HD74HC114
Dual J-K Flip-Flops (with Preset, Common Clear and
Common Clock)
Description
This flip-flop is edge sensitive to the clock input and change state on the negative transition of the clock
pulse. each flip-flop has independent J, K and preset inputs and Q and
Q outputs. Two flip-flops are
controlled by a common clear and a common clock. Preset and clear are independent of the clock and
accomplished by a low logic level on the corresponding input.
Features
High Speed Operation: t
pd
(Clock to Q) = 18 ns typ (C
L
= 50 pF)
High Output Current: Fanout of 10 LSTTL Loads
Wide Operating Voltage: V
CC
= 2 to 6 V
Low Input Current: 1 A max
Low Quiescent Supply Current: I
CC
(static) = 2 A max (Ta = 25C)
HD74HC114
2
Function Table
Inputs
Output
Preset
Clear
Clock
J
K
Q
Q
L
H
X
X
X
H
L
H
L
X
X
X
L
H
L
L
X
X
X
H*
1
H*
1
H
H
L
L
No change
H
H
L
H
L
H
H
H
H
L
H
L
H
H
H
H
Toggle
H
H
L
X
X
No change
H
H
H
X
X
No change
H
H
X
X
No change
Note:
1. Q and
Q
will remain HIGH as long as Preset and Clear are Low, but Q and
Q
are unpredictable,
if Preset and Clear go HIGH simultaneously.
Pin Arrangement
1
(Top view)
2
3
4
5
6
7
CLK
1K
1J
1PR
1Q
1
Q
GND
V
CC
CK
2K
2J
2PR
2Q
2
Q
14
13
12
11
10
9
8
PR
PR
K
J
CK
Q
Q
PR
PR
K
J
CK
Q
Q
HD74HC114
3
DC Characteristics
Ta = 25
C
Ta = 40 to
+85
C
Item
Symbol
V
CC
(V) Min Typ Max Min
Max
Unit
Test Conditions
Input voltage
V
IH
2.0
1.5
--
--
1.5
--
V
4.5
3.15 --
--
3.15
--
6.0
4.2
--
--
4.2
--
V
IL
2.0
--
--
0.5
--
0.5
V
4.5
--
--
1.35 --
1.35
6.0
--
--
1.8
--
1.8
Output voltage
V
OH
2.0
1.9
2.0
--
1.9
--
V
Vin = V
IH
or V
IL
I
OH
= 20
A
4.5
4.4
4.5
--
4.4
--
6.0
5.9
6.0
--
5.9
--
4.5
4.18 --
--
4.13
--
I
OH
= 4 mA
6.0
5.68 --
--
5.63
--
I
OH
= 5.2 mA
V
OL
2.0
--
0.0
0.1
--
0.1
V
Vin = V
IH
or V
IL
I
OL
= 20
A
4.5
--
0.0
0.1
--
0.1
6.0
--
0.0
0.1
--
0.1
4.5
--
--
0.26 --
0.33
I
OL
= 4 mA
6.0
--
--
0.26 --
0.33
I
OL
= 5.2 mA
Input current
Iin
6.0
--
--
0.1 --
1.0
A
Vin = V
CC
or GND
Quiescent supply
current
I
CC
6.0
--
--
2.0
--
20
A
Vin = V
CC
or GND, Iout = 0
A
HD74HC114
4
AC Characteristics (C
L
= 50 pF, Input t
r
= t
f
= 6 ns)
Ta = 25
C
Ta = 40 to
+85
C
Item
Symbol
V
CC
(V) Min Typ Max Min
Max
Unit
Test Conditions
Maximum clock
f
max
2.0
--
--
6
--
5
MHz
frequency
4.5
--
--
30
--
24
6.0
--
--
35
--
28
Propagation delay t
PLH
2.0
--
--
150 --
190
ns
Clock to Q or
Q
time
t
PHL
4.5
--
18
30
--
38
6.0
--
--
26
--
33
2.0
--
--
140 --
175
Clear to Q or
Q
4.5
--
16
28
--
35
6.0
--
--
24
--
30
2.0
--
--
140 --
175
Preset to Q or
Q
4.5
--
16
28
--
35
6.0
--
--
24
--
30
Pulse width
t
w
2.0
80
--
--
100
--
ns
4.5
16
6
--
20
--
6.0
14
--
--
17
--
Setup time
t
su
2.0
100 --
--
125
--
ns
4.5
20
2
--
25
--
6.0
17
--
--
21
--
Hold time
t
h
2.0
5
--
--
5
--
ns
4.5
5
2
--
5
--
6.0
5
--
--
5
--
Removal time
t
rem
2.0
100 --
--
125
--
ns
4.5
20
0
--
25
--
6.0
17
--
--
21
--
Output rise/fall
t
TLH
2.0
--
--
75
--
95
ns
time
t
THL
4.5
--
5
15
--
19
6.0
--
--
13
--
16
Input capacitance
Cin
--
--
5
10
--
10
pF
Hitachi Code
JEDEC
EIAJ
Weight (reference value)
DP-14
Conforms
Conforms
0.97 g
Unit: mm
7.62
0.25
0
15
19.20
20.32 Max
1
8
14
7
1.30
2.54
0.25
0.48
0.10
6.30
7.40 Max
0.51 Min
2.54 Min
5.06 Max
+ 0.10
0.05
2.39 Max
