time-out period is
reached. Delaying gain/attenuation changes until zero crossings reduces instantaneous output voltage changes, which
reduces audible "clicks."
0 = Gain/Attenuation Changes Applied on Signal Zero Crossing or After a 10-12 ms Time-Out
1 = Gain/Attenuation Changes Applied Immediately

DAC1T

DAC1 Gain/Attenuation Change Timing. This bit controls when changes to the DAC1 gain/attenuation setting
(Control Register 9) take effect. When set to "1," changes take effect immediately. When reset to "0," changes are
delayed until either the output level on DAC1 crosses zero (midscale), or until after a 10 to 12 ms time-out period is
reached. Delaying gain/attenuation changes until zero crossings reduces instantaneous output voltage changes, which
reduces audible "clicks."
0 = Gain/Attenuation Changes Applied on Signal Zero Crossing or After a 10-12 ms Time-Out
1 = Gain/Attenuation Changes Applied Immediately

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 0110 1000 (8868 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions powered down). The MSB half (Data 15 through Data 8) of this Control Reg-
ister is cleared to default and cannot be written to also when: the AAMEN bit (analog input to analog mix disabled),
or the ANAEN bit (analog channels powered down) in Control Register 27 is reset to "0."

Address 9

Output Control--DAC1 Analog Gain/Attenuation

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LDA1GM

res

LDA1G5

LDA1G4

LDA1G3

LDA1G2

LDA1G1

LDA1G0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RDA1GM

res

RDA1G5

RDA1G4

RDA1G3

RDA1G2

RDA1G1

RDA1G0

LDA1GM

Left DAC1 Analog Mute
0 = Left DAC1 Enabled
1 = Left DAC1 Muted

REV. 0

AD1843

LDA1G5:0

Left DAC1 Analog/Digital Gain/Attenuation Select. Least significant bit represents 1.5 dB. Note that the
implementation of the attenuation is mixed analog and digital.
0 00000 =

+12.0 dB:

+12.0 dB Analog,

+0.0 dB Digital

0 01000 =

0.0 dB:

+0.0 dB Analog,

+0.0 dB Digital

0 11111 =

34.5 dB:

34.5 dB Analog,

+0.0 dB Digital

1 00000 =

36.0 dB:

34.5 dB Analog,

1.5 dB Digital

1 11111 =

82.5 dB:

34.5 dB Analog,

48.0 dB Digital

RDA1GM

Right DAC1 Analog Mute
0 = Right DAC1 Enabled
1 = Right DAC1 Muted

RDA1G5:0

Right DAC1 Analog/Digital Gain/Attenuation Select. Least significant bit represents 1.5 dB. Note that the
implementation of the attenuation is mixed analog and digital.
0 00000 =

+12.0 dB:

+12.0 dB Analog,

+0.0 dB Digital

0 01000 =

0.0 dB:

+0.0 dB Analog,

+0.0 dB Digital

0 11111 =

34.5 dB:

34.5 dB Analog,

+0.0 dB Digital

1 00000 =

36.0 dB:

34.5 dB Analog,

1.5 dB Digital

1 11111 =

82.5 dB:

34.5 dB Analog,

48.0 dB Digital

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled); when the ANAEN bit in Control Register Address 27 is reset to "0"
(analog channels powered down); or when the DA1EN bit in Control Register Address 27 is reset to "0" (DAC1
disabled).

Address 10

Output Control--DAC2 Analog Gain/Attenuation

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LDA2GM

res

LDA2G5

LDA2G4

LDA2G3

LDA2G2

LDA2G1

LDA2G0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RDA2GM

res

RDA2G5

RDA2G4

RDA2G3

RDA2G2

RDA2G1

RDA2G0

LDA2GM

Left DAC2 Analog Mute
0 = Left DAC2 Enabled
1 = Left DAC2 Muted

LDA2G5:0

Left DAC2 Analog/Digital Gain/Attenuation Select. Least significant bit represents 1.5 dB. Note that the imple-
mentation of the attenuation is mixed analog and digital.
0 00000 =

+12.0 dB:

+12.0 dB Analog,

+0.0 dB Digital

0 01000 =

0.0 dB:

+0.0 dB Analog,

+0.0 dB Digital

0 11111 =

34.5 dB:

34.5 dB Analog,

+0.0 dB Digital

1 00000 =

36.0 dB:

34.5 dB Analog,

1.5 dB Digital

1 11111 =

82.5 dB:

34.5 dB Analog,

48.0 dB Digital

RDA2GM

Right DAC2 Analog Mute
0 = Right DAC2 Enabled
1 = Right DAC2 Muted

RDA2G5:0

Right DAC2 Analog/Digital Gain/Attenuation Select. Least significant bit represents 1.5 dB. Note that the imple-
mentation of the attenuation is mixed analog and digital.
0 00000 =

+12.0 dB:

+12.0 dB Analog,

+0.0 dB Digital

0 01000 =

0.0 dB:

+0.0 dB Analog,

+0.0 dB Digital

0 11111 =

34.5 dB:

34.5 dB Analog,

+0.0 dB Digital

1 00000 =

36.0 dB:

34.5 dB Analog,

1.5 dB Digital

1 11111 =

82.5 dB:

34.5 dB Analog,

48.0 dB Digital

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 1000 1000 1000 (8888 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled); when the ANAEN bit in Control Register Address 27 is reset to "0"
(analog channels powered down); or when the DA2EN bit in Control Register Address 27 is reset to "0" (DAC2
disabled).

AD1843

REV. 0

Address 11

Output Control--DAC1 Digital Attenuation

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LDA1AM

res

LDA1A5

LDA1A4

LDA1A3

LDA1A2

LDA1A1

LDA1A0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RDA1AM

res

RDA1A5

RDA1A4

RDA1A3

RDA1A2

RDA1A1

RDA1A0

LDA1AM

Left DAC1 Digital Mute
0 = Left DAC1 Enabled
1 = Left DAC1 Muted

LDA1A5:0

Left DAC1 Digital Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111111 = 94.5 dB Attenuation

RDA1AM

Right DAC1 Digital Mute
0 = Right DAC1 Enabled
1 = Right DAC1 Muted

RDA1A5:0

Right DAC1 Digital Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111111 = 94.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled).

Address 12

Output Control--DAC2 Digital Attenuation

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LDA2AM

res

LDA2A5

LDA2A4

LDA2A3

LDA2A2

LDA2A1

LDA2A0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RDA2AM

res

RDA2A5

RDA2A4

RDA2A3

RDA2A2

RDA2A1

RDA2A0

LDA2AM

Left DAC2 Digital Mute
0 = Left DAC2 Enabled
1 = Left DAC2 Muted

LDA2A5:0

Left DAC2 Digital Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111111 = 94.5 dB Attenuation

RDA2AM

Right DAC2 Digital Mute
0 = Right DAC2 Enabled
1 = Right DAC2 Muted

RDA2A5:0

Right DAC2 Digital Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111111 = 94.5 dB Attenuation

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

REV. 0

AD1843

Address 13

Digital Mix Control--ADC to DAC1

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LAD1MM

res

LAD1M5

LAD1M4

LAD1M3

LAD1M2

LAD1M1

LAD1M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RAD1MM

res

RAD1M5

RAD1M4

RAD1M3

RAD1M2

RAD1M1

RAD1M0

Restrictions: ADC and DAC channel mixed must receive conversion rate from same Clock Generator. Serial interface must be run-
ning at a rate greater than or equal to the ADC/DAC conversion rate. For bus master: SDFS frequency

ADC/DAC conversion rate. For

bus slave: TSI frequency

ADC/DAC conversion rate.

LAD1MM

Digital Mix of Left ADC Output with Left DAC1 Input Mute.
0 = Mix Enabled
1 = Mix Muted

LAD1M5:0

Digital Mix of Left ADC Output with Left DAC1 Input Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111110 = 93.0 dB Attenuation
111111 = Full Mute

RAD1MM

Digital Mix of Right ADC Output with Right DAC1 Input Mute.
0 = Mix Enabled
1 = Mix Muted

RAD1M5:0

Digital Mix of Right ADC Output with Right DAC1 Input Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111110 = 93.0 dB Attenuation
111111 = Full Mute

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1000 0000 1000 0000 (8080 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled).

Address 14

Digital Mix Control--ADC to DAC2

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

LAD2MM

res

LAD2M5

LAD2M4

LAD2M3

LAD2M2

LAD2M1

LAD2M0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

RAD2MM

res

RAD2M5

RAD2M4

RAD2M3

RAD2M2

RAD2M1

RAD2M0

ADC/DAC conversion rate. For

bus slave: TSI frequency

ADC/DAC conversion rate.

LAD2MM

Digital Mix of Left ADC Output with Left DAC2 Input Mute.
0 = Mix Enabled
1 = Mix Muted

LAD2M5:0

Digital Mix of Left ADC Output with Left DAC2 Input Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111110 = 93.0 dB Attenuation
111111 = Full Mute

RAD2MM

Digital Mix of Right ADC Output with Right DAC2 Input Mute.
0 = Mix Enabled
1 = Mix Muted

RAD2M5:0

Digital Mix of Right ADC Output with Right DAC2 Input Attenuation Select. Least significant bit represents 1.5 dB.
000000 = +0.0 dB Attenuation
111110 = 93.0 dB Attenuation
111111 = Full Mute

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

AD1843

REV. 0

Address 15

Codec Configuration--Channel Sample Rate Source Select

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

DA2C1

DA2C0

DA1C1

DA1C0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

ADRC1

ADRC0

ADLC1

ADLC0

DA2C1:0

DAC2 Sample Rate Source. Selects the sample rate clock source for left and right channels of DAC2.
00 = Conversion Sample Rate is 48.0 kHz
01 = Conversion Sample Rate is from Clock Generator 1
10 = Conversion Sample Rate is from Clock Generator 2
11 = Conversion Sample Rate is from Clock Generator 3

DA1C1:0

DAC1 Sample Rate Source. Selects the sample rate clock source for left and right channels of DAC1.
00 = Conversion Sample Rate is 48.0 kHz
01 = Conversion Sample Rate is from Clock Generator 1
10 = Conversion Sample Rate is from Clock Generator 2
11 = Conversion Sample Rate is from Clock Generator 3

ADRC1:0

ADC Right Sample Rate Source. Selects the sample rate clock source for the right ADC channel.
00 = Conversion Sample Rate is 48.0 kHz
01 = Conversion Sample Rate is from Clock Generator 1
01 = Conversion Sample Rate is from Clock Generator 2
11 = Conversion Sample Rate is from Clock Generator 3

ADLC1:0

ADC Left Sample Rate Source. Selects the sample rate clock source for the left ADC channel.
00 = Conversion Sample Rate is 48.0 kHz
01 = Conversion Sample Rate is from Clock Generator 1
10 = Conversion Sample Rate is from Clock Generator 2
11 = Conversion Sample Rate is from Clock Generator 3

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Address 16

Clock Generator 1 Control--Mode

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C1REF

C1VID

C1PLLG

C1P200

C1X8/7

C1C128

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C1M7

C1M6

C1M5

C1M4

C1M3

C1M2

C1M1

C1M0

C1REF

Clock Generator 1 Reference Select. Selects the fundamental clock reference used by Clock Generator 1 to
synthesize its "Conversion" (sample) and "Bit" clock rates.

0 = Clocks are referenced to the input on pin XTALI (crystal or master clock input).

Sample clock frequency is defined by Control Register Address 17 and Bit C1X8/7.

Sample clock phase may be shifted by Control Register Address 18.

Bit clock frequency is defined by bits C1M7:0 and C1P200.

Bit C1VID is ignored.

1 = Clocks are referenced to the input on pin SYNC1 (Sync 1 Clock Input).

Sample clock frequency is defined by C1VID and C1M7:0.

