PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 1 OF 7
REV.
0
OUTSIDE DIMENSION
13.00
0.26
6.50
7.62
2.54
13.00
3.50
3.0
0
0.4
1.20
2.
7
0
0.5
XXX
4.80
Date Code
Y210BH
Turn On / Turn Off time
Output
T
ON
Input
T
OFF
90%
10%
1
4
2
4
3
3
DEVICE
DEVICE
NORMALLY OPEN
1 FORM A
Absolute Maximum Ratings
Ta=25
EmitterInput
DetectorOutput
Reverse Voltage .................................... 5.0V Output Breakdown Voltage ..................... 350V
Continuous Forward Current ..................
50mA Continuous Load Current ..................
130mA
Peak Forward Current ................................. 1A Power Dissipation ..............................
500mW
Power Dissipation ..............................
100mW
Derate Linearly from 25 .................. 1.3mW/
General Characteristics
Isolation Test Voltage .................. 5000VACrms Storage Temperature Range ...... -40 to +125
Operating Temperature Range ...
-40 to +85
Isolation Resistance
Vio=500VTa=25 ........................... 10
10
Junction Temperature .............................. 100
Total Power Dissipation ........................ 550mW
Derate Linearly from 25 .................. 2.5mW/
Soldering Temperature
2mm from case10 sec ........................... 260
Unitmm
Tolerance0.2mm
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 2 OF 7
REV.
0
Electro-optical Characteristics
Ta=25
Parameter
Symbol
Conditions
Min. Typ. Max. Unit.
EmitterInput
Forward Voltage
V
F
I
F
=10mA
1.2
1.5
V
Operation Input Current
IF
ON
V
L
=20VI
L
=100mAt=10ms
5.0
mA
Recovery Input Current
IF
OFF
V
L
=20VI
L
5A
0.05 mA
DetectorOutput
Output Breakdown Voltage
V
B
I
B
=50A 350
V
Output Off-State Leakage
IT
OFF
V
T
=100VI
F
=0mA
0.7 2 A
I/O Capacitance
C
ISO
I
F
=0f=1MHz
6 pF
ON Resistance
R
ON
I
L
=100mAI
F
=10mA
28
35
Turn-On Time
T
ON
0.1
0.5
ms
Turn-Off Time
T
OFF
I
F
=10mAV
L
=20V
t=10msI
L
=100mA
0.3
0.5
ms
Schematic and Wiring Diagrams
Schematic
Output
Configuration
Load Connection
Wiring Diagrams
2
1
D
E
VICE
3
DEVICE
4
1a AC/DC
-
I
L
Load
(AC,DC)
V
L
(AC,DC)
2
IN
V
F
I
1
I
L
V
L
3
Load
4
V
2
IN
I
F
1
3
4
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 3 OF 7
REV.
0
Data Curve
Load current vs. ambient temperature
Allowable ambient Temperature
-40 to +85
On resistance vs. ambient temperature
across terminals 3 and 4 pin
LED current5mA
Continuous load current130mADC
Load current
mA
0
-20
-40
0
20 40 60
100
80
140
40
20
60
80
100
120
On resist
ance
0
20
-20
-40
0
60
40
80
60
20
30
50
40
Ambient temperature Ta
Ambient temperature Ta
Turn On Time vs. ambient temperature
Load voltage 350VDC
LED current5mA
Continuous load current130mADC
Turn Off Time vs. ambient temperature
Load voltage 350VDC
LED current5mA
Continuous load current130mADC
T
u
rn On T
i
me
ms
80
60
40
0
-40 -20
20
0
1.2
0.4
0.6
0.8
1.0
T
u
rn Off T
i
me
ms
100
80
60
40
20
0
-20
-40
0
2.5
0.5
1.0
1.5
2.0
Ambient temperature Ta
Ambient temperature Ta
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 4 OF 7
REV.
0
LED operate current vs.
ambient temperature
Load Voltage350VDC
Continuous load current130mADC
LED Turn Off current vs.
ambient temperature
Load Voltage350VDC
Continuous load current130mADC
LED operate current
mA
-40
0
1
3
2
4
-20
0
20 40
5
60 80
LED T
u
rn Off current
mA
0
1
-20
-40
3
2
4
5
80
40
0
20
60
Ambient temperature Ta
Ambient temperature Ta
LED dropout voltage vs.
ambient temperature
LED current5 to 50mA
Voltage vs. current characteristics
of output at MOSFET portion
Measured portionacross terminals
3 and 4 pin
Ambient temperature25
LED dropout volt
age
V
80
-20
-40
0
20 40 60
1.9
1.3
0
0.9
1.1
1.7
1.5
100
5mA
50mA
10mA
20mA
30mA
V
o
lt
age VS. Current
Characteristics
60
80
20
40
100
120
Curr
en
t mA
-4
-5
-2
-3
-1
5
4
3
2
1
Voltage V
-80
-120
-100
-40
-60
-20
Ambient temperature Ta Ambient
temperature25
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 5 OF 7
REV.
0
LED forward current vs. Turn On Time
Across terminals 3 and 4pin
Load voltage350VDC
Continuous load current130mADC
Ambient temperature25
Off state leakage current
Across terminals 3 and 4 pin
Ambient temperature25
T
u
rn On T
i
me
ms
0
0
10
20
30
40
50
60
0.5
1.0
1.5
2.0
Off st
ate leakage cu
rrent
10
40
0
20
60
80
100
-12
-9
10
-6
10
-3
10
LED forward currentmA Load
voltageV
LED forward current vs. Turn Off Time
Across terminals 3 and 4 pin
Load voltage350VDC
Continuous load current130mADC
Ambient temperature25
Applied voltage vs. output capacitance
Across terminals 3 and 4 pin
Frequency1MHz
Ambient temperature25
T
u
rn Off T
i
me
ms
0
0
10
20
30
40
50
1.5
0.5
1.0
2.5
2.0
60
Output cap
acit
a
nce
pF
0
0
10
20
30
40
50
60
10
20
30
40
50
LED forward currentmA Applied
voltageV
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 6 OF 7
REV.
0
USING METHODS
Examples of resistance value to
control LED forward currentIF
SSR-MOSFET OUTPUT
IF=5mA
E
R
4
3
2
1
E R
3.3V Approx.
330
5V Approx.
640
12V Approx.
1.9K
15V Approx.
2.5K
24V Approx.
4.1K
1 LED forward current must be more than 5mAat E min.
2 LED forward current must be less than 50mAat E max.
Emin.
Emax.
PRODUCT SPECIFICATION
DATE03/01/2005
Preliminary
cosmo
ELECTRONICS CORPORATION
SOLID STATE RELAY - MOSFET OUTPUT
KAQY210BH
SHEET 7 OF 7
REV.
0
USING METHODS
Regulate the spike voltage generated on the inductive
load as follows
2
1
3
4
Load
2
1
R-C Snubber
3
4
Load
