16-Pin SOIC

Integrated
Circuit
Systems, Inc.

ICS1562B

Description

The ICS1562B is a very high performance monolithic phase-
locked loop (PLL) frequency synthesizer. Utilizing ICS's ad-
vanced CMOS mixed-mode technology, the ICS1562B
provides a low cost solution for high-end video clock genera-
tion.

The ICS1562B has differential video clock outputs (CLK+ and
CLK-) that are compatible with industry standard video DAC.
Another clock output, LOAD, is provided whose frequency is
derived from the main clock by a programmable divider. An
additional clock output is available, LD/N2, which is derived
from the LOAD frequency and whose modulus may also be
programmed.

Operating frequencies are fully programmable with direct con-
trol provided for reference divider, prescaler, feedback divider
and post-scaler.

Reset of the pipeline delay on Brooktree RAMDAC

s may

be performed under register control. Outputs may also be set
to desired states to facilitate circuit board testing.

User Programmable Differential Output Graphics Clock Generator

Features

Two programming options:
ICS1562B-001 (Parallel Programming)
ICS1562B-201 (Serial Programming)

Supports high-resolution graphics - CLK output to
260 MHz, with 400 MHz options available

Eliminates need for multiple ECL output crystal oscillators

Fully programmable synthesizer capability - not just a
clock multiplier

Circuitry included for reset of Brooktree RAMDAC pipe-
line delay

VRAM shift clock generation capability
(-201 option only)

External feedback loop capability (-201 option only)

Compact - 16-pin 0.150" skinny SOIC package

Fully backward compatible to ICS1562

CRYSTAL

OSCILLATOR

/ R

PHASE-

FREQUENCY

DETECTOR

CHARGE

PUMP

LOOP

FILTER

VCO

PRESCALER

/ A

/ M

MUX

/ 2

/ 4

/ N1

MUX

DRIVER

DIFF.

OUTPUT

DRIVER

/ N2

PROGRAMMING

INTERFACE

CLK+

CLK

LOAD

LD/N2

XTAL1

XTAL2

ICS1562B - 001 Pinout

ICS1562B - 201 Pinout

Simplified Block Diagram - ICS1562B

FEEDBACK DIVIDER

EXTFBK

BLANK

(-201 only)

Figure 1

1562 B Rev

B 10/07/04

RAMDAC is a trademark of Brooktree Corporation.

AD0

AD1

XTAL1

AD2

XTAL2

AD3

STROBE

VDD

VSS

VDDO

VSS

IPRG

LOAD

CLK+

LD/N2

CLK-

16-Pin SOIC

EXTFBK

DATA

XTAL1

HOLD

XTAL2

BLANK

DATCLK

VDD

VSS

VDDO

VSS

IPRG

LOAD

CLK+

LD/N2

CLK-

Overview

The ICS1562B is ideally suited to provide the graphics system
clock signals required by high-performance video DACs.
Fully programmable feedback and reference divider capability
allow virtually any frequency to be generated, not just simple
multiples of the reference frequency. The ICS1562B uses the
latest generation of frequency synthesis techniques developed
by ICS and is completely suitable for the most demanding
video applications.

PLL Synthesizer Description -
Ratiometric Mode

The ICS1562B generates its output frequencies using phase-
locked loop techniques. The phase-locked loop (or PLL) is a
closed-loop feedback system that drives the output frequency
to be ratiometrically related to the reference frequency pro-
vided to the PLL (see Figure 1). The reference frequency is
generated by an on-chip crystal oscillator or the reference
frequency may be applied to the ICS1562B from an external
frequency source.

The phase-frequency detector shown in the block diagram
drives the voltage-controlled oscillator, or VCO, to a frequency
that will cause the two inputs to the phase-frequency detector
to be matched in frequency and phase. This occurs when:

F(XTAL1) . Feedback Divider

VCO)

: =

Reference Divider

This expression is exact; that is, the accuracy of the output
frequency depends solely on the reference frequency provided
to the part (assuming correctly programmed dividers).

The VCO gain is programmable, which permits the ICS1562B
to be optimized for best performance at all operating frequencies.

The reference divider may be programmed for any modulus
from 1 to 128 in steps of one.

The feedback divider may be programmed for any modulus
from 37 through 448 in steps of one. Any even modulus from
448 through 896 can also be achieved by setting the "double"
bit which doubles the feedback divider modulus. The feedback
divider makes use of a dual-modulus prescaler technique that
allows the programmable counters to operate at low speed
without sacrificing resolution. This is an improvement over
conventional fixed prescaler architectures that typically im-
pose a factor-of-four penalty (or larger) in this respect.

Table 1 permits the derivator of "A" & "M" converter program-
ming directly from desired modulus.

PLL Post-Scaler

A programmable post-scaler may be inserted between the VCO
and the CLK+ and CLK- outputs of the ICS1562B. This is
useful in generating lower frequencies, as the VCO has been
optimized for high-frequency operation.

