D E S C R I P T I O N A N D F E A T U R E S
3990A Series Panel Mounted LED Indicator
E L E C T R O - O P T I C A L C H A R A C T E R I S T I C S
Features
Mounting: Will snap-fit in .217/.221 hole in panels .031/.062 thick.
Wire Leads: No.24 AWG, 4.4/4.8 long, stripped .430/.570
Anode(+): Red lead
Housing: White nylon
Lens: Polycarbonate
All dimensions
in inches.
Part
Number
Color
Typ.
Intensity
(mcd)
Rated
Current
(mA)
Continuous
Forward
Current Max.
(mA)
Forward
Voltage Typ.
(V)
Forward
Voltage Max.
(V)
Peak Forward
Current @1ms-
300pps (A)
Reverse
Break-down
Voltage Min.
(V)
3990A1
3990A3
3990A5
3991A6-5V
Red
Amber
Green
Blue
10
7
16
10
10
10
30
30
30
Use #680 Incandescent Lamp-5V , .06A, 200,000 Hours
2.0
2.2
2.2
3.0
3.0
3.0
1.0
.09
.09
5
5
5
3990A7
Yellow
6.3
10
30
2.1
3.0
1.0
5
.770
.080
.250
