PRELIMINARY
TX2TM USB 2.0 UTMI Transceiver
CY7C68000
Cypress Semiconductor Corporation
3901 North First Street
San Jose
,
CA 95134
408-943-2600
Document #: 38-08016 Rev. *E
Revised November 2, 2004
1.0
EZ-USB
TX2
Features
The Cypress EZ-USB TX2
is a Universal Serial Bus (USB)
specification revision 2.0 transceiver, serial/deserializer, to a
parallel interface of either 16 bits at 30 MHz or eight bits at 60
MHz. The TX2 provides a high-speed physical layer interface
that operates at the maximum allowable USB 2.0 bandwidth.
This allows the system designer to keep the complex high-
speed analog USB components external to the digital ASIC
which decreases development time and associated risk. A
standard interface is provided that is USB 2.0-certified and is
compliant with Transceiver Macrocell Interface (UTMI) speci-
fication version 1.05 dated 3/29/01.
Two packages are defined for the family: 56-pin SSOP and 56-
pin QFN.
The function block diagram is shown in Figure 1-1.
UTMI-compliant/USB-2.0-certified for device operation
Operates in both USB 2.0 high speed (HS), 480
Mbits/second, and full speed (FS), 12 Mbits/second
Serial-to-parallel and parallel-to-serial conversions
8-bit unidirectional, 8-bit bidirectional, or 16-bit bidirec-
tional external data interface
Synchronous field and EOP detection on receive pack-
ets
Synchronous field and EOP generation on transmit
packets
Data and clock recovery from the USB serial stream
Bit stuffing/unstuffing; bit stuff error detection
Staging register to manage data rate variation due to
bit stuffing/unstuffing
16-bit 30-MHz, and 8-bit 60-MHz parallel interface
Ability to switch between FS and HS terminations and
signaling
Supports detection of USB reset, suspend, and resume
Supports HS identification and detection as defined by
the USB 2.0 Specification
Supports transmission of resume signaling
3.3V operation
Two package options--56-pin QFN, and 56-pin SSOP
All required terminations, including 1.5K-ohm pull-up
on DPLUS, are internal to chip
Supports USB 2.0 test modes.
Figure 1-1. Block Diagram
USB
2.0
XCVR
Traffic
Sync
Elasticity
Buffer
Fast
Digital
Rx
Digital
Rx
Digital
Tx
Fast
Digital
Tx
Full-Speed Rx
Full-Speed Tx
High-Speed Tx
High-Speed Rx
BIDI Option
Also
OSC
20X
PLL
PLL_480
UTMI CLK
XTALIN/
OUT
USB
UTMI Rx Ctl
UTMI Tx Ctl
CY7C68000
UTMI CLK
UTMI Rx Data 8/16
UTMI Rx Data 8/16
CY7C68000
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 2 of 14
2.0
Applications
DSL modems
ATA interface
Memory card readers
Legacy conversion devices
Cameras
Scanners
Home PNA
Wireless LAN
MP3 players
Networking.
3.0
Functional Overview
3.1
USB Signaling Speed
TX2 operates at two of the rates defined in the USB Specifi-
cation 2.0, dated April 27, 2000:
Full speed, with a signaling bit rate of 12 Mbps
High speed, with a signaling bit rate of 480 Mbps.
TX2 does not support the low-speed (LS) signaling rate of 1.5
Mbps.
3.2
Transceiver Clock Frequency
TX2 has an on-chip oscillator circuit that uses an external 24-
MHz (100-ppm) crystal with the following characteristics:
Parallel resonant
Fundamental mode
500-
W drive level
2733 pF (5% tolerance) load capacitors.
An on-chip phase-locked loop (PLL) multiplies the 24-MHz
oscillator up to 30/60 MHz, as required by the transceiver
parallel data bus. The default UTMI interface clock (CLK)
frequency is determined by the DataBus16_8 pin.
3.3
Buses
The two packages allow for 8/16-bit bidirectional data bus for
data transfers to a controlling unit.
3.4
Reset Pin
An input pin (Reset) resets the chip. This pin has hysteresis
and is active HIGH according to the UTMI specification. The
internal PLL stabilizes approximately 200
s after V
CC
has
reached 3.3V.
