DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMHSH5-2L
type is a Silicon Schottky Rectifier, epoxy molded
in a surface mount package, designed for high
current, fast switching applications requiring a
low forward voltage drop.
The Marking Code is C2L.
CMHSH5-2L
SURFACE MOUNT
SCHOTTKY RECTIFIER
500mA, 20 VOLTS
LOW FORWARD VOLTAGE
SOD-123 CASE
Central
Semiconductor Corp.
TM
MAXIMUM RATINGS (TA=25C unless otherwise noted)
SYMBOL
UNITS
Peak Repetitive Reverse Voltage
VRRM
20
V
Peak Working Reverse Voltage
VRWM
20
V
DC Blocking Voltage
VR
20
V
Average Rectified Current
IO
500
mA
Peak Forward Surge Current
(@ rated load, halfwave, single phase, 60Hz)
IFSM
5.5
A
Junction Temperature
TJ
-65 to +125
C
Storage Temperature
Tst
-65 to +150
C
Thermal Resistance
JL
150
C/W
Thermal Resistance
JA
340
C/W
ELECTRICAL CHARACTERISTICS (TA=25C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNITS
IR
VR=10V
75
A
IR
VR=10V, TA=100C
5.0
mA
IR
VR=20V
250
A
IR
VR=20V, TA=100C
8.0
mA
VF
IF=100mA
300
mV
VF
IF=100mA, TA=100C
220
mV
VF
IF=500mA
385
mV
VF
IF=500mA, TA=100C
330
mV
CT
VR=4.0V, f=1.0MHz
60
pF
L O W
VF
