Central
Semiconductor Corp.
TM
266
SMB CASE
CMR1S-01
CMR1S-02
SUPER FAST RECOVERY RECTIFIER
1.0 AMP, 100 AND 200 VOLTS
MAXIMUM RATINGS:
(TA=25C unless otherwise noted)
SYMBOL
CMR1S
CMR1S
__-01__
-02__ UNITS
Peak Repetitive Reverse Voltage
VRRM
100
200 V
DC Blocking Voltage
VR
100
200 V
RMS Reverse Voltage
VR(RMS)
70
140 V
Average Forward Current
IO
1.0
A
Peak Forward Surge Current (8.3ms)
IFSM
30
A
Operating and Storage
Junction Temperature
TJ,Tstg -65 to +150
C
Thermal Resistance
Q
JL
20
C/W
ELECTRICAL CHARACTERISTICS: (TA=25C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
TYP MAX UNITS
IR
VR=Rated VRRM
5.0
m
A
IR
VR=Rated VRRM, TA=100C
500
m
A
VF
IF=1.0A
0.95 V
trr
IF=0.5A, IR=1.0A, Recover to 0.25A
35 ns
CJ
VR=4.0V, f=1.0MHz
10
pF
DESCRIPTION:
The Central Semiconductor 1.0 Amp Surface Mount Silicon Super Fast Recovery Rectifier is a high
quality, well constructed, highly reliable component designed for use in all types of commercial, industrial,
entertainment, computer, and automotive applications. To order devices on 12mm Tape and Reel (3000/
13" Reel), add TR13 suffix to part number.
FEATURES:
FASTER SWITCHING SPEED (35ns Max)
LOWER VF (.95V)
RUNS COOLER THAN ULTRA FAST RECTIFIER
LOW COST - HIGH RELIABILITY
GLASS PASSIVATED CHIP
"C" BEND CONSTRUCTION PROVIDES STRAIN
RELIEF WHEN MOUNTED ON PC BOARD
NEW
SUPER
FAST
