FEBRUARY 2003

DSC-4680/7

3.3 VOLT HIGH-DENSITY SUPERSYNC IITM 72-BIT FIFO
512 x 72, 1,024 x 72
2,048 x 72, 4,096 x 72
8,192 x 72, 16,384 x 72
32,768 x 72, 65,536 x 72

IDT72V7230, IDT72V7240
IDT72V7250, IDT72V7260
IDT72V7270, IDT72V7280

IDT72V7290, IDT72V72100

IDT and the IDT logo are registered trademarks of Integrated Device Technology, Inc. SuperSync II FIFO is a trademark of Integrated Device Technology, Inc.

COMMERCIAL TEMPERATURE RANGE

FEATURES:

·
·
·
·
·

Choose among the following memory organizations:

IDT72V7230

512 x 72

IDT72V7240

1,024 x 72

IDT72V7250

2,048 x 72

IDT72V7260

4,096 x 72

IDT72V7270

8,192 x 72

IDT72V7280

16,384 x 72

IDT72V7290

32,768 x 72

IDT72V72100

65,536 x 72

·
·
·
·
·

100 MHz operation (10 ns read/write cycle time)

·
·
·
·
·

User selectable input and output port bus-sizing
- x72 in to x72 out
- x72 in to x36 out
- x72 in to x18 out
- x36 in to x72 out
- x18 in to x72 out

·
·
·
·
·

Big-Endian/Little-Endian user selectable word representation

·
·
·
·
·

Fixed, low first word latency

·
·
·
·
·

Zero latency retransmit

·
·
·
·
·

Auto power down minimizes standby power consumption

·
·
·
·
·

Master Reset clears entire FIFO

·
·
·
·
·

Partial Reset clears data, but retains programmable settings

·
·
·
·
·

Empty, Full and Half-Full flags signal FIFO status

·
·
·
·
·

Programmable Almost-Empty and Almost-Full flags, each flag can
default to one of eight preselected offsets

·
·
·
·
·

Selectable synchronous/asynchronous timing modes for Almost-
Empty and Almost-Full flags

·
·
·
·
·

Program programmable flags by either serial or parallel means

·
·
·
·
·

Select IDT Standard timing (using

EF and FF flags) or First Word

Fall Through timing (using

OR and IR flags)

·
·
·
·
·

Output enable puts data outputs into high impedance state

·
·
·
·
·

Easily expandable in depth and width

·
·
·
·
·

Independent Read and Write Clocks (permit reading and writing
simultaneously)

·
·
·
·
·

Asynchronous operation of Output Enable,

·
·
·
·
·

Read Chip Select (

RCS ) on Read Side

·
·
·
·
·

Available in a 256-pin Fine Pitch Ball Grid Array package (PBGA)

·
·
·
·
·

Features JTAG (Boundary Scan)

·
·
·
·
·

High-performance submicron CMOS technology

·
·
·
·
·

Industrial temperature range (40

°°
°°
°C to +85°°°°°C) is available

FUNCTIONAL BLOCK DIAGRAM

INPUT REGISTER

OUTPUT REGISTER

RAM ARRAY

512 x 72
1,024 x 72
2,048 x 72
4,096 x 72
8,192 x 72

16,384 x 72
32,768 x 72
65,536 x 72

FLAG

LOGIC

FF/IR

PAF

EF/OR

PAE

READ POINTER

READ

CONTROL

LOGIC

WRITE CONTROL

LOGIC

RESET

LOGIC

WEN

WCLK

-D

(x72, x36 or x18)

MRS

REN

RCLK

-Q

(x72, x36 or x18)

OFFSET REGISTER

FWFT/SI

SEN

4680 drw01

BUS

CONFIGURATION

CONTROL

LOGIC

PFM

FSEL0
FSEL1

SCLK

PRS

JTAG

CONTROL

(BOUNDARY SCAN)

TCK

TMS

TRST

TDO

TDI

RCS

WRITE POINTER

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

PIN CONFIGURATION

PBGA (BB256-1, order code: BB)

TOP VIEW

DESCRIPTION:

The IDT72V7230/72V7240/72V7250/72V7260/72V7270/72V7280/

72V7290/72V72100 are exceptionally deep, high speed, CMOS First-In-First-
Out (FIFO) memories with clocked read and write controls and a flexible Bus-
Matching x72/x36/x18 data flow. These FIFOs offer several key user benefits:
· Flexible x72/x36/x18 Bus-Matching on both read and write ports
· The period required by the retransmit operation is fixed and short.
· The first word data latency period, from the time the first word is written to an

empty FIFO to the time it can be read, is fixed and short.

· High density offerings up to 4 Mbit

Bus-Matching Sync FIFOs are particularly appropriate for network, video,

telecommunications, data communications and other applications that need to
buffer large amounts of data and match busses of unequal sizes.

Each FIFO has a data input port (D

) and a data output port (Q

), both of

which can assume either a 72-bit, 36-bit or a 18-bit width as determined by the
state of external control pins Input Width (IW), Output Width (OW), and Bus-
Matching (BM) pin during the Master Reset cycle.

The input port is controlled by a Write Clock (WCLK) input and a Write Enable

(

WEN) input. Data is written into the FIFO on every rising edge of WCLK when

WEN is asserted. The output port is controlled by a Read Clock (RCLK) input

Q33

Q32

Q31

Q29

Q17

Q14

Q11

Q62

Q59

Q56

Q44

Q41

Q38

Q26

Q24

Q23

Q35

Q34

Q30

Q28

Q16

Q13

Q10

Q61

Q58

Q55

Q43

Q40

Q37

Q25

Q21

Q22

Q47

Q46

Q45

Q27

Q15

Q12

Q60

Q57

Q54

Q42

Q39

Q36

Q18

Q19

Q20

Q50

Q49

Q48

SEN

D51

D52

D53

GND

D63

D64

D65

D66

D67

D68

GND

PRS

WEN

REN

D69

D70

D71

TDI

RCS

Q69

Q70

Q71

TCK

PAE

RCLK

Q66

Q67

Q68

GND

VCC

WCLK

PAF

D47

D46

D45

VCC

MRS

GND

VCC

D50

D49

D48

VCC

Q63

Q64

Q65

D27

D15

D12

D60

D57

D54

D42

D39

D36

D18

D19

D20

Q51

Q52

Q53

D28

D16

D13

D10

D61

D58

D55

D43

D40

D37

D25

D21

D22

D33

D32

D31

D29

D17

D14

D11

D62

D59

D56

D44

D41

D38

D26

D24

D23

A1 BALL PAD CORNER

GND

VCC

TRST

VCC

FS0

TDO

GND

TMS

VCC

GND

VCC

GND

VCC

GND

FS1

GND

VCC

GND

PFM

VCC

FWFT/
SI

GND

4680 drw02

GND SCLK

D35

D34

D30

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

DESCRIPTION (CONTINUED)

Figure 1. Single Device Configuration Signal Flow Diagram

and Read Enable (

REN) input. Data is read from the FIFO on every rising edge

of RCLK when

REN is asserted. An Output Enable (OE) input is provided for

three-state control of the outputs.

A Read Chip Select (

RCS) input is also provided for synchronous enable

and disable of the read port control input,

REN. The RCS input is synchronized

to the read clock, and also provides three-state control of the Q

outputs. When

RCS is disable, REN will be disabled internally and data outputs will be in
High-Impedance state.

The frequencies of both the RCLK and the WCLK signals may vary from 0

to f

MAX

with complete independence. There are no restrictions on the frequency

of the one clock input with respect to the other.

There are two possible timing modes of operation with these devices: IDT

Standard mode and First Word Fall Through (FWFT) mode.

In IDT Standard mode, the first word written to an empty FIFO will not appear

on the data output lines unless a specific read operation is performed. A read
operation, which consists of activating

REN and enabling a rising RCLK edge,

will shift the word from internal memory to the data output lines.

