CS4272

24-Bit, 192 kHz Stereo Audio CODEC

D/A Features

High Performance

114 dB Dynamic Range
-100 dB THD+N

Up to 192 kHz Sampling Rates

Differential Analog Architecture

Volume Control with Soft Ramp

1 dB Step Size
Zero Crossing Click-free Transitions

Selectable Digital Filters

Fast and Slow Roll Off

ATAPI Mixing Functions

Selectable Serial Audio Interface Formats

Left Justified up to 24-bit
I

S up to 24-bit

Right Justified 16-, 18-, 20-, and 24-Bit

Control Output for External Muting

Selectable 50/15

s De-emphasis

A/D Features

High Performance

114 dB Dynamic Range
-100 dB THD+N

Up to 192 kHz Sampling Rates

Differential Analog Architecture

Multi-bit Delta Sigma Conversion

High-pass Filter or DC Offset Calibration

Low-Latency Digital Anti-alias Filtering

Automatic Dithering of 16-bit Data

Selectable Serial Audio Interface Formats

Left Justified up to 24-bit
I

S up to 24-bit

System Features

Direct Interface with 5V to 2.5V Logic Levels

Internal Digital Loopback

On-chip Oscillator

Stand-Alone or Control Port Functionality

2.5 V to 5 V

Left and

Right Mute

Controls

Modulator

Low-Latency

Anti-Alias Filter

External

Mute Control

Configuration

Internal Voltage

Reference

Internal

Oscillator

Volume

Control

Selectable

Interpolation

Filter

Selectable

Interpolation

Filter

Reset

Left

Differential

Output

Right

Differential

Output

Switched Capacitor

DAC and Filter

Multibit

Oversampling

ADC

Multibit

Oversampling

ADC

Low-Latency

Anti-Alias Filter

High Pass Filter &

DC Offset Calibration

High Pass Filter &

DC Offset Calibration

ri
a

l
Inte

rfac

e / Loo

pba

c
k

Left

Differential

Input

Right

Differential

Input

Volume

Control

L
e
ve

l T

r
a

n
s
l
ator

v
e
l Tra

n
s
lat

o
r

Serial

Audio

Input

Serial

Audio

Output

3.3 V to 5 V

5 V

Hardware or

C/SPI

Control Data

Switched Capacitor

DAC and Filter

AUGUST '05

DS593F1

CS4272

DS593F1

Stand-Alone Mode Feature Set

System Features

Serial Audio Port Master or Slave Operation
Internal Oscillator for Master Clock

D/A Features

Auto-mute on Static Samples
44.1 kHz 50/15

s De-emphasis Available

Selectable Serial Audio Interface Formats

Left Justified up to 24-bit

S up to 24-bit

A/D Features

Automatic Dithering for 16-bit Data
High-pass Filter
Selectable Serial Audio Interface Formats

Left Justified up to 24-bit

S up to 24-bit

Software Mode Feature Set

System Features

Serial Audio Port Master or Slave Operation
Internal Oscillator for Master Clock
Internal Digital Loopback Available

D/A Features

Selectable Auto-mute
Selectable Interpolation Filters
Selectable 32-, 44.1-, and 48-kHz De-emphasis

Filters

Configurable ATAPI Mixing Functions
Configurable Volume and Muting Controls
Selectable Serial Audio Interface Formats

Left Justified up to 24-bit

S up to 24-bit

Right Justified 16, 18, 20, and 24-bit

A/D Features

Selectable Dithering for 16-bit Data
Selectable High-pass Filter or DC Offset Calibration
Selectable Serial Audio Interface Formats

Left Justified up to 24-bit

S up to 24-bit

General Description

The CS4272 is a high-performance, integrated audio
CODEC. The CS4272 performs stereo analog-to-digital
(A/D) and digital-to-analog (D/A) conversion of up to
24-bit serial values at sample rates up to 192 kHz.

The D/A offers a volume control that operates with a
1 dB step size. It incorporates selectable soft ramp and
zero crossing transition functions to eliminate clicks and
pops.

The D/A's integrated digital mixing functions allow a va-
riety of output configurations ranging from a channel
swap to a stereo-to-mono downmix.

Standard 50/15

s de-emphasis is available for sam-

pling rates of 32, 44.1, and 48 kHz for compatibility with
digital audio programs mastered using the 50/15

s pre-

emphasis technique.

Integrated level translators allow easy interfacing be-
tween the CS4272 and other devices operating over a
wide range of logic levels.

An on-chip oscillator eliminates the need for an external
crystal oscillator circuit. This can reduce overall design
cost and conserve circuit board space. The CS4272 au-
tomatically uses the on-chip oscillator in the absence of
an applied master clock, making this feature easy to
use.

Independently addressable high-pass filters are avail-
able for the right and left channel of the A/D. This allows
the A/D to be used in a wide variety of applications
where one audio channel and one DC measurement
channel is desired.

The CS4272's wide dynamic range, negligible distor-
tion, and low noise make it ideal for applications such as
A/V receivers, DVD-R, CD-R, digital mixing consoles,
effects processors, set-top box systems, and automo-
tive audio systems.

Ordering Information

Product

Description

Package

Pb-Free

Grade

Temp Range

Container Order #

CS4272

24-Bit, 192 kHz

Stereo Audio CODEC

28-pin

TSSOP

YES

Commercial -10°

+70° C

Tube

CS4272-CZZ

Tape & Reel CS4272-CZZR

Automotive

-40° to +85° C

Tube

CS4272-DZZ

Tape & Reel CS4272-DZZR

CDB4272

CS4272 Evaluation Board

CDB4272

CS4272

DS593F1

TABLE OF CONTENTS

1. PIN DESCRIPTIONS - SOFTWARE MODE ............................................................................. 5
2. PIN DESCRIPTIONS - STAND-ALONE MODE ....................................................................... 7
3. CHARACTERISTICS AND SPECIFICATIONS ........................................................................ 9

SPECIFIED OPERATING CONDITIONS................................................................................. 9
ABSOLUTE MAXIMUM RATINGS ........................................................................................... 9
DAC ANALOG CHARACTERISTICS - COMMERCIAL GRADE............................................ 10
DAC ANALOG CHARACTERISTICS - AUTOMOTIVE GRADE ............................................ 11
DAC COMBINED INTERPOLATION & ON-CHIP ANALOG FILTER RESPONSE................ 12
ADC ANALOG CHARACTERISTICS - COMMERCIAL GRADE............................................ 14
ADC ANALOG CHARACTERISTICS - AUTOMOTIVE GRADE ............................................ 15
ADC DIGITAL FILTER CHARACTERISTICS......................................................................... 16
DC ELECTRICAL CHARACTERISTICS ................................................................................ 17
DIGITAL CHARACTERISTICS............................................................................................... 17
SWITCHING CHARACTERISTICS - SERIAL AUDIO PORT................................................. 18
SWITCHING CHARACTERISTICS - I²C MODE CONTROL PORT....................................... 21
SWITCHING CHARACTERISTICS - SPI CONTROL PORT ................................................. 22

4. TYPICAL CONNECTION DIAGRAM ..................................................................................... 23
5. APPLICATIONS ..................................................................................................................... 24

5.1 Stand-Alone Mode ........................................................................................................... 24

5.1.1 Recommended Power-Up Sequence ................................................................. 24
5.1.2 Master/Slave Mode ............................................................................................. 24
5.1.3 System Clocking ................................................................................................. 24

5.1.3.1 Crystal Applications (XTI/XTO) ........................................................... 24
5.1.3.2 Clock Ratio Selection .......................................................................... 25

5.1.4 16-Bit Auto-Dither ............................................................................................... 26
5.1.5 Auto-Mute ........................................................................................................... 26
5.1.6 High Pass Filter ................................................................................................... 26
5.1.7 Interpolation Filter .............................................................................................. 26
5.1.8 Mode Selection & De-Emphasis ......................................................................... 26
5.1.9 Serial Audio Interface Format Selection ............................................................. 26

5.2 Control Port Mode ........................................................................................................... 27

5.2.1 Recommended Power-Up Sequence - Access to Control Port Mode ................ 27
5.2.2 Master / Slave Mode Selection ........................................................................... 27
5.2.3 System Clocking ................................................................................................. 27

5.2.3.1 Crystal Applications (XTI/XTO) ........................................................... 27
5.2.3.2 Clock Ratio Selection .......................................................................... 28

5.2.4 Internal Digital Loopback .................................................................................... 30
5.2.5 Dither for 16-Bit Data .......................................................................................... 30
5.2.6 Auto-Mute ........................................................................................................... 30
5.2.7 High Pass Filter and DC Offset Calibration ......................................................... 30
5.2.8 Interpolation Filter .............................................................................................. 31
5.2.9 De-Emphasis ...................................................................................................... 31
5.2.10 Oversampling Modes ........................................................................................ 31

5.3 De-Emphasis Filter .......................................................................................................... 31
5.4 Analog Connections ........................................................................................................ 32

5.4.1 Input Connections ............................................................................................... 32
5.4.2 Output Connections ............................................................................................ 33

5.5 Mute Control .................................................................................................................... 34
5.6 Synchronization of Multiple Devices ................................................................................ 34
5.7 Grounding and Power Supply Decoupling ....................................................................... 34

6. CONTROL PORT INTERFACE .............................................................................................. 35

CS4272

DS593F1

6.1 SPI Mode ......................................................................................................................... 35
6.2 I²C Mode .......................................................................................................................... 36

7. REGISTER QUICK REFERENCE .......................................................................................... 37
8. REGISTER DESCRIPTION .................................................................................................... 38

8.1 Mode Control 1 - Address 01h ......................................................................................... 38

8.1.1 Functional Mode (Bits 7:6) .................................................................................. 38
8.1.2 Ratio Select (Bits 5:4) ......................................................................................... 38
8.1.3 Master / Slave Mode (Bit 3) ................................................................................. 38
8.1.4 DAC Digital Interface Format (Bits 2:0) ............................................................... 38

