Heavy Duty General Purpose Relay
HG4505
FEATURES
Bridging-over contact configurations for heavy inductive
load breaking
1 Form X and 2 Form X contact form
Quick connect, PCB terminal, screw mounting for choice
"Great Wall" mark approved
Other approvals pending
CONTACT RATING
CONTACT DATA
Form
1 Form X (1QH)
2 Form X (2QH)
Material
Service Life
Mechanical
Electrical
Initial Contact Resistance
AgCdO
50 m
max. at 0.1A, 6VDC
5 x 10
6
ops.
10
5
ops.
Resistive
30A, 240VAC
2 x 25A, 240VAC
UL /CSA RATING (PENDING)
Form
1 Form X (1QH)
30A, 277VAC
10A, 125VAC
1.5HP, 125VAC
3HP, 277VAC
86LRA, 20FLA, 125VAC
60LRA, 14.1FLA, 277VAC
2 Form X (2QH)
25A, 277VAC
10A, 125VAC
1HP, 125VAC
2HP, 277VAC
69LRA, 16FLA, 125VAC
43LRA, 10FLA, 277VAC
Resistive
T V
Motor
COIL DATA
Coil Voltage
Code
Nominal
Voltage
( VDC/ VAC)
Must Operate
Voltage max.
( VDC/ VAC)
Must Release
Voltage min.
( VDC/ VAC)
Resistance (
) 10%
Power Comsumption
DC
Type
AC
003
006
012
024
048
100
110
220
006
012
024
048
110
/120
/240
220
3
6
12
24
48
100
110
220
6
12
24
48
110
/120
/240
220
2.25
4.5
9.0
18.0
36.0
75.0
82.5
165.0
4.8
9.6
19.2
38.4
88.0
/96.0
/192.0
176.0
0.3
0.6
1.2
2.4
4.8
10.0
11.0
22.0
0.6
1.2
2.4
4.8
11.0
/12.0
/24.0
22.0
4.7
1.9W
1.7 --
2.7VA
18.8
75.0
300.0
1200.0
5200.0
6300.0
21000.0
8.8
35.0
130.0
480.0
2150.0
8880.0
HG4505
1/2
Package air conditioners
UPS
Heaters and refrigeration control
TYPICAL APPLICATIONS
CHARACTERISTICS
Operate Time
Release Time
Insulation Resistance
Dielectric Strength
Shock Resistance
Weight
Vibration Resistance
Ambient Temperature
30 ms. max.
30 ms. max.
100 M
, at 500 VDC, 50%RH
4000 Vrms, 1 min. between coil and contacts
2000 Vrms, 1 min. between open contacts
2000 Vrms, 1 min. between adjacent contacts
10 g, 11ms. functional; 100 g, destructive
DA 1.5mm, 10 - 55 Hz
-55C to 70C
90 g, approx.
HG4505
REFERENCE CURVES
HG4505
2/2
OVERALL DIMENSIONS, MOUNTING HOLES AND WIRING DIAGRAMS (mm)
Overall Dimensions
Mounting Holes (Bottom View)
Wiring Diagrams (Bottom View)
NOTES
1.
All parameters, unless otherwise specified, are measured at ambient temperature 23C.
2.
Custom-made services available with operational quantity. Please let us know your special requirements.
3.
Specifications subject to change without prior notice.
ORDERING DESIGNATION
Example:
HG4505 /
220
A -
1QH
1
C
4
G
Model
Version
Contact Material
Mounting Version
Contact Gap
Nil: Quick Connect; 4: PCB Terminal
Nil: Standard; G: Big Gap
C: AgCdO; S: AgSnOInO
1: Sealed; 2: Dust Cover
DC/AC
Contact Form
1QH: 1 Form X; 2QH: 2 Form X
Nil: DC Coil; A: AC Coil
Coil Voltage Code