3.5
Line State
The Line State output pins LineState[1:0] are driven by combi-
national logic and may be toggling between the "J" and the "K"
states. They are synchronized to the CLK signal for a valid
signal. On the CLK edge the state of these lines reflect the
state of the USB data lines. Upon the clock edge the 0-bit of
the LineState pins is the state of the DPLUS line and the one
bit of LineState is the DMINUS line. When synchronized, the
set-up and hold timing of the LineState is identical to the
parallel data bus.
3.6
Full-speed vs. High-speed Select
The FS vs. HS is done through the use of both XcvrSelect and
the TermSelect input signals. The TermSelect signal enables
the 1.5 K ohm pull-up on to the DPLUS pin. When TermSelect
is driven LOW, a SE0 is asserted on the USB providing the HS
termination and generating the HS Idle state on the bus. The
XcvrSelect signal is the control which selects either the FS
transceivers or the HS transceivers. By setting this pin to a "0"
the HS transceivers are selected and by setting this bit to a "1"
the FS transceivers are selected.
3.7
Operational Modes
The operational modes are controlled by the OpMode signals.
The OpMode signals are capable of inhibiting normal
operation of the transceiver and evoking special test
modes.
These modes take effect immediately and take precedence
over any pending data operations. The transmission data rate
when in OpMode depends on the state of the XcvrSelect
input.
Mode 0 allows the transceiver to operate with normal USB
data decoding and encoding.
Mode 1 allows the transceiver logic to support a soft
disconnect feature which three-states both the HS and FS
transmitters, and removes any termination from the USB,
making it appear to an upstream port that the device has been
disconnected from the bus.
Mode 2 disables Bit Stuff and NRZI encoding logic so 1s
loaded from the data bus becomes Js on the DPLUS/DMINUS
lines and 0s become Ks.
4.0
DPLUS/DMINUS Impedance Termina-
tion
The CY7C68000 does not require external resistors for USB
data line impedance termination or an external pull up resistor
on the DPLUS line. These resistors are incorporated into the
part. They are factory trimmed to meet the requirements of
USB 2.0. Incorporating these resistors also reduces the pin
count on the part.
OpMode[1:0]
Mode
Description
00
0
Normal operation
01
1
Non-driving
10
2
Disable Bit Stuffing and
NRZI encoding
11
3
Reserved
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 3 of 14
5.0
Pin Assignments
The following pages illustrate the individual pin diagrams that
are available in the 56-pin QFN and 56-pin SSOP packages.
The packages offered use either an 8-bit (60-MHz) or 16-bit
(30-MHz) bus interface.
D4
D3
V
CC
D2
Re
s
e
r
v
ed
D1
D0
CLK
Data
Bu
s1
6_8
Uni
_bi
di
GND
TX
Va
li
d
V
CC
Va
li
d
H
56-pin QFN
Figure 5-1. CY7C68000 56-pin QFN Pin Assignment
28
27
26
25
24
23
22
21
20
19
18
17
16
15
43
44
45
46
47
48
49
50
51
52
53
54
55
56
1
2
3
4
5
6
7
8
9
10
11
12
13
14
42
41
40
39
38
37
36
35
34
33
32
31
30
29
GND
D5
Reserved
D6
D7
D8
D9
Reserved
D10
D11
V
CC
D12
GND
D13
TXReady
Suspend
Reset
AV
CC
XTALOUT
XTALIN
AGND
AV
CC
DPLUS
DMINUS
AGND
XcvrSelect
TermSelect
OpMode0
V
CC
D14
D15
Res
e
rv
ed
Res
e
rv
ed
RXE
rro
r
RX
A
c
ti
v
e
RX
V
a
l
i
d
GND
Li
neS
tate
1
Li
neS
tate
0
V
CC
GND
O
p
Mo
de1
CY7C68000
56-pin QFN
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 4 of 14
5.1
CY7C68000 Pin Descriptions
56-pin SSOP
Figure 5-2. CY7C68000 56-pin SSOP Pin Assignment
DPLUS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
CLK
DataBus16_8
Uni_Bidi
GND
TXValid
V
CC
ValidH
TXReady
Suspend
Reset
AVCC
XTALOUT
XTALIN
AGND
AVCC
DMINUS
AGND
XcvrSelect
TermSelect
OpMode0
OpMode1
GND
V
CC
LineState0
LineState1
GND
RXValid
D10
D0
D1
Reserved
D2
V
CC
D3
D4
GND
D5
Reserved
D6
D7
D8
D9
Reserved
D11
V
CC
D12
GND
D13
V
CC
D14
D15
Reserved
Reserved
RXError
RXActive
Table 5-1. Pin Descriptions
[1]
SSOP QFN
Name
Type
Default
Description
11
4
AVCC
Power
N/A
Analog V
CC
. This signal provides power to the analog section of the chip.