Sample clock phase is locked to SYNC1 and cannot be shifted.

Bit clock frequency is defined by bits C1M7:0 and C1P200 unless in Video Lock Mode (C1VID set to "1")
where the Bit clocks are not produced.

Control Register Addresses 17, 18 and the C1X8/7 bit are ignored.

REV. 0

AD1843

C1VID

Clock Generator 1 Video Lock Mode. This bit is used to select between lock modes when the Clock Generator 1 is
referenced to SYNC1 (C1REF set to "1"). This bit should be reset to "0" if C1REF is reset to "0." When reset to
"0," Clock Generator 1 is in normal lock mode where the Conversion clock will be frequency and phase locked to
SYNC1, and the Bit clock frequency is chosen using bits C1M7:0 and C1P200. When set to "1," Clock Generator 1
is in video lock mode, where the Conversion clock frequency is selected using bits C1M7:0, and a Bit clock is not pro-
duced.

C1PLLG

Clock Generator 1 PLL Loop Gain Select. If reset to "0," this bit selects finite PLL loop gain, and if set to "1," this
bit selects infinite PLL loop gain. This bit should nominally be reset to "0." Setting it to "1" may enhance the PLL's
ability to lock to certain SYNC1 inputs, but it may also increase conversion noise.

C1P200

Clock Generator 1 Bit Clock +200 Frequency Modifier. When set to "1," the Bit clock driven out of pin BIT1 will
have a frequency that is 200 Hertz greater than the frequency selected through bit C1M7:0. This bit is ignored when
in Video Lock Mode (C1VID set to "1"). C1P200 only modifies the bit clock driven on the BIT1 pin.

C1X8/7

Clock Generator 1 Conversion Clock 8/7 Frequency Modifier. When set to "1," the Conversion clock frequency gen-
erated will be 8/7 times the value programmed in Control Register Address 17. This bit is ignored when clocks are
referenced to SYNC1 (C1REF set to "1").

C1C128

Clock Generator 1 Conversion Clock Pin (CONV1) Frequency Select. When set to "1," the frequency driven on to
the CONV1 pin will be 128 times the conversion rate. When reset to "0," the frequency driven on to the CONV1 pin
will be the same as the conversion rate. C1C128 only modifies the clock frequency driven on the CONV1 pin.

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

C1M7:0

Clock Generator 1 Clock Rate Modifiers.

When not in Video Lock Mode (C1REF and C1VID are not both set to "1"):
Bits C1M7:0 select the Bit clock rate which will be driven out on pin BIT1. Using the following table, the least sig-
nificant four bits (C1M3:0) are programmed to the desired Bit clock rate, and the most significant four bits
(C1M7:4) must be programmed to the Conversion clock rate established using Control Register Address 17 and the
C1X8/7 bit. If the actual Conversion clock differs from the value selected by C1M7:4, then the resultant Bit clock
will be different from the rate selected by the ratio of the C1M7:4 selected rate to the Control Register Address 17
plus the C1X8/7 bit actual rate.

C1M3:0

Bit Clock Frequency*

C1M7:4

Conversion (Sample) Rate

0000

2,400

Hertz

0000

7,200

Hertz

0001

4,800

0001

8,400

0010

7,200

0010

9,000

0011

9,600

0011

9,600

0100

12,000

0100

11,200

0101

14,400

0101

12,000

0110

16,800

0110

12,800

0111

19,200

0111

7,200

8/7

1000

21,600

1000

9,000

8/7

1001

24,000

1001

9,600

8/7

1010

26,400

1010

12,000

8/7

1011

28,800

1011

Reserved

1100

Reserved

1100

Reserved

1101

Reserved

1101

Reserved

1110

Reserved

1110

Reserved

1111

See Below

1111

See Below

*Bit clock frequencies listed will be increased by 200 Hz if C1P200 is set to "1."

When C1M7:4 is programmed to "1111" and C1M3:0 is programmed to "1111," the Bit clock rate will be 128 times
the Conversion rate.

When in Video Lock Mode (C1REF and C1VID are both set to "1"):
Bits C1M7:0 select the Conversion clock rate. The most significant bit (C1M7) must be set to indicate
the type of video lock, either NTSC or PAL. For an NTSC lock, C1M7 must be reset to "0," and the SYNC1 pin
must receive the NTSC sync frequency (525 lines/frame

30 Hz

1000/1001 frame rate

15.734 kHz). For a PAL

lock, C1M7 must be set to "1," and the SYNC1 pin must receive the PAL sync frequency (625 lines/frame

25 Hz

frame rate

15.625 kHz). The next three most significant bits (C1M6:4) select a desired base Conversion clock rate,

and the least significant four bits (C1M3:0) select a divisor. The Conversion clock created by Clock Generator 1 will
be the base divided by the divisor. The following tables list the possible choices for base and divisor.

AD1843

REV. 0

NTSC

(C1M7 = "0"):

Base Frequency In Hz (C1M6:4)
48,000

32,000

44,100

2/3

48,000*

44,056

Divisor

(C1M3:0)

(000)

(001)

(010)

(011)

(100)

(101)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

*When C1M6:4 = "100," base frequency is 48,000 Hz only if NTSC sync rate is increased by 1001/1000, or is exactly 15.750 kHz.

PAL

(C1M7 = "1"):

Base Frequency In Hz (C1M6:4)
48,000

32,000

44,100

2/3

Divisor

(C1M3:0)

(000)

(001)

(010)

(011)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

Initial default state after reset: 0000 0000 1111 1111 (00FF hex). Cleared to default and cannot be written to
when: the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

Address 17

Clock Generator 1 Control--Sample Rate

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C1C15

C1C14

C1C13

C1C12

C1C11

C1C10

C1C9

C1C8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C1C7

C1C6

C1C5

C1C4

C1C3

C1C2

C1C1

C1C0

C1C15:0

Clock Generator 1 Conversion (Sample) Rate Select. Defines the conversion rate produced by Clock Generator 1
when not referenced to the SYNC1 pin (Control Register Address 16 Bit 15 [C1REF]). One LSB represents exactly
one Hertz, assuming a 24.576 MHz clock input on the XTALI pin. Usable range is 4 kHz (0x0FA0) to 54 kHz
(0xD2F0).

Initial default state after reset: 1011 1011 1000 0000 (BB80 hex), which is 48 kHz, assuming a 24.576 MHz clock in-
put on the XTALI pin. Cleared to default and cannot be written to when: the RESET pin is asserted LO; or when
the PWRDWN pin is asserted LO.

Address 18

Clock Generator 1 Control--Sample Phase Shift

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

C1PD

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C1P7

C1P6

C1P5

C1P4

C1P3

C1P2

C1P1

C1P0

C1PD

Clock Generator 1 Phase Shift Direction. This bit controls the direction of sample clock phase shift.
0 = Phase Advance
1 = Phase Retard

C1P7:0

Clock Generator 1 Phase Shift Magnitude. These bits control the magnitude of sample clock phase shift. One LSB
represents exactly 0.12 degrees. LSBs are processed and decremented at a rate of 3.072 MHz (assuming a 24.576
MHz clock input on the XTALI pin). When this register is read, it indicates any phase advance/retard remaining to
be processed as of the beginning of slot 0 if bus master, or when TSI was received if bus slave. This register may be

REV. 0

AD1843

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the G1EN bit in Control Register
Address 28 is reset to "0" (clock generator 1 disabled).

Address 19

Clock Generator 2 Control--Mode

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C2REF

C2VID

C2PLLG

C2P200

C2X8/7

C2C128

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C2M7

C2M6

C2M5

C2M4

C2M3

C2M2

C2M1

C2M0

C2REF

Clock Generator 2 Reference Select. Selects the fundamental clock reference used by Clock Generator 2 to
synthesize its "Conversion" (sample) and "Bit" clock rates.

0 = Clocks are referenced to the input on pin XTALI (crystal or master clock input).

Sample clock frequency is defined by Control Register Address 20 and Bit C2X8/7.

Sample clock phase may be shifted by Control Register Address 21.

Bit clock frequency is defined by bits C2M7:0 and C2P200.

Bit C2VID is ignored.

1 = Clocks are referenced to the input on pin SYNC2 (Sync 2 Clock Input).

Sample clock frequency is defined by C2VID and C2M7:0.

Sample clock phase is locked to SYNC2 and cannot be shifted.

Bit clock frequency is defined by bits C2M7:0 and C2P200 unless in Video Lock Mode (C2VID set to "1")
where the Bit clocks are not produced.

Control Register Addresses 17, 18 and the C2X8/7 bit are ignored.

C2VID

Clock Generator 2 Video Lock Mode. This bit is used to select between lock modes when the Clock Generator 2 is
referenced to SYNC2 (C2REF set to "1"). This bit should be reset to "0" if C2REF is reset to "0." When reset to
"0," Clock Generator 2 is in normal lock mode where the Conversion clock will be frequency and phase locked to
SYNC2, and the Bit clock frequency is chosen using bits C2M7:0 and C2P200. When set to "1," Clock Generator 2
is in video lock mode, where the Conversion clock frequency is selected using bits C2M7:0, and a Bit clock is not produced.

C2PLLG

Clock Generator 2 PLL Loop Gain Select. If reset to "0," this bit selects finite PLL loop gain, and if set to "1," this
bit selects infinite PLL loop gain. This bit should nominally be reset to "0." Setting it to "1" may enhance the PLL's
ability to lock to certain SYNC2 inputs, but it may also increase conversion noise.

C2P200

Clock Generator 2 Bit Clock +200 Frequency Modifier. When set to "1," the Bit clock driven out of pin BIT2 will
have a frequency that is 200 Hertz greater than the frequency selected through bit C2M7:0. This bit is ignored when
in Video Lock Mode (C2VID set to "1"). C2P200 only modifies the bit clock driven on the BIT2 pin.

C2X8/7

Clock Generator 2 Conversion Clock 8/7 Frequency Modifier. When set to "1," the Conversion clock frequency gen-
erated will be 8/7 times the value programmed in Control Register Address 20. This bit is ignored when clocks are
referenced to SYNC2 (C2REF set to "1").

C2C128

Clock Generator 2 Conversion Clock Pin (CONV2) Frequency Select. When set to "1," the frequency driven on to
the CONV2 pin will be 128 times the conversion rate. When reset to "0," the frequency driven on to the CONV2 pin
will be the same as the conversion rate. C2C128 only modifies the clock frequency driven on the CONV2 pin.

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

C2M7:0

Clock Generator 2 Clock Rate Modifiers.

When not in Video Lock Mode (C2REF and C2VID are not both set to "1"):
Bits C2M7:0 select the Bit clock rate which will be driven out on pin BIT2. Using the following table, the least sig-
nificant four bits (C2M3:0) are programmed to the desired Bit clock rate, and the most significant four bits

overwritten even if all previously programmed phase advance/retard has not been processed. When written, the con-
tents of this register (just prior to the write) are transmitted during slot 1 of the following frame (as with all Control
Register writes).

AD1843

REV. 0

(C2M7:4) must be programmed to the Conversion clock rate established using Control Register Address 20 and the
C2X8/7 bit. If the actual Conversion clock differs from the value selected by C2M7:4, then the resultant Bit clock will
be different from the rate selected by the ratio of the C2M7:4 selected rate to the Control Register Address 20 plus
the C2X8/7 bit actual rate.

C2M3:0

Bit Clock Frequency*

C2M7:4

Conversion (Sample) Rate

0000

2,400

Hertz

0000

7,200

Hertz

0001

4,800

0001

8,400

0010

7,200

0010

9,000

0011

9,600

0011

9,600

0100

12,000

0100

11,200

0101

14,400

0101

12,000

0110

16,800

0110

12,800

0111

19,200

0111

7,200

8/7

1000

21,600

1000

9,000

8/7

1001

24,000

1001

9,600

8/7

1010

26,400

1010

12,000

8/7

1011

28,800

1011

Reserved

1100

Reserved

1100

Reserved

1101

Reserved

1101

Reserved

1110

Reserved

1110

Reserved

1111

See Below

1111

See Below

*Bit clock frequencies listed will be increased by 200 Hz if C2P200 is set to "1."