The post-scaler allows the selection of:

VCO frequency

VCO frequency divided by 2

VCO frequency divided by 4

Internal register bit (AUXCLK) value

Load Clock Divider

The ICS1562B has an additional programmable divider (re-
ferred to in Figure 1 as the N1 divider) that is used to generate
the LOAD clock frequency for the video DAC. The modulus
of this divider may be set to 3, 4, 5, 6, 8, 10, 12, 16 or 20 under
register control. The design of this divider permits the output
duty factor to be 50/50, even when an odd modulus is selected.
The input frequency to this divider is the output of the PLL
post-scaler described above. Additionally, this divider can be
disabled under register control.

Digital Inputs - ICS1562B-001 Option

The AD0-AD3 pins and the STROBE pin are used to load all
control registers of the ICS1562B (-001 option). The AD0-
AD3 and STROBE pins are each equipped with a pull-up and
will be at a logic HIGH level when not connected. They may
be driven with standard TTL or CMOS logic families.

The address of the register to be loaded is latched from the
AD0-AD3 pins by a negative edge on the STROBE pin. The
data for that register is latched from the AD0-AD3 pins by a
positive edge on the STROBE pin. See Figure 2 for a timing
diagram. After power-up, the ICS1562B-001 requires 32 reg-
ister writes for new programming to become effective. Since
only 13 registers are used at present, the programming system
can perform 19 "dummy" writes to address 13 or 14 to com-
plete the sequence.

ICS1562B

Digital Inputs - ICS1562B-201 Option

The programming of the ICS1562B-201 is performed serially
by using the DATCLK, DATA, and HOLD~pins to load an
internal shift register.

DATA is shifted into the register on the rising edge of
DATCLK. The logic value on the HOLD~pin is latched at the
same time. When HOLD~ is low, the shift register may be
loaded without disturbing the operation of the ICS1562B.
When high, the shift register outputs are transferred to the
control registers, and the new programming information be-
comes active. Ordinarily, a high level should be placed on the
HOLD~ pin when the last data bit is presented. See Figure 3
for the programming sequence.

An additional control pin on the ICS1562B-201, BLANK can
perform either of two functions. It may be used to disable the
phase-frequency detector in line-locked applications. Alterna-
tively, the BLANK pin may be used as a synchronous enable
for VRAM shift clock generation. See sections on Line-Locked
Operations and VRAM shift clock generation for details.

Output Description

The differential output drivers, CLK+ and CLK, are current-
mode and are designed to drive resistive terminations in a
complementary fashion. The outputs are current-sinking only,
with the amount of sink current programmable via the IPRG
pin. The sink current, which is steered to either CLK+or CLK-,
is four times the current supplied to the IPRG pin. For most
applications, a resistor from VDDO to IPRG will set the current
to the necessary precision. Additionally, minor adjustment to
the duty factor can be achieved under register control.

The LOAD output is a high-current CMOS type drive whose
frequency is controlled by a programmable divider that may be
selected for a modulus of 3, 4, 5, 6, 8, 10, 12, 16 or 20. It may
also be suppressed under register control. The load output may
be programmed to output the VCO frequency divided by 2 (see
AUX_N1 description in Register Mapping section), inde-
pendent of the differential output and N1 divider modulus.

The LD/N2 output is high-current CMOS type drive whose
frequency is derived from the LOAD output. The programma-
ble modulus may range from 1 to 512 in steps of one.

DATA VALID

ADDRESS VALID

AD0-AD3

STROBE

ICS1562B-001 Register Loading

Figure 2

DATCLK

DATA

HOLD

DATA_1

DATA_2

DATA_56

ICS1562B-201 Register Loading

Figure 3

This allows the synthesizer to be completely programmed for
the desired frequency before it is made active. Once the part
has been "unlocked" by the 32 writes, programming becomes
effective immediately.

ALL registers identified in the data sheet (0-9, 11, 12 & 15)
MUST be written upon initial programming. The programming
registers are not initialized upon power-up, but the latched
outputs of those registers are. The latch is made transparent
after 32 register writes. If any register has not been written, the
state upon power-up (random) will become effective. Registers
13 & 14 physically do not exist. Register 10 does exist, but is
reserved for future expansion. To insure compatibility with
possible future modifications to the database, ICS recommends
that all three unused locations be written with zero.

ICS1562B

Pipeline Delay Reset Function

The ICS1562B implements the clocking sequence required to
reset the pipeline delay on Brooktree RAMDACs when the
LOAD output is programmed for a modulus of either 3, 4, 5,
6, 8 or 10. This sequence can be generated by setting the
appropriate register bit (DACRST) to a logic 1 and then reset-
ting to logic 0.

When changing frequencies, it is advisable to allow 500 mi-
croseconds after the new frequency is selected to activate the
reset function. The output frequency of the synthesizer should
be stable enough at that point for the video DAC to correctly
execute its reset sequence. See Figure 4 for a diagram of the
pipeline delay reset sequence.

