E816B-1/4
www.eLED.com
DATA NO :EA0103
REV NO :V1 DATE :AUG/29/2001
Selection Guide
E816BID
HIGH EFFICIENCY RED
E816BGD
GREEN
E816BYD
YELLOW
E816BSRx
SUPER BRIGHT RED
Package Dimensions
10mm
BLINKING LED LAMPS
Note:
1.
1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notic
e.
Description
The Green source color devices are made with Gallium Phosphide Green Light Emitting Diode.
The High Efficiency Red source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
The Yellow source color devices are made with Gallium Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made with Gallium Aluminum Arsenide Red Light Emitting Diode.
Features
1.10mm DIAMETER BIG LAMP WITH BULIT-IN
BLINKING IC.
2.OPERATION VOLTAGE FROM 3.5V to 14V.
3.BLINKING FREQUENCY FROM 3.0Hz to 1.5Hz.
.
