2012 Size

Chip Band Pass Filter

for W-LAN

ESLB-S540A

Ver.A

CONFIDENTIAL

The contents of this document is the property of Hitachi Metals Ltd. and

may not be communicated to any other party in any form without the prior

written contents of Hitachi Metals Ltd..

CONFIDENTIAL

The contents of this document is the property of Hitachi Metals Ltd. and

may not be communicated to any other party in any form without the prior

written contents of Hitachi Metals Ltd..

All the technical data and information contained

herein are subject to change without notice.

Page-No. 1/4

DATE.

DATA-No.

P/N

`04- 2- 4

ESLB-S540A

DWN.

M.Uchida

2MT43485

Shape & Size

Specifications(Temporary)

1.25

2.0

0.3

1.0

0.65

unit(mm)

1,3,4,6 Ground

5 OUT

2 IN

Marking:Temporary

Parameter

Unit

Center Frequency(fo)

MHz

5400

Passband Width

MHz

fo +/- 500

Insertion Loss

(at 25 deg.C)

1.4 max

Insertion Loss

(at -35 to +85 deg.C)

1.5 max

Ripple in passband

0.3 min

Input Ret.Loss

10 min

Attenuation1

25 min

(at DC-2.5GHz)

Attenuation2

23 min

(at 9.8-11.8GHz)

Attenuation3

10 min

(at 14.7-17.7GHz)

Characteristec Impedance Ohm

Handling Power

0.5 max

Operating Temperature

deg.C

-35 to +85

Page-No. 1/4

DATE.

DATA-No.

P/N

`04- 2- 4

ESLB-S540A

DWN.

M.Uchida

2MT43485

ESLB-S540A Ver.A Sample DATA

m14

freq=4.900GHz

dB(S (4,3))=-0.751

m15

freq=5.900GHz

dB(S (4,3))=-0.786

m16

freq=5.400GHz

dB(S (4,3))=-0.735

m 1

fre q =4.900GHz

dB(S (3,3))=-16.487

m 2

fre q =5.900GHz

dB(S (3,3))=-14.542

4.75

5.00

5.25

5.50

5.75

6.00

6.25

4.50

6.50

-4

-3

-2

-1

-5

-40

-30

-20

-10

-50

fre q , GHz

dB(

(4,3))

m14

m15

m16

dB(
S

(3,3))

Page-No. 1/4

DATE.

DATA-No.

P/N

`04- 2- 4

ESLB-S540A

DWN.

M.Uchida

2MT43485

freq=2.500GHz

dB(S (2,1))=-42.863

freq=9.800GHz

dB(S (2,1))=-27.588

freq=11.80GHz

dB(S (2,1))=-37.928

freq=14.70GHz

dB(S (2,1))=-27.038

freq=17.70GHz

dB(S (2,1))=-27.058

3.0

5.5

8.0

10.5

13.0

15.5

18.0

0.5

20.0

-50

-40

-30

-20

-10

-60

freq, GHz

dB(

(2,1))

Foot Pattern

Foot Pattern Example

0. 35

0. 3

0. 35

0
.
8

0
.
5
5

Ground

50ohm strip line

Page-No. 1/4

DATE.

DATA-No.

P/N

`04- 2- 4

ESLB-S540A

DWN.

M.Uchida

2MT43485
