DESCRIPTION
The GS3015 incorporates Gennum's GL504 preamp, three of
the required capacitors and a mid supply referencing 48K
resistor. All that is required for a fully functional hearing aid
system is the addition of a microphone, receiver, volume
control, interstage coupling capacitor and an MPO adjusting
potentiometer.
The GS3015 has been designed to mount on the back of the
Microtronics PJ88S Socket Volume Control. This translates to
a saving in space within the hearing instrument, as the circuitry
mounts directly beneath the volume control. If the VC requires
replacing, it is a simple procedure to remove the defective unit
from the socket and install a new device. This does not disturb
the electronic circuitry.
The major advantage of the GL504 over other preamplifiers is
the electronic MPO adjustment. Since conventional MPO is not
possible in a class D receiver, Gennum provides it in the
preamp.
BLOCK DIAGRAM
V.C. Preamp Hybrid
for Class D
Gennum's GL504 preamp
mounts on back of Microtronic PJ88S VC Socket
low external parts count
designed to drive Class D integrated receivers
adjustable peak clipper
low current drain (150
A) typical
low noise and distortion
FEATURES
STANDARD PACKAGING
Hybrid Typical Dimensions
0.192 in x 0.194 in x 0.113 in
(4.88 mm x 4.93 mm x 2.85 mm)
GS3015 - HYB DATA SHEET
C2
47n
C3
47n
V
B
5
R
MIC
7
V
REC
GND
R1
48K
3
2
8
6
1
4
GS3015
R
PULL
C1
33
10
A
OUT
9
5
3
6
HYBRID
- B
1
7
8
A
IN
V
MIC
2
4
C
IN
CT
B
IN
MPO
11
B
OUT
- A
All resistors in ohms, all capacitors
in farads unless otherwise stated
Revision Date: May 1998
Document No. 520 - 92 - 05
GENNUM CORPORATION P.O. Box 489, Stn. A, Burlington, Ontario, Canada L7R 3Y3 tel. +1 (905) 632-2996
Web Site: www.gennum.com E-mail: hipinfo@gennum.com
520 - 92 - 05
2
ABSOLUTE MAXIMUM RATINGS
PARAMETER
VALUE/UNITS
Supply Voltage
3 V DC
Power Dissipation
25 mW
Operating Temperature Range
-10
C to +40
C
Storage Temperature Range
-20
C to +70
C
CAUTION
CLASS 1 ESD SENSITIVITY
PIN CONNECTION
PARAMETER
SYMBOL
CONDITIONS
MIN TYP MAX UNITS
Amplifier Current
I
AMP
V
IN
= 0, R
MPO
= 0
75
150
225
A
System Gain
A
V
V
IN
= -80 dBV, R
MPO
= 0
, Freq.= 5 kHz
44.5
46.5
48.5
dB
Maximum Output
MPO
V
IN
= -50 dBV, R
MPO
= 0
-16
-14
-12
dBV
MPO Range
MPO
V
IN
= -50 dBV, R
MPO
= 10 k
10
12
14
dB
Input Referred Noise
IRN
NFB 0.2 to 10 kHz at 12 dB/oct
-
2
-
V
RMS
Distortion
THD
-
<1.0
-
%
On Chip Pull-up Resistance
R
PULL
-
48
-
k
On Chip Microphone Resistor
R
MIC
-
4
-
k
Mic Decoupling Capacitor
C1
-20%
3.3
+20%
F
Input Coupling Capacitor
C2
-10%
0.047
+10%
F
Output Coupling Capacitor
C3
-10%
0.047
+10%
F
Output Resistor
R1
-5%
48
+5%
k
Output Impedance (Pad 1)
R
OUT
-
24
-
k
ELECTRICAL CHARACTERISTICS
Conditions: Frequency = 1 kHz, Temperature = 25
C
All parameters and switches remain as shown in Test Circuit unless otherwise stated in "Conditions" column