When C2M7:4 is programmed to "1111" and C2M3:0 is programmed to "1111," the Bit clock rate will be 128 times
the Conversion rate.

When in Video Lock Mode (C2REF and C2VID are both set to "1"):
Bits C2M7:0 select the Conversion clock rate. The most significant bit (C2M7) must be set to indicate the type of
video lock, either NTSC or PAL. For an NTSC lock, C2M7 must be reset to "0," and the SYNC2 pin must receive
the NTSC sync frequency (525 lines/frame

30 Hz

1000/1001 frame rate

15.734 kHz). For a PAL lock, C2M7

must be set to "1," and the SYNC2 pin must receive the PAL sync frequency (625 lines/frame

25 Hz frame rate

15.625 kHz). The next three most significant bits (C2M6:4) select a desired base Conversion clock rate, and the least
significant four bits (C2M3:0) select a divisor. The Conversion clock created by Clock Generator 2 will be the base
divided by the divisor. The following tables list the possible choices for base and divisor.

NTSC

(C2M7 = "0"):

Base Frequency In Hz (C2M6:4)
48,000

32,000

44,100

2/3

48,000*

44,056

Divisor

(C2M3:0)

(000)

(001)

(010)

(011)

(100)

(101)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

*When C2M6:4 = "100," base frequency is 48,000 Hz only if NTSC sync rate is increased by 1001/1000, or is exactly 15.750 kHz.

PAL

(C2M7 = "1"):

Base Frequency In Hz (C2M6:4)
48,000

32,000

44,100

2/3

Divisor

(C2M3:0)

(000)

(001)

(010)

(011)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

Initial default state after reset: 0000 0000 1111 1111 (00FF hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

REV. 0

AD1843

Address 20

Clock Generator 2 Control--Sample Rate

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C2C15

C2C14

C2C13

C2C12

C2C11

C2C10

C2C9

C2C8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C2C7

C2C6

C2C5

C2C4

C2C3

C2C2

C2C1

C2C0

C2C15:0

Clock Generator 2 Conversion (Sample) Rate Select. Defines the conversion rate produced by Clock Generator 2 when
not referenced to the SYNC2 pin (Control Register Address 19 Bit 15 [C2REF]). One LSB represents exactly one Hertz,
assuming a 24.576 MHz clock input on the XTALI pin. Usable range is 4 kHz (0x0FA0) to 54 kHz (0xD2F0).

Address 21

Clock Generator 2 Control--Sample Phase Shift

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

C2PD

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C2P7

C2P6

C2P5

C2P4

C2P3

C2P2

C2P1

C2P0

C2PD

Clock Generator 2 Phase Shift Direction. This bit controls the direction of sample clock phase shift.
0 = Phase Advance
1 = Phase Retard

C2P7:0

Clock Generator 2 Phase Shift Magnitude. These bits control the magnitude of sample clock phase shift. One LSB repre-
sents exactly 0.12 degrees. LSBs are processed and decremented at a rate of 3.072 MHz (assuming a 24.576 MHz clock
input on the XTALI pin). When this register is read, it indicates any phase advance/retard remaining to be processed as of
the beginning of slot 0 if bus master, or when TSI was received if bus slave. This register may be overwritten even if all pre-
viously programmed phase advance/retard has not been processed. When written, the contents of this register (just prior to
the write) are transmitted during slot 1 of the following frame (as with all Control Register writes).

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the G2EN bit in Control Register
Address 28 is reset to "0" (clock generator 2 disabled).

Address 22

Clock Generator 3 Control--Mode

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C3REF

C3VID

C3PLLG

C3P200

C3X8/7

C3C128

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C3M7

C3M6

C3M5

C3M4

C3M3

C3M2

C3M1

C3M0

C3REF

Clock Generator 3 Reference Select. Selects the fundamental clock reference used by Clock Generator 3 to synthe-
size its "Conversion" (sample) and "Bit" clock rates.

0 = Clocks are referenced to the input on pin XTALI (crystal or master clock input).

Sample clock frequency is defined by Control Register Address 23 and Bit C3X8/7.

Sample clock phase may be shifted by Control Register Address 24.

Bit clock frequency is defined by bits C3M7:0 and C3P200.

Bit C3VID is ignored.

AD1843

REV. 0

1 = Clocks are referenced to the input on pin SYNC3 (Sync 3 Clock Input).

Sample clock frequency is defined by C3VID and C3M7:0.

Sample clock phase is locked to SYNC3 and cannot be shifted.

Bit clock frequency is defined by bits C3M7:0 and C3P200 unless in Video Lock Mode
(C3VID set to "1") where the Bit clocks are not produced.

Control Register Addresses 23, 24 and the C3X8/7 bits are ignored.

C3VID

Clock Generator 3 Video Lock Mode. This bit is used to select between lock modes when the Clock Generator 3 is
referenced to SYNC3 (C3REF set to "1"). This bit should be reset to "0" if C3REF is reset to "0." When reset to
"0," Clock Generator 3 is in normal lock mode where the Conversion clock will be frequency and phase locked to
SYNC3, and the Bit clock frequency is chosen using bits C3M7:0 and C3P200. When set to "1," Clock Generator 3
is in video lock mode, where the Conversion clock frequency is selected using bits C3M7:0, and a Bit clock is not produced.

C3PLLG

Clock Generator 3 PLL Loop Gain Select. If reset to "0," this bit selects finite PLL loop gain, and if set to "1," this
bit selects infinite PLL loop gain. This bit should nominally be reset to "0." Setting it to "1" may enhance the PLL's
ability to lock to certain SYNC3 inputs, but it may also increase conversion noise.

C3P200

Clock Generator 3 Bit Clock +200 Frequency Modifier. When set to "1," the Bit clock driven out of pin BIT3 will
have a frequency that is 200 Hertz greater than the frequency selected through bit C3M7:0. This bit is ignored when
in Video Lock Mode (C3VID set to "1"). C3P200 only modifies the bit clock driven on the BIT3 pin.

C3X8/7

Clock Generator 3 Conversion Clock 8/7 Frequency Modifier. When set to "1," the Conversion clock frequency gen-
erated will be 8/7 times the value programmed in Control Register Address 23. This bit is ignored when clocks are
referenced to SYNC3 (C3REF set to "1").

C3C128

Clock Generator 3 Conversion Clock Pin (CONV3) Frequency Select. When set to "1," the frequency driven on to
the CONV3 pin will be 128 times the conversion rate. When reset to "0," the frequency driven on to the CONV3 pin
will be the same as the conversion rate. C3C128 only modifies the clock frequency driven on the CONV3 pin.

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

C3M7:0

Clock Generator 3 Clock Rate Modifiers.

When not in Video Lock Mode (C3REF and C3VID are not both set to "1"):
Bits C3M7:0 select the Bit clock rate which will be driven out on pin BIT3. Using the following table, the least sig-
nificant four bits (C3M3:0) are programmed to the desired Bit clock rate, and the most significant four bits
(C3M7:4) must be programmed to the Conversion clock rate established using Control Register Address 23 and the
C3X8/7 bit. If the actual Conversion clock differs from the value selected by C3M7:4, then the resultant Bit clock
will be different from the rate selected by the ratio of the C3M7:4 selected rate to the Control Register Address 23
plus the C3X8/7 bit actual rate.

C3M3:0

Bit Clock Frequency*

C3M7:4

Conversion (Sample) Rate

0000

2,400

Hertz

0000

7,200

Hertz

0001

4,800

0001

8,400

0010

7,200

0010

9,000

0011

9,600

0011

9,600

0100

12,000

0100

11,200

0101

14,400

0101

12,000

0110

16,800

0110

12,800

0111

19,200

0111

7,200

8/7

1000

21,600

1000

9,000

8/7

1001

24,000

1001

9,600

8/7

1010

26,400

1010

12,000

8/7

1011

28,800

1011

Reserved

1100

Reserved

1100

Reserved

1101

Reserved

1101

Reserved

1110

Reserved

1110

Reserved

1111

See Below

1111

See Below

*Bit clock frequencies listed will be increased by 200 Hz if C3P200 is set to "1."

When C3M7:4 is programmed to "1111" and C3M3:0 is programmed to "1111," the Bit clock rate will be 128 times
the Conversion rate.

REV. 0

AD1843

When in Video Lock Mode (C3REF and C3VID are both set to "1"):
Bits C3M7:0 select the Conversion clock rate. The most significant bit (C3M7) must be set to indicate the type of
video lock, either NTSC or PAL. For an NTSC lock, C3M7 must be reset to "0," and the SYNC3 pin must
receive the NTSC sync frequency (525 lines/frame

30 Hz

1000/1001 frame rate

15.734 kHz). For a PAL lock,

C3M7 must be set to "1," and the SYNC3 pin must receive the PAL sync frequency (625 lines/frame

25 Hz frame

rate

15.625 kHz). The next three most significant bits (C3M6:4) select a desired base Conversion clock rate, and

the least significant four bits (C3M3:0) select a divisor. The Conversion clock created by Clock Generator 3 will be
the base divided by the divisor. The following tables list the possible choices for base and divisor.

NTSC

(C3M7 = "0"):

Base Frequency In Hz (C3M6:4)
48,000

32,000

44,100

2/3

48,000*

44,056

Divisor

(C3M3:0)

(000)

(001)

(010)

(011)

(100)

(101)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

*When C3M6:4 = "100," base frequency is 48,000 Hz only if NTSC sync rate is increased by 1001/1000, or is exactly 15.570 kHz.

PAL

(C3M7 = "1"):

Base Frequency In Hz (C3M6:4)
48,000

32,000

44,100

2/3

Divisor

(C3M3:0)

(000)

(001)

(010)

(011)

(0000)

Yes

(0001)

Yes

(0010)

Yes

(0011)

Yes

(0100)

Yes

(0101)

Yes

(0110)

Yes

(0111)

Yes

Initial default state after reset: 0000 0000 1111 1111 (00FF hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

Address 23

Clock Generator 3 Control--Sample Rate

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

C3C15

C3C14

C3C13

C3C12

C3C11

C3C10

C3C9

C3C8

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C3C7

C3C6

C3C5

C3C4

C3C3

C3C2

C3C1

C3C0

C3C15:0

Clock Generator 3 Conversion (Sample) Rate Select. Defines the conversion rate produced by Clock Generator 3
when not referenced to the SYNC3 pin (Control Register Address 22 Bit 15 [C3REF]). One LSB represents exactly
one Hertz, assuming a 24.576 MHz clock input on the XTALI pin. Usable range is 4 kHz (0x0FA0) to 54 kHz
(0xD2F0).

AD1843

REV. 0

Address 24

Clock Generator 3 Control--Sample Phase Shift

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

C3PD

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

C3P7

C3P6

C3P5

C3P4

C3P3

C3P2

C3P1

C3P0

C3PD

Clock Generator 3 Phase Shift Direction. This bit controls the direction of sample clock phase shift.
0 = Phase Advance
1 = Phase Retard

C3P7:0

Clock Generator 3 Phase Shift Magnitude. These bits control the magnitude of sample clock phase shift. One LSB
represents exactly 0.12 degrees. LSBs are processed and decremented at a rate of 3.072 MHz (assuming a 24.576
MHz clock input on the XTALI pin). When this register is read, it indicates any phase advance/retard remaining to
be processed as of the beginning of slot 0 if bus master, or when TSI was received if bus slave. This register may be
overwritten even if all previously programmed phase advance/retard has not been processed. When written, the con-
tents of this register (just prior to the write) are transmitted during slot 1 of the following frame (as with all Control
Register writes).

