GENERAL DESCRIPTION
The DS26401 is an octal, software-selectable T1, E1
or J1 framer. It is composed of eight framer/formatters
and a system (backplane) interface. Each framer has
an HDLC controller that can be mapped to any DS0
or FDL (T1)/Sa (E1) bit. The DS26401 also includes a
full-feature BERT device, which can be used with any
of the eight T1/E1 ports, and an internal clock adapter
useful for creating synchronous, high frequency
backplane timing. The DS26401 is controlled through
an 8-bit parallel port that can be configured for
nonmultiplexed Intel or Motorola operation.
APPLICATIONS
Line Cards
Routers
Add-Drop Multiplexers
IMA
DSLAMs ATM
Timing Systems
WAN Interface
PBXs
Switches
Customer-Premise
Equipment
Central Office Equipment
Go to
www.maxim-ic.com/telecom
for a complete list of
Telecommunications data sheets, evaluation kits, application
notes, and software downloads.
FEATURES
8 Independent, Full-Featured T1/E1/J1
Framers/Formatters
Independent Transmit and Receive Paths
Flexible Signaling Extraction and Insertion
Alarm Detection and Insertion
Transmit Synchronizer
AMI, B8ZS, HDB3, NRZ Line Coding
Performance Monitor Counters
BOC Message Controller (T1)
Two-Frame Elastic Store Buffers for Each
Transmitter and Receiver
One HDLC Controller per Framer
RAI-CI and AIS-CI Support
Full-Feature BERT can be Mapped to Any Port
Flexible TDM Backplane Supports Bus Rates
from 1.544MHz to 16.384MHz
Internal Clock Generator (CLAD) Supplies
16.384MHz, 8.192MHz, 4.096MHz, or 2.048MHz
JTAG Test Port
Single 3.3V Supply with 5V Tolerant Inputs
17mm x 17mm, 256-Pin BGA (1.00mm Pitch)
ORDERING INFORMATION
PART TEMP
RANGE
PIN-PACKAGE
DS26401
0C to +70C
256 BGA
DS26401N
-40C to +85C
256 BGA
DS26401
Octal T1/E1/J1 Framer
www.maxim-ic.com
DS26401 Octal T1/E1/J1 Framer
2