15
8
AVCC
Power
N/A
Analog V
CC
. This signal provides power to the analog section of the chip.
14
7
AGND
Power
N/A
Analog Ground. Connect to ground with as short a path as possible.
18
11
AGND
Power
N/A
Analog Ground. Connect to ground with as short a path as possible.
16
9
DPLUS
I/O/Z
Z
USB DPLUS Signal. Connect to the USB DPLUS signal.
17
10
DMINUS
I/O/Z
Z
USB DMINUS Signal. Connect to the USB DMINUS signal.
Note:
1.
Unused inputs should not be left floating. Tie either HIGH or LOW as appropriate. Outputs that are three-statable should only be pulled up or down to ensure
signals at power-up and in standby.
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 5 of 14
56
49
D0
I/O
Bidirectional Data Bus. This bidirectional bus is used as the entire data
bus in the 8-bit bidirectional mode or the least significant eight bits in the 16-
bit mode or under the 8 bit uni-directional mode these bits are used as inputs
for data, selected by the RxValid signal.
55
48
D1
I/O
53
46
D2
I/O
51
44
D3
I/O
50
43
D4
I/O
48
41
D5
I/O
46
39
D6
I/O
45
38
D7
I/O
44
37
D8
I/O
Bidirectional Data Bus. This bidirectional bus is used as the upper eight
bits of the data bus when in the 16-bit mode, and not used when in the 8-bit
bidirectional mode. Under the 8 bit uni-directional mode these bits are used
as outputs for data, selected by the TxValid signal.
43
36
D9
I/O
41
34
D10
I/O
40
33
D11
I/O
38
31
D12
I/O
36
29
D13
I/O
34
27
D14
I/O
33
26
D15
I/O
1
50
CLK
Output
Clock. This output is used for clocking the receive and transmit parallel data
on the D[15:0] bus.
10
3
Reset
Input
N/A
Active HIGH Reset. Resets the entire chip. This pin can be tied to V
CC
through a 0.1-
F capacitor and to GND through a 100K resistor for a 10
msec RC time constant.
19
12
XcvrSelect
Input
N/A
Transceiver Select. This signal selects between the Full Speed (FS) and
the High Speed (HS) transceivers:
0: HS transceiver enabled
1: FS transceiver enabled
20
13
TermSelect Input
N/A
Termination Select. This signal selects between the between the Full
Speed (FS) and the High Speed (HS) terminations:
0: HS termination
1: FS termination
9
2
Suspend
Input
N/A
Suspend. Places the CY7C68000 in a mode that draws minimal power from
supplies. Shuts down all blocks not necessary for Suspend/Resume opera-
tions. While suspended, TermSelect must always be in FS mode to ensure
that the 1.5 K ohm pull-up on DPLUS remains powered.
0: CY7C68000 circuitry drawing suspend current
1: CY7C68000 circuitry drawing normal current
26
19
LineState1
Output
Line State. These signals reflect the current state of the single-ended
receivers. They are combinatorial until a "usable" CLK is available then they
are synchronized to CLK. They directly reflect the current state of the
DPLUS (LineState0) and DMINUS (LineState1).
D- D+ Description
0 0 0: SE0
0 1 1: `J' State
1 0 2: `K' State
1 1 3: SE1
Table 5-1. Pin Descriptions (continued)
[1]
SSOP QFN
Name
Type
Default
Description
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 6 of 14
25
18
LineState0
Output
Line State. These signals reflect the current state of the single-ended
receivers. They are combinatorial until a "usable" CLK is available then they
are synchronized to CLK. They directly reflect the current state of the
DPLUS (LineState0) and DMINUS (LineState1).