In FWFT mode, the first word written to an empty FIFO is clocked directly

to the data output lines after three transitions of the RCLK signal. A

REN does

not have to be asserted for accessing the first word. However, subsequent
words written to the FIFO do require a LOW on

REN for access. The state of

the FWFT/SI input during Master Reset determines the timing mode in use.

For applications requiring more data storage capacity than a single FIFO

can provide, the FWFT timing mode permits depth expansion by chaining FIFOs
in series (i.e. the data outputs of one FIFO are connected to the corresponding
data inputs of the next). No external logic is required.

These FIFOs have five flag pins,

EF/OR (Empty Flag or Output Ready),

FF/IR (Full Flag or Input Ready), HF (Half-full Flag), PAE (Programmable
Almost-Empty flag) and

PAF (Programmable Almost-Full flag). The EF and FF

functions are selected in IDT Standard mode. The

IR and OR functions are

selected in FWFT mode.

HF, PAE and PAF are always available for use,

irrespective of timing mode.

PAE and PAF can be programmed independently to switch at any point in

memory. Programmable offsets determine the flag switching threshold and can
be loaded by two methods: parallel or serial. Eight default offset settings are also
provided, so that

PAE can be set to switch at a predefined number of locations

from the empty boundary and the

PAF threshold can also be set at similar

predefined values from the full boundary. The default offset values are set during
Master Reset by the state of the FSEL0, FSEL1, and

LD pins.

For serial programming,

SEN together with LD on each rising edge of

SCLK, are used to load the offset registers via the Serial Input (SI). For parallel
programming,

WEN together with LD on each rising edge of WCLK, are used

to load the offset registers via D

REN together with LD on each rising edge

of RCLK can be used to read the offsets in parallel from Q

regardless of whether

serial or parallel offset loading has been selected.

(x72, x36, x18) DATA OUT (Q

- Q

)

(x72, x36, x18) DATA IN (D

- D

)

MASTER RESET (

MRS)

READ CLOCK (RCLK)
READ ENABLE (

REN)

OUTPUT ENABLE (

OE)

EMPTY FLAG/OUTPUT READY (

EF/OR)

PROGRAMMABLE ALMOST-EMPTY (

PAE)

WRITE CLOCK (WCLK)

WRITE ENABLE (

WEN)

LOAD (

LD)

FULL FLAG/INPUT READY (

FF/IR)

PROGRAMMABLE ALMOST-FULL (

PAF)

IDT

72V7230
72V7240
72V7250
72V7260
72V7270
72V7280
72V7290

72V72100

PARTIAL RESET (

PRS)

FIRST WORD FALL THROUGH/SERIAL INPUT

(FWFT/SI)

RETRANSMIT (

RT)

4680 drw03

HALF-FULL FLAG (

HF)

SERIAL ENABLE(

SEN)

INPUT WIDTH (IW)

OUTPUT WIDTH (OW)

BIG-ENDIAN/LITTLE-ENDIAN (

BE)

INTERSPERSED/

NON-INTERSPERSED PARITY (IP)

BUS-

MATCHING

(BM)

SERIAL IN CLOCK(SCLK)

JTAG CLOCK (TCLK)

JTAG RESET (

TRST)

JTAG MODE (TMS)

(TDO)

(TDI)

READ CHIP SELECT (

RCS)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

Write Port Width

Read Port Width

x72

x36

x72

x18

x72

x36

x72

x18

TABLE 1 -- BUS-MATCHING CONFIGURATION MODES

During Master Reset (

MRS) the following events occur: the read and write

pointers are set to the first location of the FIFO. The FWFT pin selects IDT
Standard mode or FWFT mode.

The Partial Reset (

PRS) also sets the read and write pointers to the first

location of the memory. However, the timing mode, programmable flag
programming method, and default or programmed offset settings existing before
Partial Reset remain unchanged. The flags are updated according to the timing
mode and offsets in effect.

PRS is useful for resetting a device in mid-operation,

when reprogramming programmable flags would be undesirable.

It is also possible to select the timing mode of the

PAE (Programmable Almost-

Empty flag) and

PAF (Programmable Almost-Full flag) outputs. The timing

modes can be set to be either asynchronous or synchronous for the

PAE and

PAF flags.

If asynchronous

PAE/PAF configuration is selected, the PAE is asserted

LOW on the LOW-to-HIGH transition of RCLK.

PAE is reset to HIGH on the LOW-

to-HIGH transition of WCLK. Similarly, the

PAF is asserted LOW on the LOW-

to-HIGH transition of WCLK and

PAF is reset to HIGH on the LOW-to-HIGH

transition of RCLK.

If synchronous

PAE/PAF configuration is selected , the PAE is asserted and

updated on the rising edge of RCLK only and not WCLK. Similarly,

PAF is

asserted and updated on the rising edge of WCLK only and not RCLK. The
mode desired is configured during master reset by the state of the Programmable
Flag Mode (PFM) pin.

The Retransmit function allows data to be reread from the FIFO more than

once. A LOW on the

RT input during a rising RCLK edge initiates a retransmit

operation by setting the read pointer to the first location of the memory array.
A zero-latency retransmit timing mode can be selected using the Retransmit
timing Mode pin (RM). During Master Reset, a LOW on RM will select zero
latency retransmit. A HIGH on RM during Master Reset will select normal
latency.

If zero latency retransmit operation is selected, the first data word to be

retransmitted will be placed on the output register with respect to the same RCLK
edge that initiated the retransmit based on RT being LOW.

Refer to Figure 16 and 17 for Retransmit Timing with normal latency. Refer

to Figure 18 and 19 for Zero Latency Retransmit Timing.

The device can be configured with different input and output bus widths as

shown in Table 1.

A Big-Endian/Little-Endian data word format is provided. This function is

useful when the FIFO is used in Bus-Matching mode, to determine order of the
words. As an example, if Big-Endian mode is selected, then the most significant
word of the long word written into the FIFO will be read out of the FIFO first,
followed by the least significant word. If Little-Endian format is selected, then the
least significant word of the long word written into the FIFO will be read out first,
followed by the most significant word. The mode desired is configured during
master reset by the state of the Big-Endian (

BE) pin.

The Interspersed/Non-Interspersed Parity (IP) bit function allows the user

to select the parity bit in the word loaded into the parallel port (D0-Dn) when
programming the flag offsets. If Interspersed Parity mode is selected, then the
FIFO will assume that the parity bit is located in bit position D8 during the parallel
programming of the flag offsets. If Non-Interspersed Parity mode is selected,
then D8 is assumed to be a valid bit and D16 and D17 are ignored. IP mode
is selected during Master Reset by the state of the IP input pin.

If, at any time, the FIFO is not actively performing an operation, the chip will

automatically power down. Once in the power down state, the standby supply
current consumption is minimized. Initiating any operation (by activating control
inputs) will immediately take the device out of the power down state.

Both an Asynchronous Output Enable pin (

OE) and Synchronous Read

Chip Select pin (

RCS) are provided on the FIFO. The Synchronous Read

Chip Select is synchronized to the RCLK. Both the output enable and read chip
select control the output buffer of the FIFO, causing the buffer to be either HIGH
impedance or LOW impedance.

JTAG test pins are also provided, the FIFO has fully functional Boundary

Scan feature, compliant with IEEE 1149.1 Standard Test Access Port and
Boundary Scan Architecture.

The IDT72V7230/72V7240/72V7250/72V7260/72V7270/72V7280/

72V7290/72V72100 are fabricated using IDT's high speed submicron CMOS
technology.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

PIN DESCRIPTION

Symbol

Name

I/O

Description

Data Inputs

Data inputs for a 72-, 36- or 18-bit bus. When in 36- or 18-bit mode, the unused input pins should be tied
LOW.

