Monitoring Relays
Product Description
Ordering Key
Housing
Function
Type
Item number
Output
Power supply
Measuring range
TRMS AC/DC over or under current
monitoring relay
Current measuring through internal shunt
Selection of measuring range by DIP-switches
Measuring ranges from 0.1 mA to 5 A AC/DC
Adjustable current on relative scale
Adjustable hysteresis on relative scale
Adjustable delay function (0.1 to 30 s)
Programmable latching or inhibit at set level
Output: 5 A SPDT relay N.D. or N.E. selectable
For mounting on DIN-rail in accordance with
DIN/EN 50 022
35.5 mm DIN-rail housing
LED indication for relay, alarm and power supply ON
Galvanically separated power supply
Input (current level)
Terminals Y1, Y2
Measuring ranges
Direct
Internal resist.
Max. curr.
Selectable by DIP-switch
..5MA: 0.1 to 1 mA AC/DC
100
40 mA
0.2 to 2 mA AC/DC
100
40 mA
0.5 to 5 mA AC/DC
100
40 mA
Max. current for 1 s
100 mA
..50MA: 1 to 10 mA AC/DC
10
120 mA
2 to 20 mA AC/DC
10
120 mA
5 to 50 mA AC/DC
10
120 mA
Max. current for 1 s
300 mA
..500MA:10 to 100 mA AC/DC
1
700 mA
20 to 200 mA AC/DC
1
700 mA
50 to 500 mA AC/DC
1
700 mA
Max. current for 1 s
1.4 A
..5A:
0.1 to 1 A AC/DC
0.03
6 A
0.2 to 2 A AC/DC
0.03
6 A
0.5 to 5 A AC/DC
0.03
6 A
Max. current for 1 s
15 A
1-Phase True RMS AC/DC Over or Under Current
Type DIB71
Input Specifications
DIB 71 C B23 5A
DIB71 is a precise TRMS
AC/DC over or under current
(selectable by DIP-switch)
monitoring relays. Direct mea-
suring or through current
transformer.
Owing to the built-in latch
function, the ON-position of
the relay output can be
maintained. Inhibit function
can be used to avoid relay
operation when not desired
(maintenance, transitions).
The LED's indicate the state
of the alarm and the output
relay. Through the built-in
shunt it is possible to moni-
tor loads up to 5 A AC/DC.
35.5 mm wide housing suit-
able both for back and front
panel mounting.
Measuring ranges (cont.)
Standard CT (examples)
AAC
rms
Max. curr.
TADK2
50 A/5 A
5 to 50 A
60 A
TAD2
150 A/5 A
15 to 150 A
180 A
TAD6
400 A/5 A
40 to 400 A
480 A
TAD12
1000 A/5 A
100 to 1000 A
1200 A
TACO200
6000 A/5 A
600 to 6000 A
7200 A
Contact input
Terminals Z1, Y1
Disabled
> 10 k
Enabled
< 500
Latch disable
> 500 ms
Type Selection
Mounting
Output
Measuring range
Supply: 24/48 VAC
Supply: 115/230 VAC
DIN-rail
SPDT
0.1 to 5 mA AC/DC
DIB 71 C B48 5mA
DIB 71 C B23 5mA
DIN-rail
SPDT
1 to 50 mA AC/DC
DIB 71 C B48 50mA
DIB 71 C B23 50mA
DIN-rail
SPDT
10 to 500 mA AC/DC
DIB 71 C B48 500mA
DIB 71 C B23 500mA
DIN-rail
SPDT
0.1 to 5 A AC/DC
DIB 71 C B48 5A
DIB 71 C B23 5A
2
Specifications are subject to change without notice (25.09.06)
Mode of Operation
DIB71 monitors both AC and
DC over or under current
through an internal shunt.
Example 1
(connection between termi-
nals Z1, Y1 - latching func-
tion enabled)
The relay operates and latch-
es in operating position
when the measured value
exceeds (or drops below) the
set level for more than the
set delay time. Provided that
the current has dropped
below (or has exceeded) the
set point (see hysteresis set-
ting), the relay releases when
the interconnection between
terminals Z1, Y1 is interrupt-
ed or the power supply is
interrupted as well.
The red LED flashes until the
delay time has expired or the
measured value comes back
to a non-alarm value (see
hysteresis setting).
Example 2 (Stardard CT)
(no connection between ter-
minals Z1, Y1 - latch func-
tion disabled)
The relay operates when the
measured value exceeds (or
drops below) the set level for
more than the set delay time.
