Continental Device India Limited
Data Sheet
Page 1 of 3
SILICON NPN HIGHVOLTAGE TRANSISTOR
NPN transistor
Marking
CMBT5551 = G
1
ABSOLUTE MAXIMUM RATINGS
Collectorbase voltage (open emitter)
V
CBO
max.
180 V
Collectoremitter voltage (open base)
V
CEO
max.
160 V
Collector current
I
C
max.
600 mA
Total power dissipation up to T
amb
= 25 C
P
tot
max
250 mW
Junction temperature
T
j
max.
150 C
Collectoremitter saturation voltage
I
C
= 50 mA; I
B
= 5 mA
V
CEsat
max.
0.2 V
D.C. current gain
I
C
= 10 mA; V
CE
= 5 V
h
FE
min.
80
RATINGS (at T
A
= 25C unless otherwise specified)
Limiting values
Collectorbase voltage (open emitter)
V
CBO
max.
180 V
Collectoremitter voltage (open base)
V
CEO
max.
160 V
Emitterbase voltage (open collector)
V
EBO
max.
6 V
CMBT5551
PACKAGE OUTLINE DETAILS
ALL DIMENSIONS IN mm
Pin configuration
1 = BASE
2 = EMITTER
3 = COLLECTOR
3
2
1
SOT-23 Formed SMD Package
Continental Device India Limited
An ISO/TS16949 and ISO 9001 Certified Company
Continental Device India Limited
Data Sheet
Page 2 of 3
Collector current
I
C
max.
600 mA
Total power dissipation up to T
amb
= 25 C
P
tot
max
250 mW
Junction temperature
T
j
max.
150 C
Storage temperature range
T
stg
55 to +150 C
THERMAL RESISTANCE
from junction to ambient
R
th ja
500 K/W
CHARACTERISTICS (at T
A
= 25C unless otherwise specified)
Collector cutoff current
I
E
= 0; V
CB
= 120 V
I
CBO
max.
50 nA
I
E
= 0; V
CB
= 120 V; T
amb
= 100 C I
CBO
max. 50
A
Emitter cutoff current
I
C
= 0; V
EB
= 4 V
I
EBO
max.
50 nA
Breakdown voltages
I
C
= 1 mA; I
B
= 0
V
(BR)CEO
min.
160 V
I
C
= 100
A; I
E
= 0 V
(BR)CBO
min. 180 V
I
C
= 0; I
E
= 10
A
V
(BR)EBO
min.
6 V
Saturation voltages
I
C
= 10 mA; I
B
= 1 mA
V
CEsat
max.
0.15 V
V
BEsat
max.
1 V
I
C
= 50 mA; I
B
= 5 mA
V
CEsat
max.
0.2 V
V
BEsat
max.
1 V
D.C. current gain
I
C
= 1 mA; V
CE
= 5 V
h
FE
min.
80
min.
80
I
C
= 10 mA; V
CE
= 5 V
h
FE
max.
250
I
C
= 50 mA; V
CE
= 5 V
h
FE
min.
30
Smallsignal current gain
min.
50
I
C
= 1 mA; V
CE
= 10 V; f = 1 kHz
h
fe
max.
200
Output capacitance at f = 1 MHz
I
E
= 0; V
CB
= 10 V
C
o
max.
6 pF
Input capacitance at f = 1 MHz
I
C
= 0; V
EB
= 0.5 V
C
i
max.
30 pF
Transition frequency at f = 100 MHz
min.
100 MHz
I
C
= 10 mA; V
CE
= 10 V
f
T
max.
300 MHz
CMBT5551
Continental Device India Limited
Data Sheet Page 3 of 3