8.2 DAC Control - Address 02h ............................................................................................. 39

8.2.1 Auto-Mute (Bit 7) ................................................................................................. 39
8.2.2 Interpolation Filter Select (Bit 6) .......................................................................... 39
8.2.3 De-Emphasis Control (Bits 5:4) ........................................................................... 39
8.2.4 Soft Volume Ramp-Up After Error (Bit 3) ............................................................ 40
8.2.5 Soft Ramp-Down Before Filter Mode Change (Bit 2) .......................................... 40
8.2.6 Invert Signal Polarity (Bits 1:0) ............................................................................ 40

8.3 DAC Volume & Mixing Control - Address 03h ................................................................. 40

8.3.1 Channel B Volume = Channel A Volume (Bit 6) ................................................. 40
8.3.2 Soft Ramp or Zero Cross Enable (Bits 5:4) ......................................................... 40
8.3.3 ATAPI Channel Mixing and Muting (Bits 3:0) ...................................................... 41

8.4 DAC Channel A Volume Control - Address 04h .............................................................. 42
8.5 DAC Channel B Volume Control - Address 05h .............................................................. 42

8.5.1 Mute (Bit 7) .......................................................................................................... 42
8.5.2 Volume Control (Bits 6:0) .................................................................................... 42

8.6 ADC Control - Address 06h ............................................................................................. 43

8.6.1 Dither for 16-Bit Data (Bit 5) ................................................................................ 43
8.6.2 ADC Digital Interface Format (Bit 4) .................................................................... 43
8.6.3 ADC Channel A & B Mute (Bits 3:2) .................................................................... 43
8.6.4 Channel A & B High Pass Filter Disable (Bits 1:0) .............................................. 43

8.7 Mode Control 2 - Address 07h ......................................................................................... 43

8.7.1 Digital Loopback (Bit 4) ....................................................................................... 43
8.7.2 AMUTEC = BMUTEC (Bit 3) ............................................................................... 43
8.7.3 Freeze (Bit 2) ...................................................................................................... 44
8.7.4 Control Port Enable (Bit 1) .................................................................................. 44
8.7.5 Power Down (Bit 0) ............................................................................................. 44

8.8 Chip ID - Register 08h ..................................................................................................... 44

8.8.1 Chip ID (Bits 7:4) ................................................................................................. 44
8.8.2 Chip Revision (Bits 3:0) ....................................................................................... 44

9. PARAMETER DEFINITIONS .................................................................................................. 45
10. PACKAGE DIMENSIONS ..................................................................................................... 46
11. APPENDIX ............................................................................................................................ 47

CS4272

DS593F1

Pin Name

Pin Description

XTO
XTI

1,2

Crystal Connections (Input/Output) - I/O pins for an external crystal which may be used to generate
MCLK. See "Crystal Applications (XTI/XTO)" on page 24 or "Crystal Applications (XTI/XTO)" on page 27.

MCLK

Master Clock (Input/Output) -Clock source for the delta-sigma modulators. See "Crystal Applications
(XTI/XTO)" on page 24 or "Crystal Applications (XTI/XTO)" on page 27.

LRCK

Left Right Clock (Input/Output) - Determines which channel, Left or Right, is currently active on the
serial audio data line.

SCLK

Serial Clock (Input/Output) - Serial clock for the serial audio interface.

SDOUT

Serial Audio Data Output (Output) - Output for two's complement serial audio data.

SDIN

Serial Audio Data Input (Input) - Input for two's complement serial audio data.

DGND

Digital Ground (Input) - Ground reference for the internal digital section.

Digital Power (Input) - Positive power for the internal digital section.

Logic Power (Input) - Positive power for the digital input/output interface.

SCL/CCLK

Serial Control Port Clock (Input) - Serial clock for the serial control port.

SDA/CDIN

Serial Control Data (Input/Output) - SDA is a data I/O in I²C mode. CDIN is the input data line for the
control port interface in SPI mode.

AD0/CS

Address Bit 0 (I²C) / Control Port Chip Select (SPI) (Input) - AD0 is a chip address pin in I²C mode; CS
is the chip select signal for SPI format.

RST

Reset (Input) - The device enters a low power mode when this pin is driven low.

VCOM

Common Mode Voltage (Output) - Filter connection for internal common mode voltage.

AINA-
AINA+
AINB+
AINB-

16,
17,
18,

Differential Analog Input (Input) - The full scale differential input signals are presented to the delta-
sigma modulators. The full scale level is specified in the ADC Analog Characteristics specification table.

Analog Power (Input) - Positive power for the internal analog section.

AGND

Analog Ground (Input) - Ground reference for the internal analog section.

FILT+

Positive Voltage Reference (Output) - Positive reference voltage for the internal sampling circuits.

AMUTEC

Channel A Mute Control (Output) - This pin is active during power-up initialization, reset, muting, when
master clock to left/right clock frequency ratio is incorrect, or power-down.

AOUTA-
AOUTA+
AOUTB+
AOUTB-

24,
25,
26,

Differential Analog Audio Output (Output) - The full scale differential output level is specified in the
DAC Analog Characteristics specification table.

BMUTEC

Channel B Mute Control (Output) - This pin is active during power-up initialization, reset, muting, when
master clock to left/right clock frequency ratio is incorrect, or power-down.

CS4272

DS593F1

Pin Name

Pin Description

XTO
XTI

1,2

Crystal Connections (Input/Output) - I/O pins for an external crystal which may be used to generate the
master clock. See "Crystal Applications (XTI/XTO)" on page 24 or "Crystal Applications (XTI/XTO)" on
page 27.

MCLK

Master Clock (Input/Output) -Clock source for the delta-sigma modulators. See "Crystal Applications
(XTI/XTO)" on page 24 or "Crystal Applications (XTI/XTO)" on page 27.

LRCK

Left Right Clock (Input/Output) - Determines which channel, Left or Right, is currently active on the
serial audio data line.

SCLK

Serial Clock (Input/Output) - Serial clock for the serial audio interface.

SDOUT
(M/S)

Serial Audio Data Output (Output) - Output for two's complement serial audio data. This pin must be
pulled-up or pulled-down to select Master or Slave Mode. See "Master/Slave Mode" on page 24.

SDIN

Serial Audio Data Input (Input) - Input for two's complement serial audio data.

DGND

Digital Ground (Input) - Ground reference for the internal digital section.

Digital Power (Input) - Positive power for the internal digital section.

Logic Power (Input) - Positive power for the digital input/output interface.

Mode Select 0 (Input) - In conjunction with M1, selects operating mode. Functionality is described in the
Hardware Mode Speed Configuration table.

Mode Select 1 (Input) - In conjunction with M0, selects operating mode. Functionality is described in the
Hardware Mode Speed Configuration table.

I2S/LJ

Serial Audio Interface Select (Input) - Selects either the left-justified or I

S format for the Serial Audio

Interface.

RST

Reset (Input) - The device enters a low power mode when this pin is driven low.

VCOM

Common Mode Voltage (Output) - Filter connection for internal common mode voltage.

AINA-
AINA+
AINB+
AINB-

16,
17,
18,

Analog Power (Input) - Positive power for the internal analog section.

AGND

Analog Ground (Input) - Ground reference for the internal analog section.

FILT+

Positive Voltage Reference (Output) - Positive reference voltage for the internal sampling circuits.

AMUTEC

Channel A Mute Control (Output) - This pin is active during power-up initialization, reset, muting, when
master clock to left/right clock frequency ratio is incorrect, or power-down.

AOUTA-
AOUTA+
AOUTB+
AOUTB-

24,
25,
26,

Differential Analog Audio Output (Output) - The full scale differential output level is specified in the
Analog Characteristics specification table.

BMUTEC

Channel B Mute Control (Output) - This pin is active during power-up initialization, reset, muting, when
master clock to left/right clock frequency ratio is incorrect, or power-down.

CS4272

DS593F1

CHARACTERISTICS AND SPECIFICATIONS

(All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical
performance characteristics and specifications are derived from measurements taken at nominal supply voltages
and T

= 25

C.)

SPECIFIED OPERATING CONDITIONS

(AGND = 0 V; all voltages with respect to ground.)

ABSOLUTE MAXIMUM RATINGS

(GND = 0 V, All voltages with respect to ground.) (Note 1)

Notes: 1. Operation beyond these limits may result in permanent damage to the device.

Normal operation is not guaranteed at these extremes.

2. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause

SCR latch-up.

Parameters

Symbol Min Nom

Max

Units

DC Power Supplies:

Positive Analog

Positive Digital

Positive Logic

4.75

3.1

2.37

5.0
3.3
3.3

5.25
5.25
5.25

V
V
V

Ambient Operating Temperature (Power Applied)

Commercial Grade

Automotive Grade

-10
-40

-
-

+70
+85

Parameter

Symbol

Min

Typ

Max

Units

DC Power Supplies:

Analog

Logic

Digital

-0.3
-0.3
-0.3

-
-
-

+6.0
+6.0
+6.0

V
V
V

Input Current

(Note 2)

Analog Input Voltage

GND-0.3

VA+0.3

Digital Input Voltage

IND

-0.3

VL+0.3

Ambient Operating Temperature (Power Applied)

-50

+95

Storage Temperature

stg

-65

+150

CS4272

DS593F1

DAC ANALOG CHARACTERISTICS - COMMERCIAL GRADE

(Notes 3 to 7)

Notes: 3. One-half LSB of Triangular PDF dither is added to data.