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the G3EN bit in Control Register
Address 28 is reset to "0" (clock generator 3 disabled).

Address 25

Codec Configuration--Digital Filter and Mode Select

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DRSFLT

DAMIX

res

DA2FLT

DA1FLT

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

DAADR1

DAADR0

DAADL1

DAADL0

res

ADRFLT

ADLFLT

Restrictions: Modem filter should not be selected when channel sample rate is above 24 kHz.

DRSFLT

Digital Resampler Filter Mode. DAC2 is sacrificed so that the remaining four channels (left ADC, right ADC, left
and right DAC1) have sufficient resources to realize the more stringent resampling filter requirements. See below for
filter specifications. (Note: Digital resampling can be done without using the resampling filters but performance is not
as optimal.) This bit can be altered only if all channels (DAC1, DAC2, ADL, and ADR) are powered down. Note
that this bit enables the digital resampler filters, but does not enable the digital resampler data pathways. Use the
DAADR1:0 and DAADL1:0 bits to enable the resampler data pathways.
0 = Audio/Modem Filter Modes (Defined by DA1FLT, DA2FLT, ADLFLT and ADRFLT)
1 = Digital Resampler Filter Mode (DA1FLT, DA2FLT, ADLFLT and ADRFLT filter selections are ignored).

DAMIX

DAC Digital Mix Enable. When set to "1," DAC1 and DAC2 are mixed at the output of the digital interpolation fil-
ter. Left and right channels are still separated, but DAC1 and DAC2 outputs are identical. This bit can be altered
only if both DAC1 and DAC2 are powered down.
0 = Digital Mix Disabled
1 = Digital Mix Enabled

DA2FLT

DAC2 (Left and Right Channels) Digital Filter Select and Analog Output Swing Select. Digital filter selected is over-
ridden when DRSFLT is set to "1." See below for filter specifications. This bit can be altered only if DAC2
is powered down.
0 = Digital Audio Filter. Nominal analog swing is 2.000 V p-p when output level is +0.0 dB (see Control Register
Address 10).
1 = Digital Modem Filter. Nominal analog swing is 3.156 V p-p when output level is +4.5 dB (see Control Register
Address 10).

REV. 0

AD1843

DA1FLT

DAC1 (Left and Right Channels) Digital Filter Select. This bit is overridden when DRSFLT is set to "1." See be-
low for filter specifications. This bit can be altered only if DAC1 is powered down. Unlike DA2FLT, this bit does
not control the analog output swing of DAC1, which is fixed at 2.000 V p-p when the output level is set to 0 dB by
Control Register Address 9.
0 = Digital Audio Filter
1 = Digital Modem Filter

DAADR1:0

Digital ADC Right Channel Source Select.
00 = Input from Analog: ADC Right Channel (Normal Operation)
01 = Reserved
10 = Input from Digital: DAC1 Right Channel (Digital Resampler)
11 = Input from Digital: DAC2 Right Channel (Digital Resampler)

DAADL1:0

Digital ADC Left Channel Source Select.
00 = Input from Analog: ADC Left Channel (Normal Operation)
01 = Reserved
10 = Input from Digital: DAC1 Left Channel (Digital Resampler)
11 = Input from Digital: DAC2 Left Channel (Digital Resampler)

ADRFLT

ADC Right Channel Digital Filter Select and Analog Input Full Scale Mapping Select. Digital filter selected is over-
ridden when DRSFLT is set to "1." See below for filter specifications. This bit can be altered only if the ADC right
channel is powered down.
0 = Digital Audio Filter. 2.800 V p-p analog input maps to

when gain is set to 0.0 dB (see Control Register

Address 2).

1 = Digital Modem Filter. 3.156 V p-p analog input maps to

when gain is set to 0.0 dB (see Control Register

Address 2).

ADLFLT

ADC Left Channel Digital Filter Select and Analog Input Full Scale Mapping Select. Digital filter selected is over-
ridden when DRSFLT is set to "1." See below for filter specifications. This bit can be altered only if the ADC left
channel is powered down.
0 = Digital Audio Filter. 2.800 V p-p analog input maps to

when gain is set to 0.0 dB (see Control Register

Address 2).

1 = Digital Modem Filter. 3.156 V p-p analog input maps to

when gain is set to 0.0 dB (see Control Register

Address 2).

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

The table below lists the single path (DAC or ADC only) filter characteristics of the "Audio," "Modem," and "Resampler" digital
filters. Passband ripple and group delay must be doubled if the DAC is routed back through the ADC for digital resampling. For
further information, see the "Filter Selection" section and the filter frequency response plots, Figures 34 through 36.

Passband

Stopband

Linear

Filter

Ripple

Edge

Ripple

Edge

Group Delay

Audio

0.016 dB

0.400

< 91.8 dB

0.600

< 15/F

Modem

0.220 dB

0.442

< 75.7 dB

0.542

< 19/F

Resampler

0.035 dB

0.400

< 92.2 dB

0.500

< 25/F

is the conversion (sample) rate.

Address 26

Codec Configuration--Serial Interface

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DA2SM

DA1SM

res

DA2F1

DA2F0

DA1F1

DA1F0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

SCF

FRS

FRST

ADTLK

ADRF1

ADRF0

ADLF1

ADLF0

AD1843

REV. 0

DA2SM

DAC2 Stereo/Mono Mode Select. When in stereo mode, data transmitted to the AD1843 during slot 4 is
used by DAC2 left and data transmitted to the AD1843 during slot 5 is used by DAC2 right. When in
mono mode, data transmitted to the AD1843 during slot 4 is used by both DAC2 left and right, and data
transmitted to the AD1843 during slot 5 is ignored. (Note: slot 0 is assumed to be the first slot.)
0 = Stereo Mode
1 = Mono Mode

DA1SM

DAC1 Stereo/Mono Mode Select. When in stereo mode, data transmitted to the AD1843 during slot 2 is
used by DAC1 left and data transmitted to the AD1843 during slot 3 is used by DAC1 right. When in
mono mode, data transmitted to the AD1843 during slot 2 is used by both DAC1 left and right, and data
transmitted to the AD1843 during slot 3 is ignored. (Note: slot 0 is assumed to be the first slot.)
0 = Stereo Mode
1 = Mono Mode

DA2F1:0

DAC2 (Left and Right Channels) Data Format Select.
00 = 8-bit Unsigned Linear PCM
01 = 16-bit Signed Linear PCM
10 = 8-bit

-Law Companded

11 = 8-bit A-Law Companded

DA1F1:0

DAC1 (Left and Right Channels) Data Format Select.
00 = 8-bit Unsigned Linear PCM
01 = 16-bit Signed Linear PCM
10 = 8-bit

-Law Companded

11 = 8-bit A-Law Companded

SCF

SCLK Frequency Select. Changes to this bit do not take effect until shortly after the sixth slot (the final slot
owned) is completed. Relevant when the AD1843 is in Master Mode only.
0 = 12.288 MHz
1 = 16.384 MHz

FRS

Frame Size Select. Selects the number of slots per frame. Changes to this bit do not take effect until the
time specified by the FRST bit.
0 = 32 Slots per Frame
1 = 16 Slots per Frame

FRST

Frame Size Change Timing. Selects the point in time when FRS takes effect.
0 = Frame Size Changes Once the Current Frame is Complete
1 = Frame Size Changes Immediately, Beginning with the Current Frame

ADTLK

ADC Transmit Lock Mode Select. When this bit is set to "1," ADC transmit lock mode is entered. In this
mode, left and right ADC samples are transmitted during a frame only if both left and right samples are
ready to be transmitted. When not in ADC transmit lock mode, left and right samples are transmitted as
they individually become available. Note that even if left and right ADCs are programmed to the same
sample rate, unless the AD1843 is in transmit lock mode, ADC samples will not necessarily be transmitted
paired together in a TDM frame. This bit should be set to "1" only if both ADCs are powered down and
only if both ADCs will be programmed to the sample rate once they are enabled. This bit may be reset to
"0" at any time. While in ADC transmit lock mode, both ADCs must be enabled and disabled simulta-
neously (write to Control Register Address 27 must set ADLEN and ADREN both to "0" or to "1").
0 = ADC Transmit Lock Mode Disabled
1 = ADC Transmit Lock Mode Enabled

ADRF1:0

ADC Right Channel Data Format Select.
00 = 8-bit Unsigned Linear PCM
01 = 16-bit Signed Linear PCM
10 = 8-bit

-Law Companded

11 = 8-bit A-Law Companded

ADLF1:0

ADC Left Channel Data Format Select.
00 = 8-bit Unsigned Linear PCM
01 = 16-bit Signed Linear PCM
10 = 8-bit

-Law Companded

11 = 8-bit A-Law Companded

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written
to when: the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

REV. 0

AD1843

Address 27

Codec Configuration--Channel Power Down

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

DFREE

res

DDMEN

res

DA2EN

DA1EN

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

ANAEN

HPEN

res

AAMEN

res

ADREN

ADLEN

DFREE

Digital Resource Free. When set to "1," this bit reduces the level of power down normally achieved by asserting the
power down bits in this Control Register. However, it allows the digital resources of channels powered down to be
partially transferred to the remaining enabled channels and thus permits conversion rates higher than the 48 kHz
nominal maximum. See the "Supported Conversion Rates" section.
0 = Power Down of Digital Resources is Complete
1 = Power Down of Digital Resources is Incomplete, Freeing Transferable Resources to Enabled Channels

DDMEN

DAC2 to DAC1 Mix Enable/Power Down. When reset to "0," Control Register Address 3 is cleared to its default
and cannot be written.
0 = Mix is Powered Down
1 = Mix is Enabled

DA2EN

DAC2 (Left and Right Channels) Enable/Power Down. When this bit is reset to "0," DAC2 is powered down and
serial interface requests for samples (see slot 0) will cease immediately. When this bit is set to "1," DAC2 is enabled
and requests for samples resume on the next frame. Conversions will not actually begin until the first rising edge of
the conversion clock (CONV pin) after the sixth rising edge of frame sync (SDFS pin) after this bit is set to "1." This
delay allows the four word stereo input buffer for DAC2 to be filled before conversions begin and allows the serial in-
terface to synchronize with the conversion clock, which is potentially already running. This delay also allows DACs
on multiple AD1843s sharing the same frame sync to begin conversions synchronously, providing they are enabled at
any time during the same frame. When this bit is reset to "0," Control Register Address 10, which is the Output
Level Control Register for DAC2, is cleared to default and cannot be written.
0 = DAC2 is Powered Down, Control Register Address 10 (DAC2 Output Level Control) is Cleared
1 = DAC2 is Enabled

DA1EN

DAC1 (Left and Right Channels) Enable/Power Down. When this bit is reset to "0," DAC1 is powered down and
serial interface requests for samples (see slot 0) will cease immediately. When this bit is set to "1," DAC1 is enabled
and requests for samples resume on the next frame. Conversions will not actually begin until the first rising edge of
the conversion clock (CONV pin) after the sixth rising edge of frame sync (SDFS pin) after this bit is set to "1." This
delay allows the four word stereo input buffer for DAC1 to be filled before conversions begin and allows the serial in-
terface to synchronize with the conversion clock, which is potentially already running. This delay also allows DACs
on multiple AD1843s sharing the same frame sync to begin conversions synchronously, providing they are enabled at
any time during the same frame. When this bit is reset to "0," Control Register Address 9, which is the Output Level
Control Register for DAC1, is cleared to default and cannot be written.
0 = DAC1 is Powered Down, Control Register Address 9 (DAC1 Output Level Control) is Cleared
1 = DAC1 is Enabled