Reference Oscillator and Crystal
Selection

The ICS1562B has circuitry on-board to implement a Pierce
oscillator with the addition of only one external component, a
quartz crystal. Pierce oscillators operate the crystal in anti-
(also called parallel-) resonant mode. See the AC Charac-
teristics for the effective capacitive loading to specify when
ordering crystals.

Series-resonant crystals may also be used with the ICS1562B.
Be aware that the oscillation frequency will be slightly higher
than the frequency that is stamped on the can (typically 0.025-
0.05%).

As the entire operation of the phase-locked loop depends on
having a stable reference frequency, we recommend that the
crystal be mounted as closely as possible to the package. Avoid
routing digital signals or the ICS1562B outputs underneath or
near these traces. It is also desirable to ground the crystal can
to the ground plane, if possible.

If an external reference frequency source is to be used with the
ICS1562B. it is important that it be jitter-free. The rising and
falling edges of that signal should be fast and free of noise for
best results.

The loop phase is locked to the falling edges of the XTAL1
input signals if the REFPOL bit is set to logic 0.

Internal Feedback

The ICS1562B supports

LOAD (N1) and N2 divider

chains to act as the

feedback divider for the PLL.

The N1 and N2 divider chains allow a much larger modulus to
be achieved than the PLL's own feedback divider. Additionally,
the output of the N2 counter is accessible off-chip for perform-
ing horizontal reset of the graphics system, where necessary.
This mode is set under register control (ALTLOOP bit). The
reference divider (R counter) will ordinarily be set to divide by
1 in this mode, and the

reference input will be supplied to

the XTAL1 input. The output frequency of

the synthesizer

will then be:

(CLK)

: = F (XTAL1) . N1 . N2.

By using the phase-detector hardware disable mode, the PLL
can be made to free-run at the beginning of the vertical interval
of the external video, and can be reactivated at its completion.

ICS1562B-001 The ICS1562B-001 supports phase detector

disable via a special control mode. When the
PDRSTEN (phase detector reset enable) bit is
set and the last address latched is 15 (0Fh), a
high level on AD3 will disable PLL locking.

ICS1562B-201 The ICS1562B-201 supports phase detector

disable via the BLANK pin. When the
PDRSTEN bit is set, a high level on the
BLANK input will disable PLL locking.

Pipeline Delay Reset Timing

STROBE
or
DATCLK

CLK+

LOAD

10
9

CLK

Figure 4

ICS1562B

External Feedback Operation

The ICS1562B-201 option also supports the inclusion of an
external counter as the feedback divider of the PLL. This mode
is useful in graphic systems that must be "genlocked" to
external video sources.

When the EXTFBEN bit is set to logic 1, the phase-frequency
detector will use the EXTFBK pin as its feedback input. The
loop phase will be locked to the rising edges of the signal applied
to the EXTFBK input if the FBKPOL bit is set to logic 0.

VRAM Shift Clock Generation

The ICS1562B-201 option supports VRAM shift clock gen-
eration and interruption. By programming the N2 counter to
divide by 1, the LD/N2 output becomes a duplicate of the
LOAD output. When the SCEN bit is set, the LD/N2 output
may be synchronously started and stopped via the blank pin.
When BLANK is high, the LD/N2 will be free-running and in
phase with LOAD. When BLANK is taken low, the LD/N2
output is stopped at a low level. See Figure 5 for a diagram of
the sequence. Note that this use of the BLANK pin precludes its
use for phase comparator disable (see Line-Locked Operation).

Power-On Initialization

The ICS1562B has an internal power-on reset circuit that
performs the following functions:

Sets the multiplexer to pass the reference frequency
to the CLK+ and CLK- outputs.

Selects the modulus of the N1 divider (for the
LOAD clock) to be four.

These functions should allow initialization of most graphics
systems that cannot immediately provide for register program-
ming upon system power-up.

Because the power-on reset circuit is on the VDD supply, and
because that supply is filtered, care must be taken to allow the
reset to de-assert before programming. A safe guideline is to
allow 20 microseconds after the VDD supply reaches 4 volts.

Programming Notes

VCO Frequency Range: Use the post-divider to keep the
VCO frequency as high as possible within its operating
range.

Divider Range: For best results in normal situations (i.e,
pixel clock generation for hi-res displays), keep the refer-
ence divider modulus as short as possible (for a frequency
at the output of the reference divider in the few hundred
kHz to several MHz range). If you need to go to a lower
phase comparator reference frequency (usually required
for increased frequency accuracy), that is acceptable, but
jitter performance will suffer somewhat.

VCO Gain Programming: Use the minimum gain which
can reliably achieve the VCO frequency desired, as shown
on the following page:

VRAM Shift Clock Control

BLANK

LOAD

LD/N2

Figure 5

ICS1562B

Figure 6

VCO GAIN

MAX FREQUENCY

120 MHz

200 MHz

260 MHz

*SPECIAL APPLICATION. Contact factory for custom product above

260 MHz.

Phase Detector Gain: For most graphics applications and
divider ranges, set P[1, 0] = 10 and set P[2] = 1. Under
some circumstances, setting the P[2] bit "on" can reduce
jitter. During 1562 operation at exact multiples of the
crystal frequency, P[2] bit = 0 may provide the best jitter
performance.