4. Performance measurements taken with a full-scale 997 Hz sine wave under Test load R

= 3 k

, C

10 pF

5. Measurement bandwidth is 10 Hz to 20 kHz.
6. Logic "0" = GND = 0V; Logic "1" = VL; VL = VA unless otherwise noted.
7. V

is tested under load R

but does not include attenuation due to Z

OUT

Parameter

Symbol

Min

Typ

Max

Unit

Dynamic Performance
Dynamic Range

24-Bits A-Weighted

unweighted

16-Bits unweighted

108
105

114

111

-
-
-

dB
dB
dB

Total Harmonic Distortion + Noise

0 dB

-20 dB

-60 dB

THD+N

-
-
-

-100

-91
-51

-94

-45

dB
dB
dB

Idle Channel Noise / Signal-to-Noise Ratio

114

Interchannel Isolation

(1 kHz)

100

DC Accuracy
Interchannel Gain Mismatch

ICGM

0.1

Gain Drift

100

ppm/°C

Analog Output Characteristics and Specifications
Full Scale Differential Output Voltage

0.91xVA

0.96xVA

1.01xVA

Vpp

Output Resistance

(note 7)

out

100

Minimum AC-Load Resistance

Maximum Load Capacitance

100

CS4272

DS593F1

DAC COMBINED INTERPOLATION & ON-CHIP ANALOG FILTER RESPONSE

(cont) (Note 12)

Notes: 8. Slow Roll-Off interpolation filter is only available in control port mode.

9. Response is clock dependent and will scale with Fs. Note that the response plots (Figures 21 to 44) have

been normalized to Fs and can be de-normalized by multiplying the X-axis scale by Fs.

10. Single and Double Speed Mode Measurement Bandwidth is from stopband to 3 Fs.

Quad Speed Mode Measurement Bandwidth is from stopband to 1.34 Fs.

11. De-emphasis is available only in Single Speed Mode; Only 44.1 kHz De-emphasis is available in Stand-

Alone Mode.

12. Plots of this data are contained in the "Appendix" on page 47. See Figure 21 through Figure 44.

Parameter

Slow Roll-Off (Note 8)

Unit

Min

Typ

Max

Single Speed Mode - 48 kHz
Passband (Note 9)

to -0.01 dB corner

to -3 dB corner

0
0

-
-

0.417
0.499

Fs
Fs

Frequency Response 10 Hz to 20 kHz

-0.01

+0.01

StopBand

.583

StopBand Attenuation

(Note 10)

Group Delay

6.5/Fs

De-emphasis Error (Note 11)

Fs = 32 kHz

(Relative to 1 kHz)

Fs = 44.1 kHz

Fs = 48 kHz

-
-
-

±0.23
±0.14
±0.09

dB
dB
dB

Double Speed Mode - 96 kHz
Passband (Note 9)

to -0.01 dB corner

to -3 dB corner

0
0

-
-

.296
.499

Fs
Fs

Frequency Response 10 Hz to 20 kHz

-0.01

0.01

StopBand

.792

StopBand Attenuation

(Note 10)

Group Delay

3.9/Fs

Quad Speed Mode - 192 kHz
Passband (Note 9)

to -0.01 dB corner

to -3 dB corner

0
0

-
-

.104
.481

Fs
Fs

Frequency Response 10 Hz to 20 kHz

-0.01

0.01

StopBand

.868

StopBand Attenuation

(Note 10)

Group Delay

4.2/Fs

CS4272

DS593F1

ADC ANALOG CHARACTERISTICS - COMMERCIAL GRADE

Measurement Bandwidth is 10 Hz to 20 kHz unless otherwise specified. Input is 1 kHz sine wave.

Notes: 13. Referred to the typical full-scale input voltage.
Notes: 14. Measured between AIN+ and AIN-

Parameter

Symbol

Min

Typ Max

Unit

Single Speed Mode Fs = 48 kHz

Dynamic Range

A-weighted

unweighted

108
105

114

111

-
-

dB
dB

Total Harmonic Distortion + Noise (Note 13)

-1 dB

-20 dB
-60 dB

THD+N

-
-
-

-100

-91
-51

-94

-
-

dB
dB
dB

Double Speed Mode Fs = 96 kHz

Dynamic Range

A-weighted

unweighted

40 kHz bandwidth unweighted

108
105

114

111

108

-
-
-

dB
dB
dB

Total Harmonic Distortion + Noise (Note 13)

-1 dB

-20 dB
-60 dB

40 kHz bandwidth -1 dB

THD+N

-
-
-
-

-100

-91
-51
-97

-94

-
-
-

dB
dB
dB
dB

Quad Speed Mode Fs = 192 kHz

Dynamic Range

A-weighted

unweighted

40 kHz bandwidth unweighted

108
105

114

111

108

-
-
-

dB
dB
dB

Total Harmonic Distortion + Noise (Note 13)

-1 dB

-20 dB
-60 dB

40 kHz bandwidth -1 dB

THD+N

-
-
-
-

-100

-91
-51
-97

-94

-
-
-

dB
dB
dB
dB

Dynamic Performance for All Modes
Interchannel Isolation

110

Interchannel Phase Deviation

0.0001

Degree

DC Accuracy
Interchannel Gain Mismatch

0.1

Gain Error

Gain Drift

100

ppm/°C

Offset Error

HPF enabled

HPF disabled

-
-

100

-
-

LSB
LSB

Analog Input Characteristics
Full-scale Input Voltage

1.07xVA

1.13xVA

1.19xVA

Vpp

Input Impedance (Differential)

(Note 14)

Common Mode Rejection Ratio

CMRR

CS4272

DS593F1

ADC ANALOG CHARACTERISTICS - AUTOMOTIVE GRADE

Measurement Bandwidth is 10 Hz to 20 kHz unless otherwise specified. Input is 1 kHz sine wave.)

Notes: 15. Referred to the typical full-scale input voltage.
Notes: 16. Measured between AIN+ and AIN-

Parameter

Symbol

Min

Typ Max

Unit

Single Speed Mode Fs = 48 kHz

Dynamic Range

A-weighted

unweighted

106
103

114

111

-
-

dB
dB

Total Harmonic Distortion + Noise (Note 15)

-1 dB

-20 dB
-60 dB

THD+N

-
-
-

-100

-91
-51

-92

-
-

dB
dB
dB

Double Speed Mode Fs = 96 kHz

Dynamic Range

A-weighted

unweighted

40 kHz bandwidth unweighted

106
103

114

111

108

-
-
-

dB
dB
dB

Total Harmonic Distortion + Noise (Note 15)

-1 dB

-20 dB
-60 dB

40 kHz bandwidth -1 dB

THD+N

-
-
-
-

-100

-91
-51
-97

-92

-
-
-

dB
dB
dB
dB

Quad Speed Mode Fs = 192 kHz

Dynamic Range

A-weighted

unweighted

40 kHz bandwidth unweighted

106
103

114

111

108

-
-
-

dB
dB
dB

Total Harmonic Distortion + Noise (Note 15)

-1 dB

-20 dB
-60 dB

40 kHz bandwidth -1 dB

THD+N

-
-
-
-

-100

-91
-51
-97

-92

-
-
-

dB
dB
dB
dB

Dynamic Performance for All Modes
Interchannel Isolation

110

Interchannel Phase Deviation

0.0001

Degree

DC Accuracy
Interchannel Gain Mismatch

0.1

Gain Error

Gain Drift

100

ppm/°C

Offset Error

HPF enabled

HPF disabled

-
-

100

-
-

LSB
LSB

Analog Input Characteristics
Full-scale Input Voltage

1.07xVA

1.13xVA

1.19xVA

Vpp

Input Impedance (Differential)

(Note 16)

Common Mode Rejection Ratio

CMRR

CS4272

DS593F1

ADC DIGITAL FILTER CHARACTERISTICS

(Note 19)

Notes: 17. The filter frequency response scales precisely with Fs.

18. Response shown is for Fs equal to 48 kHz. Filter characteristics scale with Fs.
19. Plots of this data are contained in the "Appendix" on page 47. See Figure 45 through Figure 56.

Parameter

Symbol

Min

Typ

Max

Unit

Single Speed Mode
Passband

(-0.1 dB).

(Note 17)

0.47

Passband Ripple.

0.035

Stopband. (Note

17)

0.58

Stopband Attenuation.

-95

Group Delay.

12/Fs

Double Speed Mode
Passband

(-0.1 dB).

(Note 17)

0.45

Passband Ripple.

0.035

Stopband. (Note

17)

0.68

Stopband Attenuation.

-92

Group Delay.

9/Fs

Quad Speed Mode
Passband

(-0.1 dB).

(Note 17)

0.24

Passband Ripple.

0.035

Stopband. (Note

17)

0.78

Stopband Attenuation.

-97

Group Delay.

5/Fs

High Pass Filter Characteristics
Frequency Response -3.0 dB.

-0.13 dB.

(Note 18)

-
-

Hz
Hz

Phase Deviation

@ 20 Hz.

(Note 18)

Deg

Passband Ripple.

Filter Settling Time.

/Fs

CS4272

DS593F1

DC ELECTRICAL CHARACTERISTICS

(GND = 0 V, all voltages with respect to ground. MCLK=12.288 MHz; Master Mode)

Notes: 20. Power Down Mode is defined as RST = Low with all clocks and data lines held static.

21. Valid with the recommended capacitor values on FILT+ and VCOM as shown in the Typical Connection

Diagram.

DIGITAL CHARACTERISTICS

Parameter

Symbol

Min

Typ

Max

Unit

Power Supply
Power Supply Current

(Normal Operation)

VL,VD = 5 V

VL,VD = 3.3 V

-
-
-

41.5

53
49
28

mA
mA
mA

Power Supply Current

(Power-Down Mode)(Note 20)

VL,VD=5 V

-
-

0.025

1.76

-
-

mA
mA

Power Consumption

VL, VD=5 V

(Normal Operation)

VL, VD = 3.3 V

(Power-Down Mode)

-
-
-

433
305

510
358

mW
mW
mW

Power Supply Rejection Ratio (1 kHz)

(Note 21)

PSRR

Common Mode
Nominal Common Mode Voltage

VCOM

0.48xVA

VDC

Maximum DC Current Source/Sink from VCOM

VCOM Output Impedance

FILT+
FILT+ Nominal Voltage

FILT+

VDC

MUTEC
MUTEC Low-Level Output Voltage

MUTEC High-Level Output Voltage

Maximum MUTEC Drive Current

Parameter

Symbol

Min

Typ

Max

Units

High-Level Input Voltage

(% of VL)

70%

Low-Level Input Voltage

(% of VL)

30%

High-Level Output Voltage at I

= 2 mA

VL - 1.0

Low-Level Output Voltage at I

= 2 mA

0.4

Input Leakage Current

CS4272

DS593F1

SWITCHING CHARACTERISTICS - SERIAL AUDIO PORT

(Logic "0" = GND = 0 V;

Logic "1" = VL, C

= 20 pF)

Notes: 22. In Control Port Mode, the Ratio[1:0] bits must be configured according to tables 8 and 9 on

pages 28 and 29.