D- D+ Description
000: SE0
011: `J' State
102: `K' State
113: SE1.
22
15
OpMode1
Input
Operational Mode. These signals select among various operational
modes:
10 Description
000: Normal Operation
011: Non-driving
102: Disable Bit Stuffing and NRZI encoding
113: Reserved.
21
14
OpMode0
Input
Operational Mode. These signals select among various operational
modes:
10 Description
000: Normal Operation
011: Non-driving
102: Disable Bit Stuffing and NRZI encoding
113: Reserved.
5
54
TXValid
Input
Transmit Valid. Indicates that the data bus is valid. The assertion of Trans-
mit Valid initiates SYNC on the USB. The negation of Transmit Valid initiates
EOP on the USB. The start of SYNC must be initiated on the USB no less
than one or no more that two CLKs after the assertion of TXValid.
In HS (XcvrSelect = 0) mode, the SYNC pattern must be asserted on the
USB between 8- and 16-bit times after the assertion of TXValid is detected
by the Transmit State Machine.
In FS (Xcvr = 1), the SYNC pattern must be asserted on the USB no less
than one or more than two CLKs after the assertion of TXValid is detected
by the Transmit State Machine.
8
1
TXReady Output
Transmit Data Ready. If TXValid is asserted, the SIE must always have
data available for clocking in to the TX Holding Register on the rising edge
of CLK. If TXValid is TRUE and TXReady is asserted at the rising edge of
CLK, the CY7C68000 will load the data on the data bus into the TX Holding
Register on the next rising edge of CLK. At that time, the SIE should immedi-
ately present the data for the next transfer on the data bus
.
28
21
RXValid
Output
Receive Data Valid. Indicates that the DataOut bus has valid data. The
Receive Data Holding Register is full and ready to be unloaded. The SIE is
expected to latch the DataOut bus on the clock edge.
29
22
RXActive
Output
Receive Active. Indicates that the receive state machine has detected
SYNC and is active.
RXActive is negated after a bit stuff error or an EOP is detected.
30
23
RXError
Output
Receive Error.
0 Indicates no error.
1 Indicates that a receive error has been detected.
7
56
ValidH
I/O
ValidH. This signal indicates that the high-order eight bits of a 16-bit data
word presented on the Data bus are valid. When DataBus16_8 = 1 and
TXValid = 0, ValidH is an output, indicating that the high-order receive data
byte on the Data bus is valid. When DataBus16_8 = 1 and TXValid = 1,
ValidH is an input and indicates that the high-order transmit data byte,
presented on the Data bus by the transceiver, is valid. When DataBus16_8
= 0, ValidH is undefined. The status of the receive low-order data byte is
determined by RXValid and are present on D0D7.
Table 5-1. Pin Descriptions (continued)
[1]
SSOP QFN
Name
Type
Default
Description
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 7 of 14
2
51
DataBus16_8
Input
Data Bus 16_8. Selects between 8- and 16-bit data transfers.
116-bit data path operation enabled. CLK = 30 MHz.
08-bit data path operation enabled. When Uni_Bidi = 0, D[8:15] are unde-
fined. When Uni_Bidi =1, D[0:7] are valid on TxValid and D[8:15] are valid
on RxValid. CLK = 60 MHz
Note: DataBus16_8 is static after Power-on Reset (POR) and is only sam-
pled at the end of Reset.
13
6
XTALIN
Input
N/A
Crystal Input. Connect this signal to a 24-MHz parallel-resonant, funda-
mental mode crystal and 20-pF capacitor to GND.
It is also correct to drive XTALIN with an external 24-MHz square wave
derived from another clock source.
12
5
XTALOUT
Output
N/A
Crystal Output. Connect this signal to a 24-MHz parallel-resonant, funda-
mental mode crystal and 30-pF (nominal) capacitor to GND. If an external
clock is used to drive XTALIN, leave this pin open.
3
52
Uni_Bidi
Input
Driving this pin HIGH enables the unidirectional mode when the 8-bit
interface is selected. Uni_Bidi is static after power on reset (POR).