MRS

Master Reset

MRS initializes the read and write pointers to zero and sets the output register to all zeroes. During Master Reset,
the FIFO is configured for either FWFT or IDT Standard mode, Bus-Matching configurations, one of eight
programmable flag default settings, serial or parallel programming of the offset settings, Big-Endian/Little-Endian
format, zero latency timing mode, interspersed parity, and synchronous versus asynchronous programmable
flag timing modes.

PRS

Partial Reset

PRS initializes the read and write pointers to zero and sets the output register to all zeroes. During Partial Reset,
the existing mode (IDT or FWFT), programming method (serial or parallel), and programmable flag settings
are all retained.

Retransmit

RT asserted on the rising edge of RCLK initializes the READ pointer to zero, sets the EF flag to LOW (OR to
HIGH in FWFT mode) and does not disturb the write pointer, programming method, existing timing mode or
programmable flag settings.

RT is useful to reread data from the first physical location of the FIFO.

FWFT/SI

First Word Fall

During Master Reset, selects First Word Fall Through or IDT Standard mode. After Master Reset, this pin functions

Through/Serial In

as a serial input for loading offset registers.

Output Width

This pin, along with IW and BM, selects the bus width of the read port. See Table 1 for bus size configuration.

Input Width

This pin, along with OW and BM, selects the bus width of the write port. See Table 1 for bus size configuration.

Bus-Matching

BM works with IW and OW to select the bus sizes for both write and read ports. See Table 1 for bus size
configuration.

Big-Endian/

During Master Reset, a LOW on

BE will select Big-Endian operation. A HIGH on BE during Master Reset

Little-Endian

will select Little-Endian format.

Retransmit Timing

During Master Reset, a LOW on RM will select zero latency Retransmit timing Mode. A HIGH on RM will select

Mode

normal latency mode.

PFM

Programmable

During Master Reset, a LOW on PFM will select Asynchronous Programmable flag timing mode. A HIGH on

Flag Mode

PFM will select Synchronous Programmable flag timing mode.

Interspersed Parity

During Master Reset, a LOW on IP will select Non-Interspersed Parity mode. A HIGH will select Interspersed
Parity mode.

FSEL0

Flag Select Bit 0

During Master Reset, this input along with FSEL1 and the

LD pin, will select the default offset values for the

programmable flags

PAE and PAF. There are up to eight possible settings available.

FSEL1

Flag Select Bit 1

During Master Reset, this input along with FSEL0 and the

LD pin will select the default offset values for the

programmable flags

PAE and PAF. There are up to eight possible settings available.

WCLK

Write Clock

When enabled by

WEN, the rising edge of WCLK writes data into the FIFO and offsets into the programmable

registers for parallel programming.

WEN

Write Enable

WEN enables WCLK for writing data into the FIFO memory and offset registers.

RCLK

Read Clock

When enabled by

REN, the rising edge of RCLK reads data from the FIFO memory and offsets from the

programmable registers. (

RCS must be active).

REN

Read Enable

REN enables RCLK for reading data from the FIFO memory and offset registers. (RCS must be active).

Output Enable

OE provides asynchronous control of the output impedance of Q

During a Master or Partial Reset the

input is the only input that provide High-Impedance control of the data outputs.

RCS

Read Chip Select

RCS provides synchronous control of the read port and output impedance of Q

synchronous

RCLK

During

a Master or Partial Reset the

RCS input is don't care, if OE is LOW the data outputs will be Low-Impedance

regardless of

RCS.

SCLK

Serial Input Clock

when enabled by

SEN, the rising edge of SCLK writes one bit of data (present on the SI input), into the

programmable register for serial programming.

SEN

Serial Enable

SEN enables serial loading of programmable flag offsets.

Load

This is a dual purpose pin. During Master Reset, the state of the

LD input along with FSEL0 and FSEL1,

determines one of eight default offset values for the

PAE and PAF flags, along with the method by which these

offset registers can be programmed, parallel or serial (see Table 2). After Master Reset, this pin enables writing
to and reading from the offset registers.

FF/IR

Full Flag/

In the IDT Standard mode, the

FF function is selected. FF indicates whether or not the FIFO memory is full.

Input Ready

In the FWFT mode, the

IR function is selected. IR indicates whether or not there is space available for writing

to the FIFO memory.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

Symbol

Name

I/O

Description

PIN DESCRIPTION (CONTINUED)

EF/OR

Empty Flag/

In the IDT Standard mode, the

EF function is selected. EF indicates whether or not the FIFO memory is empty.

Output Ready

In FWFT mode, the

OR function is selected. OR indicates whether or not there is valid data available at the outputs.

PAF

Programmable

PAF goes HIGH if the number of free locations in the FIFO memory is more than offset m, which is stored in

Almost-Full Flag

the Full Offset register.

PAF goes LOW if the number of free locations in the FIFO memory is less than or

equal to m.

PAE

Programmable

PAE goes LOW if the number of words in the FIFO memory is less than offset n, which is stored in the Empty

Almost-Empty

Offset register.

PAE goes HIGH if the number of Flag words in the FIFO memory is greater than or equal to

offset n.

Half-Full Flag

HF indicates whether the FIFO memory is more or less than half-full.

Data Outputs

Data outputs for an 72-, 36- or 18-bit bus. When in 36- or 18-bit mode, the unused output pins should not
be connected. Data Outputs are not 5V tolerant regardless of the state of the

OE and RCS.

TCK

(1)

JTAG Clock

Clock input for JTAG function. One of four terminals required by IEEE Standard 1149.1-1990. Test operations
of the device are synchronous to TCK. Data from TMS and TDI are sampled on the rising edge of TCK and
outputs change on the falling edge of TCK. If the JTAG function is not used this signal needs to be tied to GND.

TDI

(1)

JTAG Test Data Input

One of four terminals required by IEEE Standard 1149.1-1990. During the JTAG boundary scan operation,
test data serially loaded via the TDI on the rising edge of TCK to either the Instruction Register, ID Register
and Bypass Register. An internal pull-up resistor forces TDI HIGH if left unconnected.

TDO

(1)

JTAG Test Data Output

One of four terminals required by IEEE Standard 1149.1-1990. During the JTAG boundary scan operation,

test data serially loaded output via the TDO on the falling edge of TCK from either the Instruction Register, ID
Register and Bypass Register. This output is high impedance except when shifting, while in SHIFT-DR and
SHIFT-IR controller states.

TMS

(1)

JTAG Mode Select

TMS is a serial input pin. One of four terminals required by IEEE Standard 1149.1-1990. TMS directs the

the device through its TAP controller states. An internal pull-up resistor forces TMS HIGH if left unconnected.

TRST

(1)

JTAG Reset

TRST is an asynchronous reset pin for the JTAG controller. The JTAG TAP controller does not automatically
reset upon power-up, thus it must be reset by either this signal or by setting TMS= HIGH for five TCK cycles.
If the TAP controller is not properly reset then the FIFO outputs will always be in high-impedance. If the JTAG
function is used but the user does not want to use

TRST, then TRST can be tied with MRS to ensure proper

FIFO operation. If the JTAG function is not used then this signal needs to be tied to GND.

NOTE:

1. These pins are for the JTAG port. Please refer to pages 22-25 and Figures 5-7.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

ABSOLUTE MAXIMUM RATINGS

Symbol

Rating

Commercial

Unit

TERM

Terminal Voltage

0.5 to +4.5

with respect to GND

STG

Storage

55 to +125

Temperature

OUT

DC Output Current

50 to +50 mA

NOTE:

1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause

permanent damage to the device. This is a stress rating only and functional operation
of the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect reliability.

NOTES:
1. With output deselected, (

2. Characterized values, not currently tested.

DC ELECTRICAL CHARACTERISTICS

(Commercial: V

= 3.3V ± 0.15V, T

= 0

°C to +70°C; JEDEC JESD8-A compliant)

CAPACITANCE

= +25

°C, f = 1.0MHz)

Symbol

Parameter

(1)

Conditions

Max.

