MODEL NO.
CDS0892
Connectorized SP2T w/Amp
F E AT U R E S
1550 - 1850 MHz
4 dB Gain
Non-Reflective
TTL Driver
Replaceable SMA Connectors
HDI
D A I C O
I n d u s t r i e s
Rev. A / Iss. 1
GND
GND
J3
+15V
CONT
J1
J2
SWITCH
SP2T
AMPLIFIER
1.773
J2
J1
+15V
CONT
GND
PART
IDENTIFICATION
.15
.05
.025 DIA 4 PLACES
TIN LEAD SOLDER (SN63) PER
QQ-S-571 COATED TO WITHIN
0.025 OF SURFACE
J3
GND
1.00
.03
.750
.104 X .304
SLOT THRU
(TYP)
.25
1.00
2.17
.xx = .02
.xxx = .010
.34
.06
.197
FREQUENCY (MHz)
T Y P I C A L P E R F O R M A N C E
a t 2 5
C
80
60
40
20
0
0
2
4
6
8
GAIN (dB)
ISO (dB)
100
400
1000
3000
1.0
1.2
1.4
1.6
1.8
VSWR
VSWR
ISO
GAIN
Parameter
Min Typ
Max Units
Conditions
Operating Frequency
1550
1850
MHz
DC Current
71
100
mA
At +15 VDC Supply
Control Type
TTL
1 Line
Logic "0" = J2 - J3
Logic "1" = J1 - J3
Control Current
High
0
60
A
VIH = +2.7 V
Low
-0.5
-1.6
mA
VIL = +0.5 V
Insertion Gain
3
4
5
dB
Flatness
0.1
0.5
dB
Noise Figure
8.2
10
dB
Isolation
45
59
dB
VSWR
Thru
1.17/1
1.5/1
Termination
1.12/1
1.5/1
Impedance
50
OHMS
Switching Speed
0.6
1
Sec
50% TTL to 90% / 10% RF
Transition (Rise/Fall) Time
340
700
nSec
90% / 10% or 10% / 90% RF
Switching
(Video)
Transients
1.3
V
Peak Value
Intercept Points
2nd
+47
dBm
350 / 150 MHz
3rd
+31
dBm
175 / 200 MHz
RF Power
Operate
+2
-1
dBm
0.1 dB Input Compression
No Damage
+5
dBm
Operating Temperature
-55
+25
+100
C
TA
