How to order:
RS1
1002
J
1
Parts Code
Resistance Value
Tolerance
Electrode type
1002 = 100 X 10
B : 0.1%
1 : Rectangular
33R0 = 33 X 10
D : 0.5%
F : 1.0%
J : 5.0%
2
0
Specifications
Performance Data
Isolated Resistor Network (8P4R-0603x4)
*1 If special design of different resistance is required, please contact Cyntec for more details.
*2 For tracking tolerance request, please contact Cyntec for more information.
*3 Made by printing process.
0.1%
Resistance Tolerance
B,D,F
J
Maximum Rated Operating Temperature
+70 C
+70 C
Maximum Operating Temperature
+125 C
+125 C
Short-time Overload
0.5%
2%
Loading Life
0.5%
3%
Moisture Life
0.5%
3%
Temperature Cycle
0.5%
1%
o
o
o
o
8
5
1
4
1.6
0.15
0.3
0.2
0.5
0.1
0.3
0.1
0.4
0.1
3.2
0.3
0.8
0.65
0.1
(1206)/(3216)
Physical Dimension
(mm)
Schematic Diagram
Power Rating
63mW/element
Resistance Range*
Resistance Tolerance *
Resistance Value
E-24
Maximum Operation Voltage
75 V
1
2
10
~ 91
100
~33K
36k
~330k
0
, 10
~1M
0.5%, 1%
0.5%, 1%
0.5%, 1%
5%