Unit

(2)

Input

= 0V

Capacitance

OUT

(1,2)

Output

OUT

= 0V

Capacitance

RECOMMENDED DC OPERATING
CONDITIONS

Symbol

Parameter

Min.

Typ.

Max.

Unit

Supply Voltage

3.15

3.3

3.45

GND

Supply Voltage

Input High Voltage

2.0

+0.3

(1)

Input Low Voltage

0.8

Operating Temperature

Commercial

NOTES:

1. V

= 3.3V ± 0.15V, JEDEC JESD8-A compliant.

2. 1.5V undershoots are allowed for 10ns once per cycle.

IDT72V7230L
IDT72V7240L
IDT72V7250L
IDT72V7260L
IDT72V7270L
IDT72V7280L
IDT72V7290L
IDT72V72100L

Commercial

CLK

= 10, 15 ns

Symbol

Parameter

Min.

Max.

Unit

(1)

Input Leakage Current

µ A

(2)

Output Leakage Current

µA

Output Logic "1" Voltage, I

= 2 mA

2.4

Output Logic "0" Voltage, I

= 4 mA

0.4

CC1

(3,4,5)

Active Power Supply Current

CC2

(3,6)

Standby Current

NOTES

1. Measurements with 0.4

IH,

0.4

OUT

CC.

3. Tested with outputs open (I

OUT

= 0).

4. RCLK and WCLK toggle at 20 MHz and data inputs switch at 10 MHz.
5. Typical I

CC1

= 15.5 + 2.275*f

+ 0.02*C

(in mA) with V

= 3.3V, t

= 25

C, f

= WCLK frequency = RCLK frequency (in MHz, using TTL levels), data switching at f

/2,

= capacitive load (in pF).

6. All Inputs = V

- 0.2V or GND + 0.2V, except RCLK and WCLK, which toggle at 20 MHz.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

AC ELECTRICAL CHARACTERISTICS

(1)

(Commercial: V

= 3.3V ± 0.15V, T

= 0

°C to +70°C; JEDEC JESD8-A compliant)

Commercial

IDT72V7230L10

IDT72V7230L15

IDT72V7240L10

IDT72V7240L15

IDT72V7250L10

IDT72V7250L15

IDT72V7260L10

IDT72V7260L15

IDT72V7270L10

IDT72V7270L15

IDT72V7280L10

IDT72V7280L15

IDT72V7290L10

IDT72V7290L15

IDT72V72100L10

IDT72V72100L15

Symbol

Parameter

Min.

Max.

Min.

Max.

Unit

Clock Cycle Frequency

100

66.7

MHz

Data Access Time

6.5

CLK

Clock Cycle Time

CLKH

Clock High Time

4.5

CLKL

Clock Low Time

4.5

Data Setup Time

3.5

Data Hold Time

0.5

ENS

Enable Setup Time

3.5

ENH

Enable Hold Time

0.5

LDS

Load Setup Time

3.5

LDH

Load Hold Time

0.5

Reset Pulse Width

(2)

RSS

Reset Setup Time

RSR

Reset Recovery Time

RSF

Reset to Flag and Output Time

FWFT

Mode Select Time

RTS

Retransmit Setup Time

3.5

OLZ

Output Enable to Output in Low Z

(3)

Output Enable to Output Valid

OHZ

Output Enable to Output in High Z

(3)

WFF

Write Clock to

FF or IR

6.5

REF

Read Clock to

EF or OR

6.5

PAFA

Clock to Asynchronous Programmable Almost-Full Flag

PAFS

Write Clock to Synchronous Programmable Almost-Full Flag

6.5

PAEA

Clock to Asynchronous Programmable Almost-Empty Flag

PAES

Read Clock to Synchronous Programmable Almost-Empty Flag

6.5

Clock to

RCSS

RCS Setup Time

3.5

RCSH

RCS Hold Time

0.5

RCSLZ

RCLK to Active from High-Z

(3)

6.5

RCSHZ

RCLK to High-Z

(3)

6.5

SKEW1

Skew time between RCLK and WCLK for

EF/OR and FF/IR

SKEW2

Skew time between RCLK and WCLK for

PAE and PAF

NOTES:
1. All AC timings apply to both Standard IDT mode and First Word Fall Through mode.
2. Pulse widths less than minimum values are not allowed.
3. Values guaranteed by design, not currently tested.
4. Data Sheet slow conditions: 85

°c, 3.0V. Data Sheet fast conditions: -40°c, 3.6V.

Input Pulse Levels

GND to 3.0V

Input Rise/Fall Times

3ns

Input Timing Reference Levels

1.5V

Output Reference Levels

1.5V

Output Load

See Figure 2

AC TEST CONDITIONS

Figure 2. Output Load

* Includes jig and scope capacitances

4680 drw04

330

30pF*

510

3.3V

D.U.T.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

FUNCTIONAL DESCRIPTION

TIMING MODES: IDT STANDARD vs FIRST WORD FALL THROUGH
(FWFT) MODE

The IDT72V7230/72V7240/72V7250/72V7260/72V7270/72V7280/

72V7290/72V72100 support two different timing modes of operation: IDT
Standard mode or First Word Fall Through (FWFT) mode. The selection of
which mode will operate is determined during Master Reset, by the state of the
FWFT/SI input.

If, at the time of Master Reset, FWFT/SI is LOW, then IDT Standard mode

will be selected. This mode uses the Empty Flag (

EF) to indicate whether or

not there are any words present in the FIFO. It also uses the Full Flag function
(

FF) to indicate whether or not the FIFO has any free space for writing. In IDT

Standard mode, every word read from the FIFO, including the first, must be
requested using the Read Enable (

REN) and RCLK.

If, at the time of Master Reset, FWFT/SI is HIGH, then FWFT mode will be

selected. This mode uses Output Ready (

OR) to indicate whether or not there

is valid data at the data outputs (Q

. It also uses Input Ready (

IR) to indicate

whether or not the FIFO has any free space for writing. In the FWFT mode,
the first word written to an empty FIFO goes directly to Q

after three RCLK rising

edges,

REN = LOW is not necessary. Subsequent words must be accessed

using the Read Enable (

REN) and RCLK.

Various signals, both input and output signals operate differently depending

on which timing mode is in effect.

IDT STANDARD MODE

In this mode, the status flags,

FF, PAF, HF, PAE, and EF operate in the

manner outlined in Table 3. To write data into to the FIFO, Write Enable (

WEN)

must be LOW. Data presented to the DATA IN lines will be clocked into the FIFO
on subsequent transitions of the Write Clock (WCLK). After the first write is
performed, the Empty Flag (

EF) will go HIGH. Subsequent writes will continue

to fill up the FIFO. The Programmable Almost-Empty flag (

PAE) will go HIGH

after n + 1 words have been loaded into the FIFO, where n is the empty offset
value. The default setting for these values are stated in the footnote of Table
2. This parameter is also user programmable. See section on Programmable
Flag Offset Loading.

If one continued to write data into the FIFO, and we assumed no read

operations were taking place, the Half-Full flag (

HF) would toggle to LOW once

the 257th word for IDT72V7230, 513rd word for IDT72V7240, 1,025th word
for IDT72V7250, 2,049th word for IDT72V7260, 4,097th word for IDT72V7270,
8,193th word for the IDT72V7280, 16,385th word for the IDT72V7290 and
32,769th word for the IDT72V72100, respectively was written into the FIFO.
Continuing to write data into the FIFO will cause the Programmable Almost-Full
flag (

PAF) to go LOW. Again, if no reads are performed, the PAF will go LOW

after (512-m) writes for the IDT72V7230, (1,024-m) writes for the IDT72V7240,
(2,048-m) writes for the IDT72V7250, (4,096-m) writes for the IDT72V7260,
(8,192-m) writes for the IDT72V7270, (16,384-m) writes for the IDT72V7280,
(32,768-m) writes for the IDT72V7290 and (65,536-m) writes for the
IDT72V72100. The offset "m" is the full offset value. The default setting for these
values are stated in the footnote of Table 2. This parameter is also user
programmable. See section on Programmable Flag Offset Loading.