Parameter

Symbol

Min

Typ

Max

Unit

Sample Rate

Single Speed Mode

Double Speed Mode

Quad Speed Mode

Fs
Fs
Fs

100

-
-
-

100
200

kHz
kHz
kHz

MCLK Specifications
MCLK Frequency

Stand-Alone Mode

(note 22)

Control Port Mode

mclk

1.024
1.024

-
-

25.600
51.200

MHz
MHz

MCLK Input Pulse Width High/Low

Stand-Alone Mode

(note 22)

Control Port Mode

clkhl

-
-

ns
ns

MCLK Output Duty Cycle

Master Mode
LRCK Duty Cycle

SCLK Duty Cycle

SCLK falling to LRCK edge

slr

-10

SCLK falling to SDOUT valid

sdo

SDIN valid to SCLK rising setup time

sdis

SCLK rising to SDIN hold time

sdih

Slave Mode
LRCK Duty Cycle

SCLK Period
(note 22)

Single Speed Mode

Double Speed Mode

Quad Speed Mode

sclkw

SCLK Pulse Width High

sclkh

SCLK Pulse Width Low

sclkl

SCLK falling to LRCK edge

slr

-10

SCLK falling to SDOUT valid

sdo

SDIN valid to SCLK rising setup time

sdis

SCLK rising to SDIN hold time

sdih

Crystal Oscillator Specifications (XTI/XTO)
Crystal Frequency Range

osc

16.384

25.600

MHz

128

(

)

---------------------

128

(

)

---------------------

( )

------------------

CS4272

DS593F1

5. APPLICATIONS

5.1

Stand-Alone Mode

5.1.1

Recommended Power-Up Sequence

1) When using the CS4272 with an external MCLK, hold RST low until the power supply, MCLK, and LRCK are

stable. When using the CS4272 with internally generated MCLK, hold RST low until the power supply is stable.

2) Bring RST high. If the internally generated MCLK is being used, it will appear on the MCLK pin prior to 1 ms from

the release of RST.

5.1.2

Master/Slave Mode

The CS4272 supports operation in either Master Mode or Slave Mode.
In Master Mode, LRCK and SCLK are outputs and are synchronously generated on-chip. LRCK is equal to Fs and
SCLK is equal to 64x Fs.
In Slave Mode, LRCK and SCLK are inputs, requiring external generation that is synchronous to MCLK. It is recom-
mended that SCLK be 64x Fs to maximize system performance.
In Stand-Alone Mode, the CS4272 will default to Slave Mode. Master Mode may be accessed by placing a 47 k

pull-up to VL on the SDOUT (M/S) pin.
Configuration of clock ratios in each of these modes will be outlined in the Tables 3 and 4.

5.1.3

System Clocking

The CS4272 will operate at sampling frequencies from 4 kHz to 200 kHz. This range is divided into three speed
modes as shown in Table 1 below.

5.1.3.1 Crystal Applications (XTI/XTO)

An external crystal may be used in conjunction with the CS4272 to generate the master clock signal. To accomplish
this, a 20 pF fundamental mode parallel resonant crystal must be connected between the XTI and XTO pins as
shown in the Typical Connection Diagram on page 23. This crystal must oscillate at the frequency shown in Table 2.
In this configuration, MCLK is a buffered output and, as shown in the Typical Connection Diagram, nothing other
than the crystal and its load capacitors should be connected to XTI and XTO. The MCLK signal will appear on the
MCLK pin prior to 1 ms from the release of RST.

To operate the CS4272 with an externally generated MCLK signal, no crystal should be used, XTI should be con-
nected to ground and XTO should be left unconnected. In this configuration, MCLK is an input and must be driven
externally with an appropriate speed clock.

Table 1. Speed Modes

Mode

Sampling Frequency

Single Speed

4-50 kHz

Double Speed

50-100 kHz

Quad Speed

100-200 kHz

Table 2. Crystal Frequencies

Mode

Crystal Frequency

Single Speed

512 x Fs

Double Speed

256 x Fs

Quad Speed

128 x Fs

CS4272

DS593F1

5.1.3.2 Clock Ratio Selection

Depending on the use of an external crystal, or whether the CS4272 is in Master or Slave Mode, different
MCKL/LRCK and SCLK/LRCK ratios may be used. These ratios are shown in the Tables 3 and 4 below.

Table 3. Clock Ratios - Stand Alone Mode With External Crystal

External Crystal Used, MCLK=Output

Master Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Single Speed

256

Double Speed

128

Quad Speed

128

Slave Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Single Speed

256

32, 64, 128

Double Speed

128

32, 64

Quad Speed

128

32, 64

Table 4. Clock Ratios - Stand Alone Mode Without External Crystal

External Crystal Not Used, MCLK=Input

Master Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Single Speed

256

Double Speed

128

Quad Speed

Slave Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Single Speed

256

32, 64, 128

384

32, 48, 64, 96, 128

512

32, 64, 128

Double Speed

128

32, 64

192

32, 48, 64

256

32, 64

Quad Speed

128

32, 64

CS4272

DS593F1

5.1.4

16-Bit Auto-Dither

The CS4272 will auto-configure to output properly dithered 16-bit data when placed in Slave Mode and a 32x SCLK
to LRCK ratio is used. In this configuration, one half of a bit of dither is added to the LSB of the 16-bit word. This
applies only to the serial audio output of the ADC and will not affect DAC performance. See Figure 9.

5.1.5

Auto-Mute

The DAC output will mute following the reception of 8192 consecutive audio samples of static 0 or -1. A single sam-
ple of non-static data will release the mute. Detection and muting are done independently for each channel. The
common mode on the output will be retained and the Mute Control pin for that channel will go active during the mute
period.

5.1.6

High Pass Filter

The operational amplifiers in the input circuitry driving the CS4272 may generate a small DC offset into the ADC.
The CS4272 includes a high pass filter after the decimator to remove any DC offset which could result in recording
a DC level, possibly yielding "clicks" when switching between devices in a multichannel system.
In Stand-Alone Mode, the high pass filter continuously subtracts a measure of the DC offset from the output of the
decimation filter. This function cannot be disabled in Stand-Alone Mode.

5.1.7

Interpolation Filter

In Stand-Alone Mode, the fast roll-off interpolation filter is used.
Filter specifications can be found in Section 3. Plots of the data are contained in the "Appendix" on page 47.

5.1.8

Mode Selection & De-Emphasis

The sample rate, Fs, can be adjusted from 4 kHz to 200 kHz. In Stand-Alone Mode, the CS4272 must be set to the
proper mode via the mode pins, M1 and M0. De-emphasis, optimized for a 44.1 kHz sampling frequency, is avail-
able.

5.1.9

Serial Audio Interface Format Selection

Either I

S or left justified serial audio data format may be selected in Stand-Alone Mode. The selection will affect

both the input and output format. Placing a 10 k

pull-up to VL on the I2S/LJ pin will select the I

S format, while

placing a 10 k

pull-down to DGND on the I2S/LJ pin will select the left justified format.

Table 5. CS4272 Stand-Alone Mode Control

Mode 1

Mode 0

Mode

Sample Rate (Fs)

De-Emphasis

Single Speed Mode

4 kHz - 50 kHz

44.1 kHz

Single Speed Mode

4 kHz - 50 kHz

Off

Double Speed Mode

50 kHz - 100 kHz

Off

Quad Speed Mode

100 kHz - 200 kHz

Off

16 -B it W ord

½ B it D ither

Figure 9. ADC 16-Bit Auto-Dither

CS4272

DS593F1

5.2

Control Port Mode

5.2.1

Recommended Power-Up Sequence - Access to Control Port Mode

1) When using the CS4272 with an external MCLK, hold RST low until the power supply, MCLK, and LRCK are

stable. When using the CS4272 with internally generated MCLK, hold RST low until the power supply is stable.
In this state, the Control Port is reset to its default settings.

2) Bring RST high. The device will remain in a low power state and the control port will be accessible. If internally

generated MCLK is being used, it will appear on the MCLK pin prior to 1 ms from the release of RST.

3) Write 03h to register 07h within 10 ms following the release of RST. This sets the Control Port Enable (CPEN)

and Power Down (PDN) bits, activating the Control Port and placing the part in power-down. When using the
CS4272 with internally generated MCLK, it is necessary to wait 1 ms following the release of RST before initi-
ating this Control Port write.

4) The desired register settings can be loaded while keeping the PDN bit set.
5) Clear the PDN bit to initiate the power-up sequence. This power-up sequence requires approximately 85 µS.

5.2.2

Master / Slave Mode Selection

The CS4272 supports operation in either Master Mode or Slave Mode.
In Master Mode, LRCK and SCLK are outputs and are synchronously generated on-chip. LRCK is equal to Fs and
SCLK is equal to 64x Fs.
In Slave Mode, LRCK and SCLK are inputs, requiring external generation that is synchronous to MCLK. It is recom-
mended that SCLK be 64x Fs to maximize system performance.
Configuration of clock ratios in each of these modes will be outlined in the Tables 8 and 9.
In Control Port Mode the CS4272 will default to Slave Mode. The user may change this default setting by changing
the status of the M/S bit in the Mode Control 1 register (01h).

5.2.3

System Clocking

The CS4272 will operate at sampling frequencies from 4 kHz to 200 kHz. This range is divided into three speed
modes as shown in Table 6 below.

