T
echnical Specification
ENERGY VERY ENDURE
CR2354
Manganese Dioxide
Lithium Coin Batteries
Dimensions(mm)
SPECIFICATION
OPERATING VOLTAGE VS. LOAD RESISTANCE
CAPACITY VS. LOAD RESISTANCE
TEMPERATURE CHARACTERISTICS
Weight(g)
Nominal voltage (V)
Nominal capacity (mAh)
Continuous standard load (mA)
Operating temperature ( C )
http:// www. evebattery.com
Email: sales@evebattery.com
EVE BATTERY CO., LTD.
Tel:+86-752-260 1898 +86-752-260 1128 Fax: +86-752-260 6033
WARNING:
Forbid short-circuit, charge between"+" and"-".
Forbid over-discharge, fire, damage.
Finish sealing less more 5 seconds at
Take out the battery when discharging to
cut-off voltage, and embedding it under the
ground or jump in the deep water.
200 C~250 C.
V0408
Latest version can be downloaded from EVE website
(voltage at 50% discharge depth)
3
500
0.2
-20 ~ +60
5.0
Duration(h)
Load
Voltage(V)
Voltage (V)
Load:
20
10
5
3
2
1
0.5
0.3
0.1
0.2
0.4
0.6
0.3
1
2
3
4
6
10
8
3.2
3.0
2.8
2.6
2.4
2.2
(M )
(A)
60 C
20 C
-10 C
~
~
Capacity(mAh)
Load:
Cut-off voltage: 2.0V
2
1
0.5
0.3
0.2
0.1
0.05
0.0 3
1
2
3
4
6
10
20
30 40
60
100
600
500
400
300
200
100
(k )
(mA)
60 C
20 C
-10 C