6
55
V
CC
Power
V
CC
. Connect to 3.3V power source.
24
17
V
CC
Power
N/A
V
CC
. Connect to 3.3V power source.
35
28
V
CC
Power
N/A
V
CC
. Connect to 3.3V power source.
39
32
V
CC
Power
N/A
V
CC
. Connect to 3.3V power source.
52
45
V
CC
Power
N/A
V
CC
. Connect to 3.3V power source.
4
53
GND
Ground
N/A
Ground.
23
16
GND
Ground
N/A
Ground.
27
20
GND
Ground
N/A
Ground.
37
30
GND
Ground
N/A
Ground.
49
42
GND
Ground
N/A
Ground.
31
24
Reserved
INPUT
Connect pin to Ground.
54
47
Reserved
INPUT
Connect pin to Ground.
47
40
Reserved
INPUT
Connect pin to Ground.
42
35
Reserved
INPUT
Connect pin to Ground.
32
25
Reserved
INPUT
Connect pin to Ground.
Table 5-1. Pin Descriptions (continued)
[1]
SSOP QFN
Name
Type
Default
Description
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 8 of 14
6.0
Absolute Maximum Ratings
Storage Temperature ................................. 65C to +150C
Ambient Temperature with Power Supplied ...... 0C to +70C
Supply Voltage to Ground Potential ............... 0.5V to +4.0V
DC Input Voltage to Any Input Pin .............................. 5.25 V
DC Voltage Applied to Outputs in High-Z State 0.5V to V
CC
+
0.5V
Power Dissipation .....................................................630 mW
Static Discharge Voltage...........................................> 2000V
Max Output Current, per IO pin..................................... 4 mA
Max Output Current, all 21IO pins ............................84 mA
7.0
Operating Conditions
T
A
(Ambient Temperature Under Bias) ............. 0C to +70C
Supply Voltage ...............................................+3.0V to +3.6V
Ground Voltage ................................................................. 0V
F
OSC
(Oscillator or Crystal Frequency) ... 24 MHz 100 ppm
.................................................................. Parallel Resonant
8.0
DC Characteristics
8.1
USB 2.0 Transceiver
USB 2.0 compliant in FS and HS modes.
Note:
2.
Connected to the USB includes 1.5k ohm internal pull-up. Disconnected has the 1.5k-ohm internal pull-up excluded.
Table 8-1. DC Characteristics
Parameter
Description
Conditions
Min.
Typ.
Max.
Unit
V
CC
Supply Voltage
3.0
3.3
3.6
V
V
IH
Input High Voltage
2
5.25
V
V
IL
Input Low Voltage
0.5
0.8
V
I
I
Input Leakage Current
0< V
IN
< V
CC
10
A
V
OH
Output Voltage High
I
OUT
= 4 mA
2.4
V
V
OL
Output Low Voltage
I
OUT
= 4 mA
0.4
V
I
OH
Output Current High
4
mA
I
OL
Output Current Low
4
mA
C
IN
Input Pin Capacitance
Except DPLUS/DMINUS/CLK
10
pF
DPLUS/DMINUS/CLK
15
pF
C
LOAD
Maximum Output Capacitance
Output pins
30
pF
I
SUSP
Suspend Current
Connected
[2]
235
293
A
Disconnected
[2]
15
55
A
I
CC
Supply Current HS Mode
Normal operation OPMOD[1:0] = 00
175
mA
I
CC
Supply Current FS Mode
Normal operation OPMOD[1:0] = 00
90
mA
t
RESET
Minimum Reset time
1.9
ms
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 9 of 14
9.0
AC Electrical Characteristics
9.1
USB 2.0 Transceiver
USB 2.0 certified in FS and HS.
9.2
Timing Diagram
9.2.1
HS/FS Interface Timing60 MHz
Table 9-1. 60-MHz Interface Timing Constraints Parameters
Parameter
Description
Min.
Typ.
Max.