5.2.3.1 Crystal Applications (XTI/XTO)

An external crystal may be used in conjunction with the CS4272 to generate the MCLK signal. To accomplish this,
a 20 pF fundamental mode parallel resonant crystal must be connected between the XTI and XTO pins as shown in
the Typical Connection Diagram on page 23. This crystal must oscillate at the frequency shown in Table 7. In this
configuration, MCLK is a buffered output and, as shown in the Typical Connection Diagram, nothing other than the
crystal and its load capacitors should be connected to XTI and XTO. The MCLK signal will appear on the MCLK pin
prior to 1 ms from the release of RST.

Table 6. Speed Modes

Mode

Sampling Frequency

Single Speed

4-50 kHz

Double Speed

50-100 kHz

Quad Speed

100-200 kHz

CS4272

DS593F1

5.2.3.2 Clock Ratio Selection

Depending on the use of an external crystal, or whether the CS4272 is in Master or Slave Mode, different
MCKL/LRCK and SCLK/LRCK ratios may be used. These ratios as well as the Control Port Register Bits that must
be set in order to obtain them are shown in Tables 8 and 9 below.

Notes: 27. For the Ratio1 and Ratio0 bits listed above, "d" indicates that any value may written.

Table 7. Crystal Frequencies

Mode

Crystal Frequency

Single Speed

512 x Fs

Double Speed

256 x Fs

Quad Speed

128 x Fs

Table 8. Clock Ratios - Control Port Mode With External Crystal

External Crystal Used, MCLK=Output

Master Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Ratio1 Bit

Ratio0 Bit

Single Speed

256

512

Double Speed

128

256

Quad Speed

128

Slave Mode

MCLK/LRCK

SCLK/LRCK

LRCK

Ratio1 Bit

Ratio0 Bit

Single Speed

256

32, 64, 128

512

32, 64, 128

Double Speed

128

32, 64

256

32, 64

Quad Speed

128

32, 64

CS4272

DS593F1

5.2.4

Internal Digital Loopback

In Control Port Mode, the CS4272 supports an internal digital loopback mode in which the output of the ADC is rout-
ed to the input of the DAC. This mode may be activated by setting the LOOP bit in the Mode Control 2 register (07h).
When this bit is set, the status of the DAC_DIF(2:0) bits in register 01h will be disregarded by the CS4272. Any
changes made to the DAC_DIF(2:0) bits while the LOOP bit is set will have no impact on operation until the LOOP
bit is released, at which time the Digital Interface Format of the DAC will operate according to the format selected in
the DAC_DIF(2:0) bits. While the LOOP bit is set, data will be present on the SDOUT pin in the format selected in
the ADC_DIF bit in register 06h.

5.2.5

Dither for 16-Bit Data

The CS4272 may be configured to properly dither for 16-bit data. To do this, the Dither16 bit in the ADC Control
Register (06h) must be set. When set, a half bit of dither is added to the least significant bit of the 16 most significant
bits of the data word. The remaining bits should be disregarded. See Figure 10. This function is useful when 16-bit
devices are downstream of the ADC. This bit should not be set when using word lengths greater than 16 bits.
It should be noted that this function is supported for all serial audio output formats, and may be activated in either
Master or Slave Mode.

5.2.6

Auto-Mute

The Auto-Mute function is controlled by the status of the AMUTE bit in the DAC Control register. When set, the DAC
output will mute following the reception of 8192 consecutive audio samples of static 0 or -1. A single sample of non-
static data will release the mute. Detection and muting are done independently for each channel. Auto-Mute detec-
tion and muting can become dependent on either channel if the MUTECA=B function is enabled. The common mode
on the output will be retained and the Mute Control pin for that channel will become active during the mute period.
The muting function is effected, similar to volume control changes, by the Soft and ZeroCross bits in the DAC Vol-
ume and Mixing Control register. The AMUTE bit is set by default.

5.2.7

High Pass Filter and DC Offset Calibration

The operational amplifiers in the input circuitry driving the CS4272 may generate a small DC offset into the A/D con-
verter. The CS4272 includes a high pass filter after the decimator to remove any DC offset which could result in
recording a DC level, possibly yielding "clicks" when switching between devices in a multichannel system.
The high pass filter continuously subtracts a measure of the DC offset from the output of the decimation filter. The
high pass filter can be independently enabled and disabled for channels A and B. If the HPFDisableA or HPFDis-
ableB bit is set during normal operation, the current value of the DC offset for the corresponding channel is frozen
and this DC offset will continue to be subtracted from the conversion result. This feature makes it possible to perform
a system DC offset calibration by:
1) Running the CS4272 with the high pass filter enabled until the filter settles. See the Digital Filter Characteristics

for filter settling time.

2) Disabling the high pass filter and freezing the stored DC offset.

16-Bit W ord

Disregard Contents

½ Bit Dither

Figure 10. Example of Dither for 16-Bit Data with 24-Bit Left Justified Format

CS4272

DS593F1

A system calibration performed in this way will eliminate offsets anywhere in the signal path between the calibration
point and the CS4272.

5.2.8

Interpolation Filter

To accommodate the increasingly complex requirements of digital audio systems, the CS4272 incorporates select-
able interpolation filters for each mode of operation. Fast and slow roll-off filters are available in each of Single, Dou-
ble, and Quad Speed modes. These filters have been designed to accommodate a variety of musical tastes and
styles. The FILT_SEL bit in the DAC Control register (02h) is used to select which filter is used. By default, the fast
roll-off filter is selected.
Filter specifications can be found in Section 3. Plots of the data are contained in the "Appendix" on page 47.

5.2.9

De-Emphasis

Three de-emphasis modes are available via the Control Port. The available filters are optimized for 32 kHz,
44.1 kHz, and 48 kHz sampling rates. See Table 13 for de-emphasis selection in Control Port Mode.

5.2.10 Oversampling Modes

The CS4272 operates in one of three oversampling modes based on the input sample rate. Mode selection is de-
termined by the M1 and M0 bits in the Mode Control 1 register. Single-Speed mode supports input sample rates up
to 50 kHz and uses a 128x oversampling ratio. Double-Speed mode supports input sample rates up to 100 kHz and
uses an oversampling ratio of 64x. Quad-Speed mode supports input sample rates up to 200 kHz and uses an over-
sampling ratio of 32x. See Table 11 for Control Port Mode settings.

5.3

De-Emphasis Filter

The CS4272 includes on-chip digital de-emphasis. Figure 11 shows the de-emphasis curve for Fs equal to 44.1 kHz.
The frequency response of the de-emphasis curve will scale proportionally with changes in sample rate, Fs. Please
see section 5.1.8 for the desired de-emphasis control for Stand-Alone mode and section 5.2.9 for control port mode.
The de-emphasis feature is included to accommodate audio recordings that utilize 50/15

S pre-emphasis equal-

ization as a means of noise reduction.
De-emphasis is only available in Single Speed Mode.

Gain

-10dB

0dB

Frequency

T2 = 15 µs

T1=50 µs

3.183 kHz

10.61 kHz

Figure 11. De-Emphasis Curve

CS4272

DS593F1

5.5

Mute Control

The Mute Control pins become active during power-up initialization, reset, muting, if the MCLK to LRCK ratio is in-
correct, and during power-down. The Auto-Mute function causes the MUTEC pin corresponding to an individual
channel to activate following the reception of 8192 consecutive audio samples of static 0 or -1 on the respective
channel. A single sample of non-zero data on this channel will cause the MUTEC pin to deactivate. In Control Port
Mode, however, auto-mute detection and muting can become dependent on either channel if the MuteB=A function
is enabled. The MUTEC pins are intended to be used as control for an external mute circuit in order to add off-chip
mute capability.
Use of the Mute Control function is not mandatory but recommended for designs requiring the absolute minimum in
extraneous clicks and pops. Also, use of the Mute Control function can enable the system designer to achieve idle
channel noise/signal-to-noise ratios which are only limited by the external mute circuit. The MUTEC pins are active-
low. See Figure 16 below for a suggested active-low mute circuit.

5.6

Synchronization of Multiple Devices

In systems where multiple ADCs are required, care must be taken to achieve simultaneous sampling. To ensure
synchronous sampling, the MCLK and LRCK must be the same for all of the CS4272's in the system. If only one
MCLK source is needed, one solution is to place one CS4272 in Master Mode, and slave all of the other CS4272's
to the one master. If multiple MCLK sources are needed, a possible solution would be to supply all clocks from the
same external source and time the CS4272 reset with the inactive edge of MCLK. This will ensure that all converters
begin sampling on the same clock edge.

5.7

Grounding and Power Supply Decoupling

As with any high resolution converter, the CS4272 requires careful attention to power supply and grounding arrange-
ments if its potential performance is to be realized. Figure 8 shows the recommended power arrangements, with VA
and VL connected to clean supplies. VD, which powers the digital filter, may be run from the system logic supply
(VL) or may be powered from the analog supply (VA) via a resistor. In this case, no additional devices should be
powered from VD. Power supply decoupling capacitors should be as near to the CS4272 as possible, with the low
value ceramic capacitor being the nearest. All signals, especially clocks, should be kept away from the VREF and
VCOM pins in order to avoid unwanted coupling into the modulators. The VREF and VCOM decoupling capacitors,
particularly the 0.1 µF, must be positioned to minimize the electrical path from VREF and AGND. The CDB4272
evaluation board demonstrates the optimum layout and power supply arrangements. To minimize digital noise, con-
nect the CS4272 digital outputs only to CMOS inputs.