ANAEN

Analog Channel Enable/Power Down. If this bit is reset to "0," all analog conversion circuitry (related to bits
DA1EN, DA2EN, ADLEN, ADREN, DDMEN and AAMEN) will be powered down. When reset to "0," the only
conversion channels usable (but must be enabled separately) are the digital resampling paths. Since resetting this bit
to "0" powers down the analog ADC, DAC1, DAC2 and analog mixers, their related output level Control Register
Addresses 4 through 7, half of 8, 9 and 10 are cleared and cannot be written while ANAEN remains "0."
0 = Analog Channels are Powered Down, Control Register Addresses 4 through 7, half of 8, 9 and 10 are Cleared to

Default (Digital to Digital Still Possible)

1 = Analog DAC and ADC Paths are Controlled by DA1EN, DA2EN, ADLEN, ADREN, DDMEN and AAMEN

HPEN

Headphone Enable/Power Down.
0 = Headphone Output is Powered Down
1 = Headphone Output is Enabled

AAMEN

Analog Input to Analog Output Mix Enable/Power Down. When reset to "0," Control Register Addresses 4 - 7 and
half of Control Register Address 8 are cleared and cannot be written.
0 = Mix is Powered Down
1 = Mix is Enabled

AD1843

REV. 0

ADREN

ADC Right Channel Enable/Power Down. When this bit is reset to "0," the right ADC channel is powered down and
serial interface sample output will cease after the current frame. When this bit is set to "1," the right ADC channel is
enabled and sampling of analog input will begin on the first rising edge of the conversion clock (CONV pin) after the
sixth rising edge of frame sync (SDFS pin). This delay allows the ADC startup to be similar to the DAC startup, and
allows some time for stale ADC data inside the AD1843 to be cleared. It also allows the serial interface to synchronize
with the conversion clock, which is potentially already running. Multiple ADCs on multiple AD1843s which share the
same frame sync will be synchronously started if they are enabled at any time during the same frame.
0 = ADC Right Channel is Powered Down
1 = ADC Right Channel is Enabled

ADLEN

ADC Left Channel Enable/Power Down. When this bit is reset to "0," the left ADC channel is powered down and
serial interface sample output will cease after the current frame. When this bit is set to "1," the left ADC channel is
enabled and sampling of analog input will begin on the first rising edge of the conversion clock (CONV pin) after the
sixth rising edge of frame sync (SDFS pin). This delay allows the ADC startup to be similar to the DAC startup, and
allows some time for stale ADC data inside the AD1843 to be cleared. It also allows the serial interface to synchronize
with the conversion clock, which is potentially already running. Multiple ADCs on multiple AD1843s which share the
same frame sync will be synchronously started if they are enabled at any time during the same frame.
0 = ADC Left Channel is Powered Down
1 = ADC Left Channel is Enabled

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 1100 0000 (00C0 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; when the PWRDWN pin is asserted LO; or when the PDNO bit in Control Register
Address 0 is set to "1" (all conversions disabled).

Address 28

Codec Configuration--Fundamental Settings

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

PDNI

ACEN

C3EN

C2EN

C1EN

ENCLKO

XCTL1

XCTL0

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

ENCV3

ENBT3

ENCV2

ENBT2

ENCV1

ENBT1

LINRSD

LINLSD

PDNI

Converter Power Down. When set to "1," this bit initiates the process of powering down all conversion channels,
overriding the settings in Control Register Address 27. Unlike the individual power down bits in Control Register
Address 27, asserting this bit allows the DAC and V

REF

output pins to slowly decay to ground. Setting this bit to "1"

results in lower power consumption than results from powering down all channels individually through Control Regis-
ter Address 27, and also reduces speaker "click" if asserted before the power supply is removed. Power down is not
complete until approximately 5 ms after this bit is set to "1." During this time, the AD1843 still requires a clock in-
put from XTALI for proper operation. When reset to "0," this bit initiates the process of preparing the AD1843 for
conversions after power down. Approximately 470 ms are necessary to exit power down. The power up/down status
of the AD1843 may be monitored through the PDNO bit in Control Register Address 0. Asserting the power down
pin (PWRDWN) will result in an even greater degree of power down as it also powers down the serial interface and
crystal oscillator. Once a power up or power down sequence has been initiated, its completion cannot be interrupted.
Changes made to the state of PDNI (i.e., writes to PDNI) are ignored until a previously pending PDNI state change
has been completely processed.
0 = Normal (Non-Power Down) Operation
1 = Initiate Power Down of All Conversion Channels

ACEN

Autocalibration Enable. When set to "1," autocalibration will occur each time power down is exited (PDNI is
changed from a "1" to a "0"). Autocalibration increases the time required to exit power down by 4 ms (from
470 ms to 474 ms). When reset to "0," autocalibration is disabled. This bit is set to "1" initially after reset and can-
not be overwritten until after the AD1843 has come out of power down (PDNO bit in Control Register Address 0
reset to "0") at least once. Note that an autocalibration cycle is always performed following a hardware reset (i.e.,
RESET

pin asserted) or a hardware power down (i.e., PWRDWN pin asserted), regardless of the state of ACEN.

0 = Autocalibration Disabled
1 = Autocalibration Enabled, Initiated upon Exiting Power Down

C3EN

Clock Generator 3 Enable/Power Down.
0 = Clock Generator 3 Powered Down
1 = Clock Generator 3 Enabled

REV. 0

AD1843

C2EN

Clock Generator 2 Enable/Power Down.
0 = Clock Generator 2 Powered Down
1 = Clock Generator 2 Enabled

C1EN

Clock Generator 1 Enable/Power Down.
0 = Clock Generator 1 Powered Down
1 = Clock Generator 1 Enabled

ENCLKO

CLKOUT Pin Enable.
0 = Clock Output is Three-stated (Powered Down)
1 = Clock Output is Enabled

XCTL1:0

External Control. The state of these independent bits is reflected on the respective XCTL1 and XCTL0 output pins.
0 = TTL Logic Level LO on XCTL1/XCTL0 pin
1 = TTL Logic Level HI on XCTL1/XCTL0 pin

ENCV3

CONV3 Pin Enable.
0 = CONV3 is Three-stated (Powered Down)
1 = CONV3 is Enabled

ENBT3

BIT3 Pin Enable.
0 = BIT3 is Three-stated (Powered Down)
1 = BIT3 is Enabled

ENCV2

CONV2 Pin Enable.
0 = CONV2 is Three-stated (Powered Down)
1 = CONV2 is Enabled

ENBT2

BIT2 Pin Enable.
0 = BIT2 is Three-stated (Powered Down)
1 = BIT2 is Enabled

ENCV1

CONV1 Pin Enable.
0 = CONV1 is Three-stated (Powered Down)
1 = CONV1 is Enabled

ENBT1

BIT1 Pin Enable.
0 = BIT1 is Three-stated (Powered Down)
1 = BIT1 is Enabled

LINRSD

Line Input Right Channel Single-Ended or Differential Configuration.
0 = Right Channel Line Input is Single-Ended
1 = Right Channel Line Input is Differential

LINLSD

Line Input Left Channel Single-Ended or Differential Configuration.
0 = Left Channel Line Input is Single-Ended
1 = Left Channel Line Input is Differential

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 1100 0100 0000 0000 (C400 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

Address 29

Reserved for Future Expansion

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

AD1843

REV. 0

Address 30

Reserved for Future Expansion

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

Address 31

Reserved for Future Expansion

Data 15

Data 14

Data 13

Data 12

Data 11

Data 10

Data 9

Data 8

res

Data 7

Data 6

Data 5

Data 4

Data 3

Data 2

Data 1

Data 0

res

Reserved for future expansion. To ensure future compatibility, write "0" to all reserved bits.

Initial default state after reset: 0000 0000 0000 0000 (0000 hex). Cleared to default and cannot be written to when:
the RESET pin is asserted LO; or when the PWRDWN pin is asserted LO.

BIT AND REGISTER MAPS

A map of all TDM time slot bit assignments and Control Register contents is summarized for reference as follows in Figure 14
and Figure 15:

INPUT SLOT

0 OR 16

1 OR 17

2 OR 18

3 OR 19

4 OR 20

5 OR 21

DATA 15

RES

DATA 15

DATA 14

RES

DATA 14

DATA 13

RES

DATA 13

DATA 12

RES

DATA 12

DATA 11

RES

DATA 11

DATA 10

RES

DATA 10

DATA 9

DA2V

DATA 9

DATA 8

DA1V

DATA 8

DATA 7

R/W

DATA 7

DATA 6

RES

DATA 6

DATA 5

RES

DATA 5

DATA 4

IA4

DATA 4

DATA 3

IA3

DATA 3

DATA 2

IA2

DATA 2

DATA 1

IA1

DATA 1

DATA 0

IA0

DATA 0

OUTPUT SLOT

0 OR 16

1 OR 17

2 OR 18

3 OR 19

4 OR 20

5 OR 21

DATA 15

RES

DATA 15

RES

DATA 14

RES

DATA 14

RES

DATA 13

RES

DATA 13

RES

DATA 12

RES

DATA 12

RES

DATA 11

RES

DATA 11

RES

DATA 10

RES

DATA 10

RES

DATA 9

ADRV

DATA 9

RES

DATA 8

ADLV

DATA 8

RES

DATA 7

RES

DATA 7

RES

DATA 6

RES

DATA 6

RES

DATA 5

RES

DATA 5

RES

DATA 4

RES

DATA 4

RES

DATA 3

RES

DATA 3

RES

DATA 2

RES

DATA 2

RES

DATA 1

DA2RQ

DATA 1

RES

DATA 0

DA1RQ

DATA 0

RES

Figure 14. AD1843 TDM Time Slot Bit Assignment Map

REV. 0

AD1843

Figure 15. AD1843 Control Register Map

Register readback (on the following frame) matches the data
written. Writes to these Control Registers will fail until the
AD1843 internal clocks are stabilized. If the system has been
designed for 16 slots per frame, it is suggested that this first
"polling write/readback" is to Control Register Address 26,
with FRS (Bit 6) set to "1" and FRST (Bit 5) set to "1,"
so that the AD1843 will support the 16 slot per frame mode
immediately.