Unit
Notes
T
CSU_MIN
Minimum set-up time for TXValid
8
ns
T
CH_MIN
Minimum hold time for TXValid
1
ns
T
DSU_MIN
Minimum set-up time for Data (transmit direction)
8
ns
T
DH_MIN
Minimum hold time for Data (transmit direction)
1
ns
T
CCO
Clock to Control out time for TXReady, RXValid,
RXActive and RXError
1
8
ns
T
CDO
Clock to Data out time (Receive direction)
1
8
ns
TCSU_MIN
TCH_MIN
TDSU_MIN
TDH_MIN
TCDO
TCCO
DataIn
DataOut
Control_Out
Control_In
CLK
Figure 9-1. 60-MHz Interface Timing Constraints
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 10 of 14
9.2.2
HS/FS Interface Timing30 MHz
TCSU_MIN
TCH_MIN
TDSU_MIN
TDH_MIN
TCVO
TCCO
DataIn
DataOut
Control_Out
Control_In
CLK
TCDO
TVSU_MIN
TVH_MIN
Figure 9-2. 30-MHz Timing Interface Timing Constraints
Table 9-2. 30 MHz Timing Interface Timing Constraints Parameters
Parameter
Description
Min.
Typ.
Max.
Unit
Notes
T
CSU_MIN
Minimum set-up time for TXValid
20
ns
T
CH_MIN
Minimum hold time for TXValid
1
ns
T
DSU_MIN
Minimum set-up time for Data (Transmit direction)
20
ns
T
DH_MIN
Minimum hold time for Data (Transmit direction)
1
ns
T
CCO
Clock to Control Out time for TXReady, RXValid,
RXActive and RXError
1
20
ns
T
CDO
Clock to Data out time (Receive direction)
1
20
ns
T
VSU_MIN
Minimum set-up time for ValidH (transmit Direction)
20
ns
T
VH_MIN
Minimum hold time for ValidH (Transmit direction)
1
ns
T
CVO
Clock to ValidH out time (Receive direction)
1
20
ns
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 11 of 14
10.0
Ordering Information
11.0
Package Diagrams
The TX2 is available in two packages:
56-pin SSOP
56-pin QFN.
Table 10-1. Ordering Information
Ordering Code
Package Type
CY7C68000-56LFC
56 QFN
CY7C68000-56PVC
56 SSOP
CY7C68000-56PVCT
56 SSOP Tape/Reel
CY3683
EZ-USB TX2 Development Board
51-85062-*C
Figure 11-1. 56-lead Shrunk Small Outline Package O56
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 12 of 14
12.0
PCB Layout Recommendations
[3]
The following recommendations should be followed to ensure
reliable high-performance operation.
At least a four-layer impedance controlled boards are
required to maintain signal quality.
Specify impedance targets (ask your board vendor what
they can achieve).
To control impedance, maintain trace widths and trace
spacing.
Minimize stubs to minimize reflected signals.
Connections between the USB connector shell and signal
ground must be done near the USB connector.
Bypass/flyback caps on VBus, near connector, are recom-
mended.
DPLUS and DMINUS trace lengths should be kept to within
2 mm of each other in length, with preferred length of
2030mm.
Maintain a solid ground plane under the DPLUS and
DMINUS traces. Do not allow the plane to be split under
these traces.
It is preferred is to have no vias placed on the DPLUS or
DMINUS trace routing.
Isolate the DPLUS and DMINUS traces from all other signal
traces by no less than 10 mm.
Note:
3.
Source for recommendations: EZ-USB FX2TM PCB Design Recommendations, http:///www.cypress.com/cfuploads/support/app_notes/FX2_PCB.pdf High-
Speed USB Platform Design Guidelines, http://www.usb.org/developers/docs/hs_usb_pdg_r1_0.pdf.
Figure 11-2. 56-lead Quad Flatpack No Lead Package (8 x 8 mm) (SAWN VERSION)
A
8.10[0.319]
7.90[0.311]
7.90[0.311]
8.10[0.319]
0.20[0.008] REF.
0.04[0.0015] MAX.
C
0.50[0.020]
6.55[0.258]
6.45[0.254]
0.28[0.011]
0.18[0.007]
6.55[0.258]
6.45[0.254]
SEATING
PLANE
C
0.08[0.003]
0.30[0.012]
0.50[0.020]
1.00[0.039] MAX.