LPF

-V

560

Audio

Out

2 k

10 k

-V

MMUN2111LT1

AOUT

MUTEC

CS4272

Couple

47 k

Figure 16. Suggested Active-Low Mute Circuit

CS4272

DS593F1

6. CONTROL PORT INTERFACE

The Control Port is used to load all the internal settings of the CS4272. The operation of the Control Port may be
completely asynchronous to the audio sample rate. However, to avoid potential interference problems, the Control
Port pins should remain static if no operation is required.
The Control Port has 2 modes: SPI and I²C, with the CS4272 operating as a slave to control messages in both
modes. If I²C operation is desired, AD0/CS should be tied to VA or AGND. If the CS4272 ever detects a high to low
transition on AD0/CS after power-up, SPI mode will be selected. The Control Port registers are write-only in SPI
mode.
Upon release of the RST pin, the CS4272 will wait approximately 10 ms before it begins its start-up sequence. The
part defaults to Stand-Alone Mode, in which all operational modes are controlled as described under "Stand-Alone
Mode" on page 24. The Control Port is active at all times, and if bit 1 of register 07h (CPEN) is set, the part enters
Control-Port Mode and all operational modes are controlled by the Control Port registers. This bit can be set at any
time, but to avoid unpredictable output noises, bit 1 (CPEN) and bit 0 (PDN) of register 07h should be set by writing
03h before the end of the 10 ms start-up wait period. All registers can then be set as desired before releasing the
PDN bit to begin the start-up sequence. If system requirements do not allow writing to the control port immediately
following the release of RST, the SDIN line should be held at logic "0" until the proper serial mode can be selected.

6.1

SPI Mode

In SPI mode, CS is the CS4272 chip select signal, CCLK is the control port bit clock, CDIN is the input data line from
the microcontroller and the chip address is 0010000. All control signals are inputs and data is clocked in on the rising
edge of CCLK.
Figure 17 shows the operation of the Control Port in SPI mode. To write to a register, bring CS low. The first 7 bits
on CDIN form the chip address, and must be 0010000. The eighth bit is a read/write indicator (R/W), which must be
low to write. The next 8 bits form the Memory Address Pointer (MAP), which is set to the address of the register that
is to be updated. The next 8 bits are the data which will be placed into the register designated by the MAP. See
Table 10 on page 36.

The CS4272 has MAP auto increment capability, enabled by the INCR bit in the MAP. If INCR is 0, then the MAP
will stay constant for successive writes. If INCR is set, then MAP will auto increment after each byte is written, al-
lowing block writes to successive registers.

MAP

MSB

LSB

DATA

byte 1

byte n

R/W

MAP = Memory Address Pointer

ADDRESS

CHIP

CDIN

CCLK

0010000

Figure 17. Control Port Timing, SPI mode

CS4272

DS593F1

6.2

I²C

Mode

In I²C mode, SDA is a bi-directional data line. Data is clocked into and out of the part by the clock, SCL, with the clock
to data relationship as shown in Figure 18. There is no CS pin. Pin AD0 forms the partial chip address and should be
tied to VA or AGND as required. The upper 6 bits of the 7-bit address field must be 001000. To communicate with the
CS4272, the LSB of the chip address field, which is the first byte sent to the CS4272, should match the setting of the
AD0 pin. The eighth bit of the address byte is the R/W bit (high for a read, low for a write). If the operation is a write,
the next byte is the Memory Address Pointer, MAP, which selects the register to be read or written. The MAP is then
followed by the data to be written. If the operation is a read, then the contents of the register pointed to by the MAP will
be output after the chip address.
The CS4272 has MAP auto increment capability, enabled by the INCR bit in the MAP. If INCR is 0, then the MAP
will stay constant for successive writes. If INCR is set, then MAP will auto increment after each byte is written, al-
lowing block reads or writes of successive registers.

Table 10. Memory Address Pointer (MAP)

INCR

Reserved

MAP3

MAP2

MAP1

MAP0

INCR - Auto MAP Increment Enable

Default = `0'.
0 - Disabled
1 - Enabled

MAP(3:0) - Memory Address Pointer

Default = `0000'.

SDA

SCL

001000

ADDR
AD0

R/W

Start

ACK

DATA
1-8

ACK

DATA
1-8

ACK

Stop

Note: If operation is a write, this byte contains the Memory Address Pointer, MAP.

Note 1

Figure 18. Control Port Timing,

I²C

Mode

CS4272

DS593F1

REGISTER DESCRIPTION

** All registers are read/write in I²C mode and write only in SPI mode, unless otherwise noted**

8.1

Mode Control 1 - Address 01h

8.1.1

Functional Mode (Bits 7:6)

Function:

Selects the required range of input sample rates.

8.1.2

Ratio Select (Bits 5:4)

Function:

These bits are used to select the clocking ratios in Control Port Mode. Please refer to Table 8, "Clock
Ratios - Control Port Mode With External Crystal," on page 28 or Table 9, "Clock Ratios - Control Port
Mode Without External Crystal," on page 29 for information on which of these bits to set to obtain spe-
cific clock ratios.

8.1.3

Master / Slave Mode (Bit 3)

Function:

This bit selects either master or slave operation. Setting this bit will select master mode, while clearing
this bit will select slave mode.

8.1.4

DAC Digital Interface Format (Bits 2:0)

Function:

The required relationship between LRCK, SCLK and SDIN for the DAC is defined by the DAC Digital
Interface Format and the options are detailed in Table 12 and Figures 3-5.

Ratio1

Ratio0

M/S

DAC_DIF2

DAC_DIF1

DAC_DIF0

Table 11. Functional Mode Selection

Mode

Single-Speed Mode: 4 to 50 kHz sample rates (default)

Single-Speed Mode: 4 to 50 kHz sample rates

Double-Speed Mode: 50 to 100 kHz sample rates

Quad-Speed Mode: 100 to 200 kHz sample rates

Table 12. DAC Digital Interface Formats

DAC_DIF2 DAC_DIF1 DAC_DIF0

Description

Format

Figure

Left Justified, up to 24-bit data (default)

S, up to 24-bit data

Right Justified, 16-bit Data

Right Justified, 24-bit Data

Right Justified, 20-bit Data

Right Justified, 18-bit Data

Reserved

CS4272

DS593F1

8.2

DAC Control - Address 02h

8.2.1

Auto-Mute (Bit 7)

Function:

When set, enables the Auto-Mute function. See "Auto-Mute" on page 30.

8.2.2

Interpolation Filter Select (Bit 6)

Function:

This Function allows the user to select whether the Interpolation Filter has a fast or slow roll off. When
set, this bit selects the slow roll off filter, when cleared it selects the fast roll off filter. The - 3 dB corner
is approximately the same for both filters, but the slope of the roll off is greater for the fast roll off filter.

8.2.3

De-Emphasis Control (Bits 5:4)

Function:

Implementation of the standard 50/15

s digital de-emphasis filter response, Figure 19, requires re-

configuration of the digital filter to maintain the proper filter response for 32, 44.1 or 48 kHz sample
rates. NOTE: De-emphasis is available only in Single-Speed Mode. See Table 13 below.

AMUTE

FILT_SEL

DEM1

DEM0

RMP_UP

RMP_DN

INV_A

INV_B

Table 13. De-Emphasis Mode Selection

DEM1

DEM0

Description

Disabled (default)

44.1 kHz de-emphasis

48 kHz de-emphasis

32 kHz de-emphasis

Gain

-10dB

0dB

Frequency

T2 = 15 µs

T1=50 µs

3.183 kHz

10.61 kHz

Figure 19. De-Emphasis Curve

CS4272

DS593F1

8.2.4

Soft Volume Ramp-Up After Error (Bit 3)

Function:

An un-mute will be performed after executing a filter mode change, after a MCLK/LRCK ratio change
or error, and after changing the Functional Mode. When this bit is set, this un-mute is effected, similar
to attenuation changes, by the Soft and ZeroCross bits in the DAC Volume & Mixing Control register.
When cleared, an immediate un-mute is performed in these instances.

Note: For best results, it is recommended that this feature be used with the RMP_DN bit.

8.2.5

Soft Ramp-Down Before Filter Mode Change (Bit 2)

Function:

A mute will be performed prior to executing a filter mode change. When this bit is set, this mute is
effected, similar to attenuation changes, by the Soft and ZeroCross bits in the DAC Volume & Mixing
Control register. When cleared, an immediate mute is performed prior to executing a filter mode
change.

Note: For best results, it is recommended that this feature be used in conjunction with the RMP_UP
bit.

8.2.6

Invert Signal Polarity (Bits 1:0)

Function:

When set, this bit activates an inversion of the signal polarity for the appropriate channel. This is use-
ful if a board layout error has occurred, or other situations where a 180 degree phase shift is desirable.

8.3

DAC Volume & Mixing Control - Address 03h

8.3.1

Channel B Volume = Channel A Volume (Bit 6)

Function:

The AOUTA and AOUTB volume levels are independently controlled by the A and the B Channel Vol-
ume Control Bytes when this function is disabled. The volume on both AOUTA and AOUTB are de-
termined by the A Channel Volume Control Byte and the B Channel Byte is ignored when this function
is enabled. Volume and muting functions are effected by the Soft Ramp and ZeroCross functions be-
low.

8.3.2

Soft Ramp or Zero Cross Enable (Bits 5:4)

Function:

Soft Ramp Enable

Soft Ramp allows level changes, both muting and attenuation, to be implemented by incrementally
ramping, in 1/8 dB steps, from the current level to the new level at a rate of 1 dB per 8 left/right clock
periods. See Table 14 on page 41.

Zero Cross Enable

Zero Cross Enable dictates that signal level changes, either by attenuation changes or muting, will
occur on a signal zero crossing to minimize audible artifacts. The requested level change will occur
after a time-out period between 512 and 1024 sample periods (10.7 ms to 21.3 ms at 48 kHz sample
rate) if the signal does not encounter a zero crossing. The zero cross function is independently mon-

Reserved

B=A

Soft

ZeroCross

ATAPI3

ATAPI2

ATAPI1

ATAPI0

CS4272

DS593F1

8.4

DAC Channel A Volume Control - Address 04h

See 8.5 DAC Channel B Volume Control - Address 05h

8.5

DAC Channel B Volume Control - Address 05h

8.5.1

Mute (Bit 7)

Function:

The DAC output will mute when this bit is set. Though this bit is active high, it should be noted that
the MUTEC pins are active low. The common mode voltage on the output will be retained when this
bit is set. The muting function is effected, similar to attenuation changes, by the Soft and ZeroCross
bits in the Volume and Mixing Control register. The MUTEC pin for the respective channel will become
active during the mute period if the MUTE bit is set. Both the AMUTEC and BMUTEC will become
active if either MUTE register is enabled and the MUTECB=A bit (register 7) is enabled.

