KSD-T0C033-000
1
Description
Medium power amplifier
Features
Large collector current : I
C
=500mA
Low collector saturation voltage enabling low-voltage operation : V
CE(sat)
= 0.25 Max.
Complementary pair with 2SA1979N
Ordering
Information
Type NO.
Marking
Package Code
2SC5342N
C5342
TO-92N
Outline Dimensions unit :
mm
2SC5342N
Epitaxial planar NPN silicon transistor
S
S
e
e
m
m
i
i
c
c
o
o
n
n
d
d
u
u
c
c
t
t
o
o
r
r
PIN Connections
1. Emitter
2. Collector
3. Base
3
.
0
9
~
3
.
2
9
0.40 Max.
1.27 Typ.
4
.
2
0
~
4
.
4
0
0.52 Max.
2.25 Max.
1
3
.
5
0
~
1
4
.
5
0
4.20~4.40
2
.
1
4
T
y
p
.
0.90 Max.
3.55 Typ
2 3
1
KSD-T0C033-000
2
2SC5342N
Absolute Maximum Ratings
(Ta=25
C)
Characteristic Symbol
Rating
Unit
Collector-base voltage
V
CBO
40 V
Collector-emitter voltage
V
CEO
32 V
Emitter-base voltage
V
EBO
5 V
Collector current
I
C
500
mA
Collector power dissipation
P
C
400
mW
Junction temperature
T
J
150 C
Storage temperature range
T
stg
-55~150 C
Electrical Characteristics
(Ta=25
C)
Characteristic Symbol
Test
Condition
Min.
Typ.
Max.
Unit
Collector-emitter breakdown voltage
BV
CEO
I
C
=1mA, I
B
=0 32
-
-
V
Collector cut-off current
I
CBO
V
CB
=40V, I
E
=0 -
-
0.1
A
Emitter cut-off current
I
EBO
V
EB
=5V, I
C
=0 -
-
0.1
A
DC current gain
h
FE
*
V
CE
=1V, I
C
=100mA 70
-
240
-
Collector-emitter saturation voltage
V
CE(sat)
I
C
=100mA, I
B
=10mA -
0.25
V
Base-emitter voltage
V
BE
V
CE
=1V, I
C
=100mA -
0.75
1.0
V
Transition frequency
f
T
V
CE
=6V, I
C
=20mA -
200
-
MHz
Collector output capacitance
C
ob
V
CB
=6V, I
E
=0, f=1MHz
-
7.0
-
pF
* : h
FE
Rank / O : 70~140, Y : 120~240
KSD-T0C033-000
4
2SC5342N
The AUK Corp. products are intended for the use as components in general electronic
equipment (Office and communication equipment, measuring equipment, home
appliance, etc.).
Please make sure that you consult with us before you use these AUK Corp. products
in equipments which require high quality and / or reliability, and in equipments which
could have major impact to the welfare of human life(atomic energy control, airplane,
spaceship, transportation, combustion control, all types of safety device, etc.). AUK
Corp. cannot accept liability to any damage which may occur in case these AUK Corp.
products were used in the mentioned equipments without prior consultation with AUK
Corp..
Specifications mentioned in this publication are subject to change without notice.