When the FIFO is full, the Full Flag (

FF) will go LOW, inhibiting further write

operations. If no reads are performed after a reset,

FF will go LOW after D writes

to the FIFO. D = 512 writes for the IDT72V7230, 1,024 writes for the
IDT72V7240, 2,048 writes for the IDT72V7250, 4,096 writes for the IDT72V7260,
8,192 writes for the IDT72V7270, 16,384 writes for the IDT72V7280, 32,768
writes for the IDT72V7290, 65,536 writes for the IDT72V72100, respectively.

If the FIFO is full, the first read operation will cause

FF to go HIGH.

Subsequent read operations will cause

PAF and HF to go HIGH at the conditions

described in Table 3. If further read operations occur, without write operations,
PAE will go LOW when there are n words in the FIFO, where n is the empty
offset value. Continuing read operations will cause the FIFO to become empty.
When the last word has been read from the FIFO, the

EF will go LOW inhibiting

further read operations.

REN is ignored when the FIFO is empty.

When configured in IDT Standard mode, the

EF and FF outputs are double

Relevant timing diagrams for IDT Standard mode can be found in Figure

10,11,12,16 and 18.

FIRST WORD FALL THROUGH MODE (FWFT)

In this mode, the status flags,

IR, PAF, HF, PAE, and OR operate in the

manner outlined in Table 4. To write data into to the FIFO,

WEN must be LOW.

Data presented to the DATA IN lines will be clocked into the FIFO on subsequent
transitions of WCLK. After the first write is performed, the Output Ready (

OR)

flag will go LOW. Subsequent writes will continue to fill up the FIFO.

PAE will

go HIGH after n + 2 words have been loaded into the FIFO, where n is the empty
offset value. The default setting for these values are stated in the footnote of Table
2. This parameter is also user programmable. See section on Programmable
Flag Offset Loading.

If one continued to write data into the FIFO, and we assumed no read

operations were taking place, the

HF would toggle to LOW once the 258th word

for the IDT72V7230, 514th word for the IDT72V7240, 1,026th word for the
IDT72V7250, 2,050th word for the IDT72V7260, 4,098th word for the
IDT72V7270, 8,194th word for the IDT72V7280, 16,386th word for the
IDT72V7290 and 32,770th word for the IDT72V72100, respectively was
written into the FIFO. Continuing to write data into the FIFO will cause the

PAF

to go LOW. Again, if no reads are performed, the

PAF will go LOW after (513-m)

writes for the IDT72V7230, (1,025-m) writes for the IDT72V7240, (2,049-m)
writes for the IDT72V7250, (4,097-m) writes for the IDT72V7260 and (8,193-m)
writes for the IDT72V7270, 16,385 writes for the IDT72V7280, 32,769 writes
for the IDT72V7290 and 65,537 writes for the IDT72V72100, where m is the
full offset value. The default setting for these values are stated in the footnote
of Table 2.

When the FIFO is full, the Input Ready (

IR) flag will go HIGH, inhibiting further

write operations. If no reads are performed after a reset,

IR will go HIGH after

D writes to the FIFO. D = 513 writes for the IDT72V7230, 1,025 writes for the
IDT72V7240, 2,049 writes for the IDT72V7250, 4,097 writes for the IDT72V7260
and 8,193 writes for the IDT72V7270, 16,385 writes for the IDT72V7280,
32,769 writes for the IDT72V7290, 65,537 writes for the IDT72V72100,
respectively. Note that the additional word in FWFT mode is due to the capacity
of the memory plus output register.

If the FIFO is full, the first read operation will cause the

IR flag to go LOW.

Subsequent read operations will cause the

PAF and HF to go HIGH at the

conditions described in Table 4. If further read operations occur, without write
operations, the

PAE will go LOW when there are n + 1 words in the FIFO, where

n is the empty offset value. Continuing read operations will cause the FIFO to
become empty. When the last word has been read from the FIFO,

OR will go

HIGH inhibiting further read operations.

REN is ignored when the FIFO is

empty.

When configured in FWFT mode, the

OR flag output is triple register-

buffered, and the

IR flag output is double register-buffered.

Relevant timing diagrams for FWFT mode can be found in Figure 13, 14,15,

17, and 19.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

PROGRAMMING FLAG OFFSETS

Full and Empty Flag offset values are user programmable. The IDT72V7230/

72V7240/72V7250/72V7260/72V7270/72V7280/72V7290/72V72100 have
internal registers for these offsets. There are eight default offset values selectable
during Master Reset. These offset values are shown in Table 2. Offset values
can also be programmed into the FIFO in one of two ways; serial or parallel
loading method. The selection of the loading method is done using the

LD (Load)

pin. During Master Reset, the state of the

LD input determines whether serial

or parallel flag offset programming is enabled. A HIGH on

LD during Master

Reset selects serial loading of offset values. A LOW on

LD during Master Reset

selects parallel loading of offset values.

In addition to loading offset values into the FIFO, it is also possible to read

the current offset values. Offset values can be read via the parallel output port
Q

-Qn, regardless of the programming mode selected (serial or parallel). It is

not possible to read the offset values in serial fashion.

Figure 3, Programmable Flag Offset Programming Sequence, summaries

the control pins and sequence for both serial and parallel programming modes.
For a more detailed description, see discussion that follows.

The offset registers may be programmed (and reprogrammed) any time after

Master Reset, regardless of whether serial or parallel programming has been
selected. Valid programming ranges are from 0 to D-1.

SYNCHRONOUS vs ASYNCHRONOUS PROGRAMMABLE FLAG
TIMING SELECTION

The IDT72V7230/72V7240/72V7250/72V7260/72V7270/72V7280/

72V7290/72V72100 can be configured during the Master Reset cycle with
either synchronous or asynchronous timing for

PAF and PAE flags by use of

the PFM pin.

If synchronous

PAF/PAE configuration is selected (PFM, HIGH during

MRS), the PAF is asserted and updated on the rising edge of WCLK only and
not RCLK. Similarly,

PAE is asserted and updated on the rising edge of RCLK

only and not WCLK. For detail timing diagrams, see Figure 23 for synchronous
PAF timing and Figure 24 for synchronous PAE timing.

If asynchronous

PAF/PAE configuration is selected (PFM, LOW during

MRS), the PAF is asserted LOW on the LOW-to-HIGH transition of WCLK and
PAF is reset to HIGH on the LOW-to-HIGH transition of RCLK. Similarly, PAE
is asserted LOW on the LOW-to-HIGH transition of RCLK.

PAE is reset to HIGH

on the LOW-to-HIGH transition of WCLK. For detail timing diagrams, see Figure
25 for asynchronous

PAF timing and Figure 26 for asynchronous PAE timing.

IDT72V7230, 72V7240

FSEL1

FSEL0

Offsets n,m

511

255

127

FSEL1

FSEL0

Program Mode

Serial

(3)

Parallel

(4)

IDT72V7250, 72V7260, 72V7270, 72V7280

FSEL1

FSEL0

Offsets n,m

1,023

511

255

127

FSEL1

FSEL0

Program Mode

Serial

(3)

Parallel

(4)

IDT72V7290, 72V72100

FSEL1

FSEL0

Offsets n,m

16,383

8,191

4,095

2,047

1,023

511

255

127

FSEL1

FSEL0

Program Mode

Serial

(3)

Parallel

(4)

TABLE 2 -- DEFAULT PROGRAMMABLE
FLAG OFFSETS

NOTES:
1. n = empty offset for

PAE.

2. m = full offset for

PAF.