Board Test Support

It is often desirable to statically control the levels of the output
pins for circuit board test. The ICS1562B supports this through
a register programmable mode, AUXEN. When this mode is
set, two register bits directly control the logic levels of the
CLK+/CLK- pins and the LOAD pin. This mode is activated
when the S[0] and S[1] bits are both set to logic 1. See Register
Mapping for details.

Power Supplies and Decoupling

The ICS1562B has two VSS pins to reduce the effects of
package inductance. Both pins are connected to the same
potential on the die (the ground bus). BOTH of these pins
should connect to the ground plane of the video board as close
to the package as is possible.

The ICS1562B has a VDDO pin which is the supply of +5 volt
power to all output drivers. This pin should be connected to the
power plane (or bus) using standard high-frequency decou-
pling practice. That is, capacitors should have low series induc-
tance and be mounted close to the ICS1562B.

The VDD pin is the power supply pin for the PLL synthesizer
circuitry and other lower current digital functions. We recom-
mend that RC decoupling or zener regulation be provided for
this pin (as shown in the recommended application circuitry).
This will allow the PLL to "track" through power supply
fluctuations without visible effects. See Figure 6 for typical
external circuitry.

ICS1562B

Register Mapping - ICS1562B-001 (Parallel Programming Option)

NOTE: IT IS NOT NECESSARY TO UNDERSTAND THE FUNCTION OF THESE BITS TO USE THE ICS1562B. PC SOFTWARE IS AVAILABLE
FROM ICS TO AUTOMATICALLY GENERATE ALL REGISTER VALUES BASED ON REQUIREMENTS. CONTACT FACTORY FOR DETAILS.

REG#

BIT(S)

BIT REF.

DESCRIPTION

0-3

R[0]..R[3]

Reference divider modulus control bits

0-2

R[4]..R[6]

Modulus = value + 1

REFPOL

PLL locks to the rising edge of XTAL1 input when REFPOL=1 and
to the falling edge of XTAL1 when REFPOL=0.

0-3

A[0]..A[3]

Controls A counter. When set to zero, modulus=7. Otherwise,
modulus=7 for "value" underflows of the prescaler, and modulus=6
thereafter until M counter underflows.

0-3

M[0]..M[3]

M counter control bits

0-1

M[4]..M[5]

Modulus = value + 1

FBKPOL

External feedback polarity control bit. The PLL will lock to the falling

edge of EXTFBK when FBKPOL=1 and to the rising edge of
EXTFBK when FBKPOL=0.

DBLFREQ

Doubles modulus of dual-modulus prescaler (from 6/7 to 12/14).

0-3

N1[0]..N1[3]

Sets N1 modulus according to this table. These bits are set to imple-

ment a divide-by-four on power-up.

N1[3]

N1[2]

N1[1]

N1[0]

RATIO

X=Don't Care

ICS1562B

REG#

BIT(S)

BIT REF.

DESCRIPTION

0-3

N2[0]..N2[3]

Sets the modulus of the N2 divider.

0-3

N2[4]..N2[7]

The input of the N2 divider is the output of the N1 divider in all clock

modes except AUXEN.

N2[8]

0-2

V[0]..V[1]

Sets the gain of the VCO.

0-1

P[0]..P[1]

Sets the gain of the phase detector according to this table.

[P2]

Phase detector tuning bit. Normally should be set to one.

V[2]

V[1]

V[0]

VCO GAIN

(MHz/VOLT)

P[1]

P[0]

GAIN (uA/radian)

0.05

0.15

0.5

1.5

LOADEN~

Load clock divider enable (active low). When set to logic 1, the
LOAD and LD/N2 outputs will cease toggling.

SKEW-

Differential output duty factor adjust.

SKEW+

SKEW-

Default

Reduces T

HIGH

by approximately

100 ps

Increases T

HIGH

by approximately

100 ps

Do not use

ICS1562B

REG#

BIT(S)

BIT REF.

DESCRIPTION

0-1

S[0]..S[1]

PLL post-scaler/test mode select bits

S[1] S[0]

DESCRIPTION

Post-scaler=1. F(CLK)=F(PLL). The output of the N1 divider
drives the LOAD output which, in turn, drives the N2 divider.

Post-scaler=2. F(CLK)=F(PLL)/2. The output of the N1 divider
drives the LOAD output which, in turn, drives the N2 divider.

Post-scaler=4. F(CLK)=F(PLL)/4. The output of the N1 divider
drives the LOAD output which, in turn, drives the N2 divider.

AUXEN CLOCK MODE. The AUXCLK bit drives the differential
outputs CLK+ and CLK- and the AUXN1 bit drives the LOAD
output which, in turn, drives the N2 divider.

