Main Features
High Sensitivity Full Frame CCD Sensor
2300 x 3500 Resolution with 10 m Square Pixels
Bayer Color Mosaic
12-bit Dynamic Range
Very Low Noise: 65 dB SNR
Binning and ROI Modes
LVDS or CameraLink Data Format (Base Configuration)
High Data Rate: 25 Mpixels/s
Flexible and Easy to Operate via RS-232 Control
Trigger Mode: Free Run or External Trigger Modes
Binning 2 x 2 and 4 x 4, Up to 5 ROI
Exposure Time
Gain: -5 to 29 dB by Steps of 0.04 dB
Offset: 0 to 255 LSB
White Balance Adjustment
Test Pattern Generation
Single Power Supply: 24V
DC
High Reliability CE and FCC Compliant
F (Nikon) Mount Adapter (Lens Not Supplied)
Product Description
This camera is designed to meet high performance and quality requirements while
providing ease of use.
Atmel manages the entire process, from the sensor to the camera. The result is a
camera able to work in 12 bits, with dedicated electronics that provides excellent
signal to noise ratio.
High sensitivity and excellent color reproduction.
The programmable settings let the user work with different integration times, gains
and offsets. The external trigger allows the user to synchronize the camera on an
external event while the hardware white balance adjustment avoids subsequent
software processing.
Applications
The performance and reliability of this camera make it well suited for the most
demanding applications such as film and document scanning, semiconductor and
PCB inspection, DNA analysis, metrology, X-ray imaging, etc...
Color 8 Megapixels
LVDS and
CameraLink
TM
Digital Cameras
CAMELIA C1 LV 8M
CAMELIA C1 CL 8M
Preliminary
Rev. 5320AIMAGE04/03
2
CAMELIA C1 8M LVDS and CameraLink Cameras
5320AIMAGE04/03
Improvements
The Camelia 8M has been redesigned:
To add new features:
Gain: 928 steps from -5 to 29 dB
Offset: 0 to 255 LSB
Test pattern: ramps up from 0 to 2298 pixel values on each line
White balance: by separate gain adjustment for the 4 colors of the 2 x 2
Bayer mosaic
To improve the electro-optical performances, in particular by:
Reducing power consumption from 8.5W down to 5.5W, using a new front
panel and internal heat sink. This lowers the CCD temperature by 5
C thus
decreasing the magnitude of "white pixels".
Decreasing the typical temporal noise from 2.7 to 2.4 LSB
Implementing new color filter
To interface with more standard and cheaper cables
To improve reliability
Camelia C1 8M is CE and FCC compliant
What changes for the user?
New additional commands for gain, offset and test pattern
RS-232 transmission speed increased from 9600 to 19200 bauds for LVDS
cameras (9600 bauds for CameraLink cameras)
Interface connectors:
DATA & SYNC is a 3M MDR connector with better availability, the same
pinout but different mechanics
RS-232 is a D-Sub 9 female for full-duplex transmission
The power supply connector has a camera standard pinout
TTL CONTROL is a new D-Sub 9 male connector avoiding the use of a Y
cable
New rear panel (see position of connectors)
Increased sensitivity: blue x3.5, green x3, red x5 at 3200K on 400 to 700 nm
3
CAMELIA C1 8M LVDS and CameraLink Cameras
5320AIMAGE04/03
Imaging System
Description
Figure 1. LVDS Camera Imaging System
Figure 2. CameraLink Camera Imaging System
4
CAMELIA C1 8M LVDS and CameraLink Cameras
5320AIMAGE04/03
The Camelia camera is powered by a single +24V power supply. It is configurable via
the serial port of the computer (by using either CommCam software or standard RS-232
communicator as TTY or Hyperterminal) for LSD cameras. Camelia is configurable via
the serial communication of CameraLink for CameraLink cameras. It also can send digi-
tal video.
As Camelia's CCD is a full frame sensor, the user must use either pulsed lighting or a
chopper/shutter in front of the camera in order to have only incident lighting on the CCD
during integration time. The user must design an electro-optical interface to drive the
camera, the shutter/chopper or lighting by using the SHUTTER signal delivered by the
camera. If required, the system can send an external trigger or external ITC (integration
time control signal) to the camera.
The BG38 Filter is essential to achieve a correct white balance on Color Cameras and
for use with standard optics (for achromaticity purpose).
Note that the following Elements are not provided by Atmel:
Shutter (LCD or Mechanical)
BG38 (Anti-infra Red) Filter
Control Box
Lens
Light Source
+24V Power Supply
Computer
For a complete explanation of the utility of the BG38 Filter and the Shutter, please con-
sult the associated FAQ and the sample images on the Atmel's "Camera Documentation
& Software" CD-Rom.
5
CAMELIA C1 8M LVDS and CameraLink Cameras
5320AIMAGE04/03
CCD Description
Image Format
35.0 mm (V) x 23.0 mm (H)
Figure 3. Sensor Organization
Note:
The camera does not output to the 16 dark references.
Active Pixels
Pixel Geometry
Pixel pitch is 10 m x 10 m.
Figure 4. Filter Mosaic (BAYER Pattern)
Note:
The first active pixel of first active line is blue.
MPP Photosensitive Zone
Output Register
16 Dark References
3500 Lines
2300 Columns
Table 1. Active Pixels
Mode (set via serial com)
Image Size (H x V)
Timing Diagram Correspondence
No binning
2300 x 3500
H = M
V = N
2 x 2 pixel binning
1150 x 1750
4 x 4 pixel binning
574 x 875
First Column
G
R
G
R
B
G
B
G
G
R
G
R
First Line
B
G
B
G