8.5.2

Volume Control (Bits 6:0)

Function:

The digital volume control allows the user to attenuate the signal in 1 dB increments from 0 to -127 dB.
Volume settings are decoded as shown in Table 16. The volume changes are implemented as dictat-
ed by the Soft and ZeroCross bits in the DAC Volume & Mixing Control register (see section 8.3.2).

Table 15. ATAPI Decode

ATAPI3

ATAPI2

ATAPI1

ATAPI0

AOUTA

AOUTB

MUTE

b[(L+R)/2]

MUTE

b[(L+R)/2]

MUTE

b[(L+R)/2]

a[(L+R)/2]

MUTE

a[(L+R)/2]

b[(L+R)/2]

MUTE

VOL6

VOL5

VOL4

VOL3

VOL2

VOL1

VOL0

Table 16. Digital Volume Control Example Settings

Binary Code

Decimal Value

Volume Setting

0000000

0 dB

0010100

-20 dB

0101000

-40 dB

0111100

-60 dB

1011010

-90 dB

CS4272

DS593F1

8.6

ADC Control - Address 06h

8.6.1

Dither for 16-Bit Data (Bit 5)

Function:

When set, this bit activates the Dither for 16-Bit Data feature as described in "Dither for 16-Bit Data"
on page 30.

8.6.2

ADC Digital Interface Format (Bit 4)

Function:

The required relationship between LRCK, SCLK and SDOUT for the ADC is defined by the ADC Dig-
ital Interface Format. The options are detailed in Table 17 and may be seen in Figure 3 and 4.

8.6.3

ADC Channel A & B Mute (Bits 3:2)

Function:

When this bit is set, the output of the ADC for the selected channel will be muted.

8.6.4

Channel A & B High Pass Filter Disable (Bits 1:0)

Function:

When this bit is set, the internal high-pass filter for the selected channel will be disabled.The current
DC offset value will be frozen and continue to be subtracted from the conversion result. See "High
Pass Filter and DC Offset Calibration" on page 30.

8.7

Mode Control 2 - Address 07h

8.7.1

Digital Loopback (Bit 4)

Function:

When this bit is set, an internal digital loopback from the ADC to the DAC will be enabled. Please refer
to "Internal Digital Loopback" on page 30.

8.7.2

AMUTEC = BMUTEC (Bit 3)

Function:

When this function is enabled, the individual controls for AMUTEC and BMUTEC are internally con-
nected through an AND gate prior to the output pins. Therefore, the external AMUTEC and BMUTEC
pins will go active only when the requirements for both AMUTEC and BMUTEC are valid.

Reserved

Dither16

ADC_DIF

MUTEA

MUTEB

HPFDisableA HPFDisableB

Table 17. ADC Digital Interface Formats

ADC_DIF

Description

Format

Figure

Left Justified, up to 24-bit data (default)

S, up to 24-bit data

Reserved

LOOP

MUTECA=B

FREEZE

CPEN

PDN

CS4272

DS593F1

8.7.3

Freeze (Bit 2)

Function:

This function allows modifications to the control port registers without the changes taking effect until
FREEZE is disabled. To make multiple changes in the Control Port registers take effect simultaneous-
ly, set the FREEZE bit, make all register changes, then clear the FREEZE bit.

8.7.4

Control Port Enable (Bit 1)

Function:

This bit is cleared by default, allowing the device to power-up in Stand-Alone Mode. Control Port
Mode can be accessed by setting this bit. This will allow the operation of the device to be controlled
by the registers and the pin definitions will conform to Control Port Mode. See "Recommended Power-
Up Sequence - Access to Control Port Mode" on page 27.

8.7.5

Power Down (Bit 0)

Function:

The device will enter a low-power state whenever this bit is set. The power-down bit is set by default
and must be cleared before normal operation in Control Port Mode can occur. The contents of the
control registers are retained when the device is in power-down.

8.8

Chip ID - Register 08h

This is a Read-Only register.

8.8.1

Chip ID (Bits 7:4)

Function:

Chip ID code for the CS4272. Permanently set to 0000b (0h).

8.8.2

Chip Revision (Bits 3:0)

Function:

Chip Revision code for the CS4272.

Revision A is coded as 0000b (0h).
Revision B is coded as 0000b (0h).

PART3

PART2

PART1

PART0

REV3

REV2

REV1

REV0

CS4272

DS593F1

PARAMETER DEFINITIONS

Dynamic Range

The ratio of the rms value of the signal to the rms sum of all other spectral components over the specified
bandwidth. Dynamic Range is a signal-to-noise ratio measurement over the specified bandwidth made
with a -60 dBFS signal. 60 dB is added to resulting measurement to refer the measurement to full-scale.
This technique ensures that the distortion components are below the noise level and do not affect the
measurement. This measurement technique has been accepted by the Audio Engineering Society,
AES17-1991, and the Electronic Industries Association of Japan, EIAJ CP-307. Expressed in decibels.

Total Harmonic Distortion + Noise

The ratio of the rms value of the signal to the rms sum of all other spectral components over the specified
bandwidth (typically 10 Hz to 20 kHz), including distortion components. Expressed in decibels. Measured
at -1 and -20 dBFS as suggested in AES17-1991 Annex A.

Frequency Response

A measure of the amplitude response variation from 10 Hz to 20 kHz relative to the amplitude response
at 1 kHz. Units in decibels.

Interchannel Isolation

A measure of crosstalk between the left and right channels. Measured for each channel at the converter's
output with no signal to the input under test and a full-scale signal applied to the other channel. Units in
decibels.

Interchannel Gain Mismatch

The gain difference between left and right channels. Units in decibels.

Gain Error

The deviation from the nominal full-scale analog output for a full-scale digital input.

Gain Drift

The change in gain value with temperature. Units in ppm/°C.

Offset Error

The deviation of the mid-scale transition (111...111 to 000...000) from the ideal. Units in mV.

CS4272

DS593F1

10.PACKAGE DIMENSIONS

Notes: 1. "D" and "E1" are reference datums and do not included mold flash or protrusions, but do include mold

mismatch and are measured at the parting line, mold flash or protrusions shall not exceed 0.20 mm per
side.

2. Dimension "b" does not include dambar protrusion/intrusion. Allowable dambar protrusion shall be

0.13 mm total in excess of "b" dimension at maximum material condition. Dambar intrusion shall not
reduce dimension "b" by more than 0.07 mm at least material condition.

3. These dimensions apply to the flat section of the lead between 0.10 and 0.25 mm from lead tips.

THERMAL CHARACTERISTICS AND SPECIFICATIONS

Notes: 4.

is specified according to JEDEC specifications for multi-layer PCBs.

INCHES

MILLIMETERS

NOTE

DIM

MIN

NOM

MAX

MIN

NOM

MAX

0.47

1.20

0.002

0.004

0.006

0.05

0.10

0.15

0.03150

0.035

0.04

0.80

0.90

1.00

0.00748

0.0096

0.012

0.19

0.245

0.30

2,3

0.378 BSC

0.382 BSC

0.386 BSC

9.60 BSC

9.70 BSC

9.80 BSC

0.248

0.2519

0.256

6.30

6.40

6.50

0.169

0.1732

0.177

4.30

4.40

4.50

0.026 BSC

0.65 BSC

0.020

0.024

0.029

0.50

0.60

0.75

0°

4°

8°

0°

4°

8°

JEDEC #: MO-153

Controlling Dimension is Millimeters.

Parameters

Symbol

Min

Typ

Max

Units

Package Thermal Resistance (Note 4)

28-TSSOP

-
-

37
13

-
-

°C/Watt
°C/Watt

Allowable Junction Temperature

135

28L TSSOP (4.4 mm BODY) PACKAGE DRAWING

1 2 3

SEATING

PLANE

SIDE VIEW

END VIEW

TOP VIEW

CS4272

DS593F1

11.APPENDIX

0.4

0.5

0.6

0.7

0.8

0.9

120

100

Frequency(normalized to Fs)

Amplitude (dB)

0.4

0.42

0.44

0.46

0.48

0.5

0.52

0.54

0.56

0.58

0.6

120

100

Frequency(normalized to Fs)

Amplitude (dB)

Figure 21. DAC Single Speed (fast) Stopband Rejection

Figure 22. DAC Single Speed (fast) Transition Band

0.45

0.46

0.47

0.48

0.49

0.5

0.51

0.52

0.53

0.54

0.55

Frequency(normalized to Fs)

Amplitude (dB)

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

0.02

0.015

0.01

0.005

0.01

0.015

0.02

Frequency(normalized to Fs)

Amplitude (dB)

Figure 23. DAC Single Speed (fast) Transition Band (detail)

Figure 24. DAC Single Speed (fast) Passband Ripple

0.4

0.5

0.6

0.7

0.8

0.9

120

100

Frequency(normalized to Fs)

Amplitude (dB)

0.4

0.42

0.44

0.46

0.48

0.5

0.52

0.54

0.56

0.58

0.6

120

100

Frequency(normalized to Fs)

Amplitude (dB)

Figure 25. DAC Single Speed (slow) Stopband Rejection

Figure 26. DAC Single Speed (slow) Transition Band

CS4272

DS593F1

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

0.02

0.015

0.01

0.005

0.01

0.015

0.02

Frequency(normalized to Fs)

Amplitude (dB)

0.45

0.46

0.47

0.48

0.49

0.5

0.51

0.52

0.53

0.54

0.55

Frequency(normalized to Fs)

