DM74LS112A
Dual Negative-Edge-Triggered Master-Slave J-K Flip-Flop
with Preset, Clear, and Complementary Outputs
General Description
This device contains two independent negative-edge-trig-
gered J-K flip-flops with complementary outputs. The J and
K data is processed by the flip-flop on the falling edge of
the clock pulse. The clock triggering occurs at a voltage
level and is not directly related to the transition time of the
falling edge of the clock pulse. Data on the J and K inputs
may be changed while the clock is HIGH or LOW without
affecting the outputs as long as the setup and hold times
are not violated. A low logic level on the preset or clear
inputs will set or reset the outputs regardless of the logic
levels of the other inputs.
Ordering Code:
Devices also available in Tape and Reel. Specify by appending the suffix letter "X" to the ordering code.
Connection Diagram
Function Table
H
=
HIGH Logic Level
L
=
LOW Logic Level
X
=
Either LOW or HIGH Logic Level
=
Negative Going Edge of Pulse
Q
0
=
The output logic level before the indicated input conditions were
established.
Toggle
=
Each output changes to the complement of its previous level on
each falling edge of the clock pulse.
Note 1: This configuration is nonstable; that is, it will not persist when
preset and/or clear inputs return to their inactive (HIGH) level.
Order Number
Package Number
Package Description
DM74KS112AM
M16A
16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150 Narrow
DM74LS112AN
N16E
16-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide
Inputs
Outputs
PR
CLR CLK
J
K
Q
Q
L
H
X
X
X
H
L
H
L
X
X
X
L
H
L
L
X
X
X
H (Note 1)
H (Note 1)
H
H
L
L
Q
0
Q
0
H
H
H
L
H
L
H
H
L
H
L
H
H
H
H
H
Toggle
H
H
H
X
X
Q
0
Q
0
www.fairchildsemi.com
2
D
M
74LS1
1
2A
Absolute Maximum Ratings
(Note 2)
Note 2: The "Absolute Maximum Ratings" are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the absolute maximum ratings.
The "Recommended Operating Conditions" table will define the conditions
for actual device operation.
Recommended Operating Conditions
Note 3: C
L
=
15 pF, R
L
=
2 k
, T
A
=
25
C and V
CC
=
5V.
Note 4: The symbol (
) indicates the falling edge of the clock pulse is used for reference.
Note 5: C
L
=
50 pF, R
L
=
2 k
, T
A
=
25
C and V
CC
=
5V.
Supply Voltage
7V
Input Voltage
7V
Operating Free Air Temperature Range
0
C to
+
70
C
Storage Temperature Range
-
65
C to
+
150
C
Symbol
Parameter
Min
Nom
Max
Units
V
CC
Supply Voltage
4.75
5
5.25
V
V
IH
HIGH Level Input Voltage
2
V
V
IL
LOW Level Input Voltage
0.8
V
I
OH
HIGH Level Output Current
-
0.4
mA
I
OL
LOW Level Output Current
8
mA
f
CLK
Clock Frequency (Note 3)
0
30
MHz
f
CLK
Clock Frequency (Note 5)
0
25
MHz
t
W
Pulse Width
Clock HIGH
20
(Note 3)
Preset LOW
25
ns
Clear LOW
25
t
W
Pulse Width
Clock HIGH
25
(Note 5)
Preset LOW
30
ns
Clear LOW
30
t
SU
Setup Time (Note 3)(Note 4)
20
ns
t
SU
Setup Time (Note 4)(Note 5)
25
ns
t
H
Hold Time (Note 3)(Note 4)
0
ns
t
H
Hold Time (Note 4)(Note 5)
5
ns
T
A
Free Air Operating Temperature
0
70
C
3
www.fairchildsemi.com
DM74LS1
1
2
A
Electrical Characteristics
over recommended operating free air temperature range (unless otherwise noted)
Note 6: All typicals are at V
CC
=
5V, T
A
=
25
C.
Note 7: Not more than one output should be shorted at a time, and the duration should not exceed one second. For devices, with feedback from the outputs,
where shorting the outputs to ground may cause the outputs to change logic state an equivalent test may be performed where V
O
=
2.125V with the minimum
and maximum limits reduced by one half from their stated values. This is very useful when using automatic test equipment.
Note 8: With all outputs OPEN, I
CC
is measured with the Q and Q outputs HIGH in turn. At the time of measurement the clock is grounded.
Switching Characteristics
at V
CC
=
5V and T
A
=
25
C
Symbol
Parameter
Conditions
Min
Typ
Max
Units
(Note 6)
V
I
Input Clamp Voltage
V
CC
=
Min, I
I
=
-
18 mA
-
1.5
V
V
OH
HIGH Level
V
CC
=
Min, I
OH
=
Max
2.7
3.4
V
Output Voltage
V
IL
=
Max, V
IH
=
Min
V
OL
LOW
Level V
CC
=
Min, I
OL
=
Max
0.35
0.5
Output Voltage
V
IL
=
Max, V
IH
=
Min
V
I
OL
=
4 mA, V
CC
=
Min
0.25
0.4
I
I
Input Current @ Max
V
CC
=
Max, V
I
=
7V
J, K
0.1
Input Voltage
Clear
0.3
mA
Preset
0.3
Clock
0.4
I
IH
HIGH Level Input Current
V
CC
=
Max, V
I
=
2.7V
J, K
20
Clear
60
A
Preset
60
Clock
80
I
IL
LOW Level Input Current
V
CC
=
Max, V
I
=
0.4V
J, K
-
0.4
Clear
-
0.8
mA
Preset
-
0.8
Clock
-
0.8
I
OS
Short Circuit Output Current
V
CC
=
Max (Note 7)
-
20
-
100
mA
I
CC
Supply Current
V
CC
=
Max (Note 8)
4
6
mA
From (Input)
R
L
=
2 k
Symbol
Parameter
To (Output)
C
L
=
15 pF
C
L
=
50 pF
Units
Min
Max
Min
Max
f
MAX
Maximum Clock Frequency
30
25
MHz
t
PLH
Propagation Delay Time
Preset to Q
20
24
ns
LOW-to-HIGH Level Output
t
PHL
Propagation Delay Time
Preset to Q
20
28
ns
HIGH-to-LOW Level Output
t
PLH
Propagation Delay Time
Clear to Q
20
24
ns
LOW-to-HIGH Level Output
t
PHL
Propagation Delay Time
Clear to Q
20
28
ns
HIGH-to-LOW Level Output
t
PLH
Propagation Delay Time
Clock to Q or Q
20
24
ns
LOW-to-HIGH Level Output
t
PHL
Propagation Delay Time
Clock to Q or Q
20
28
ns
HIGH-to-LOW Level Output
www.fairchildsemi.com
4
D
M
74LS1
1
2A
Physical Dimensions
inches (millimeters) unless otherwise noted
16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150 Narrow
Package Number M16A
5
www.fairchildsemi.com
DM74LS1
1
2
A
Dual
Negat
ive
-
Edge-
T
r
i
ggered Maste
r
-Sl
ave J-K Fli
p
-
F
lop wit
h
Pr
eset,
Cl
ear
, and
Compl
e
m
ent
ary
Out
puts
Physical Dimensions
inches (millimeters) unless otherwise noted (Continued)
16-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide
Package Number N16E
