MODEL NO.
D S W M6309
S w i t c h N e t w o r k
F E AT U R E S
Broad Band, 1 - 2000 MHz
Modular Design
Phase Tracking,
2 Degrees
Hermetic Aluminum Case
HDI
D A I C O
I n d u s t r i e s
Rev. N/D / Iss. 1
PORT SELECT
Switch State
Port
S1 (J66 to J73)
S2
S3
2
2
2
1
2
0
J58 to J65
J10 to J17
J18 to J25
0
0
0
S3
J10 to J17
S1
0
0
1
J58 to J65
J2 to J9
J18 to J25
0
1
0
S3
J2 to J9
S1
0
1
1
J50 to J57
Not Sel.
Not Sel.
1
0
0
J26 to J33
Not Sel.
Not Sel.
1
0
1
J34 to J41
Not Sel.
Not Sel.
1
1
0
J42 to J49
Not Sel.
Not Sel.
1
1
1
J10 to J17
J2 to J9
J18 to J25
S2
S3
CONTROL
STROBE
PORT 2
2
PORT 2
1
PORT 2
0
+5V
GND
-15V
PHASE ADJUST
J66 to J73
J58 to J65
J50 to J57
J42 to J49
J34 to J41
J26 to J33
S1
0.400
0.180
1.800
0.625
0.475
0.850
0.125 TYP
1.610
0.950
-15V
GND
+5V
0.252
.008
OSP CONN, 7 PLACES
POR
T 2
0
POR
T 2
1
POR
T 2
2
STROBE
J2-J9
J10-J17
J26-J33 J18-J25
J66-J73
J34-J41
J42-J49
J58-J65
J50-J57
0.200
3.000
.400
0.180
REF
3.000
.400
1.500
0.200
0.600
6 - 32 X .475 DEEP, MAX
INSERTS 3 PLACES
-15V
GND
+5V
POR
T 2
0
POR
T 2
1
POR
T 2
2
STROBE
0.470
1.180
0.520
0.520
2.930
3.400
0.135
0.700
0.520
0.960
0.520
0.25 REF
FEMALE SMA
CON, 2 PLACES
0.030 DIA
7 PLACES
Parameter
Min Typ
Max Units
Conditions
Operating Frequency
1
1200
MHz
J2 to J25, S1
250
2000
MHz
J26 to J73, S2 and S3
DC Current
50
mA
At +5 VDC Supply
37
mA
At -15 VDC Supply
Control Type
TTL
See Logic Table
Control Current
High
10
A
VIH = +2.7 V
Low
10
A
VIL = +0.5 V
Isolation
50
55
dB
Any Port to Port
Insertion Loss
1.0
1.5
dB
1 - 20 MHz, S1
1.5
2.0
dB
20 - 1200 MHz, S1
1.5
2.0
dB
1200 - 2000 MHz, S2 and S3
2.0
2.5
dB
250 - 1200 MHz, S2 and S3
VSWR
1.5/1
Intercept Points
2nd
75
80
dBm
3rd
45
49
dBm
Amplitude Balance
0.1
0.3
dB
Phase Balance
1
DEG
1 - 20 MHz, S1
2
DEG
20 - 2000 MHz, S1, S2 and S3
P1dB Compression
+15
+21
dBm
1 - 20 MHz
+20
+30
dBm
20 - 2000 MHz
No Damage
+30
dBm
Operating Temperature
0
+25
+70
C
TA
