HD74LV164A
8-bit Parallel-out Serial-in Shift Register
ADE-205-266 (Z)
1st Edition
March 1999
Description
The HD74LV164A is 8-bit shift register has gated serial inputs and clear. Each register bit is a D-type
master/slave flip-flop. Inputs A & B permit complete control over the incoming data. A low at either or
both inputs inhibits entry of new data and resets the first flip-flop to the low level at the next clock pulse. A
high level on one input enables the other input which will then determine the state of the first flip-flop.
Data at the serial inputs may be changed while the clock is high or low, but only information meeting the
setup and hold time but only information meeting the setup and hold time requirements will be entered.
Data is serially shifted in and out of the 8-bit register during the positive going transition of the clock pulse.
Clear is independent of the clock and accomplished by low level at the clear input.
Low-voltage and high-speed operation is suitable for the battery-powered products (e.g., notebook
computers), and the low-power consumption extends the battery life.
Features
V
CC
= 2.0 V to 5.5 V operation
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
Typical V
OL
ground bounce < 0.8 V (@V
CC
= 3.3 V, Ta = 25
C)
Typical V
OH
undershoot > 2.3 V (@V
CC
= 3.3 V, Ta = 25
C)
Output current
6 mA (@V
CC
= 3.0 V to 3.6 V),
12 mA (@V
CC
= 4.5 V to 5.5 V)
HD74LV164A
2
Function Table
Inputs
Outputs
CLR
CLK
A
B
QA
QB
...
QD
L
X
X
X
L
L
...
L
H
X
X
Q
A0
Q
B0
...
Q
H0
H
H
H
H
Q
An
...
Q
Gn
H
L
X
L
Q
An
...
Q
Gn
H
X
L
L
Q
An
...
Q
Gn
Note:
H: High level
L: Low level
X: Immaterial
: Low to high transition
: High to low transition
Q
AD
, Q
B0
...Q
H0
: Outputs remain unchanged.
Q
An
, Q
Bn
...Q
Gn
: Data shifted from the previous stage on a positive edge at the clock input.
Pin Arrangement
11
12
9
10
13
14
8
V
CC
Q
H
Q
G
Q
F
Q
E
CLR
1
2
3
4
5
6
7
A
B
Q
A
Q
B
Q
C
Q
D
GND
CLK
(Top view)
HD74LV164A
3
Absolute Maximum Ratings
Item
Symbol
Ratings
Unit
Conditions
Supply voltage range
V
CC
0.5 to 7.0
V
Input voltage range*
1
V
I
0.5 to 7.0
V
Output voltage range*
1, 2
V
O
0.5 to V
CC
+ 0.5
V
Output: H or L
0.5 to 7.0
V
CC
: OFF
Input clamp current
I
IK
20
mA
V
I
< 0
Output clamp current
I
OK
50
mA
V
O
< 0 or V
O
> V
CC
Continuous output current
I
O
25
mA
V
O
= 0 to V
CC
Continuous current through
V
CC
or GND
I
CC
or I
GND
50
mA
Maximum power dissipation
at Ta = 25
C (in still air)*
3
P
T
785
mW
SOP
500
TSSOP
Storage temperature
Tstg
65 to 150
C
Notes: The absolute maximum ratings are values which must not individually be exceeded, and furthermore,
no two of which may be realized at the same time.
1. The input and output voltage ratings may be exceeded if the input and output clamp-current
ratings are observed.
2. This value is limited to 5.5 V maximum.
3. The maximum package power dissipation was calculated using a junction temperature of 150
C.
HD74LV164A
4
Recommended Operating Conditions
Item
Symbol
Min
Max
Unit
Conditions
Supply voltage range
V
CC
2.0
5.5
V
Input voltage range
V
I
0
5.5
V
Output voltage range
V
O
0
V
CC
V
H or L
Output current
I
OH
--
50
A
V
CC
= 2.0 V
--
2
mA
V
CC
= 2.3 to 2.7 V
--
6
V
CC
= 3.0 to 3.6 V
--
12
V
CC
= 4.5 to 5.5 V
I
OL
--
50
A
V
CC
= 2.0 V
--
2
mA
V
CC
= 2.3 to 2.7 V
--
6
V
CC
= 3.0 to 3.6 V
--
12
V
CC
= 4.5 to 5.5 V
Input transition rise or fall rate
t /
v
0
200
ns/V
V
CC
= 2.3 to 2.7 V
0
100
V
CC
= 3.0 to 3.6 V
0
20
V
CC
= 4.5 to 5.5 V
Operating free-air temperature
Ta
40
85
C
Note:
Unused or floating inputs must be held high or low.