3. As well as selecting serial programming mode, one of the default values will also

be loaded depending on the state of FSEL0 & FSEL1.

4. As well as selecting parallel programming mode, one of the default values will

also be loaded depending on the state of FSEL0 & FSEL1.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

IDT72V7240

IDT72V7250

1 to n

(1)

(n+1) to 1,024

1,025 to (2048-(m+1))

(2048-m)

to 2,047

2,048

1 to n

(1)

(n+1) to 512

513 to (1,024-(m+1))

(1024-m)

to 1,023

1,024

TABLE 3

STATUS FLAGS FOR IDT STANDARD MODE

Number of

Words in

FIFO

1 to n+1

(n+2) to 1,025

(n+2) to 2,049

(n+2) to 4,097

1,026 to (2,049-(m+1))

2,050 to (4,097-(m+1))

4,098 to (8,193-(m+1))

(2,049-m)

to 2,048

(4,097-m)

to 4,096

(8,193-m)

to 8,192

2,049

4,097

8,193

I
R

TABLE 4

STATUS FLAGS FOR FWFT MODE

Number of

Words in

FIFO

1 to n+1

(n+2) to 513

514 to (1,025-(m+1))

(1,025-m)

to 1,024

1,025

4680 drw 05

1 to n+1

(n+2) to 8,193

(n+2) to 16,385

8,194 to (16,385-(m+1))

16,386 to (32,769-(m+1))

(16,385-m)

to 16,384

(32,769-m)

to 32,768

16,385

32,769

1 to n+1

(n+2) to 32,769

32,770 to (65,537-(m+1))

(65,537-m)

to 65,536

65,537

I
R

Number of

Words in

FIFO

1 to n+1

(n+2) to 257

258 to (513-(m+1))

(513-m)

to 512

513

IDT72V7240

IDT72V7250

IDT72V7260

IDT72V7230

IDT72V7270

IDT72V7280

IDT72V7290

IDT72V72100

1 to n

(

1 to n

(1)

(n+1) to 8,192

(n+1) to 16,384

8,193 to (16,384-(m+1))

16,385 to (32,768-(m+1))

(16,384-m)

to 16,383

(32,768-m)

to 32,767

16,384

32,768

1 to n

(1)

(n+1) to 32,768

32,769 to (65,536-(m+1))

(65,536-m)

to 65,535

65,536

IDT72V7270

IDT72V7280

IDT72V7290

IDT72V72100

HHL

Number of

Words in

FIFO

IDT72V7260

1 to n

(1)

(n+1) to 4,096

4,097 to (8,192-(m+1))

(8,192-m)

to 8,191

8,192

1 to n

(1)

(n+1) to 2,048

2,049 to (4,096-(m+1))

(4,096-m)

to 4,095

4,096

IDT72V7230

1 to n

(1)

(n+1) to 256

257 to (512-(m+1))

(512-m)

512

NOTE:

See table 2 for values for n, m.

NOTE:

See table 2 for values for n, m.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

D/Q17

D/Q0

D/Q8

EMPTY OFFSET REGISTER (

PAE)

# of Bits Used

1st Parallel Offset Write/Read Cycle

Interspersed
Parity

D/Q35 D/Q19

D/Q17

D/Q0

D/Q8

FULL OFFSET REGISTER (

PAF)

# of Bits Used

2nd Parallel Offset Write/Read Cycle

Interspersed
Parity

x36 Bus Width

Non-Interspersed
Parity

D/Q35 D/Q19

D/Q17

D/Q0

D/Q16

EMPTY OFFSET (LSB) REGISTER (

PAE)

Data Inputs/Outputs

# of Bits Used

1st Parallel Offset Write/Read Cycle

2nd Parallel Offset Write/Read Cycle

Data Inputs/Outputs

FULL OFFSET (LSB) REGISTER (

PAF)

Non-Interspersed
Parity

Interspersed
Parity

D/Q0

D/Q8

x18 Bus Width

D/Q17

D/Q16

# of Bits Used:
09 bits for the IDT72V7230
10 bits for the IDT72V7240
11 bits for the IDT72V7250
12 bits for the IDT72V7260
13 bits for the IDT72V7270
14 bits for the IDT72V7280
15 bits for the IDT72V7290
16 bits for the IDT72V72100
Note: All unused input bits
are don't care.

4680 drw07

D/Q17

D/Q0

D/Q8

EMPTY OFFSET REGISTER (

PAE)

# of Bits Used

1st Parallel Offset Write/Read Cycle

Interspersed
Parity

D/Q71 D/Q19

D/Q17

D/Q0

D/Q8

FULL OFFSET REGISTER (

PAF)

# of Bits Used

2nd Parallel Offset Write/Read Cycle

Interspersed
Parity

x72 Bus Width

Non-Interspersed
Parity

D/Q71 D/Q19

Figure 3. Programmable Flag Offset Programming Sequence (Continued)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

FUNCTIONAL DESCRIPTION
(CONTINUED)

SERIAL PROGRAMMING MODE

If Serial Programming mode has been selected, as described above, then

programming of

PAE and PAF values can be achieved by using a combination

of the

LD, SEN, SCLK and SI input pins. Programming PAE and PAF proceeds

as follows: when

LD and SEN are set LOW, data on the SI input are written, one

bit for each SCLK rising edge, starting with the Empty Offset LSB and ending
with the Full Offset MSB. A total of 18 bits for the IDT72V7230, 20 bits for the
IDT72V7240, 22 bits for the IDT72V7250, 24 bits for the IDT72V7260, 26 bits
for the IDT72V7270, 28 bits for the IDT72V7280, 30 bits for the IDT72V7290
and 32 bits for the IDT72V72100. See Figure 20, Serial Loading of
Programmable Flag Registers, for the timing diagram for this mode.

Using the serial method, individual registers cannot be programmed

selectively.

PAE and PAF can show a valid status only after the complete set

of bits (for all offset registers) has been entered. The registers can be
reprogrammed as long as the complete set of new offset bits is entered. When
LD is LOW and SEN is HIGH, no serial write to the registers can occur.

Write operations to the FIFO are allowed before and during the serial

programming sequence. In this case, the programming of all offset bits does not
have to occur at once. A select number of bits can be written to the SI input and
then, by bringing

LD and SEN HIGH, data can be written to FIFO memory via

by toggling

WEN. When WEN is brought HIGH with LD and SEN restored

to a LOW, the next offset bit in sequence is written to the registers via SI. If an
interruption of serial programming is desired, it is sufficient either to set

LD LOW

and deactivate

SEN or to set SEN LOW and deactivate LD. Once LD and SEN

are both restored to a LOW level, serial offset programming continues.

From the time serial programming has begun, neither programmable flag

will be valid until the full set of bits required to fill all the offset registers has been
written. Measuring from the rising SCLK edge that achieves the above criteria;
PAF will be valid after three more rising WCLK edges plus t

PAF

PAE will be valid

after the next three rising RCLK edges plus t

PAE

It is only possible to read the flag offset values via the parallel output port Qn.

PARALLEL MODE

If Parallel Programming mode has been selected, as described above, then

programming of

PAE and PAF values can be achieved by using a combination

of the

LD, WCLK, WEN and D

input pins. Programming

PAE and PAF

proceeds as follows:

LD and WEN must be set LOW. For x72, x36 or x18 bit

input bus widths, data on the inputs D

are written into the Empty Offset Register

on the first LOW-to-HIGH transition of WCLK. Upon the second LOW-to-HIGH
transition of WCLK, data are written into the Full Offset Register. The third
transition of WCLK writes, once again, to the Empty Offset Register. See Figure
3, Programmable Flag Offset Programming Sequence. See Figure 21,
Parallel Loading of Programmable Flag Registers, for the timing diagram for
this mode.