Amplitude (dB)

Figure 27. DAC Single Speed (slow) Transition Band (detail)

Figure 28. DAC Single Speed (slow) Passband Ripple

0.4

0.5

0.6

0.7

0.8

0.9

120

100

Frequency(normalized to Fs)

Amplitude (dB)

0.4

0.42

0.44

0.46

0.48

0.5

0.52

0.54

0.56

0.58

0.6

120

100

Frequency(normalized to Fs)

Amplitude (dB)

Figure 29. DAC Double Speed (fast) Stopband Rejection

Figure 30. DAC Double Speed (fast) Transition Band

0.45

0.46

0.47

0.48

0.49

0.5

0.51

0.52

0.53

0.54

0.55

Frequency(normalized to Fs)

Amplitude (dB)

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

0.02

0.015

0.01

0.005

0.01

0.015

0.02

Frequency(normalized to Fs)

Amplitude (dB)

Figure 31. DAC Double Speed (fast) Transition Band (detail)

Figure 32. DAC Double Speed (fast) Passband Ripple

CS4272

DS593F1

0.45

0.46

0.47

0.48

0.49

0.5

0.51

0.52

0.53

0.54

0.55

Frequency(normalized to Fs)

Amplitude (dB)

0.05

0.1

0.15

0.2

0.25

0.2

0.15

0.1

0.05

0.1

0.15

0.2

Frequency(normalized to Fs)

Amplitude (dB)

Figure 39. DAC Quad Speed (fast) Transition Band (detail)

Figure 40. DAC Quad Speed (fast) Passband Ripple

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

120

100

Frequency(normalized to Fs)

Amplitude (dB)

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

120

100

Frequency(normalized to Fs)

Amplitude (dB)

Figure 41. DAC Quad Speed (slow) Stopband Rejection

Figure 42. DAC Quad Speed (slow) Transition Band

0.45

0.46

0.47

0.48

0.49

0.5

0.51

0.52

0.53

0.54

0.55

Frequency(normalized to Fs)

Amplitude (dB)

0.02

0.04

0.06

0.08

0.1

0.12

0.02

0.015

0.01

0.005

0.01

0.015

0.02

Frequency(normalized to Fs)

Amplitude (dB)

Figure 43. DAC Quad Speed (slow) Transition Band (detail)

Figure 44. DAC Quad Speed (slow) Passband Ripple

CS4272

DS593F1

-140

-130

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

Frequency (normalized to Fs)

l
i
t
u

e (d

-140

-130

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.40

0.42

0.44

0.46

0.48

0.50

0.52

0.54

0.56

0.58

0.60

Frequency (normalized to Fs)

plit

e (

Figure 45. ADC Single Speed Mode Stopband Rejection

Figure 46. ADC Single Speed Mode Transition Band

-10

-9

-8

-7

-6

-5

-4

-3

-2

-1

0.45

0.46

0.47

0.48

0.49

0.50

0.51

0.52

0.53

0.54

0.55

Frequency (normalized to Fs)

l
i
t
u

e
(

-0.10

-0.08

-0.05

-0.03

0.00

0.03

0.05

0.08

0.10

0.00

0.05

0.10

0.15

0.20

0.25

0.30

0.35

0.40

0.45

0.50

Frequency (normalized to Fs)

i
t
ude

(dB

)

Figure 47. ADC Single Speed Mode Transition Band (Detail)

Figure 48. ADC Single Speed Mode Passband Ripple

-140

-130

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

Frequency (normalized to Fs)

itude

(dB

)

-140

-130

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.40

0.43

0.45

0.48

0.50

0.53

0.55

0.58

0.60

0.63

0.65

0.68

0.70

Frequency (normalized to Fs)

Amplit

e
(

Figure 49. ADC Double Speed Mode Stopband Rejection

Figure 50. ADC Double Speed Mode Transition Band

CS4272

DS593F1

-10

-9

-8

-7

-6

-5

-4

-3

-2

-1

0.40

0.43

0.45

0.48

0.50

0.53

0.55

Frequency (normalized to Fs)

i
t
ude (

)

-0.10

-0.08

-0.05

-0.03

0.00

0.03

0.05

0.08

0.10

0.00

0.05

0.10

0.15

0.20

0.25

0.30

0.35

0.40

0.45

0.50

Frequency (normalized to Fs)

i
t
ude

(

)

Figure 51. ADC Double Speed Mode Transition Band (Detail)

Figure 52. ADC Double Speed Mode Passband Ripple

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

Frequency (normalized to Fs)

ude

(

)

-130

-120

-110

-100

-90

-80

-70

-60

-50

-40

-30

-20

-10

0.2

0.25

0.3

0.35

0.4

0.45

0.5

0.55

0.6

0.65

0.7

0.75

0.8

Frequency (normalized to Fs)

e (

)

Figure 53. ADC Quad Speed Mode Stopband Rejection

Figure 54. ADC Quad Speed Mode Transition Band

-10

-9

-8

-7

-6

-5

-4

-3

-2

-1

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

0.55

0.6

Frequency (normalized to Fs)

Amplit

ude

-0.10

-0.08

-0.06

-0.04

-0.02

0.00

0.02

0.04

0.06

0.08

0.10

0.00

0.05

0.10

0.15

0.20

0.25

Frequency (normalized to Fs)

plit

e (d

Figure 55. ADC Quad Speed Mode Transition Band (Detail)

Figure 56. ADC Quad Speed Mode Passband Ripple

CS4272

DS593F1

Table 18. Revision History

Release

Date

Changes

January 2003

Advance Release

PP1

March 2003

Preliminary Release

PP2

October 2003

- Updated Figure 8 on page 23.
- Updated Table 9 on page 29.
- Updated the DC Electrical Characteristics table on page 17.
- Updated the DAC Analog Filter Response tables on pages 10 and 11.
- Updated the ADC Digital Filter Characteristics table on page 16.
- Updated the DAC Full Scale Differential Output Voltage specification on

pages 10 and 11.

PP3

September 2004

Add lead-free device ordering info.

August 2005

Final Release
- Updated Ordering Information on page 2.
- Updated Specified Operating Conditions table on page 9 to reflect ordering-

suffix independent temperature grade information.

- Updated DAC Analog Characteristics tables on pages 10 and 11 to reflect

ordering-suffix independent temperature grade information.

- Updated ADC Analog Characteristics tables on pages 14 and 15 to reflect

ordering-suffix independent temperature grade information.

- Updated the DC Electrical Characteristics table on page 17.
- Corrected error in the SCLK Period units shown in the Switching Character-

istics - Serial Audio Port table on page 18.

- Corrected error in the Memory Address Pointer table on page 36.
- Updated Chip ID register description on page 44.

Contacting Cirrus Logic Support

For all product questions and inquiries contact a Cirrus Logic Sales Representative.

To find one nearest you go to

www.cirrus.com

IIMPORTANT NOTICE
Cirrus Logic, Inc. and its subsidiaries ("Cirrus") believe that the information contained in this document is accurate and reliable. However, the information is sub-

ject to change without notice and is provided "AS IS" without warranty of any kind (express or implied). Customers are advised to obtain the latest version of

relevant information to verify, before placing orders, that information being relied on is current and complete. All products are sold subject to the terms and con-

ditions of sale supplied at the time of order acknowledgment, including those pertaining to warranty, indemnification, and limitation of liability. No responsibility

is assumed by Cirrus for the use of this information, including use of this information as the basis for manufacture or sale of any items, or for infringement of

patents or other rights of third parties. This document is the property of Cirrus and by furnishing this information, Cirrus grants no license, express or implied

under any patents, mask work rights, copyrights, trademarks, trade secrets or other intellectual property rights. Cirrus owns the copyrights associated with the

information contained herein and gives consent for copies to be made of the information only for use within your organization with respect to Cirrus integrated

circuits or other products of Cirrus. This consent does not extend to other copying such as copying for general distribution, advertising or promotional purposes,

or for creating any work for resale.

CERTAIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF DEATH, PERSONAL INJURY, OR SEVERE

PROPERTY OR ENVIRONMENTAL DAMAGE ("CRITICAL APPLICATIONS"). CIRRUS PRODUCTS ARE NOT DESIGNED, AUTHORIZED OR WARRANTED

FOR USE IN AIRCRAFT SYSTEMS, MILITARY APPLICATIONS, PRODUCTS SURGICALLY IMPLANTED INTO THE BODY, AUTOMOTIVE SAFETY OR SE-

CURITY DEVICES, LIFE SUPPORT PRODUCTS OR OTHER CRITICAL APPLICATIONS. INCLUSION OF CIRRUS PRODUCTS IN SUCH APPLICATIONS

IS UNDERSTOOD TO BE FULLY AT THE CUSTOMER'S RISK AND CIRRUS DISCLAIMS AND MAKES NO WARRANTY, EXPRESS, STATUTORY OR IM-

PLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, WITH REGARD TO ANY CIRRUS

PRODUCT THAT IS USED IN SUCH A MANNER. IF THE CUSTOMER OR CUSTOMER'S CUSTOMER USES OR PERMITS THE USE OF CIRRUS PROD-

UCTS IN CRITICAL APPLICATIONS, CUSTOMER AGREES, BY SUCH USE, TO FULLY INDEMNIFY CIRRUS, ITS OFFICERS, DIRECTORS, EMPLOYEES,

DISTRIBUTORS AND OTHER AGENTS FROM ANY AND ALL LIABILITY, INCLUDING ATTORNEYS' FEES AND COSTS, THAT MAY RESULT FROM OR

ARISE IN CONNECTION WITH THESE USES.

Cirrus Logic, Cirrus, and the Cirrus Logic logo designs are trademarks of Cirrus Logic, Inc. All other brand and product names in this document may be trade-

marks or service marks of their respective owners.

SPI is a trademark of Motorola, Inc.

ÐÐ»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: CS4272

Document Outline

Ð­Ð»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: CS4272

Document Outline

ÐÐ»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: CS4272
