Features
Super light in weight.
High sensitivity.
Switching capacity up to 16A.
PC board mounting.
Ordering Information
NT76 C S DC12V C 0.2
1 2 3 4 5 6
1 Part number
NT76
2 Contact arrangement
A:1A
C:1C
3 Enclosure
S: Sealed type
Z: Dust cover
4 Coil rated Voltage(V)
DC:3,5,6,9,12,18,24,48,100
5 Contact material
C: Ag CdO
S: Ag SnO
2
I
n
2
O
3
6 Coil power consumption
0.2:0.2W
0.25:0.25W
0.45:0.45W
0.6:0.6W
Contact Data
Contact Arrangement
1A SPSTNO
f
1C SPDT(B-M)
Contact Material
Ag CdO Ag SnO
2
I
n
2
O
3
Contact Rating (resistive)
1A: 16A/250VAC, 30VDC ; 1C: 10A/250VAC, 30VDC
T
V 16A/250VAC,30VDC
Max. Switching Power
300W 2500VA
Max. Switching Voltage
110VDC 380VAC Max. Switching Current:16A
Contact Resistance or Voltage drop
50m Item 3.12 of IEC255-7
Electrical
10
5
Item 3.30 of IEC255-7
Operation
life
Mechanical
10
7
Item 3.31 of IEC255-7
Coil Parameter
Coil voltage
VDC
Dash
numbers
Rated
Max.
Coil
resistance
10%
Pickup
voltage
VDC(max)
(75%of rated
voltage )
release
voltage
VDC(min)
(5% of rated
voltage)
Coil power
consumption
W
Operate
Time
Ms
Release
Time
ms
005-200
5
6.5
125
3.75
0.25
006-200
6
7.8
180
4.50
0.30
009-200
9
11.7
405
6.75
0.45
012-200
12
15.6
720
9.00
0.60
018-200
18
23.4
1620
13.5
0.90
024-200
24
31.2
2880
18.0
1.20
0.20
10
5
048-250
48
52.8
9216
38.4
2.40
0.25
10
5
005-450
5
6.5
56
3.75
0.25
006-450
6
7.8
80
4.50
0.30
009-450
9
11.7
180
6.75
0.45
012-450
12
15.6
320
9.00
0.60
018-450
18
23.4
720
13.5
0.90
024-450
24
31.2
1280
18.0
1.20
048-450
48
52.8
5120
38.4
2.40
0.45
10
5
100-600
100
130
16600
80.0
10.0
0.6
10
5
CAUTION
: 1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
87
N T 7 6
22.3
16.6
11
E160644
R2033977.03
Patent No.: 99206684.0
E9930952E01
www.dblectro.com
Operation condition
Insulation Resistance
100M min (at 500VDC)
Item 7 of IEC255-5
Dielectric Strength
Between contacts
Between contact and coil
50Hz 750V
50Hz 1500V
Item 6 of IEC255-5
Item 6 of IEC255-5
Shock resistance
100m/s
2
11ms
IEC68-2-27 Test Ea
Vibration resistance
10~55Hz double amplitude 1.5mm
IEC68-2-6 Test Fc
Terminals strength
10N
IEC68-2-21 Test Ua1
Solderability
235
x
2
3
x
0.5s
IEC68-2-20 Test Ta method 1
Ambient Temperature
-40~85
Relative Humidity
85% (at 20
)
IEC68-2-3Test Ca
Mass
10g
Qualification inspection:
Perform the qualification test as specified in the table
of IEC255-19-1 and minimum sample size 24.
Safety approvals
Safety approval
UL
T
V
Load
1A 16A/250VAC 1C 10A/250VAC
16A/250VAC;14VDC
Dimensions (Unit: mm)
Reference Data
NOTES
1).Dimensions are in millimeter.
2).Inch equivalents are given for general information only.
NT76
Dimensions
Wiring diagram
(Bottom views)
mm
>
0.3
0.012
0.4
0.016
0.6
0.024
0.9
0.035
1.1
0.043
1.3 0.051
2.26
0.089
3.9
0.153
7.62
0.300
10.16 0.400
11.0 0.433
12.7 0.500
16.6
0.653
17.78
0.700
22.3
0.878
Mounting (Bottom views)
