Uses Potentiometer for
Economical Pow er Control
Industry Standard Package
FastFax Document No. 205
SERIES RPC.
Rev. 041902
PAGE 1 OF 2
The RPC series proportional controllers
provide a cost effective method of con-
trolling power in many different appli-
cations such as heaters, universal
motors or incandescent lamps. A cus-
tomer provided potentiometer is all that
is required for control. All modules are
supplied with KS100 protective cover.
Series RPC
Solid State Proportional Controller
15-40 Amp, 120/240/480 Vac Output
8 M O D E L
N U M B E R S
RPC1215 RPC1225 RPC1240
RPC2415 RPC2425 RPC2440
RPC4815 RPC4825 RPC4840
OUTPUT SPECIFICATIONS
Operating Voltage (47-63 Hz) [Vac]
90-130
90-130
90-130
200-240 200-240 200-240
400-480 400-480 400-480
Max. Load Current
[Arms]
15
25
40
15
25
40
15
25
40
Min. Load Current, [mArms]
70
80
90
70
80
90
70
80
90
Transient Overvoltage [Vpk]
400
400
400
600
600
600
1200
1200
1200
Max. Surge Current, (16.6ms) [Apk]
150
250
625
150
250
625
150
250
625
Max. On-State Voltage Drop @ Rated Current [Vpk]
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
Thermal Resistance Junction to Case [R
JC]
1.48
1.02
.63
1.48
1.02
.63
1.48
1.02
.63
Maximum I2 t for Fusing, (8.3 msec.) [A2sec]
94
260
1620
94
260
1620
94
260
1620
Max. Off-State Leakage Current @ Rated Voltage [mArms]
10
10
10
7
7
7
3
3
3
Min. Off-State dv/dt @ Max. Rated Voltage [V/sec]
500
500
500
500
500
500
500
500
500
Max. Turn-On Time
[msec]
Max. Turn-Off Time [msec]
Power Factor (Min.) with Max. Load
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
Snubber (Internal)
yes
yes
yes
yes
yes
yes
no
no
no
INPUT SPECIFICATIONS
Resistor, Variable [Ohms]
150K (1W) 150K (1W) 150K (1W)
1M (1/2W) 1M (1/2W) 1M (1/2W) 1M (1/2W) 1M (1/2W) 1M (1/2W)
GENERAL NOTES
All parameters at 25C unless otherwise specified.
Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
Heat sinking required, for derating curves see page 2.
Potentiometer should be selected with regards to line voltage isolation.
W ARNING
Control to load is not isolated, excercise care in handling the
RPC products to avoid the risk of electric shock.
2002 CRYDOM CORP, Specifications subject to change without notice.
For recommended applications and more information contact:
USA: Sales Support (877) 502-5500 Tech Support (877) 702-7700 FAX (619) 710-8540
Crydom Corp, 2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email: sales@crydom.com WEB SITE: http://www.crydom.com
UK: +44 (0)1202 365070 FAX +44 (0)1202 365090 Crydom International Ltd., 7 Cobham
Road, Ferndown Industrial Estate, Ferndown, Dorset BH21 7PE, Email: intsales@crydom.com.
GERMANY: +49 (0)180 3000 506
1.87
(47.5)
.78
(19.8)
2.30
(58.4)
1.70
(43.2)
.87
(22.1)
.45
(11.4)
1.10
(27.9)
8-32 TERMINAL
(2 PLACES )
1.00
(25.4)
6-32 TERMINAL
(2 PLACES)
1.80
(45.7)
1
2
OUTPUT
3
4
INPUT
MOUNTING
HOLE/SLOT
0.17 (4.3) DIA.
GENERAL SPECIFICATIONS
Dielectric Strength, All Terminals to Base
2500 Vrms
Ambient Operating Temperature Range
-30 to 80C
Ambient Storage Temperature Range
-40 to 125C
M ECHANICAL SPECIFICATIONS
Weight: (typical)
3.2oz. (90g)
Encapsulation:
Thermally Conductive Epoxy
Terminals:
Screws and Saddle Clamps Furnished, Unmounted
CAUTION
All terminals are
at Line Voltage
Potential.
30
20
10
25
15
5
0
5
10
20
25
15
20
40
60
80
Load Current [Arms]
Max Ambient Temp. [C]
Power Dissipation
95
120
Base Plate Temp [
C]
25A
1C/W
100
110
3C/W
NO HEATSINK
60
40
20
0
10
20
40
50
30
20
40
60
80
Load Current [Arms]
Max Ambient Temp. [C]
Power Dissipation
90
Base Plate Temp [
C]
40A
2C/W
1C/W .5C/W
100
110
120
1.5C/W
NO HEATSINK
2C/W
15
10
5
0
3
6
12
15
9
20
40
60
80
Load Current [Arms]
Max Ambient Temp. [C]
Power Dissipation
Base Plate Temp [
C]
15A
4C/W
2C/W
6C/W
NO HEATSINK
112
124
116
120
CURRENT DERATING CURVES
W IRING
DIAGRAM
PERCENTAGE ON vs. INPUT RESISTANCE
100
80
60
40
20
0
Percentage ON
RPC1215, RPC1225, RPC1240
RPC4815, RPC4825, RPC4840
50 Hz
60 Hz
100
80
60
40
20
0
0
200
400
600
800
1200
1000
Input Resistance [k
]
0
20
40
60
80
120
100
140
Input Resistance [k
]
Percentage ON
RPC2415, RPC2425, RPC2440
100
80
60
40
20
0
0
200
400
600
800
1200
1000
Input Resistance [k
]
Percentage ON
50 Hz
60 Hz
50 Hz
60 Hz
PROPORTIONAL
CONTROLLER
1
2
4
3
~
Variable Resistance
FastFax Document No. 205
SERIES RPC.
Rev. 041902
PAGE 2 OF 2
Series RPC
Solid State Proportional Controller
15-40 Amp, 120/240/480 Vac Output
2002 CRYDOM CORP, Specifications subject to change without notice.
All dimensions are in inches (millimeters)
Screw Torque Requirements:
6-32 Screws - 10 in. lbs.,
8-32 and 10-32 Screws - 20in. lbs.
(Screws dry without grease.)
