D E S C R I P T I O N A N D F E A T U R E S
7512B8 Series Bright5PipesTM FlexpipeTM Fiber-Optic Lightpipe
AR E A
S T AY OUT
L
C
P A NE L L E NS
S IDE V IE W
-.000
+.003
(2 P LC S )
.156
F R ONT V IE W
B OAR D R E F .
.092 P .C .
F R ONT P ANE L
C LE AR P OLY C AR B ONAT E
MAT E R IAL:
B LAC K LE X AN
B AS E MAT E R IAL:
1.033
2.236
.992
.250
.740
.293
1.084
.648
.552
.200
R E F .
1.453
R E F .
1.253
2.570
.020
.060
.552
8 P LC S .
.100 S Q.
T Y P .
.200
.178
.200
.400
Flexible optical lightpipe with precision fiberoptics for long
distance SMT LED to lens.
Eliminates need for precision mechanical alignment of
components to panel.
7512B8 is designed for use with CMD67-21 and 67-22
series Bright Chip LEDs.
Precision engineered with ray tracing for bright, optically
precise even indication and attractive appearance.
ESD protection from circuitry for exceptional reliability.
High contrast and wide viewing angle for greater
visibility.
Parts inserted after reflow to permit LED pad inspection
before assembly.
Large lens provides high visibility.
Water clear optics for variety of LED colors.
All dimensions in inches.
Mounting hole pattern on page 1-X7.
Note:
Due to their complex nature, all FlexpipeTM
pads must be custom designed to meet your
application needs.
America:
CML Innovative Technologies,Inc.
147 Central Avenue
Hackensack -NJ 07601 -USA
Tel:1-201-489 -8989
Fax:1-201-489 -6911
e-mail:americas@cml-it.com
Europe:
CML Technologies GmbH &Co.KG
Robert-Bunsen-Str.1
67098 Bad Drkheim -GERMANY
Tel:+49 (0)6322 9567-0
Fax:+49 (0)6322 9567-88
e-mail:europe@cml-it.com
Asia:
CML Innovative Technologies,Inc.
61 Aida Street
Singapore 459975
Tel:(65)9630 -5003
e-mail:asia@cml-it.com
CML-IT reserves the right to make specification revisions that enhance the design and/or performance of the product