AUX_CLK

When in the AUXEN clock mode, this bit controls the differential
outputs.

AUX_N1

When in the AUXEN clock mode, this bit controls the LOAD output

(and consequently the N2 output according to its programming).
When not in the AUXEN clock mode, this bit, if set to one, will over-
ride the N1 divider modulus and output the VCO frequency divided
by two [F(PLL)/2] at the LOAD output.

RESERVED

Must be set to zero.

JAMPLL

Tristates phase detector outputs; resets phase detector logic, and

resets R, A, M, and N2 counters.

DACRST

Set to zero for normal operation. When set to one, the CLK+output

is kept high and the CLK- output is kept low. (All other device func-
tions are unaffected.) When returned to zero, the CLK+ and CLK-
outputs will resume toggling on a rising edge of the LD output
(+/- 1 CLK period). To initiate a RAMDAC reset sequence,
simply write a one to this register bit followed by a zero.

SELXTAL

When set to logic 1, passes the reference frequency to the post-scaler.

ALTLOOP

Controls substitution of N1 and N2 dividers into feedback loop of PLL.
When this bit is a logic 1, the N1 and N2 dividers are used.

PDRSTEN

Phase-detector reset enable control bit. When this bit is set, the AD3

pin becomes a transparent reset input to the phase detector.
See

"Internal Feedback Operation" section for more

details on the operation of this function.

ICS1562B

Register Mapping - ICS1562B-201 (Serial Programming Option)

BIT(S)

BIT REF.

DESCRIPTION

1-4

N1[0]..N1[3]

Sets N1 modulus according to this table. These bits are set to implement

a divide-by-four on power-up.

N1[3]

N1[2]

N1[1]

N1[0]

RATIO

RESERVED

Must be set to zero.

JAMPLL

Tristates phase detector outputs, resets phase detector logic, and resets
R, A, M, and N2 counters.

DACRST

Set to zero for normal operations. When set to one, the CLK+ output is

kept high and the CLK- output is kept low. (All other device functions are
unaffected.) When returned to zero, the CLK+ and CLK- outputs will
resume toggling on a rising edge of the LD output (+/

1 CLK period).

To initiate a RAMDAC reset sequence, simply write a one to this register
bit followed by a zero.

SELXTAL

When set to logic 1, passes the reference frequency to the post-scaler.

ALTLOOP

Controls substitution of N1 and N2 dividers into feedback loop of PLL.
When this bit is a logic 1, the N1 and N2 dividers are used.

SCEN

VRAM shift clock enable bit. When logic 1, the BLANK pin can be used
to disable the LD/N2 output.

EXTFBKEN

External PLL feedback select. When logic 1, the EXTFBK pin is used for
the phase-frequency detector feedback input.

PDRSTEN

Phase detector reset enable control bit. When this bit is set, a high level
on the BLANK input will disable PLL locking. See

"Internal Feedback

Operation" section for more details on the operation of this function.

ICS1562B

BIT(S)

BIT REF.

DESCRIPTION

13-14

S[0]..S[1]

PLL post-scaler/test mode select bits.

S[1] S[0]

DESCRIPTION

Post-scaler=1. F(CLK)=F(PLL). The output of the N1 divider
drives the LOAD output which, in turn, drives the N2 divider.

Post-scaler=2. F(CLK)=F(PLL)/2. The output of the N1 divider
drives the LOAD output which, in turn, drives the N2 divider.

Post-scaler=4. F(CLK)=F(PLL)/4. The output of the N1 divder
drives the LOAD output which, in turn, drives the N2 divider.

AUXEN CLOCK MODE. The AUXCLK bit drives the differential
outputs CLK+ and CLK- and the AUXN1 bit drives the LOAD
output which, in turn, drives the N2 divider.

AUX_CLK

When in the AUXEN clock mode, this bit controls the differential outputs.

AUX_N1

When in the AUXEN clock mode, this bit controls the N1 output (and

consequently the N2 output according to its programming). When not in
the AUXEN clock mode, this bit, if set to one, will override the N1 divider
modulus and output the VCO frequency divided by two [F(PLL)/2] at the
LOAD output.

17-24

N2[0]..N2[7]

Sets the modulus of the N2 divider. The input of the N2 divider is the

N2[8]

output of the N1 divider in all clock modes except AUXEN.

25-27

V[0]..V[2]

Sets the gain of VCO according to this table.

V[2]

V[1]

V[0]

VCO GAIN

(MHz/VOLT)

29-30

P[0]..P[1]

Sets the gain of the phase detector according to this table.

P[1]

P[0]

GAIN (uA/radian)

0.05

0.15

0.5

1.5

RESERVED

Set to zero.

P[2]

Phase detector tuning bit. Should normally be set to one.

ICS1562B

BIT(S)

BIT REF.

DESCRIPTION

33-38

M[0]..M[5]

M counter control bits
Modulus = value +1

FBKPOL

External feedback polarity control bit. The PLL will lock to the falling

edge of EXTFBK when FBKPOL=1 and to the rising edge of EXTFBK
when FBKPOL=0.

