G5SBA20 AND G5SBA60
GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage - 200 and 600 Volts
Forward Current - 6.0 Amperes
FEATURES
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
This series is UL listed under the Recognized Component
Index, file number E54214
High case dielectric
strength of 1500 V
RMS
Ideal for printed circuit boards
Glass passivated chip junction
High surge current capability
High temperature soldering guaranteed:
260C/10 seconds, 0.375 (9.5mm) lead length,
5lbs. (2.3kg) tension
MECHANICAL DATA
Case: Molded plastic body over passivated junctions
Terminals: Plated leads solderable per MIL-STD-750,
Method 2026
Mounting Position: Any
(NOTE 3)
Mounting Torque: 5 in. - lb. max.
Weight: 0.15 ounce, 4.0 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25C ambient temperature unless otherwise specified.
SYMBOLS G5SBA20
G5SBA60
UNITS
Maximum repetitive peak reverse voltage
V
RRM
200
600
Volts
Maximum RMS voltage
V
RMS
140
420
Volts
Maximum DC blocking voltage
V
DC
200
600
Volts
Maximum average forward rectified T
C
=100C
(NOTE 1)
6.0
output current at
T
A
=25C
(NOTE 2)
I
(AV)
2.8
Amps
Peak forward surge current single sine-wave
superimposed on rated load (JEDEC Method)
I
FSM
150
Amps
Rating for fusing (t<8.3ms)
I
2
t
60
A
2
sec
Maximum instantaneous forward voltage drop
per leg at 3.0A
V
F
1.05
Volts
Maximum DC reverse current at T
A
=25C
5.0
rated DC blocking voltage per leg T
A
=125C
I
R
500
mA
Typical thermal resistance per leg
(NOTE 2)
R
QJA
22
(NOTE 1)
R
QJC
3.4
C/W
Operating junction and storage temperature range
T
J
, T
STG
-55 to +150
C
NOTES:
(1) Unit case mounted on Al plate heatsink.
(2) Units mounted on P.C.B. with 0.5 x 0.5" (12 x 12mm) copper pads and 0.375" (9.5mm) lead length
(3) Recommended mounting position is to bolt down on heatsink with silicone thermal compound for maximum heat transfer with #6 screw
0.125 (3.2) x 45
o
CHAMFER
0.085 (2.16)
0.065 (1.65)
0.020 R (TYP.)
0.880 (22.3)
0.860 (21.8)
0.100 (2.54)
0.085 (2.16)
0.160 (4.1)
0.140 (3.5)
0.075
(1.9) R.
0.080
0.060
(2.03)
(1.52)
0.050 (1.27)
0.040 (1.02)
0.080
0.065
(2.03)
(1.65)
0.210
0.190
(5.33)
(4.83)
Polarity shown on front side of case, positive lead by beveled corner
0.140 (3.56)
0.130 (3.30)
9
o
TYP.
5
o
TYP.
0.085 (2.16)
0.075 (1.90)
0.022 (0.56)
0.018 (0.46)
0.310 (7.9)
0.290 (7.4)
0.740 (18.8)
0.720 (18.3)
0.710 (18.0)
0.690 (17.5)
Dimensions in inches and (millimeters)
Case Style GBU
Polarity shown on front side of case, positive lead beveled corner.
If preferred, marking may be on reverse side of case.
Lead forming option with 10mm-7.5mm-7.5mm spacing is available.
2/24/99
NEW PRODUCT NEW PRODUCT NEW PRODUCT
0
50
100
150
0
2.0
4.0
6.0
8.0
1
10
100
0
50
100
150
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.01
0.1
1
10
100
0.1
1
10
100
10
100
1,000
0.01
0.1
1
10
100
0.1
1
10
100
0
20
40
60
80
100
0.01
0.1
1
10
100
500
RATINGS AND CHARACTERISTICS CURVES G5SBA20 THRU G5SBA60
FIG. 1 - DERATING CURVE OUTPUT
RECTIFIED CURRENT
TEMPERATURE, C
P.C.B. MOUNTING, T
A
HEATSINK MOUNTING, T
C
PERCENT OF RATED PEAK REVERSE
VOLTAGE, %
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
INST
ANT
ANEOUS REVERSE CURRENT
, MICROAMPERES
T
J
=25C
PULSE WIDTH=300
ms
1% DUTY CYCLE
FIG. 3 - TYPICAL FORWARD CHARACTERISTICS
PER LEG
INST
ANT
ANEOUS FOR
W
ARD CURRENT
,
AMPERES
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
PER LEG
REVERSE VOLTAGE, VOLTS
T
J
=25
C
f=1.0 MH
Z
Vsig=50mVp-p
T
J
=25C
A
VERAGE FOR
W
ARD OUTPUT
CURRENT
, AMPERES
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
PER LEG
NUMBER OF CYCLES AT 60 Hz
PEAK FOR
W
ARD SURGE CURRENT
,
AMPERES
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT PER LEG
T
J
=125C
FIG. 6 - TYPICAL TRANSIENT THERMAL
IMPEDANCE
TRANSIENT
THERMAL
IMPEDANCE,
C/W
t, HEATING TIME, sec.
T
J
=T
J
max.
SINGLE SINE-WAVE
(JEDEC Method)
1.0 CYCLE
JUNCTION CAP
ACIT
ANCE, pF
PDF
ZIP
