v
Naturally air-cooled head
SPECTRAL RESPONSE CHARACTERISTICS
SYSTEM CONFIGURATION
APPLICATIONS
q
Faint light observation under a microscope
q
Continuous imaging of high-speed moving objects
q
Kinetic changes in light intensity
These low noise/high frame rate camera systems maintain the
superb noise characteristic of the conventional cooled CCD cam-
era, while at the same time adding high speed.
In order to achieve both high speed and a low noise characteris-
tic, a progressive scan interline CCD is used, which eliminates
the need for a mechanical shutter. This means that problems
such as vibration caused by the mechanical shutter at high frame
rates, and the lifetime of the mechanical shutter, have been com-
pletely eliminated. In addition, taking advantage of the low dark
current characteristic of the CCD used in these models, cooling
can be suppressed to the minimum necessary level, and by
switching from a conventional forced cooling system to a system
which discharges heat by natural means, operation is significantly
improved.
C4880-80- A
FEATURES
q
Progressive scan interline CCD used with no mechani-
cal shutter
q
Two scan modes as well as sub-array and binning
functions available
q
Maximum frame rate of up to approximately 500 frames/
sec
q
Fast scan readout with low noise
q
Full computer control
TYPE NO.
Bit number on A/D converter
12: Fast scan mode 10-bit
High precision scan mode 12-bit
14: Fast scan mode 10-bit
High precision scan mode 14-bit
22: Fast scan mode 12-bit
High precision scan mode 12-bit
24: Fast scan mode 12-bit
High precision scan mode 14-bit
Quantum efficiency (%)
Wavelength (nm)
20
400
300
600
500
700
800
900
1,000 1,100
30
40
50
0
10
Camera controller
Camera head
Hermetically vacuum-sealed
air-cooled head
CCD
ICX-074
(Interline CCD)
Image input board Software
Computer
Image acquisition unit (kit)
Commercially available
software
* This is typical, not guaranteed.
Fast Scan Multi Format
Cooled CCD
Camera
C4880-80
DATA SHEET
SPECIFICATIONS
DIMENSIONAL OUTLINES
q
Camera head (approx. 1.3 kg)
q
Camera controller (approx. 6.3 kg)
Model name
C4880-80-
-A
Camera head type
Naturally air-cooled head
Circulating water cooler (sold separately)
Vacuum pump (sold separately)
Imaging device
ICX-074 Model 1/2 full-pixel scanning interline CCD
Effective no. of pixels
656 (H)
494 (V)
Cell size
9.9 (H)
9.9 (V)
m
Effective area
6.49 (H)
4.89 (V) mm
Readout noise
Min.
5 electrons r.m.s.
Typ.
7 electrons r.m.s.
Full well capacity
30,000 to 50,000 electrons
Dynamic range
Typ.
4,300 : 1
Max.
10,000 : 1
Frame rate
High-precision scan mode
1Hz (1
1 binning), 310Hz (32
32 binning)
Fast scan mode
28Hz (1
1 binning), 529Hz (32
32 binning)
Cooling method
Peltier cooling / natural air cooling
Cooling temperature
0C (Cools the CCD element to 20 C less than the ambient temperature)
CCD cooling control
Normally ON
Dark current
3 electrons/pixel/sec
Exposure time
1/8,000 sec to 10 sec
A/D converter
12 / 14 bits
Lens mount
C-mount
Mechanical shutter
Variable analog gain
Front panel dial / software-controlled switching, 1 - 10 times (high-speed scan)
Variable offset
Front panel dial / software-controlled switching (fast scan)
Amp gain
2 steps (fast scan), 3 steps (precision scan)
Binning scan
Yes
Sub-array scan
1/1, 1/2, 1/4, 1/8 (H)
any desired number (V)
Super-pixel scan
2
2, 4
4, 8
8, 16
16, 32
32
External trigger input
Yes
Output signal (digital output)
Parallel digital output (conforms to RS-422)
External control
RS-232C
Ambient storage temperature
-10 to +50 C
Ambient operating temperature
0 C to +40 C
Ambient operating/storage humidity
70% max. (with no condensation)
Line voltage
100 / 117 / 220 / 240 VAC, 50/60 Hz
Power consumption
Approx. 115 VA
MULTI FORMAT CCD CAMERA
C4880-80
90
1
75
1
32
0.
5
37.5
0.5
8
0.
5
160
2
48
0.5
60
1
40
1
40
1
3
1
18
0.5
4-M3
1/4-20UNC
1-32UN C-mount
CAMERA CONTROLLER
C4880-80
POWER
GAIN
CONTRAST ENHANCEMENT
MIN
MAX
OFFSET
0
232
1
383
2
74
1
7
1
s
High-precision scan mode
q
Full frame readout
Binning number
1
1
2
2
4
4
8
8
16
16
32
32
No. of pixels (H
V) 656
494 328
247 164
123 82
61
41
30
20
15
Frame rate (Hz)
1
4
14
45
133
310
Binning number
1
1
4
4
No. of pixels (H
V) 100
100 25
25
Frame rate (Hz)
25
127
q
Sub-array scan (100
100 area)
s
Fast scan mode
q
Full frame readout
q
Sub-array scan (100
100 area)
Binning number
1
1
2
2
4
4
8
8
16
16
32
32
No. of pixels (H
V) 656
494 328
247 164
123 82
61
41
30
20
15
Frame rate (Hz)
28
53
102
189
328
529
Binning number
1
1
4
4
No. of pixels (H
V) 100
100 25
25
Frame rate (Hz)
90
170
Note: Values for scan speeds are typical values. Please consult with
HAMAMATSU for further information.