The act of writing offsets in parallel employs a dedicated write offset register

pointer. The act of reading offsets employs a dedicated read offset register
pointer. The two pointers operate independently; however, a read and a write
should not be performed simultaneously to the offset registers. A Master Reset
initializes both pointers to the Empty Offset register. A Partial Reset has no effect
on the position of these pointers.

Write operations to the FIFO are allowed before and during the parallel

programming sequence. In this case, the programming of all offset registers does
not have to occur at one time. One offset register can be written and then by
bringing

LD HIGH, write operations can be redirected to the FIFO memory.

When

LD is set LOW again, and WEN is LOW, the next offset register in sequence

is written to. As an alternative to holding

WEN LOW and toggling LD, parallel

programming can also be interrupted by setting

LD LOW and toggling WEN.

Note that the status of a programmable flag (

PAE or PAF) output is invalid

during the programming process. From the time parallel programming has
begun, a programmable flag output will not be valid until the appropriate offset
word has been written to the register pertaining to that flag. Measuring from the
rising WCLK edge that achieves the above criteria;

PAF will be valid after two

more rising WCLK edges plus t

PAF

PAE will be valid after the next two rising

RCLK edges plus t

PAE

plus t

SKEW2

The act of reading the offset registers employs a dedicated read offset

-Q

pins when

LD is set LOW and REN is set LOW. For x72, x36 or x18 output bus

width, data are read via Q

-Q

from the Empty Offset Register on the first

LOW-to-HIGH transition of RCLK. Upon the second LOW-to-HIGH transition
of RCLK, data are read from the Full Offset Register. The third transition of RCLK
reads, once again, from the Empty Offset Register. See Figure 3, Program-
mable Flag Offset Programming Sequence. See Figure 22, Parallel Read of
Programmable Flag Registers, for the timing diagram for this mode.

It is permissible to interrupt the offset register read sequence with reads or

writes to the FIFO. The interruption is accomplished by deasserting

REN, LD,

or both together. When

REN and LD are restored to a LOW level, reading of

the offset registers continues where it left off. It should be noted, and care should
be taken from the fact that when a parallel read of the flag offsets is performed,
the data word that was present on the output lines Qn will be overwritten.

Parallel reading of the offset registers is always permitted regardless of

which timing mode (IDT Standard or FWFT modes) has been selected.

RETRANSMIT OPERATION

The Retransmit operation allows data that has already been read to be

accessed again. There are 2 modes of Retransmit operation, normal latency
and zero latency. There are two stages to Retransmit: first, a setup procedure
that resets the read pointer to the first location of memory, then the actual
retransmit, which consists of reading out the memory contents, starting at the
beginning of memory.

Retransmit setup is initiated by holding

RT LOW during a rising RCLK edge.

REN and WEN must be HIGH before bringing RT LOW. When zero latency is
utilized,

REN does not need to be HIGH before bringing RT LOW. At least two words,

but no more than D - 2 words should have been written into the FIFO, and read
from the FIFO, between Reset (Master or Partial) and the time of Retransmit
setup. D = 512 for the IDT72V7230, 1,024 for the IDT72V7240, 2,048 for the
IDT72V7250, 4,096 for the IDT72V7260, 8,192 for the IDT72V7270, 16,384
for the IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the
IDT72V72100. In FWFT mode, D = 513 for the IDT72V7230, 1,025 for the
IDT72V7240, 2,049 for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for
the IDT72V7270, 16,385 for the IDT72V7280, 32,769 for the IDT72V7290 and
65,537 for the IDT72V72100.

If IDT Standard mode is selected, the FIFO will mark the beginning of the

Retransmit setup by setting

EF LOW. The change in level will only be noticeable

EF was HIGH before setup. During this period, the internal read pointer is

initialized to the first location of the RAM array.

When

EF goes HIGH, Retransmit setup is complete and read operations

may begin starting with the first location in memory. Since IDT Standard mode
is selected, every word read including the first word following Retransmit setup
requires a LOW on

REN to enable the rising edge of RCLK. See Figure 16,

Retransmit Timing (IDT Standard Mode), for the relevant timing diagram.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

If FWFT mode is selected, the FIFO will mark the beginning of the Retransmit

setup by setting

OR HIGH. During this period, the internal read pointer is set

to the first location of the RAM array.

When

OR goes LOW, Retransmit setup is complete; at the same time, the

contents of the first location appear on the outputs. Since FWFT mode is selected,
the first word appears on the outputs, no LOW on

REN is necessary. Reading

all subsequent words requires a LOW on

REN to enable the rising edge of

RCLK. See Figure 17, Retransmit Timing (FWFT Mode), for the relevant timing
diagram.

For either IDT Standard mode or FWFT mode, updating of the

PAE, HF

and

PAF flags begin with the rising edge of RCLK that RT is setup. PAE is

synchronized to RCLK, thus on the second rising edge of RCLK after

RT is setup,

the

PAE flag will be updated. HF is asynchronous, thus the rising edge of RCLK

that

RT is setup will update HF. PAF is synchronized to WCLK, thus the second

rising edge of WCLK that occurs t

SKEW

after the rising edge of RCLK that

is setup will update

PAF. RT is synchronized to RCLK.

The Retransmit function has the option of two modes of operation, either

"normal latency" or "zero latency". Figure 16 and Figure 17 mentioned
previously, relate to "normal latency". Figure 18 and Figure 19 show "zero
latency" retransmit operation. Zero latency basically means that the first data
word to be retransmitted, is placed onto the output register with respect to the
RCLK pulse that initiated the retransmit.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

SIGNAL DESCRIPTION

INPUTS:

DATA IN (D

- D

)

Data inputs for 72-bit wide data (D

- D

), data inputs for 36-bit wide data

- D

) or data inputs for 18-bit wide data (D

- D

CONTROLS:

MASTER RESET (

MRS )

A Master Reset is accomplished whenever the

MRS input is taken to a LOW

state. This operation sets the internal read and write pointers to the first location
of the RAM array.

PAE will go LOW, PAF will go HIGH, and HF will go HIGH.

If FWFT/SI is LOW during Master Reset then the IDT Standard mode,

along with

EF and FF are selected. EF will go LOW and FF will go HIGH. If

FWFT/SI is HIGH, then the First Word Fall Through mode (FWFT), along with
IR and OR, are selected. OR will go HIGH and IR will go LOW.

All control settings such as OW, IW, BM,

BE, RM, PFM and IP are defined

during the Master Reset cycle.

During a Master Reset, the output register is initialized to all zeroes. A Master

Reset is required after power up, before a write operation can take place.

MRS

is asynchronous.

See Figure 8, Master Reset Timing, for the relevant timing diagram.

PARTIAL RESET (

PRS )

A Partial Reset is accomplished whenever the PRS input is taken to a LOW

state. As in the case of the Master Reset, the internal read and write pointers
are set to the first location of the RAM array, PAE goes LOW, PAF goes HIGH,
and HF goes HIGH.

Whichever mode is active at the time of Partial Reset, IDT Standard mode

or First Word Fall Through, that mode will remain selected. If the IDT Standard
mode is active, then

FF will go HIGH and EF will go LOW. If the First Word Fall

Through mode is active, then

OR will go HIGH, and IR will go LOW.

Following Partial Reset, all values held in the offset registers remain

unchanged. The programming method (parallel or serial) currently active at
the time of Partial Reset is also retained. The output register is initialized to all
zeroes.

PRS is asynchronous.

A Partial Reset is useful for resetting the device during the course of

operation, when reprogramming programmable flag offset settings may not be
convenient.

See Figure 9, Partial Reset Timing, for the relevant timing diagram.

RETRANSMIT (

RT )

The Retransmit operation allows data that has already been read to be

Retransmit setup is initiated by holding

RT LOW during a rising RCLK edge.

REN and WEN must be HIGH before bringing RT LOW. When zero latency is
utilized,

REN does not need to be HIGH before bringing RT LOW.

