Miniature PCB Power Relay
HG4510
FEATURES
20A switching capacity
Withstand inrush current of 60A
10KV surge voltage between coil and contacts
TYPICAL APPLICATIONS
Air conditioners
Heaters and refrigeration control
Microwave oven
CONTACT RATING
Form
1 Form A (H)
20A, 250VAC
Resistive
UL/CSA RATING
COIL DATA
Coil Voltage
Code
Nominal
Voltage
(VDC)
Must Operate
Voltage max.
(VDC)
Must Release
Voltage min.
(VDC)
Power Consumption
Resistance () 10%
005
006
012
5
6
12
40
0.9W
160
3.5
4.2
8.4
0.5
0.6
1.2
CONTACT DATA
Material
Initial Contact Resistance
Service Life
Mechanical
AgCdO
50 m max. at 1A, 6VDC
5 x 10
6
ops.
10
5
ops.
Electrical
ORDERING DESIGNATION
Example: HG4510 / 012 - H 1 C
Model
Coil Voltage Code
Contact Form
H: 1 Form A
Version
Contact Material
C: AgCdO
1: Sealed
CHARACTERISTICS
Operate Time
Release Time
Insulation Resistance
Dielectric Strength
Shock Resistance
Vibration Resistance
Ambient Temperature
Weight
15 ms. max.
10 ms. max.
1000 M, at 500 VDC, 50%RH
2000 Vrms, 1 min. between coil and contacts
1000 Vrms, 1 min. between open contacts
20 g, 11ms. functional; 100g, destructive
DA 1.5mm, 10 - 55 Hz
-40C to 55C
42g, approx.
HG4510 1/2
8 mm creepage distance
Form
1 Form A (H)
20A, 220VAC
Resistive
Max. Switching Power
Max. Switching Voltage
Max. Switching Current
5000VA
250VAC
20A
024
24
640
16.8
2.4
26.4
Max. Allowable
Voltage
(VDC)
5.5
6.5
13.2
27.8
Surge Voltage 10,000 V, between coil and contacts
48
2560 33.6 4.8 52.8
048
HG4510
REFERENCE CURVE
OVERALL DIMENSIONS, MOUNTING HOLES AND WIRING DIAGRAM (mm)
Overall Dimensions
Mounting Holes (Bottom View) Wiring Diagram
NOTES
1. All parameters, unless otherwise specified, are measured at ambient temperature 23C.
2. Custom-made services available with operational quantity. Please let us know your special requirements.
3. Specifications subject to change without prior notice.
HG4510 2/2
Max. Switching Capacity
Switching Current (A)
100
50
10
5
1
0.5
0.1
1 3 5 710 30 50 100 500 1000
Switching Voltage (V)
Life Expectancy
Operations
(X
10
3
)
5000
1000
500
300
100
50
10
0 2 4 6 8 10 12 14 16 18 20 22
Switching Current (A)
DB LECTRO INC. 3600 boul. Matte suite I Brossard J4Y-2Z2
TEL: (450)-444-1424 FAX: (450)-444-4714