4. Put the conversion resources into standby. With the ex-

ception of the serial interface, the AD1843 is still completely
powered down before this step. The PDNI bit (Control Reg-
ister Address 28, Bit 15) should now be reset to "0" to ini-
tiate the process of taking the AD1843 conversion resources
out of power down and into standby. This requires approxi-
mately 470 ms. An autocalibration cycle always occurs
(automatically, without user programming or intervention)
following the deassertion of the RESET pin or the
PWRDWN

pin (i.e., hardware reset or hardware power

down), adding another approximately 4 ms, for a total of
approximately 474 ms. Subsequent software power-down
cycles, programmed using Control Register bits, do not ordi-
narily require additional calibration cycles. The original cali-
bration information is retained during the power down
sequence. However, the user can force an autocalibration to
occur following a software power down by setting ACEN
(Control Register Address 28, Bit 14) to "1." The host CPU
or DSP can poll the PDNO bit (Control Register Address 0,
Bit 14) to determine when the conversion resources are out
of power down. Alternatively, the host CPU or DSP can
write to Control Register Address 27 (using a data pattern
different from the initial reset default), and proceed when the

CONTROL REG

ADDRESS 0

ADDRESS 1

ADDRESS 2

ADDRESS 3

ADDRESS 4

ADDRESS 5

ADDRESS 6

ADDRESS 7

ADDRESS 8

ADDRESS 9

ADDRESS 10

ADDRESS 11

ADDRESS 12

ADDRESS 13

ADDRESS 14

ADDRESS 15

ADDRESS 16

ADDRESS 17

ADDRESS 18

ADDRESS 19

ADDRESS 20

ADDRESS 21

ADDRESS 22

ADDRESS 23

ADDRESS 24

ADDRESS 25

ADDRESS 26

ADDRESS 27

ADDRESS 28

ADDRESS 29

ADDRESS 30

ADDRESS 31

DATA 15

INIT

RES

LSS2

LD1MM

LX1MM

LX2MM

LX3MM

LMCMM

MNMM

LDA1GM

LDA2GM

LDA1AM

LDA2AM

LAD1MM

LAD2MM

RES

C1REF

C1C15

RES

C2REF

C2C15

RES

C3REF

C3C15

RES

DRSFLT

DA2SM

DFREE

PDNI

RES

DATA 14

PDNO

RES

LSS1

RES

C1VID

C1C14

RES

C2VID

C2C14

RES

C3VID

C3C14

RES

DAMIX

DA1SM

RES

ACEN

RES

DATA 13

RES

LSS0

RES

LDA1G5

LDA2G5

LDA1A5

LDA2A5

LAD1M5

LAD2M5

RES

C1PLLG

C1C13

RES

C2PLLG

C2C13

RES

C3PLLG

C3C13

RES

C3EN

RES

DATA 12

RES

LMGE

LD1M4

LX1M4

LX2M4

LX3M4

LMCM4

MNM4

LDA1G4

LDA2G4

LDA1A4

LDA2A4

LAD1M4

LAD2M4

RES

C1P200

C1C12

RES

C2P200

C2C12

RES

C3P200

C3C12

RES

DDMEN

C2EN

RES

DATA 11

RES

LIG3

LD1M3

LX1M3

LX2M3

LX3M3

LMCM3

MNM3

LDA1G3

LDA2G3

LDA1A3

LDA2A3

LAD1M3

LAD2M3

DA2C1

C1X8/7

C1C11

RES

C2X8/7

C2C11

RES

C3X8/7

C3C11

RES

DA2F1

RES

C1EN

RES

DATA 10

RES

LIG2

LD1M2

LX1M2

LX2M2

LX3M2

LMCM2

MNM2

LDA1G2

LDA2G2

LDA1A2

LDA2A2

LAD1M2

LAD2M2

DA2C0

C1C128

C1C10

RES

C2C128

C2C10

RES

C3C128

C3C10

RES

DA2F0

RES

ENCLKO

RES

DATA 9

RES

SU2

LIG1

LD1M1

LX1M1

LX2M1

LX3M1

LMCM1

MNM1

LDA1G1

LDA2G1

LDA1A1

LDA2A1

LAD1M1

LAD2M1

DA1C1

RES

C1C9

RES

C2C9

RES

C3C9

RES

DA2FLT

DA1F1

DA2EN

XCTL1

RES

DATA 8

RES

SU1

LIG0

LD1M0

LX1M0

LX2M0

LX3M0

LMCM0

MNM0

LDA1G0

LDA2G0

LDA1A0

LDA2A0

LAD1M0

LAD2M0

DA1C0

RES

C1C8

C1PD

RES

C2C8

C2PD

RES

C3C8

C3PD

DA1FLT

DA1F0

DA1EN

XCTL0

RES

DATA 7

RES

RSS2

RD1MM

RX1MM

RX2MM

RX3MM

RMCMM

ALLMM

RDA1GM

RDA2GM

RDA1AM

RDA2AM

RAD1MM

RAD2MM

RES

C1M7

C1C7

C1P7

C2M7

C2C7

C2P7

C3M7

C3C7

C3P7

DAADR1

SCF

ANAEN

ENCV3

RES

DATA 6

RES

RSS1

RES

MNOM

RES

C1M6

C1C6

C1P6

C2M6

C2C6

C2P6

C3M6

C3C6

C3P6

DAADR0

FRS

HPEN

ENBT3

RES

DATA 5

RES

RSS0

RES

HPOM

RDA1G5

RDA2G5

RDA1A5

RDA2A5

RAD1M5

RAD2M5

RES

C1M5

C1C5

C1P5

C2M5

C2C5

C2P5

C3M5

C3C5

C3P5

DAADL1

FRST

RES

ENCV2

RES

DATA 4

RES

RMGE

RD1M4

RX1M4

RX2M4

RX3M4

RMCM4

HPOS

RDA1G4

RDA2G4

RDA1A4

RDA2A4

RAD1M4

RAD2M4

RES

C1M4

C1C4

C1P4

C2M4

C2C4

C2P4

C3M4

C3C4

C3P4

DAADL0

ADTLK

AAMEN

ENBT2

RES

DATA 3

ID3

OVR1

RIG3

RD1M3

RX1M3

RX2M3

RX3M3

RMCM3

SUMM

RDA1G3

RDA2G3

RDA1A3

RDA2A3

RAD1M3

RAD2M3

ADRC1

C1M3

C1C3

C1P3

C2M3

C2C3

C2P3

C3M3

C3C3

C3P3

RES

ADRF1

RES

ENCV1

RES

DATA 2

ID2

OVR0

RIG2

RD1M2

RX1M2

RX2M2

RX3M2

RMCM2

RES

RDA1G2

RDA2G2

RDA1A2

RDA2A2

RAD1M2

RAD2M2

ADRC0

C1M2

C1C2

C1P2

C2M2

C2C2

C2P2

C3M2

C3C2

C3P2

RES

ADRF0

RES

ENBT1

RES

DATA 1

ID1

OVL1

RIG1

RD1M1

RX1M1

RX2M1

RX3M1

RMCM1

DAC2T

RDA1G1

RDA2G1

RDA1A1

RDA2A1

RAD1M1

RAD2M1

ADLC1

C1M1

C1C1

C1P1

C2M1

C2C1

C2P1

C3M1

C3C1

C3P1

ADRFLT

ADLF1

ADREN

LINRSD

RES

DATA 0

ID0

OVL0

RIG0

RD1M0

RX1M0

RX2M0

RX3M0

RMCM0

DAC1T

RDA1G0

RDA2G0

RDA1A0

RDA2A0

RAD1M0

RAD2M0

ADLC0

C1M0

C1C0

C1P0

C2M0

C2C0

C2P0

C3M0

C3C0

C3P0

ADLFLT

ADLF0

ADLEN

LINLSD

RES

Figure 16 shows an annotated version of the AD1843 detailed
block diagram, indicating the specific Control Register bit fields
which configures the various features of the SoundComm codec.

START-UP SEQUENCE

The following paragraphs describe a typical, generic start-up
sequence, for the purpose of helping hardware, systems and
software driver engineers understand some of the considerations
involved in bringing up a system which includes the AD1843.
Note that it does not exhaustively outline all of the flexible con-
figurations and features available in the AD1843.

1. System power supplies stabilize. Ideally, the AD1843

RESET

pin should be held LO during this period. If

RESET

is not asserted, the AD1843 will come up in an un-

known state.

2. Assert the RESET signal (PLCC Pin 52, TQFP Pin 65).

Once the power supplies have stabilized, the AD1843 RE-
SET

must be asserted LO for at least 100 ns with BM

(PLCC Pin 10, TQFP Pin 12) tied to the appropriate level to
establish whether the codec is serial bus master or slave.

3. Deassert the RESET signal and enter a wait period to

allow the AD1843 internal clocks and the external crys-
tal oscillator to stabilize. The wait period duration will be
typically 400

s to 800

s after RESET is deasserted, but sig-

nificantly longer time may be necessary depending on
XTALI and XTALO pin parasitics. If the AD1843 is serial
bus master, the host CPU or DSP can poll the INIT bit
(Control Register Address 0, Bit 15) to determine when the
AD1843 is ready to proceed. Alternatively, the host CPU or
DSP can write to Control Register 16 through 24, or 26 or
28 (using a data pattern different from the initial reset default
for that Control Register), and proceed when the Control

AD1843

REV. 0

Figure 16. AD1843 Annotated Detailed Block Diagram with Control Register Address and Data Values

PDMNFT

8 9

GNDD

CMOUT

REF

CLOCK GENERATION

CLKOUT

XTALI

XTALO

SYNC3

SYNC2

SYNC1

CONV3

CONV2

CONV1

BIT3

BIT2

BIT1

HPOUTR

HPOUTC

HPOUTL

LOUT2LP

LOUT2LN

LOUT2RP

LOUT2RN

LEFT

RIGHT

20dB

LEFT

RIGHT

ADC

DAC1

DAC2

LOUT1L

LOUT1R

AUX3L

AUX2R

AUX1L

AUX2L

AUX1R

LINRP

LINRN

MICR

MICL

GN/AT = GAIN/ATTENUATION

DRIVER

HPEN[27]

CONTROL

AND STATUS

REGISTERS

AD1843

AAFILTL

AAFILTR

SUML

SUMR

LINLP

LINLN

MOUT

RESET

PWRDWN

MUTE

MNOM[8]

MUTE

DAMIX[25]

AUX3R

MIN

ADC

ADLEN[27]

ADREN[27]

PGA

LIG[2]

RIG[2]

µ/A

LAW

SCLK

SDFS

SDI

SDO

TSO

TSI

XCTL [1:0]

VOLTAGE REFERENCE

RMGE[2]

LMGE[2]

(0)

(1)

(2)

(3)

(4)

(5)

(6)

(7)

RSS[2]

LSS[2]

(2)

(3)

DAADL[25]

DAADR[25]

(0)

DAADL[25]

DAADR[25]

SELECTOR

µ/A

LAW

µ/A

LAW

[ ] INDICATES CONTROL REGISTER ADDRESS

( ) INDICATES CONTROL REGISTER DATA

MUTE

HPOM[8]

MUTE

SUMM[8]

MUTE

LDA2GM[10]

RDA2GM[10]

GN/AT

LDA2G[10]

RDA2G[10]

DAC

DA2EN[27]

GN/AT

LD2M[3]

RD2M[3]

MUTE

LD2MM[3]

RD2MM[3]

ALLMM[8]

GN/AT

LDA1G[9]

RDA1G[9]

MUTE

LDA1GM[9]

RDA1GM[9]

DAC

DA1EN[27]

LEFT

RIGHT

MUTE

MNMM[8]

ALLMM[8]

MUTE

LX3MM[6]

RX3MM[6]

ALLMM[8]

GN/AT

LX3M[6]

RX3M[6]

GN/AT

LX2M[5]

RX2M[5]

GN/AT

LX1M[4]

RX1M[4]

GN/AT

LMCM[7]

RMCM[7]

GN/AT

MNM[8]

MUTE

LX2MM[5]

RX2MM[5]

ALLMM[8]

MUTE

LX1MM[4]

RX1MM[4]

ALLMM[8]

MUTE

LMCMM[7]

RMCMM[7]

ALLMM[8]

LEFT

RIGHT

MUTE

LDA1AM[11]

RDA1AM[11]

ATTN

LDA1A[11]

RDA1A[11]

MUTE

LDA2AM[12]

RDA2AM[12]

ATTN

LDA2A[12]

RDA2A[12]

FIFO

ATTN

LAD2M[14]

RAD2M[14]

FILTL

FILTR

GNDA

MUTE

DAMIX[25]

MUTE

LAD2MM[14]

RAD2MM[14]

ATTN

LAD1M[13]

RAD1M[13]

MUTE

LAD1MM[13]

RAD1MM[13]

REV. 0

AD1843

RESET

= LO

PWRDWN

= HI,

RESET

= HI

PWRDWN

= LO

PWRDWN

= HI

ACEN = 1

ACEN = 0

PDNI = 1 OR

PWRDWN

= LO

PDNI = 1

PDNI = 0

CONVERSION

RESOURCES

POWER DOWN

INIT = 0

PDNO = 1

ALL DOWN

INIT = 1

PDNO =1

INITIALIZING

INIT = 1

PDNO = 1

TIME: 800µs?

