MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
SM5391
THRU
SM5399
SM-1(DO-213AB)
TECHNICAL SPECIFICATIONS OF SURFACE MOUNT SILICON RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 1.5 Amperes
Dimensions in inches and (millimeters)
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current T
A
= 75
o
C
Peak Forward Surge Current I
FM
(surge): 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Typical Junction Capacitance (Note 1)
Operating and Storage Temperature Range
SYMBOL
V
RRM
V
DC
I
O
I
FSM
C
J
T
J
, T
STG
V
RMS
Amps
1.5
50
-65 to +150
pF
o
C
UNITS
Volts
Volts
Typical Thermal Resistance (Note 2)
50
100
200
400
600
800
1000
50
100
200
400
600
800
1000
35
70
140
280
420
560
700
60
Volts
Amps
30
o
C/ W
R
JC
V
F
I
R
1.4
100
Amps
Maximum Forward Voltage at 1.5A DC
Volts
Maximum DC Reverse Current at
Rated DC Blocking Voltage
@T
A
= 25
o
C
@T
A
= 125
o
C
5.0
RECTIFIER SPECIALISTS
R
DC COMPONENTS CO., LTD.
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Mounting position: Any
* Weight: 0.12 gram
* Terminals: Solder plated solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes cathode end
FEATURES
* Ideal for surface mounted applications
* Low leakage current
*
Glass passivated junction
NOTES : 1. Measured at 1.0 MHz and applied reverse voltage of 4.0VDC
2. Thermal resistance (Junction to Ambient),.24in (6.0mm ) coppeer pads to each terminal.
2
2
SM5393 SM5395
SM5398 SM5399
SM5397
SM5392
SM5391
.205(5.2)
.190(4.8)
.028(.60)
.018(.46)
.106(2.7)
.095(2.4)
SOLDERABLE
ENDS
