Agilent HDSP-S51E Series
27.4 mm (1.08 inch) General Purpose
5 x 7 Dot Matrix Alphanumeric Displays
Data Sheet
Description
These displays have a 27.4 mm
(1.08 inch) character height and
use industry standard size and pin-
out. The devices are available in
either common row anode or
common row cathode configura-
tions. The displays come in only
black face paint and are available in
a choice of GaP Red (HER) or GaP
Features
5 x 7 Dot matrix font
Stackable horizontally
Industry standard pin-out
22.86 mm (0.9 in.) Dual-In-Line
(DIP) leads on 2.54 mm (0.1 in.)
centers
Choice of colors
Single color: GaP Red or
GaP Green
Bi-color: GaP Red and
GaP Green
Face paint color: black
Design flexibility
Common row anode or
common row cathode
Categorized for luminous intensity
or luminance
Green categorized for color
Applications
Suitable for indoor use
Not recommended for industrial
applications, i.e., operating
temperature requirements
exceeding 85
C or below -35
C
Extreme temperature cycling not
recommended
[1]
Green colors. The Bi-color
display consists of GaP Red and
Green colors.
These parts are subjected to Out-
going Quality Assurance (OQA)
inspection with an AQL of
0.065% for functional and visual/
cosmetic defects.
Devices
GaP Red
Green
HDSP-
HDSP-
Description
S51E
S51G
27.4 mm Black Surface Common Row Anode
S56E
S56G
27.4 mm Black Surface Common Row Cathode
B51Z
27.4 mm Black Surface Bi-Color Common Row Anode
B56Z
27.4 mm Black Surface Bi-Color Common Row Cathode
Note:
1. For details, please contact your local Agilent components sales office or an authorized distributor.
2
Package Dimensions
Single Color
27.42
(1.080)
22.60
(0.890)
ROW
COL
1
2
3
4
5
6
7
1
2
3
4
5
2.54 x 6 = 15.24
(0.1 x 6 = 0.60)
8.00
(0.315)
3.00 (0.118)
4.57
(0.180)
4.57
(0.180)
2.54
(0.10)
PART NO.
0.51
(0.020)
22.85
(0.900)
3.26
(0.128)
31.80
(1.252)
7.00
(0.276)
PIN 1
31.80
(1.252)
0.50
(0.020)
3
Internal Circuit Diagram
Common Row Cathode (Single Color)
PIN NO.
CONNECTION
1
ROW 5
2
ROW 7
3
COLUMN 2
4
COLUMN 3
5
ROW 4
6
COLUMN 5
7
ROW 6
8
ROW 3
9
ROW 1
10
COLUMN 4
11
COLUMN 3
12
ROW 4
13
COLUMN 1
14
ROW 2
9
10
6
3
4
5
3
2
13
1
14
8
5
1
7
2
1
2
3
4
5
6
7
PIN
COLUMN
ROW
12
4
4
Internal Circuit Diagram
Common Row Anode (Single Color)
PIN NO.
CONNECTIION
1
ROW 5
2
ROW 7
3
COLUMN 2
4
COLUMN 3
5
ROW 4
6
COLUMN 5
7
ROW 6
8
ROW 3
9
ROW 1
10
COLUMN 4
11
COLUMN 3
12
ROW 4
13
COLUMN 1
14
ROW 2
4
9
10
6
3
4
5
3
2
13
1
14
8
5
1
7
2
1
2
3
4
5
6
7
11
PIN
COLUMN
ROW
12
5
Package Dimensions
Bi-Color
27.42
(1.080)
22.60
(0.890)
ROW
COL
1
2
3
4
5
6
7
1
2
3
4
5
2 x 9 = 18.00
(0.079 x 9 = 0.709)
4.57
(0.180)
4.57
(0.180)
2.00
(0.079)
PART NO.
0.51
(0.020)
22.85
(0.900)
3.26
(0.128)
31.80
(1.252)
0.50
(0.020)
31.80
(1.252)
3.00 (0.118)
PIN 1
8.00
(0.315)
7.00
(0.276)