AUTOCAL

INIT = 0

PDNO = 1

TIME: < 4ms

STBY

CONVERSION RESOURCES

POWERED UP

INIT = 0

PDNO = 0

ADCL

ADCR

DAC1

DAC2

CONVERSION RESOURCES

ENTERING POWER DOWN

INIT = 0

PDNO = 1

TIME: < 5ms

PWRDWN

= LO

PDNI = 0

CONVERSION RESOURCES

EXITING POWER DOWN

INIT = 0

PDNO = 1

TIME: < 470ms

INTERFACE: DOWN
CLOCK GENERATORS: DOWN
CONVERSIONS: DOWN

INTERFACE: READS ONLY IF SLAVE,
DOWN IF MASTER
CLOCK GENERATORS: DOWN
CONVERSIONS: DOWN

INTERFACE: ALIVE
CLOCK GENERATORS: ENABLEABLE
(CONTROL REGISTER ADDRESS 28)
CONVERSIONS: DOWN

INTERFACE: ALIVE
CLOCK GENERATORS: ENABLEABLE
(CONTROL REGISTER ADDRESS 28)
CONVERSIONS: ENABLEABLE
(CONTROL REGISTER ADDRESS 27)

NONE

16-24, 26, 28

POTENTIALLY ALL,
DEPENDING ON
ENABLED
RESOURCES
(SEE TEXT)

16-24, 26, 28

AD1843 STATE

ACTIVITY LEVEL

WRITABLE

REGISTERS

= STATE

= TRANSMISSION (WILL NOT BE INTERRUPTED ONCE STARTED UNLESS

RESET

= LO)

REGISTERS ARE ALWAYS READABLE, UNLESS

RESET

= LO

Figure 17. AD1843 Start-Up Sequence State Diagram

Control Register readback (on the following frame) matches
the data written. Writes to Control Register Address 27 will
fail unless the conversion resources are out of power down.

5. Power up the clock generators and enable clock output

pins. When the PDNI bit (Control Register Address 28, Bit
15) is reset to "0" in Step 4 above, the C3EN, C2EN,
C1EN, CONV[3:1], and BIT[3:1] bits, which are also lo-
cated in Control Register Address 28, may be set to "1" to
power up any clock generators which will be used, and to
enable any conversion clock and bit clock outputs needed.
While waiting for the conversion resources to enter standby,
it is convenient to write to the clock generator Control Regis-
ters (16 through 24) to select sample rates, bit clock frequen-
cies, external/internal sample rate lock mode, etc. This is
also a convenient time to write to Control Register Address
26 (if it was not already written in Step 3) to select the serial
interface configuration such as data format, SCLK fre-
quency, etc.

6. Configure conversion resources while they are in

standby. Once in standby, the conversion resources may be
configured. They are forced to their defaults whenever pow-
ered down. Control Register Address 2 may be written to se-
lect between ADC sources and gain levels. Control Register
Address 15 may be written to select the assignments of
sample clock sources to conversion resource. Control Regis-
ter Addresses 13 and 14 may be written to enable digital data
flow paths which mix ADC output back into the DAC input.
Control Register Address 25 may be written to select conver-
sion resource filter mode (audio, modem or resampler), and
to select digital data flow paths which may be used to achieve

digital-to-digital sample rate conversion and DAC-to-DAC
digital mixing. Note that, with the exception of filter mode
and DAC-to-DAC digital mixing, all of these configuration
selections may also be changed while a conversion resource is
out of standby and enabled.

7. Enable conversion resources. Conversion resources are

taken out of standby and enabled by writes to Control Regis-
ter Address 27. Control Register Address 27 contains indi-
vidual enable bits for the conversion resources which are
grouped as follows: DAC1 (stereo pair); DAC2 (stereo pair);
ADC left channel; ADC right channel; DAC2 to DAC1 mix;
and ADC input to DAC1 output mix.

If a DAC is enabled, it will begin requesting playback
samples on the next TDM frame (i.e., the DA2RQ and/or
the DA1RQ flags in the Status Register will be set to "1").
Conversions will not actually begin until the first rising edge
of the conversion clock (assigned to the DAC) after the sixth
rising edge of the frame sync (SDFS) signal. This delay al-
lows the four word deep stereo FIFOs to be filled before con-
versions begin. (Six frames are required to fill a four word
deep FIFO because on the first frame, the DAC playback is
enabled; on the second frame, the DA2RQ and/or DA1RQ
flags are set to "1"; then four more frames are required to ac-
tually fill the FIFO.)

If an ADC is enabled, sampling of the analog input will be-
gin on the first rising edge of the conversion clock (assigned
to the ADC) after the sixth rising edge of the frame sync
(SDFS) signal. The data valid flags (ADRV and/or ADLV)
in the Status Word will be set to a "1," indicating a sample is
being transmitted shortly thereafter. The exact TDM frame

AD1843

REV. 0

in which the valid flag is first asserted, and continues to be
asserted in future frames, depends on how the AD1843 is
configured, i.e., the sample rates selected, the frame size
selected, and how the shared digital resources within the
AD1843 are internally allocated to process all conversion
channels. Note that because of this, two ADCs which are
enabled during the same frame and share the same sample
rate clock, will not necessarily transmit data during the same
frames thereafter, even though their analog inputs will always
be sampled at the same instant in time. The two ADCs will
transmit data during the same frame if ADTLK (Control
Register Address 26, Bit 4) is set HI. See the description of
the ADTLK bit for restrictions.

If mixing is enabled, either a mix from DAC2 to DAC1 or a
mix from an ADC input to a DAC output, then the mix will
begin during the same TDM frame that it is enabled.

8. Configure conversion resources while they are enabled.

Once enabled, DAC output gain/attenuation levels may be
changed using Control Register Addresses 3 through 10.
These registers are forced to their default of full attenuation
whenever the resource they control is either in standby or
completely powered down. Note that while a conversion re-
source is enabled, all configuration selections related to it
may be changed except those outlined in Step 6.

The AD1843 Start-Up Sequence state diagram is shown in
Figure 17.

APPLICATIONS CIRCUITS

The AD1843 SoundComm Codec has been designed to require
a minimum of external circuitry. The recommended circuits are
shown in Figures 18 through 34. Analog Devices estimates that
the total cost of all the components shown in these Figures (in-
cluding the crystal but not including the DAA) to be less than
$6 in 10,000 piece quantities.

Industry-standard compact disc "line-levels" are 2 V

rms cen-

tered around analog ground. (For other audio equipment, "line
level" is much more loosely defined.) The AD1843 SoundComm
Codec is a +5 V analog supply powered device. Nominal line
level voltage swings for the AD1843 are defined to be 1 V rms
(ADRFLT and ADLFLT = 0) for a sine wave ADC input and
0.707 V rms for a sine wave DAC output (DA2FLT = 0). Thus,
2 V rms input analog signals must be attenuated and either cen-
tered around the reference voltage intermediate between 0 V
and +5 V or ac-coupled. The CMOUT pin will be at this inter-
mediate voltage, nominally 2.25 V. It has limited drive but can
be used as a voltage datum to an op amp input. CMOUT load-
ing should be minimized to limit any audible clicks and pops.
Note that dc-coupled inputs are not recommended, as they pro-
vide no performance benefits with the AD1843 architecture.
Furthermore, dc offsets on inputs create the potential for clicks
when changing the input mix gain/attenuation/mute.

The RESET pin must be asserted at or shortly after power up in
order to initialize the AD1843 Control Registers to their default
states. If the AD1843 will not be used immediately, and if it is
desired to utilize the mono input to mono output feedthrough
feature, it is essential that the mono output is ac-coupled to pre-
vent audible pops and clicks. It is recommended that all outputs
are ac coupled, as standing current in output loads or in the
voltage reference will contribute to audible pops and clicks.

A circuit for 2 V rms line-level inputs is shown in Figure 18.
Note that this is a divide-by-two resistive divider, and that the
line input is being used in a single-ended configuration. The
1

F ac-coupling capacitor may be of any type (tantalum is a

popular choice).

LINLP

5.1k

1µF

5.1k

LINRP

5.1k

1µF

5.1k

1nF

Figure 18. AD1843 2 V rms Single-Ended Line-Level
Input Circuit

If line-level inputs are already at the 1 V rms levels expected by
the AD1843, the circuit shown in Figure 19 below should be
used. Note that when single-ended line inputs are desired, only
the LINRP and LINLP pins are used. DO NOT use the
LINRN or LINLN pins if the line input is single-ended.

LINLP

1µF

LINRP

Figure 19. AD1843 1 V rms Single-Ended Line-Level
Input Circuit

The three auxiliary inputs, the SUM inputs, and the mono in-
put of the AD1843 present an input impedance which is lower
than the stereo line input. The circuit shown in Figure 20
should be used with 2 V rms swings on these inputs. With 1 V
rms swings, the circuit in Figure 19 above should be used.

4.1k

1µF

3.3k

AUX1L
AUX2L
AUX3L
SUML

1nF

4.1k

1µF

3.3k

1nF

MIN

4.1k

1µF

3.3k

AUX1R
AUX2R
AUX3R
SUMR

1nF

Figure 20. AD1843 2 V rms Aux, SUM, and Mono Input
Circuits

For optimal performance, the AD1843 includes provision for a
differential configuration of the LIN inputs. Figure 21 illus-
trates a simple single-ended to differential converter. For the
best noise immunity, the circuitry to the left of the dotted line
should be located as close to the driving signal source as possible.
The 0.9K resistor and the 1000 pF capacitor are manda-
tory when using the LINRN and/or the LINLN inputs.
Furthermore, the 0.9K resistor and the 1000 pF NPO capacitor
should be located as close to the AD1843 as possible. If the
output range of the source does not match that of the AD1843
input, the op amp gain setting resistor values should be scaled
to match the source voltage range to the AD1843 input voltage
range.

Inexpensive feedback capacitors can be added (as shown in the
Figure 21 with dotted lines) for additional noise filtering (6 dB
per octave). Without the additional filter capacitor, there is a
single antialiasing pole at approximately 160 kHz. There is

REV. 0

AD1843

"room" in the frequency domain for a second pole, especially in
modem applications, where the signal bandwidth is 4.2 kHz. A
suggested capacitor value is 120 pF when using the 10K op amp
feedback resistor as shown, for a 3 dB point of approximately
133 kHz. Note that the combined effect of both filters causes a
gain error of approximately 0.1% at 4.2 kHz.

1µF

0.9k

LINRN
LINLN

10k

1/2

SSM2135

10k

SOURCE

10k

1/2

SSM2135

1µF

1000pF
NPO

LINLP
LINRP

CLOSE TO SOURCE

CLOSE TO AD1843

1µF

CMBUF

Figure 21. Single-Ended to Differential Converter

The AD1843 Codec contains an optional +20 dB gain block to
accommodate condenser microphones. Particular system re-
quirements will depend upon the characteristics of the intended
microphone. Figure 22 illustrates one example of how an elec-
tret condenser mic requiring phantom power could be con-
nected to the AD1843. CMOUT is shown buffered by an op
amp; the current drawn from CMOUT should be as minimal as
possible. Note that if a battery-powered microphone is used,
the buffer and R2s are not needed. The values of R1, R2, and
C should be chosen in light of the mic characteristics and in-
tended gain. Typical values for these might be R1 = 20 k

R2 = 2 k

, and C = 220 pF. Figure 22 shows a voltage follower

buffer on the CMOUT signal. The output of this buffer,
CMBUF, can be used in any circuit which needs the common-
mode bias point from the AD1843's on-chip voltage reference.
The AD820 is a JFET input op amp whose very high imped-
ance inputs present essentially no load on the CMOUT output
from the AD1843.

