EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 1/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Features :
Small double-end package
Low forward voltage
View angle 120
Peak wavelength
p
=875nm
Description :
SIR67-21C is an infrared emitting diode in miniature SMD package which is molded
in a water clear plastic with flat top view lens. The device is spectrally matched with
silicon photodiode and phototransistor.
Applications :
Floppy disk drive
Optoelectronic switch
Smoke detector
Camera
VCR
Video
CHIP
PART NO.
MATERIAL
LENS COLOR
SIR
GaAlAs
Water Clear
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 2/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Package Dimensions :
Notes :
1.All dimensions are in millimeter.
2.General Tolerance:
0.1mm
3.Lead spacing is measured where the lead emerge from the package .
4.Lens color
Water clear.
5.Above specification may be changed without notice. EVERLIGHT will reserve authority on
material change for above specification.
6.These specification sheets include materials protected under copyright of EVERLIGHT
corporation . Please don't reproduce or cause anyone to reproduce them without EVERLIGHT's
consent.
7.When using this product , please observe the absolute maximum ratings and the instructions
for use outlined in these specification sheets. EVERLIGHT assumes no responsibility for any
damage resulting from use of the product which does not comply with the absolute maximum
ratings and the instructions included in these specification sheets.
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 3/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Absolute Maximum Ratings at T
A
= 25
Parameter
Symbol
Rating
Unit
Notice
Continuous Forward Current
I
F
65
mA
Peak Forward Current
Pulse width=100
s,Duty cycle=1
I
FP
1.0
A
Reverse Voltage
V
R
5
V
Operating Temperature
Topr
-25 ~ +85
Storage Temperature
Tstg
-40 ~ +85
Soldering Temperature
Tsol
260
Power Dissipation at(or below)
25
Free Air Temperature
Pd
130
Electronic Optical Characteristics :
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
0.5
1.1
----
I
F
=20mA
----
4.5
----
I
F
=100mA,tp=100
s, t
P
/T=0.01
Radiant Intensity
Ee
----
40
----
mW/sr
I
F
=1A,tp=100
s, t
P
/T=0.01
Peak Wavelength
P
----
875
----
nm
I
F
=20mA
Spectral
Bandwidth
----
80
----
nm
I
F
=20mA
----
1.3
1.6
I
F
=20mA
----
1.4
1.8
I
F
=100mA,tp=100
s, t
P
/T=0.01
Forward Voltage
V
F
----
2.6
4.0
V
I
F
=1A,tp=100
s, t
P
/T=0.01
Reverse Current
I
R
----
10
A
V
R
=5V
View Angle
2
1/2
----
120
----
deg
I
F
=20mA
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 4/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Typical Electrical/Optical/Characteristics Curves
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 5/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Typical Electrical/Optical/Characteristics Curves
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 6/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Reliability Test Item And Condition
The reliability of products shall be satisfied with items listed below.
Confidence level:90%
LTPD:10%
NO.
Item
Test Conditions
Test
Hours/
Cycle
Sample
Size
Failure
Judgement
Criteria
Ac/Re
1
REFLOW
TEMP : 240
5
5 sec
6 Min
22 PCs More than
90% of lead
to be
covered by
soldering
0/1
H : +85
30 min
2
Temperature Cycle
5 min
50 cycle
22 PCs
I
R
2
0.8
V
F
1.2
0/1
L : -55
30 min
H : +100
5 min
U :Upper
specification
limit
3
Thermal Shock
10 sec
50 cycle
22 PCs
L :Lower
specification
limit
0/1
L : -10
5 min
4
High Temperature
Storage
TEMP. : +100
1000 hrs
22 PCs
0/1
5
Low Temperature
Storage
TEMP. : -55
1000 hrs
22 PCs
0/1
6
DC Operating Life
I
F
=20mA
1000 hrs
22 PCs
0/1
7
High Temperature /
High Humidity
85
/ 85% R.H.
1000 hrs
22 PCs
0/1
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 7/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Test Method For Power :
Condition :
Test Item :
Unit : mW/sr
EVERLIGHT ELECTRONICS CO., LTD.
DEVICE NUMBER : DIS-672-018 REV : 1.1
ECN :
PAGE : 8/8
TOP Infrared LED
MODEL NO :
SIR67-21C
Packing Specifications
CPN
:
Customer's Production Number
P/N
:
Production Number
QTY
:
Packing Quantity
CAT
:
Ranks
HUE
:
Peak Wavelength
REF :
Reference
LOT NO : Lot Number
MADE IN TAIWAN
:
Production place
Packing Quantity Specification
SIR67-21C