DBLFREQ

Doubles modulus of dual-modulus prescaler (from 6/7 to 12/14).

41-44

A[0]..A[3]

Controls A counter. When set to zero, modulus=7. Otherwise,
modulus=7 for "value" underflows of the prescaler, and modulus=6
thereafter until M counter underflows.

RESERVED

Set to zero.

LOADEN~

Load clock divider enable (active low). When set to logic 1, the LOAD
and LD/N2 outputs will cease toggling.

SKEW-

Differential output duty factor adjust.

SKEW+

49-55

R[0]..R[6]

Reference divider modulus control bits
Modulus = value + 1

REFPOL

PLL locks to the rising edge of XTAL1 input when REFPOL=1 and to
the falling edge of XTAL1 when REFPOL=0.

SKEW+

SKEW-

Default

Reduces T

HIGH

by approximately

100 ps

Increases T

HIGH

by approximately

100 ps

Do not use

ICS1562B

Table 1 - "A" & "M" Divider Programming

Feedback Divider Modulus Table

A[2]..A[0]-

001

010

011

100

101

110

111

000

M[5]..M[0]

000000

000001

000010

000011

000100

000101

000110

000111

001000

001001

001010

001011

001100

001101

001110

105

001111

100

101

102

103

112

010000

103

104

105

106

107

108

109

119

010001

109

110

111

112

113

114

115

126

010010

115

116

117

118

119

120

121

133

010011

121

122

123

124

125

126

127

140

010100

127

128

129

130

131

132

133

147

010101

133

134

135

136

137

138

139

154

010110

139

140

141

142

143

144

145

161

010111

145

146

147

148

149

150

151

168

011000

151

152

153

154

155

156

157

175

011001

157

158

159

160

161

162

163

182

011010

163

164

165

166

167

168

169

189

011011

169

170

171

172

173

174

175

196

011100

175

176

177

178

179

180

181

203

011101

181

182

183

184

185

186

187

210

011110

187

188

189

190

191

192

193

217

011111

193

194

195

196

197

198

199

224

A[2]..A[0]-

001

010

011

100

101

110

111

000

M[5]..M[0]

100000

199

200

201

202

203

204

205

231

100001

205

206

207

208

209

210

211

238

100010

211

212

213

214

215

216

217

245

100011

217

218

219

220

221

222

223

252

100100

223

224

225

226

227

228

229

259

100101

229

230

231

232

233

234

235

266

100110

235

236

237

238

239

240

241

273

100111

241

242

243

244

245

246

247

280

101000

247

248

249

250

251

252

253

287

101001

253

254

255

256

257

258

259

294

101010

259

260

261

262

263

264

265

301

101011

265

266

267

268

269

270

271

308

101100

271

272

273

274

275

276

277

315

101101

277

278

279

280

281

282

283

322

101110

283

284

285

286

287

288

289

329

101111

289

290

291

292

293

294

295

336

110000

295

296

297

298

299

300

301

343

110001

301

302

303

304

305

306

307

350

110010

307

308

309

310

311

312

313

357

110011

313

314

315

316

317

318

319

364

110100

319

320

321

322

323

324

325

371

110101

325

326

327

328

329

330

331

378

110110

331

332

333

334

335

336

337

385

110111

337

338

339

340

341

342

343

392

111000

343

344

345

346

347

348

349

399

111001

349

350

351

352

353

354

355

406

111010

355

356

357

358

359

360

361

413

111011

361

362

363

364

365

366

367

420

111100

367

368

369

370

371

372

373

427

111101

373

374

375

376

377

378

379

434

111110

379

380

381

382

383

384

385

441

111111

385

386

387

388

389

390

391

448

Notes:

To use this table, find the desired modulus in the table. Follow the column up to find the A divider programming values.
Follow the row to the left to find the M divider programming. Some feedback divisors can be achieved with two or three
combinations of divider settings. Any are acceptable for use.

The formula for the effective feedback modulus is:

N =[(M +1) . 6] +A

except when A=0, then:

N=(M +1) . 7

Under all circumstances:

ICS1562B

Pin Descriptions - ICS1562B-001

PIN#

NAME

DESCRIPTION

CLK+

Clock out (non-inverted)

CLK

Clock out (inverted)

LOAD

Load output. This output is normally at the CLK frequency divided by N1.

XTAL1

Quartz crystal connection 1/external reference frequency input

XTAL2

Quartz crystal connection 2

AD0

Address/Data Bit 0 (LSB)

AD1

Address/Data Bit 1

AD2

Address/Data Bit 2

AD3

Address/Data Bit 3 (MSB)

LD/N2

Divided LOAD output. See text.

STROBE

Control for address/data latch

VDD

PLL system power (+5V. See application diagram.)

VDDO

Output stage power (+5V)

IPRG

Output stage current set

5,6

VSS

Device ground. Both pins must be connected to the same ground potential.