1/2 SSM2135

OR AD820

1µF

CMOUT

MICL

LEFT ELECTRET

CONDENSER

MICROPHONE

INPUT

RIGHT ELECTRET

CONDENSER

MICROPHONE

INPUT

0.33µF

1/2 AD820

1/2 SSM2135

OR AD820

1µF

MICR

0.33µF

CMBUF

Figure 22. AD1843 "Phantom-Powered" Microphone
Input Circuit

Connect unused analog inputs to CMBUF or leave them
unconnected; do not connect unused analog inputs to
either analog power or ground!

Figure 23 shows ac-coupled line outputs. The resistors are used
to center the output signals around analog ground. If dc-
coupling is desired, CMOUT could be used with op amps as
mentioned above, if desired.

LOUT1R

LOUT2RP

47k

1µF

LOUT1L

LOUT2LP

47k

1µF

Figure 23. AD1843 (Single-Ended) Line Output
Connections

For optimal performance, the AD1843 DAC2 output has provi-
sion for a differential configuration. A simple differential-to-
single-ended conversion circuit is shown in Figure 24. The
noise rejection of this circuit is limited by the match of the R

and R

resistors. The resistors should be 1% tolerance compo-

nents. The equation that determines the output voltage is as
follows:

= (R

)(V+) (R

)(V)

For maximum noise immunity, this circuit should be located in
close proximity to where V

is processed. Another differential

receiver option is the SSM2141, which provides better matching
than a discrete implementation.

1/2

SSM2135

1/2

SSM2135

LOUT2LN

(V)

10pF

LOUT2LP

(V+)

CMBUF

1/2

SSM2135

1/2

SSM2135

LOUT2RN

(V)

10pF

LOUT2RP

(V+)

CMBUF

Figure 24. AD1843 Differential-to-Single-Ended Converter
Line Output Connections

A circuit for headphone drive is illustrated in Figure 25. The
AD1843 headphone output is designed to drive loads of 32
ohms or smaller (i.e., higher impedance). If larger loads are
used (e.g., 16 ohms or 8 ohms), the analog output will be dis-
torted for large output signals because of current limiting.
"Walkman"-type headphone impedances are generally around
32 ohms. Telephone handset impedances are typically 150 ohms.

HPOUTL

HPOUTR

HPOUTC

Figure 25. AD1843 Headphone Drive Connections

Figure 26 shows an example circuit for the mono output
(MOUT) from the AD1843. The OP279 is a single +5 V supply
op amp which can drive a small 8 ohm or 16 ohm speaker to
modest levels.

AD1843

REV. 0

MOUT

CMBUF

10k

1/2

OP279

OPTIONAL

TO PC
SPEAKER

470µF

Figure 26. AD1843 Mono Output Circuit

Figure 27 illustrates reference bypassing. V

REF

should only be

connected to its bypass capacitors. The 10

F capacitor should

be tantalum, and the 0.1

F capacitor should be ceramic. Figure

27 shows an optional voltage follower buffer on the CMOUT
signal. The output of this buffer, CMBUF, can be used in any
circuit which needs the common-mode bias point from the
AD1843's on-chip voltage reference. The AD820 is a JFET in-
put op amp whose very high impedance inputs present essen-
tially no load on the CMOUT output from the AD1843.

REF

10µF

0.1µF

CMOUT

10µF

0.1µF

CMBUF

1/2

AD820

OPTIONAL BUFFER

Figure 27. AD1843 Voltage Reference Bypassing

Figure 28 illustrates the signal-path filtering capacitors, FILTL
and FILTR, connections to analog ground. The 1.0

F capaci-

tors required by the AD1843 can be of any type.

1.0µF

FILTL

1.0µF

FILTR

Figure 28. AD1843 External Filter Capacitor Connections

Figure 29 illustrates the antialias filtering capacitors, AAFILTL
and AAFILTR, connections to analog ground. The 1000 pF
capacitors must be NPO types.

1000pF

NPO

AAFILTL

AAFILTR

1000pF
NPO

Figure 29. AD1843 Antialias Filter Capacitor Connections

The 24.576 MHz crystal shown in the crystal connection cir-
cuitry of Figure 30 should be fundamental-mode and parallel-
tuned. Note that using the exact data sheet frequency is not

required and that external clock sources can be used in place of
the AD1843's internal oscillator. If using an external clock
source, apply it to the crystal input pin (XTALI) while leaving
the crystal output pin (XTALO) unconnected. Attention

24.576 MHz

XTALI

XTALO

2064pF

Figure 30. AD1843 Crystal Connections

should be paid to providing a low-jitter external input clock.
Ideally, there should be no greater than 5 ns rms of random
(white) phase jitter to ensure that it does not significantly de-
grade the SNR of the AD1843.

Figure 31 and Figure 32 show example circuits for a Data
Access Arrangement (DAA). These circuits are shown as
examples only; DAA circuits are subject to regulatory approval
since they connect directly to the Public Switched Telephone
Network (PSTN).

220

SSI 73M9001

TXA

TXA/

MONSUM

TIP

RING

OH/

RLY2/

AG0

AG1

POWER/

RXA

SPK

SPK/

TRAN1

TRAN2

RI/

REOUT1

REOUT2

VCCA

VCCD

AGND

DGND

+5VA

56k

TO AD1843

XCTL0

RING

INDICATION

TO HOST

INTERRUPT

RJ11

SINGLE

PHONE

COIL

220µF

TO
AD1843 LINLP

TO
AD1843 MIN

LOUT2LN
LOUT2LP

FROM AD1843

COIL

Figure 31. Silicon Systems DAA Example Circuit

Figure 32. Cermetek DAA Example Circuit

XMIT+

XMIT

RCV

OFFHK

TIP

RING

GND

CERMETEK
CH1837
DAA

C3 100nF

C2 100nF

C1 100nF

LOUT2LP

LOUT2LN

LINLP

XCTL0

U3B

SN74HC14

U3A

SN74HC14

AD1843

C4 100nF

EARTH

GROUND

VR1

MOV

VR3
MOV

VR2

MOV

CURRENT

LIMIT

CURRENT

LIMIT

C6, 1nF

1.5kV

C5, 1nF
1.5kV

RING (RED)

TIP (GREEN)

RJ-11 JACK

U3D

SN74HC14

U3C

SN74HC14

R1
100k

IRQ

TO DSP OR HOST

CPU INTERRUPT

+ C7

4.7µF TANT
(OPTIONAL)

NOTES:
1. VR1,2,3. OVER VOLTAGE AND LIGHTNING PROTECTION
MOV SIDACTORS. AVAILABLE AS A SINGLE UNIT FROM
TECCOR, PART NUMBER P3203AB OR P3203AA.

2. C5,6. EMI/RFI SUPPRESSION. HIGH VOLTAGE DISK
CERAMIC CAPACITORS, 1nF 1.5kV.

3. F1,2. CURRENT LIMITING DEVICES. RAYCHEM POLY FUSE,
PART NUMBER TB600-45; LITTLE FUSE TYPE 251.250 OR
BUSSMAN TYPE MCR1/4. FOR NON UL APPLICATIONS,
A 10 OHM, 1/8W CARBON FILM RESISTOR MAY BE USED.

4. L1,2. EMI/RFI SUPPRESSION. FERRITE BEADS, FAIR-RITE
PART NUMBER 2643666611 OR 2943666661.

5. J1. FCC APPROVED RJ-11 JACK. REF FCC PUBLIC NOTICE #42269

INDUCTOR

REV. 0

AD1843

Good, standard engineering practices should be applied for
power-supply decoupling. Decoupling capacitors should be
placed as close as possible to package pins. If a separate analog
power supply is not available, we recommend the circuit shown
in Figure 33 for using a single +5 V supply. This circuitry
should be as close to the supply pins as is practical.

FERRITE OR

SUITABLE

INDUCTOR

1.6

0.1µF

1µF

FERRITE OR

SUITABLE

INDUCTOR

0.1µF

1µF

0.1µF

+5V

SUPPLY

0.1µF

1µF

Figure 33. AD1843 Recommended Power Supply

Bypassing

Figure 34 illustrates an optional circuit for generating the +5 V
analog supply for the AD1843. The +12 V rail available on the
ISA bus can be regulated down to +5 V using an ordinary 7805
three-terminal regulator and the bypassing and decoupling
capacitors shown. The digital supply should still be decoupled
and bypassed as shown above in Figure 33.

10µF

220nF

10µF

220nF

+12V

PC 0 V

FERRITE

BEAD

OUT

GND

7805

AGND

DGND

+5VA

1µF

Figure 34. AD1843 Optional Analog Supply Regulation

Analog Devices recommends a split ground plane as shown in
Figure 35a (PQFP) and Figure 35b (TQFP). The analog plane
and the digital plane are connected directly under the AD1843.
Splitting the ground plane directly under the SoundComm
Codec is optimal because analog pins will be located above the
analog ground plane and digital pins will be located directly
above the digital ground plane for the best isolation. The digital
ground and analog ground should be tied together in the vicin-
ity of the AD1843. Other schemes may also yield satisfactory
results. If the split ground plane recommended here is not pos-
sible, the AD1843 should be entirely over the analog ground
plane.

ANALOG

GROUND

PLANE

DIGITAL

GROUND

PLANE

AD1843

PQFP

Figure 35a. AD1843 Recommended PQFP Ground Plane

ANALOG

GROUND

PLANE

DIGITAL

GROUND

PLANE

AD1843

TQFP

Figure 35b. AD1843 Recommended TQFP Ground Plane

REV. 0

AD1843

TABLE OF CONTENTS

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL PRODUCT DESCRIPTION . . . . . . . . . . . . .

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . .

PIN DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PIN CONFIGURATIONS . . . . . . . . . . . . . . . . . . . . . . .

7, 8

DETAILED FUNCTIONAL BLOCK DIAGRAM . . . . .

DETAILED PRODUCT DESCRIPTION . . . . . . . . . . . .

FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . .

SERIAL INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . .

SERIAL INTERFACE INPUT . . . . . . . . . . . . . . . . . . . .

SERIAL INTERFACE OUTPUT . . . . . . . . . . . . . . . . . .

CONTROL REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . .

BIT AND REGISTER MAPS . . . . . . . . . . . . . . . . . . . . . .

START-UP SEQUENCE . . . . . . . . . . . . . . . . . . . . . . . . .

APPLICATIONS CIRCUITS . . . . . . . . . . . . . . . . . . . . .

FREQUENCY RESPONSE PLOTS . . . . . . . . . . . . . . . .

OUTLINE DIMENSIONS

Dimensions shown in inches and (mm)

ST-100

100-Terminal Plastic Thin Quad Flatpack (TQFP)

SEATING

PLANE

0.026 (0.65)

0.014 (0.35)

0.061 (1.55)

0.049 (1.25)

TYP

0.007 (0.177)

0.003 (0.077)

 10

0.004

(0.102)

MAX LEAD

COPLANARITY

TOP VIEW

(PINS DOWN)

100

0.012 (0.20)

0.004 (0.10)

0.640 (16.25)

0.620 (15.75)

0.555 (14.10)

0.547 (13.90)

0.020 (0.50)

BSC

S-80

80-Terminal Plastic Quad Flatpack (PQFP)

SEATING

PLANE

0.096 (2.45)

MAX

0.037 (0.95)

0.026 (0.65)

0.004 (0.10)

MAX

0.083 (2.10)

0.075 (1.90)

0.010 (0.25)

MIN

0.015 (0.38)

0.009 (0.22)

0.690 (17.45)

0.667 (16.95)

0.555 (14.10)

0.547 (13.90)

0.555 (14.10)

0.547 (13.90)

0.690 (17.45

0.667 (16.95)

0.486 (12.35) TYP

TOP VIEW

(PINS DOWN)

0.029 (0.73)

0.023 (0.57)

Ð­Ð»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: AD1843

ÐÐ»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: AD1843