It releases when the current
drops below (or exceeds) the
set level (see hysteresis set-
ting) or when power supply
is interrupted.
Note
When the inhibit contact is
opened, if the input signal is
already in alarm position, the
delay time needs to elapse
before relay activation.
DIB71
Power supply
Overvoltage cat. III
Rated operational voltage
(IEC 60664, IEC 60038)
through terminals:
A1, A2 or A3, A2
B48:
24/48 VAC 15%
45 to 65 Hz, insulated
B23:
115/230 VAC 15%
45 to 65 Hz, insulated
Dielectric voltage
Supply to input
4 kV (1.2/50 s)
Supply to output
4 kV (1.2/50 s)
Input to output
4 kV (1.2/50 s)
Rated operational power
AC
3 VA
Supply Specifications
Power ON delay
1 s 0.5 s or 6 s 0.5 s
Reaction time
(input signal variation from
-20% to +20% or from
+20% to -20% of set value)
Alarm ON delay
< 100 ms
Alarm OFF delay
< 100 ms
Accuracy
(15 min warm-up time)
Temperature drift
1000 ppm/C
Delay ON alarm
10% on set value 50 ms
Repeatability
0.5% on full-scale
Indication for
Power supply ON
LED, green
Alarm ON
LED, red (flashing 2 Hz
during delay time)
Output relay ON
LED, yellow
Environment
(EN 60529)
Degree of protection
IP 20
Pollution degree
3
Operating temperature
5A
-20 to 50C, R.H. < 95%
others
-20 to 60C, R.H. < 95%
Storage temperature
-30 to 80C, R.H. < 95%
Housing
Dimensions
35.5 x 81 x 67.2 mm
Material
PA66
Weight
Approx. 150 g
Screw terminals
Tightening torque
Max. 0.5 Nm
acc. to IEC 60947
Approvals
UL, CSA
CE Marking
Yes
EMC
Electromagnetic Compatibillity
Immunity
According to EN 61000-6-2
Emission
According to EN 61000-6-3
General Specifications
Output
SPDT relay
Rated insulation voltage
250 VAC
Contact ratings (AgSnO
2
)
Resistive loads
AC 1
5 A @ 250 VAC
DC 12
5 A @ 24 VDC
Small inductive loads AC 15
2.5 A @ 250 VAC
DC 13
2.5 A @ 24 VDC
Mechanical life
30 x 10
6
operations
Electrical life
10
5
operations
(at 5 A, 250 V, cos
= 1)
Operating frequency
7200 operations/h
Dielectric strength
Dielectric voltage
2 kVAC (rms)
Rated impulse withstand volt. 4 kV (1.2/50 s)
Output Specifications
Specifications are subject to change without notice (25.09.06)
3
Adjust the input range set-
ting the DIP switches 1 and
2 as shown in figure.
Select the desired function
setting the DIP switches 3 to
6 as shown in figure.
To access the DIP switches
open the plastic cover as
shown in figure.
Selection of level and time
delay:
Upper knob:
Setting of hysteresis on rela-
tive scale: 0 to 30% on set
value.
Centre knob:
Current level setting on rela-
tive scale: 10 to 110% on
full scale.
Lower knob:
Setting of delay on alarm
time on absolute scale (0.1
to 30 s).
DIB71
Function/Range/Level and Time Delay Setting
Relay working mode
ON: Normally De-energized
OFF: Normally Energized
Measuring range
SW1
ON
ON
OFF
SW2
OFF
ON
ON
5MA
1 mA
2 mA
5 mA
50MA
10 mA
20 mA
50 mA
500MA 100 mA 200 mA 500 mA
5A
1 A
2 A
5 A
Power ON delay
ON: 6 s 0.5 s
OFF: 1 s 0.5 s
Contact input
ON: Latch function enable
OFF: Inhibit function enable
Monitoring function
ON: Over current
OFF: Under current
Operation Diagrams
Over current - N.D. relay
Under current - N.D. relay
Under current - Latch function - N.D. relay
Over current - Inhibit function - N.D. relay
4
Specifications are subject to change without notice (25.09.06)
DIB71
67.2
67.2
18.7
18.7
4
5
4
5
35.5
35.5
8
1
8
1
2
Dimensions
N (-)
m
Z1
Y1
Y2
A1
A3
A2
15
16
18
L
I
N (-)
PE
m
Z1
Y1
Y2
A1
A3
A2
15
16
18
L
I
Wiring Diagrams
48/230 VAC 24/115 VAC
48/230 VAC 24/115 VAC
Latch/Inhibit
enable
Example 1
Example 2