Pin Descriptions - ICS1562B-201

PIN#

NAME

DESCRIPTION

CLK+

Clock out (non-inverted)

CLK

Clock out (inverted)

LOAD

Load output. This output is normally at the CLK frequency divided by N1.

XTAL1

Quartz crystal connection 1/external reference frequency input

XTAL2

Quartz crystal connection 2

DATCLK

Data Clock (Input)

DATA

Serial Register Data (Input)

HOLD~

HOLD (Input)

BLANK

Blanking (Input). See Text.

LD/N2

Divided LOAD output/shift clock. See text.

EXTFBK

External feedback connection for PLL (input). See text.

VDD

PLL system power (+5V. See application diagram.)

VDDO

Output stage power (+5V)

IPRG

Output stage current set

5,6

VSS

Device ground. Both pins must be connected.

ICS1562B

Absolute Maximum Ratings

VDD, VDDO (measured to V

). . . . . . . . . . . . . . . . . . . . . . . 7.0 V

Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

-0.5 to V

+ 0.5 V

Digital Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V

-0.5 to V

DDO

+ 0.5 V

Ambient Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . -55 to 125

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -65 to 150

Junction Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Soldering Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

Recommended Operating Conditions

VDD, VDDO (measured to V

). . . . . . . . . . . . . . . . . . . . . . . 4.75 to 5.25 V

Operating Temperature (Ambient) . . . . . . . . . . . . . . . . . . . . . 0 to 70

DC Characteristics

TTL-Compatible Inputs
001 Option - (AD0-AD3, STROBE),
201 Option - (DATCLK, DATA, HOLD, BLANK, EXTFBK)

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNITS

Input High Voltage

2.0

+0.5

Input Low Voltage

-0.5

0.8

Input High Current

=VDD

Input Low Current

=0.0

200

Input Capacitance

Hysteresis (STROBE/DATCLK)

hys

=5V

.20

.60

XTAL1 Input

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNITS

Input High Voltage

3.75

+0.5

Input Low Voltage

-0.5

1.25

CLK+, CLK- Outputs

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNITS

Differential Output Voltage

0.6

LOAD, LD/N2 Outputs

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNITS

Output High Voltage (Ioh = 4.0mA)

2.4

Output Low Voltage (Iol = 8.0mA)

0.4

ICS1562B

AC Characteristics

SYMBOL

PARAMETER

MIN

TYP

MAX

UNITS

vco

VCO Frequency (see Note 1)

260

MHz

xtal

Crystal Frequency

MHz

Cpar

Crystal Oscillator Loading Capacitance

load

LOAD Frequency

MHz

xhi

XTAL1 High Time (when driven externally)

xlo

XTAL1 Low Time (when driven externally)

lock

PLL Acquire Time (to within 1%)

500

VDD Supply Current

t.b.d.

ddo

VDDO Supply Current (excluding CLK+/

termination)

t.b.d.

high

Differential Clock Output Duty Cycle
(see Note 2)

clk

Differential Clock Output Cumulative Jitter
(see Note 3)

<0.06

pixel

DIGITAL INPUTS - ICS1562B-001

Address Setup Time

Address Hold Time

Data Setup Time

Data Hold Time

STROBE Pulse Width (T

or T

)

DIGITAL INPUTS - ICS1562B-201

DATA/HOLD~ Setup Time

DATA/HOLD~ Hold Time

DATCLK Pulse Width (T

or T

)

PIPELINE DELAY RESET

Reset Activation Time

2*Tclk

Reset Duration

4*Tload

Restart Delay

2*Tload

Restart Matching

-1*Tclk

+1.5*Tclk

DIGITAL OUTPUTS

CLK+/CLK

Clock Rate

260

MHz

LOAD To LD/N2 Skew (Shift Clock Mode)

-2

Note 1: Use of the post-divider is required for frequencies lower than 40 MHz on CLK+ & CLK- outputs. Use of the post-divider

is recommended for output frequencies lower than 65 MHz.

Note 2: Using load circuit of Figure 6. Duty cycle measured at zero crossings of difference voltage between CLK+ and CLK-.
Note 3: Cumulative jitter is defined as the maximum error (in the domain) if any CLK edge, at any point in time, compared with

the equivalent edge generated by an ideal frequency source.
ICS laboratory testing indicates that the typical value shown above can be treated as a maximum jitter specification in
virtually all applications. Jitter performance can depend somewhat on circuit board layout, decoupling, and register
programming.

ICS1562B

ICS1562B Application Information

Output Circuit Considerations for the ICS1562B

Output Circuitry

The dot clock signals CLK and CLK- are typically the highest
frequency signals present in the workstation. To minimize
problems with EMI, crosstalk, and capacitive loading extra
care should be taken in laying out this area of the PC board.
The ICS1562B is packaged in a 0.2"-wide 16-pin SOIC pack-
age. This permits the clock generator, crystal, and related
components to be laid out in an area the size of a postage stamp.
The ICS1562B should be placed as close as possible to the
RAMDAC. The CLK and CLK- pins are running at VHF
frequencies; one should minimize the length of PCB trace
connecting them to the RAMDAC so that they don't become
radiators of RF energy.

