DS21208 Rev. G-2
1 of 2
GBPC15005/W - GBPC1510/W
GBPC15005/W - GBPC1510/W
15A GLASS PASSIVATED BRIDGE RECTIFIER
Features
GBPC-W
C
A
G
E
B
H
(AC)
(AC)
(+)
( - )
H
J
A
C
K
A
M
B
H
H
L
P
A
P
(AC)
(AC)
( - )
( + )
GBPC
"W" Suffix Designates Wire Leads
No Suffix Designates Faston Terminals
GBPC / GBPC-W
Dim
Min
Max
A
28.30
28.80
B
7.40
8.25
C
16.10
17.10
E
18.80
21.30
G
13.80
14.80
H
Hole for #10 screw
5.08
5.59
J
17.60
18.60
K
10.90
11.90
L
0.97
1.07
M
31.80
P
17.60
18.60
All Dimensions in mm
Mechanical Data
Glass Passivated Die Construction
Diffused Junction
Low Reverse Leakage Current
Low Power Loss, High Efficiency
Surge Overload Rating to 300A Peak
Electrically Isolated Metal Base for Maximum
Heat Dissipation
Case to Terminal Isolation Voltage 1500V
UL Listed Under Recognized Component
Index, File Number E94661
Case: Molded Plastic with Heatsink Internally
Mounted in the Bridge Encapsulation
Terminals: Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: As Marked on Case
Mounting: Through Hole for #10 Screw
Mounting Torque: 8.0 Inch-pounds Maximum
GBPC Weight: 20 grams (approx.)
GBPC-W Weight: 14 grams (approx.)
Mounting Position: Any
Maximum Ratings and Electrical Characteristics
@ T
A
= 25
C unless otherwise specified
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Symbol
GBPC15
005/W
GBPC15
01/W
GBPC15
02/W
GBPC15
04/W
GBPC15
06/W
GBPC15
08/W
GBPC15
10/W
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
50
100
200
400
600
800
1000
V
RMS Reverse Voltage
V
R(RMS)
35
70
140
280
420
560
700
V
Average Rectified Output Current
@ T
C
= 70
C
I
O
15
A
Non-Repetitive Peak Forward Surge Current
8.3ms single half sine-wave superimposed on rated load
(JEDEC Method)
I
FSM
300
A
Forward Voltage (per element)
@ I
F
= 7.5A
V
FM
1.1
V
Peak Reverse Current
@ T
C
= 25
C
at Rated DC Blocking Voltage
@ T
C
= 125
C
I
R
5.0
500
mA
I
2
t Rating for Fusing
(Note 1)
I
2
t
374
A
2
s
Typical Junction Capacitance
(Note 2)
C
j
300
pF
Typical Thermal Resistance per leg
(Note 3)
R
qJC
1.4
C/W
Operating and Storage Temperature Range
T
j,
T
STG
-65 to +150
C
Notes:
1. Non-repetitive, for t > 1.0ms and t < 8.3ms.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3. Thermal resistance junction to case mounted on heatsink.
DS21208 Rev. G-2
2 of 2
GBPC15005/W - GBPC1510/W
0.01
0.1
1.0
10
100
0
0.4
0.8 1.0
1.6 1.8
0.6
0.2
1.2 1.4
I
,
INST
ANT
ANEOUS
FOR
W
ARD
CURRENT
(A)
F
V , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics (per element)
F
T = 25C
j
Pulse Width = 300s
0
100
200
300
400
1
10
100
I
,
PEAK
FWD.
SURGE
CURRENT
(A)
FSM
NUMBER OF CYCLES AT 60 Hz
Fig. 3 Max Non-Repetitive Surge Current
Single Half-Sine Wave
(JEDEC Method)
T = 150C
j
10
100
1000
0.1
1.0
10
100
C
,
CAP
ACIT
ANCE
(pF)
j
V , REVERSE VOLTAGE (V)
Fig. 4 Typical Junction Capacitance (per element)
R
f = 1 Mhz
T = 25C
j
0.01
0.1
1.0
10
100
40
20
60
80
100
120
140
I
,
INST
ANT
ANEOUS
REVERSE
CURRENT
(A)
R
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics (per element)
T = 125C
j
T = 130C
j
T = 25C
j
50V - 400V
600V - 1000V
0
5
10
15
20
0
25
50
75
100
125
150
I
,
A
V
ERAGE
FOR
W
A
RD
CURRENT
(A)
F
T , CASE TEMPERATURE (C)
Fig. 1 Forward. Current Derating Curve
C
Resistive or
Inductive load
Mounted on a
220 x 220 x 50 mm
AL plate heatsink
