EXAMINED BY :
FILE NO
. CAS-10240
EMERGING DISPLAY
ISSUE
: MAR.20,2001
APPROVED BY
:
TECHNOLOGIES CORPORATION
TOTAL PAGE
: 7
VERSION
: 1
C
USTOMER
A
CCEPTANCE
S
PECIFICATIONS
MODEL NO . :
FOR MESSRS :
E S16201(T R A N SFL EC T IV E T Y PE S)
CUSTOMER'S APPROVAL
DATE
:
_____________________________
BY
:
_____________________________
ACDS
175-177 route de Genas - 69100 VILLEURBANNE - France
Tl : +33 4 72 91 26 80 - Fax : +33 4 72 35 18 06
http://www.acds.fr
E M E R G I N G D I S P L A Y
MODEL NO
.
VERSION
TECHNOLOGIES CORPORATION
ES16201(TRANSFLECTIVE TYPES)
1
DOC
.
FIRST ISSUE
R E C O R D S OF R E V I S I O N
MAR.20,2001
D A T E
REVISED
PAGE
NO.
S U M M A R Y
ACDS
175-177 route de Genas - 69100 VILLEURBANNE - France
Tl : +33 4 72 91 26 80 - Fax : +33 4 72 35 18 06
http://www.acds.fr
E M E R G I N G D I S P L A Y
MODEL NO
.
VERSION
TECHNOLOGIES CORPORATION
ES16201 (TRANSFLECTIVE TYPES)
1
NUMBERING SYSTEM
Polarizer Mode Backlight
Code value
P
Module type :
LCD type +
LCD color
Code
Value
STN +
Yellow-Green
STN + Gray
Y
G
Transflective
S : Chip on glass
E S 16 2 01 G P
ACDS
175-177 route de Genas - 69100 VILLEURBANNE - France
Tl : +33 4 72 91 26 80 - Fax : +33 4 72 35 18 06
http://www.acds.fr
E M E R G I N G D I S P L A Y
MODEL NO
.
VERSION
TECHNOLOGIES CORPORATION
ES16201(TRANSFLECTIVE TYPES)
1
T A B L E O F C O N T E N T S
NO. I T E M PAGE
===============================================================
1.
GENERAL SPECIFICATIONS
--------------------------------------------
1
2.
MECHANICAL SPECIFICATIONS
---------------------------------------
1
3.
ABSOLUTE MAXIMUM RATINGS
-------------------------------------
2
4.
ELECTRICAL CHARACTERISTICS
-------------------------------------
3
5.
OPTICAL CHARACTERISTICS
------------------------------------------
3
6.
OUTLINE DIMENSION
--------------------------------------------------
4
7.
DETAIL DRAWING OF DOT MATRIX
--------------------------------
5
8.
BLOCK DIAGRAM
-----------------------------------------------------
5
9.
INTERFACE SIGNALS
--------------------------------------------------
6
10.
POWER SUPPLY
-------------------------------------------------------
7
11.
DISPLAY DATA RAM ADDRESS
-------------------------------------
7
ACDS
175-177 route de Genas - 69100 VILLEURBANNE - France
Tl : +33 4 72 91 26 80 - Fax : +33 4 72 35 18 06
http://www.acds.fr
E M E R G I N G D I S P L A Y
MODEL NO
.
VERSION PAGE
TECHNOLOGIES CORPORATION
ES16201(TRANSFLECTIVE TYPES)
1 1
1.
GENERAL SPECIFICATIONS
1 . 1
GENERAL SPECIFICATIONS
PLEASE REFER TO :
CUSTOMER ACCEPTANCE STANDARD SPECIFICATIONS :
E U - 0 0 2 A
1 . 2
APPLICATION NOTES FOR CONTROLLER / DRIVER : NT7603
PLEASE REFER TO :
CUSTOMER ACCEPTANCE STANDARD SPECIFICATIONS :
E U - N T 7 6 0 3
1 . 3
THIS INDIVIDUAL SPECIFICATIONS IS PRIOR TO GENERAL
SPECIFICATIONS .
2 . MECHANICAL SPECIFICATIONS
( 1 ) NUMBER OF CHARACTER
--------------------
16 CH * 2 LINE
( 2 ) MODULE SIZE
--------------------------------
69.0W * 30.0H * 3.0D (max.) mm
( 3 ) EFFECTIVE AREA
-----------------------------
63.0W * 18.0H mm
( 4 ) CHARACTER FONT
---------------------------
5 * 7 DOTS + CURSOR
( 5 ) CHARACTER SIZE
---------------------------
2.96W * 5.56H mm
( 6 ) CHARACTER PITCH
---------------------------
3.55(W)*5.94 (H)
( 7 ) DOT SIZE
-------------------------------------
0.56W * 0.66H mm
( 8 ) DOT PITCH
-----------------------------------
0.60W * 0.70H mm
( 9 ) LCD TYPE *
( 10 ) DRIVING METHOD
---------------------------
1 / 16 DUTY MULTIPLEX DRIVE
* PLEASE REFER TO NUMBERING SYSTEM