CT
BIN
MPO
CIN
BOUT
VMIC
8
11
6
7
10
9
2
1
3
4
5
VREC
AOUT
GND
VB
AIN
TOP VIEW
520 - 92 - 05
3
C2
47n
C3
47n
1.3 VDC
5
R
MIC
7
47n
R1
48K
3
2
8
6
1
4
R
PULL
C1
33
11
VOUT
R
FA
=100K
9
5
3
6
GS3015
HYBRID
4
- B
1
7
8
R
MPO
=10K
I
AMP
V IN
1kHz
3.92K
2
10
- A
All resistors in ohms, all capacitors in farads unless otherwise stated
Fig.1 Production Test Circuit
All resistors in ohms, all capacitors in farads unless otherwise stated
Fig. 2 Typical Hearing Instrument Application
C2
47n
C3
47n
1.3 VDC
5
R
MIC
7
VC SWITCH
47n
R1
48K
1
3
2
8
6
1
4
R
PULL
C1
33
MIC
2
CLASS D
INTEGRATED
RECEIVER
VC
9
5
3
6
GS3015
HYBRID
8
4
- B
1
7
11
10
R
MPO
10K
- A
520 - 92 - 05
4
0 5 10 15 20 25 30
RMPO (k
)
Fig. 7 Relative Amplifier Current vs MPO Resistance
R
VC
=33K
R
VC
=10K
-100 -90 -80 -70 -60 -50 -40 -30 -20
INPUT (dBV)
R
MPO
=0
R
MPO
=3.3k
R
MPO
=10k
Fig. 4
I
/ O for Various R
MPO
Values
-140 -120 -100 -80 -60 -40 -20
INPUT (dBV)
Fig. 3
I
/ O for Various R
VC
Values
R
VC
=100K
20
200
2K
20K
FREQUENCY (Hz)
C=0
C=0.1
C=0.22
-15
-25
-35
-45
-55
-65
-75
-85
-95
2
0
-2
-4
-6
-8
-10
-12
-14
-16
-18
-20
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-10
-15
-20
-25
-30
-35
-40
-45
-50
Fig. 5 Frequency Response for Various C||C2 Values
R
VC
=3.3K
10
9
8
7
6
5
4
3
2
1
0
-90 -86 -82 -78 -74 -70 -66 -62 -58
INPUT (dBV)
Fig. 6 Distortion vs Input Level (R
VC
=100k
)
RELATIVE AMPLIFIER CURRENT (
A)
OUTPUT (dBV)
THD (%)
OUTPUT (dBV)
RELATIVE OUTPUT (dB)
520 - 92 - 05
5
Fig. 10 Hybrid Layout and Dimensions
No Load
50K Load
Fig. 8 Output vs MPO Resistance
10
100
1K
10K 100K
FREQUENCY (Hz)
Fig. 9
Preamplifier A Open Loop Voltage Gain
0 10 100 1K 10K 100K
RMPO (
)
-10
-14
-18
-22
-26
-30
-34
-38
-42
-46
-50
55
50
45
40
35
Dimensioning units are inches. Dimensions shown in
parenthesis are in millimetres, converted from inches
and include minor round off errors 1.0000 inches = 25.4mm.
Minimum pad size 0.015in x 0.025in (0.38mm x 0.64mm).
Pad numbers & capacitor numbers for illustration only.
Dimensions tolerances:+0.013in -0.002in (+0.33mm -0.05mm)
unless otherwise stated.
XXXXXX - work order number.
0.080 MAX
(2.03)
0.192
(4.88)
0.123MAX
(3.13)
8
11
6
7
10
9
2
1
3
4
5
TOP VIEW
BOTTOM VIEW
0.194
(4.93)
8
11
6
7
10
9
2
1
3
4
5
C3
C2
0.063 MAX
(1.60)
C1
3015
XXXXXX
OUTPUT (dBV)
GAIN (dB)
520 - 92 - 05
6
BOTTOM VIEW
OF SWITCHES
BATTERY SWITCH
E
S
A
BATTERY SWITCH
S
A
E
BATTERY SW
BATTERY SW
eg. left volume control potentiometer
88S - 00 - 011 - 1 - 25 - 104/00
eg. right volume control potentiometer
88S - 00 - 011 - 2 - 24 - 104/00
eg. of socket
88S 10-1-1/00
For more information on Microtronic ordering codes, refer to MIcrotronic Data Sheet PJ88S
Fig. 11 Gennum Hybrid Concept with Microtronic PJ88S VC Socket
MPO TRIMMER
VOLUME
CONTROL
BATTERY
MIC
+
- +
11
9
1
10
8
7
6
5
4
3
2
REC
+
Fig. 12 Typical Assembly Diagram