TOP VIEW
BOTTOM VIEW
SIDE VIEW
PIN #1
CORNER
PIN #1
CORNER
E-PAD
(PAD SIZE VARY
BY DEVICE TYPE)
DIMENSIONS IN MM[INCHES] MIN.
MAX.
REFERENCE JEDEC MO-220
51-85187-*A
56-Lead QFN 8 x 8 mm (Sawn Version) LS56B
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 13 of 14
Cypress Semiconductor Corporation, 2004. The information contained herein is subject to change without notice. Cypress Semiconductor Corporation assumes no responsibility for the use
of any circuitry other than circuitry embodied in a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor intended to be
used for medical, life support, life saving, critical control or safety applications, unless pursuant to an express written agreement with Cypress. Furthermore, Cypress does not authorize its
products for use as critical components in life-support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user. The inclusion of Cypress
products in life-support systems application implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.
13.0
Quad Flat Package No Leads (QFN)
Package Design Notes
Electrical contact of the part to the Printed Circuit Board (PCB)
is made by soldering the leads on the bottom surface of the
package to the PCB. Hence, special attention is required to the
heat transfer area below the package to provide a good ther-
mal bond to the circuit board. A Copper (Cu) fill is to be de-
signed into the PCB as a thermal pad under the package. Heat
is transferred from the TX2 through the device's metal paddle
on the bottom side of the package. Heat from here, is conduct-
ed to the PCB at the thermal pad. It is then conducted from the
thermal pad to the PCB inner ground plane by an array of via.
A via is a plated through hole in the PCB with a finished diam-
eter of 13 mil. The QFN's metal die paddle must be soldered
to the PCB's thermal pad. Solder mask is placed on the board
top side over each via to resist solder flow into the via. The
mask on the top side also minimizes outgassing during the
solder reflow process.
For further information on this package design please refer to
the application note "Surface Mount Assembly of AMKOR's
MicroLeadFrame (MLF) Technology." This application note
can be downloaded from AMKOR's web site from the following
URL http://www.amkor.com/products/notes_papers/MLFApp
Note.pdf. The application note provides detailed information
on board mounting guidelines, soldering flow, rework process,
etc.
Figure 13-1 below display a cross-sectional area underneath
the package. The cross section is of only one via. The solder
paste template needs to be designed to allow at least 50%
solder coverage. The thickness of the solder paste template
should be 5 mil. It is recommended that "No Clean", type 3
solder paste is used for mounting the part. Nitrogen purge is
recommended during reflow.
Figure 13-2 is a plot of the solder mask pattern image of the assembly (darker areas indicate solder).
EZ-USB TX2 is a trademark of Cypress Semiconductor. All product and company names mentioned in this document are the
trademarks of their respective holders.
Figure 13-1. Crosssection of the Area Underneath the QFN Package
Figure 13-2. Plot of the Solder Mask (White Area)
0.017" dia
Solder Mask
Cu Fill
Cu Fill
PCB Material
PCB Material
0.013" dia
Via hole for thermally connecting the
QFN to the circuit board ground plane.
This figure only shows the top three layers of the
circuit board: Top Solder, PCB Dielectric, and
the Ground Plane
CY7C68000
PRELIMINARY
Document #: 38-08016 Rev. *E
Page 14 of 14
Document History Page
Document Title: CY7C68000 TX2TM USB 2.0 UTMI Transceiver
Document Number: 38-08016
REV.
ECN NO.
Issue Date
Orig. of
Change
Description of Change
**
112019
03/01/02
KKU
New data sheet
*A
113885
07/01/02
KKU
Updated pinouts on BGA package, signal names.
Added timing diagrams.
*B
118521
11/18/02
KKU/
BHA
Added USB Logo.
Updated characterization data.
Changed from Preliminary to Final.
*C
124507
02/21/03
BHA
Changed ISB Suspend Current maximums.
*D
126665
07/03/03
KKU
Removed BGA package and added Rev C of QFN package drawing with PCB
layout Recommendations for the QFN package.
*E
285634
SEE ECN
KKU
Updated description on signals DataBus16_8, and D0-D15.
Updated data sheet format.
PDF
ZIP
