KSD-T0C006-000
1
2SC5345N
NPN Silicon Transistor
Description
RF amplifier
Features
High transition frequency : f
T
=550MHz(Typ.) @[V
CE
=6V, I
C
=1mA]
Low output capacitance : C
ob
=1.4pF (Typ.) @[V
CB
=6V, I
E
=0]
Low base time constant and high gain
Excellent noise response
Ordering
Information
Type NO.
Marking
Package Code
2SC5345N C5345
TO-92N
Outline Dimensions unit :
mm
S
S
e
e
m
m
i
i
c
c
o
o
n
n
d
d
u
u
c
c
t
t
o
o
r
r
PIN Connections
1. Emitter
2. Collector
3. Base
3
.
0
9
~
3
.
2
9
0.40 Max.
1.27 Typ.
4
.
2
0
~
4
.
4
0
0.52 Max.
2.25 Max.
1
3
.
5
0
~
1
4
.
5
0
4.20~4.40
2
.
1
4
T
y
p
.
0.90 Max.
3.55 Typ
2 3
1
KSD-T0C006-000
2
2SC5345N
Absolute Maximum Ratings
(Ta=25
C)
Characteristic Symbol
Rating
Unit
Collector-base voltage
V
CBO
30 V
Collector-emitter voltage
V
CEO
20 V
Emitter-base voltage
V
EBO
4 V
Collector current
I
C
20
mA
Collector power dissipation
P
C
400
mW
Junction temperature
T
J
150
C
Storage temperature range range
T
stg
-55~150
C
Electrical Characteristics
(Ta=25
C)
Characteristic Symbol
Test
Condition
Min.
Typ.
Max.
Unit
Collector-emitter breakdown voltage
BV
CEO
I
C
=5mA, I
B
=0 20
-
-
V
Collector cut-off current
I
CBO
V
CB
=30V, I
E
=0 -
-
0.5
A
Emitter cut-off current
I
EBO
V
EB
=4V, I
C
=0 -
-
0.5
A
DC current gain
h
FE
*
V
CE
=6V, I
C
=1mA 40
-
240
-
Collector-emitter saturation voltage
V
CE(sat)
I
C
=10mA, I
B
=1mA -
-
0.3
V
Base-emitter voltage
V
BE
V
CE
=6V, I
C
=1mA -
0.7
0.9
V
Transition frequency
f
T
V
CE
=6V, I
C
=1mA -
550
-
MHz
Collector output capacitance
C
ob
V
CB
=6V, I
E
=0, f=1MHz
-
1.4
-
pF
* : h
FE
rank / R : 40~80, O : 70~140, Y : 120~240
KSD-T0C006-000
4
2SC5345N
Electrical Characteristic Curves
Fig. 9 I
C
- y
re
Fig. 8 I
C
- y
fe
Fig. 7 I
C
- y
oe
The AUK Corp. products are intended for the use as components in general electronic equipment
(Office and communication equipment, measuring equipment, home appliance, etc.).
Please make sure that you consult with us before you use these AUK Corp. products in equipments
which require high quality and / or reliability, and in equipments which could have major impact to the
welfare of human life(atomic energy control, airplane, spaceship, transportation, combustion control, all
types of safety device, etc.). AUK Corp. cannot accept liability to any damage which may occur in case
these AUK Corp. products were used in the mentioned equipments without prior consultation with AUK
Corp..
Specifications mentioned in this publication are subject to change without notice.
