GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT
BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS,
THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
23A017
1.7 Watts, 20 Volts, Class A
Linear to 2300 MHz
GENERAL DESCRIPTION
The 23A017 is a COMMON EMITTER transistor capable of providing 1.7
Watts of Class A, RF output power to 2300 MHz. This transistor is
specifically designed for general Class A amplifier applications. It utilizes
gold metalization and diffused ballasting to provide high reliability and
supreme ruggedness. The transistor uses a fully hermetic High Temperature
Solder Sealed package.
CASE OUTLINE
55BT, STYLE 2
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25 C 6.0 Watts
o
Maximum Voltage and Current
BVces Collector to Emitter Voltage 50 Volts
BVebo Emitter to Base Voltage 3.5 Volts
Ic Collector Current 800 mA
Maximum Temperatures
Storage Temperature - 65 to + 200 C
o
Operating Junction Temperature + 200 C
o
ELECTRICAL CHARACTERISTICS @ 25 C
O
SYMBOL
CHARACTERISTICS
TEST CONDITIONS
MIN
TYP
MAX
UNITS
Pout
Pin
Pg
Ft
VSWR
Power Out
Power Input
Power Gain
Transition Frequency
Load Mismatch Tolerance
F = 2.3 GHz
Ic = 280 mA
Vcc = 20 Volts
Vce = 20V, Ic =280 mA
1.7
6.25
3.4
2.2
7.6
3.7
.38
9:1
Watts
Watts
dB
GHz
BVebo
BVces
BVceo
h
FE
Cob
jc
Emitter to Base Breakdown
Collector to Emitter Breakdown
Collector to Emitter Breakdown
DC Current Gain
Capacitance
Thermal Resistance
Ie = 2 mA
Ic = 20 mA
Ic = 20 mA
Vce = 5 V, Ic = 200 mA
Vcb = 28V, f = 1 MHz
3.5
50
22
20
4.8
14
16
Volts
Volts
Volts
pF
C/W
o
Initial Issue June, 1994
23A017-2 (20V, 280mA)
MMICAD for Windows Fri Aug 26 16:40:51 1994
CIRCUIT: MES
FREQ --- S11 --- --- S21 --- --- S12 --- --- S22 ---
Mhz MAG ANG MAG ANG MAG ANG MAG ANG
0.100 0.88100 -163.605 19.2828 108.728 0.01696 20.3017 0.40786 -108.493
0.200 0.91933 -173.623 10.1715 93.8230 0.01815 15.0322 0.33797 -134.089
0.300 0.92878 -178.162 6.88113 83.9582 0.01835 14.2324 0.33201 -143.137
0.400 0.92829 178.890 5.17666 77.4229 0.01889 15.7121 0.33829 -147.054
0.500 0.92797 176.552 4.13396 72.1900 0.01961 17.2633 0.35146 -149.085
0.600 0.92815 174.478 3.43409 66.9399 0.02020 20.6484 0.36691 -150.380
0.700 0.92879 172.692 2.93024 61.3260 0.02077 21.3137 0.38529 -151.448
0.800 0.92918 171.110 2.55303 56.5103 0.02163 23.1242 0.40451 -152.378
0.900 0.93018 169.391 2.26111 51.8779 0.02229 25.1797 0.42486 -153.325
1.000 0.93013 167.742 2.02737 47.4561 0.02354 27.0967 0.44582 -154.415
1.100 0.92855 166.099 1.83394 43.0705 0.02442 27.9353 0.46679 -155.694
1.200 0.92862 164.492 1.67430 38.7969 0.02555 28.5464 0.48814 -157.053
1.300 0.92812 162.903 1.53984 34.6105 0.02670 30.4013 0.50816 -158.620
1.400 0.93001 161.284 1.42500 30.4737 0.02791 30.2711 0.52765 -160.323
1.500 0.92981 159.592 1.32593 26.3548 0.02932 31.4205 0.54646 -162.039
1.600 0.92904 157.807 1.23713 22.2103 0.03120 31.5900 0.56433 -163.921
1.700 0.92699 155.955 1.15833 18.1552 0.03234 32.3130 0.58133 -165.915
1.800 0.92673 154.139 1.08790 14.1996 0.03410 31.9861 0.59696 -167.963
1.900 0.92543 152.289 1.02388 10.3988 0.03626 32.1420 0.61140 -169.997
2.000 0.92657 150.463 0.96863 6.69497 0.03827 32.1540 0.62506 -171.952
2.100 0.92738 148.455 0.91938 2.91897 0.04095 30.5798 0.63969 -173.949
2.200 0.92485 146.338 0.87181 -0.81298 0.04295 29.3390 0.65165 -176.080
2.300 0.91984 144.183 0.82748 -4.32557 0.04434 27.1262 0.66332 -177.960
2.400 0.91478 142.269 0.78973 -7.70741 0.04553 26.4539 0.67602 -179.717
2.500 0.91098 140.452 0.75697 -10.9869 0.04692 26.5970 0.69046 178.437
2.600 0.91075 138.500 0.72774 -14.3164 0.04875 26.5432 0.70306 176.415
2.700 0.90981 136.330 0.70053 -17.6197 0.05122 26.3291 0.71429 174.516
2.800 0.90780 134.185 0.67628 -20.8994 0.05419 25.9254 0.72683 172.617
2.900 0.90337 131.906 0.65284 -24.2352 0.05703 24.8914 0.73750 170.621
3.000 0.89919 129.639 0.63127 -27.4546 0.06055 24.1487 0.74689 168.631