At the frequencies that the ICS1562B is capable of, PC board
traces may be long enough to be a significant portion of a
wavelength of that frequency. PC traces for CLK and CLK-
should be treated as transmission lines, not just interconnecting
wires. These lines can take two forms: microstrip and stripline.
A microstrip line is shown below:

Essentially, the microstrip is a copper trace on a PCB over a
ground plane. Typically, the dielectric is G10 glass epoxy. It
differs from a standard PCB trace in that its width is calculated
to have a characteristic impedance. To calculate the charac-
teristic impedance of a microstrip line one must know the width
and thickness of the trace, and the thickness and dielectric
constant of the dielectric. For G10 glass epoxy, the dielectric
constant (e

) is about 5. Propagation delay is strictly a function

of dielectric constant. For G10 propagation, delay is calculated
to be 1.77 ns/ft.

Stripline is the other form a PCB transmission line can take. A
buried trace between ground planes (or between a power plane
and a ground plane) is common in multi-layer boards.
Attempting to create a workstation design without the use of
multi-layer boards would be adventurous to say the least, the
issue would more likely be whether to place the interconnect
on the surface or between layers. The between layer approach
would work better from an EMI standpoint, but would be more
difficult to lay out. A stripline is shown below:

Using 1 oz. copper (0.0015" thick) and 0.040" thickness G10,
a 0.010" trace will exhibit a characteristic impedance of 75

in a stripline configuration.

Typically, RAMDACs require a V

of V

-1.0 Volts as a

guaranteed logical "1" and a V

of V

-1.6 as a guaranteed

logical "0." Worst case input capacitance is 10 pF.

Output circuitry for the ICS1562B is shown in the following
diagram. It consists of a 4/1 current mirror, and two open drain
output FETs along with inverting buffers to alternately enable
each current-sinking driver. Both CLK and CLK- outputs are
connected to the respective CLOCK and CLOCK inputs of the
RAMDAC with transmission lines and terminated in their
equivalent impedances by the Thevenin equivalent impedances
of R1 and R2 or R1' and R2'.

The ICS1562B is incapable of sourcing current, so V

must

be set by the ratios of these resistors for each of these lines. R1
and R2 are electrically in parallel from an AC standpoint
because V

is bypassed to ground through bypass-capacitor

network C

. If we picked a target impedance of 75

for our

transmission line impedance, a value of 91

for R1 and R1'

and a value of 430

for R2 and R2' would yield a Thevinin

equivalent characteristic impedance of 75.1

and a V

value

of V

-.873 Volts, a margin of 0.127 Volts. This may be

adequate; however, at higher frequencies one must contend
with the 10 pF input capacitance of the RAMDAC. Values of
82

for R1 and R1' and 820

for R2 and R2' would give us a

characteristic impedance of 74.5

and a V

value of V

-.45.

With a .55 Volt margin on V

, this voltage level might be safer.

To set a value for V

, we must determine a value for I

prg

that

will cause the output FET's to sink an appropriate current. We
desire V

to be V

-1.6 or greater. V

-2 would seem to be a

safe value. Setting up a sink current of 25 milliamperes would
guarantee this through our 82

pull-up resistors. As this is

controlled by a 4/1 current mirror, 7 mA into I

prg

should set this

current properly. A 510

resistor from V

to I

prg

should work

fine.

Resistors Rt and Rt' are shown as series terminating resistors
at the ICS1562B end of the transmission lines. These are not
required for operation, but may be useful for meeting EMI
requirements. Their intent is to interact with the input capaci-
tance of the RAMDAC and the distributed capacitance of the
transmission line to soften up rise and fall times and conse-
quently cut some of the high-order harmonic content that is
more likely to radiate RF energy. In actual usage they would
most likely be 10 to 20

resistors or possibly ferrite beads.

is shown as multiple capacitors. Typically, a 22

f tantalum

should be used with separate .1

F and 220pf capacitors placed

as close to the pins as possible. This provides low series
inductance capacitors right at the source of high frequency
energy. R

is used to isolate the circuitry from external

sources of noise. Five to ten ohms should be adequate.

Great care must be used when evaluating high frequency
circuits to achieve meaningful results. The 10 pF input capaci-
tance and long ground lead of an ordinary scope probe will
make any measurements made with it meaningless. A low
capacitance FET probe with a ground connection directly
connected to the shield at the tip will be required. A 1GHz
bandwidth scope will be barely adequate, try to find a faster
unit.

ICS1562B Output Circuitry

ICS1562B Application Information

Ð­Ð»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: ICS1562B

ÐÐ»ÐµÐºÑ‚Ñ€Ð¾Ð½Ð½Ñ‹Ð¹ ÐºÐ¾Ð¼Ð¿Ð¾Ð½ÐµÐ½Ñ‚: ICS1562B
