ESS Technology, Inc.
SAM0556-031804
1
ESS Technology, Inc.
ES6629
Vibratto-II DVD Processor
Product Brief
DESCRIPTION
The ES6629 Vibratto
II processor is a highly integrated
single-chip DVD solution that integrates read channel,
ECC, Servo DSP, MCU, and MPEG-2 decoder that has a
state-of-the-art 480p/576p progressive-scan video feature
to provide brilliant and sharp, flicker-free video output, and
S/PDIF input and output support. The ES6629 performs
audio/video stream data processing, TV encoding,
Macrovision
copy protection, DVD system navigation,
system control, and housekeeping functions.
The Vibratto-II DVD processor is built on the ESS
p rop rie tar y d u al CPU P ro g ra m m ab l e M u l ti m e d i a
Processor (PMP) core consisting of 32-bit RISC and 64-bit
DSP processors and offers the best DVD feature set. The
processing units enable simultaneous parallel execution of
system commands and data processing to perform
specialized encoding and decoding tasks.
The RISC processor performs bit stream parsing, control
audio data output, transfer video and audio data to the
v e c t o r e n g i n e a n d s e r v i c e s y s t e m c o n t r o l a n d
housekeeping functions. The vector engine performs
audio and video micro-code processing required by A/V
standards, such as Dolby
Digital, MPEG and JPEG
imaging. These processing tasks include video motion
compensation and estimation, loop filtering, Discrete
Cosine Transforms (DCT), inverse DCT, quantization, and
inverse quantization.
The Vibratto-II DVD processor supports all popular pick-up
units, industry standard I
2
S audio data input and output,
EPROM and DRAM access. It also supports both letterbox
and pan-and-scan displays, sub-picture overlay, and On-
Screen Display (OSD).
The Vibratto-II's Unified Memory Architecture enables the
lowest possible system memory cost by consolidating
multiple memory subsystems into a single unit.
In addition, the Vibratto-II DVD solution offers support for
Karaoke CD+G, HDCD, CD-DA, MP3, and WMA.
The ES6629 Vibratto-II DVD processor with DTS support
is offered with the ES6629D, which has the same pinout
as the standard ES6629. The ES6629 and ES6629D DVD
processors are available in a 208-pin Plastic Quad Flat
Pack (PQFP) device package.
FEATURES
Single-chip DVD processor incorporating all front-end
and back-end functions.
Unified memory architecture.
Proven focusing, sledding, tracking, and CLV/CAV
spindle servo control.
Proven ECC, EFM/EFM+ demodulation, and EDC circuit.
Built-in ADCs and DACs for servo control signals.
Direct interface to the ES6603 servo AFE chip.
Integrated NTSC/PAL encoder with pixel-adaptive
de-interlacer and five 10-bit 54 MHz video DACs.
DVD-Video, DVD-VR, VCD 1.1 and 2.0, and SVCD.
Media playback with CD-ROM, CD-R/RW, DVD-R/RW,
and DVD+R/RW.
Up to 7.1 channel audio outputs.
Direct interface of 16-bit DRAM up to 128-Mb capacity.
Direct interface for up to 4 banks of 8-bit EPROM or Flash
EPROM for up to 4 MB per bank.
Macrovision 7.1 for NTSC/PAL interlaced video.
Macrovision AGC 1.03-compliant for 480p progressive
scan video.
Simultaneous composite, S-video and YUV outputs.
CCIR 656/601 YUV 4:2:2 output.
OSD controller supports 256 colors in 8 degrees of
transparency.
Subpicture Unit (SPU) decoder supports karaoke lyric,
subtitles, and EIA-608 compliant Line 21 Captioning.
SmartLogo
for custom JPEG wallpaper.
JPEG digital photo support (Kodak Picture CD
and
Fujifilm FujiColor CD
).
ESS Music SlideshowTM.
WindowsTM Media Audio (WMA).
Bass management.
Dolby Digital (AC-3), Dolby Pro LogicTM, and Pro Logic II.
DTS
surround (ES6629D only).
S/PDIF digital audio input and output.
MPEG AAC and Multichannel.
SRS TruSurround
.
Professional karaoke with full scoring scheme.
4
http://www.esstech.com
2004 ESS Technology, Inc.
SAM0556-031804
ES6629 PRODUCT BRIEF
ORDERING INFORMATION
No part of this publication may be reproduced, stored in a retrieval
system, transmitted, or translated in any form or by any means,
electronic, mechanical, manual, optical, or otherwise, without the prior
written permission of ESS Technology, Inc.
ESS Technology, Inc. makes no representations or warranties
regarding the content of this document.
All specifications are subject to change without prior notice.
ESS Technology, Inc. assumes no responsibility for any errors
contained herein.
U.S. patents pending.
MPEG is the Moving Picture Experts Group of the ISO/IEC. References
to MPEG in this document refer to the ISO/IEC JTC1 SC29 committee
draft ISO 11172 dated January 9, 1992.
Vibratto, SmartBright, SmartLogo, SmartColor, and Music Slideshow
are trademarks of ESS Technology, Inc.
Dolby is a trademark of Dolby Laboratories, Inc.
Trusurround, Trusurround XT, SRS, and (o) symbol are trademarks of
SRS Labs., Inc.
All other trademarks are trademarks of their respective companies and
are used for identification purposes only.
ESS Technology, Inc.
48401 Fremont Blvd.
Fremont, CA 94538
Tel: (510) 492-1088
Fax: (510) 492-1898
ORDERING INFORMATION
Other Vibratto-II DVD Processors
Part Number
Description
Package
ES6629F
Vibratto-II DVD, Servo Control, Progressive scan, and TV encoder
208-pin PQFP
ES6629FD
Vibratto-II DVD, Servo Control, Progressive scan, DTS surround, and TV encoder
208-pin PQFP
The letter F at the end of the part number identifies the package type PQFP.
ES6603SF
DVD Servo AFE for Vibratto-II
64-pin LQFP
The letter SF at the end of the part number identifies the package type LQFP with lead-free leads. This device is also for non
lead-free designs and has the same soldering requirement as the Vibratto-II devices.
Part Number
Description
Package
ES6688FA
Vibratto-II DVD, Servo Control, Progressive scan, MPEG-4, DVD-Audio, and TV encoder
208-pin PQFP
ES6688FAD
Vibratto-II DVD, Servo Control, Progressive scan, MPEG-4, DVD-Audio, DTS surround,
and TV encoder
208-pin PQFP
ES6698F
Vibratto-II DVD, Servo Control, Progressive scan, DivX (certified), DVD-Audio, and TV
encoder
208-pin PQFP
ES6698FD
Vibratto-II DVD, Servo Control, Progressive scan, DivX (certified), DVD-Audio, DTS
surround, and TV encoder
208-pin PQFP
The letter F at the end of the part number identifies the package type PQFP.