If IDT Standard mode is selected, the FIFO will mark the beginning of the

Retransmit setup by setting

EF LOW. The change in level will only be noticeable

EF was HIGH before setup. During this period, the internal read pointer is

initialized to the first location of the RAM array.

When

EF goes HIGH, Retransmit setup is complete and read operations

may begin starting with the first location in memory. Since IDT Standard mode

is selected, every word read including the first word following Retransmit setup
requires a LOW on

REN to enable the rising edge of RCLK. See Figure 16,

Retransmit Timing (IDT Standard Mode), for the relevant timing diagram.

If FWFT mode is selected, the FIFO will mark the beginning of the Retransmit

setup by setting

OR HIGH. During this period, the internal read pointer is set

to the first location of the RAM array.

When

OR goes LOW, Retransmit setup is complete; at the same time, the

contents of the first location appear on the outputs. Since FWFT mode is selected,
the first word appears on the outputs, no LOW on

REN is necessary. Reading

all subsequent words requires a LOW on

REN to enable the rising edge of

RCLK. See Figure 17, Retransmit Timing (FWFT Mode), for the relevant timing
diagram.

In Retransmit operation, zero latency mode can be selected using the

Retransmit Mode (RM) pin during a Master Reset. This can be applied to both
IDT Standard mode and FWFT mode.

Note, the Read Chip Select (

RCS) input must be LOW during Retransmit.

The

RCS input enables/disables the REN input.

FIRST WORD FALL THROUGH/SERIAL IN (FWFT/SI)

This is a dual purpose pin. During Master Reset, the state of the FWFT/

SI input determines whether the device will operate in IDT Standard mode or
First Word Fall Through (FWFT) mode.

If, at the time of Master Reset, FWFT/SI is LOW, then IDT Standard mode

will be selected. This mode uses the Empty Flag (

EF) to indicate whether or

not there are any words present in the FIFO memory. It also uses the Full Flag
function (

FF) to indicate whether or not the FIFO memory has any free space

for writing. In IDT Standard mode, every word read from the FIFO, including
the first, must be requested using the Read Enable (

REN) and RCLK.

If, at the time of Master Reset, FWFT/SI is HIGH, then FWFT mode will be

selected. This mode uses Output Ready (

OR) to indicate whether or not there

is valid data at the data outputs (Q

. It also uses Input Ready (

IR) to indicate

whether or not the FIFO memory has any free space for writing. In the FWFT
mode, the first word written to an empty FIFO goes directly to Q

after three RCLK

rising edges,

REN = LOW is not necessary. Subsequent words must be

accessed using the Read Enable (

REN) and RCLK.

After Master Reset, FWFT/SI acts as a serial input for loading

PAE and PAF

offsets into the programmable registers. The serial input function can only be
used when the serial loading method has been selected during Master Reset.
Serial programming using the FWFT/SI pin functions the same way in both IDT
Standard and FWFT modes.

WRITE CLOCK (WCLK)

A write cycle is initiated on the rising edge of the WCLK input. Data setup

and hold times must be met with respect to the LOW-to-HIGH transition of the
WCLK. It is permissible to stop the WCLK. Note that while WCLK is idle, the

FF/

IR, PAF and HF flags will not be updated. (Note that WCLK is only capable of
updating

HF flag to LOW.) The Write and Read Clocks can either be

independent or coincident.

WRITE ENABLE (

WEN )

When the

WEN input is LOW, data may be loaded into the FIFO RAM array

on the rising edge of every WCLK cycle if the device is not full. Data is stored
in the RAM array sequentially and independently of any ongoing read
operation.

When

WEN is HIGH, no new data is written in the RAM array on each WCLK

cycle.

To prevent data overflow in the IDT Standard mode,

FF will go LOW,

inhibiting further write operations. Upon the completion of a valid read cycle,

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

FF will go HIGH allowing a write to occur. The FF is updated by two WCLK
cycles + t

SKEW

after the RCLK cycle.

To prevent data overflow in the FWFT mode,

IR will go HIGH, inhibiting

further write operations. Upon the completion of a valid read cycle,

IR will go

LOW allowing a write to occur. The

IR flag is updated by two WCLK cycles +

SKEW

after the valid RCLK cycle.

WEN is ignored when the FIFO is full in either FWFT or IDT Standard mode.

READ CLOCK (RCLK)

A read cycle is initiated on the rising edge of the RCLK input. Data can be

read on the outputs, on the rising edge of the RCLK input. It is permissible to
stop the RCLK. Note that while RCLK is idle, the

EF/OR, PAE and HF flags will

not be updated. (Note that RCLK is only capable of updating the

HF flag to

HIGH.) The Write and Read Clocks can be independent or coincident.

READ ENABLE (

REN )

When Read Enable is LOW, data is loaded from the RAM array into the output

When the

REN input is HIGH, the output register holds the previous data

and no new data is loaded into the output register. The data outputs Q

-Q

maintain the previous data value.

In the IDT Standard mode, every word accessed at Q

, including the first

word written to an empty FIFO, must be requested using

REN provided that RCS

is LOW. When the last word has been read from the FIFO, the Empty Flag (

EF)

will go LOW, inhibiting further read operations.

REN is ignored when the FIFO

is empty. Once a write is performed,

EF will go HIGH allowing a read to occur.

The

EF flag is updated by two RCLK cycles + t

SKEW

after the valid WCLK cycle.

In the FWFT mode, the first word written to an empty FIFO automatically goes

to the outputs Q

, on the third valid LOW-to-HIGH transition of RCLK + t

SKEW

after the first write.

REN and RCS do not need to be asserted LOW. In order

to access all other words, a read must be executed using

REN and RCS must

be enabled LOW. The RCLK LOW-to-HIGH transition after the last word has
been read from the FIFO, Output Ready (

OR) will go HIGH with a true read

(RCLK with

REN = LOW; RCS = LOW), inhibiting further read operations. REN

is ignored when the FIFO is empty.

SERIAL CLOCK (

SCLK )

During serial loading of the programmable flag offset registers, a rising edge

on the SCLK input is used to load serial data present on the SI input provided
that the

SEN input is LOW.

SERIAL ENABLE (

SEN )

The

SEN input is an enable used only for serial programming of the offset

registers. The serial programming method must be selected during Master
Reset.

SEN is always used in conjunction with LD. When these lines are both

LOW, data at the SI input can be loaded into the program register one bit for each
LOW-to-HIGH transition of SCLK.

When

SEN is HIGH, the programmable registers retains the previous

settings and no offsets are loaded.

SEN functions the same way in both IDT

Standard and FWFT modes.

OUTPUT ENABLE (

OE )

When Output Enable is enabled (LOW), the parallel output buffers receive

data from the output register. When

OE is HIGH, the output data bus (Q

) goes

into a high impedance state. Note, during a Master or Partial Reset

RCS can

be HIGH or LOW,

OE is the only input that can place the output bus into High-

Impedance.

READ CHIP SELECT (

RCS )

The Read Chip Select input provides synchronous control of the Read

output port. When

RCS goes LOW, the next rising edge of RCLK causes the

Qn outputs to go to the LOW Z state. When

RCS goes HIGH, the next RCLK

rising edge causes the Qn outputs to return to HIGH Z. During a Master or Partial
Reset the

RCS input can be HIGH or LOW. OE provides High-Impedance

control of the data outputs. If

OE is LOW the data outputs will be Low-Impedance

regardless of

RCS until the first rising edge of RCLK after reset is complete. Then

RCS is HIGH the data outputs will go to High-Impedance.

During the time while

RCS is HIGH (disabled) all read operations are

ignored. That is, the

REN input is disabled and data is not clocked from the RAM

array to the output register.

The

RCS input does not effect the operation of the flags. For example, when

the first word is written to an empty FIFO, the

EF will still go from LOW to HIGH

based on a rising edge of RCLK

, regardless of the state of the RCS input.

Also, when operating the FIFO in FWFT mode the first word written to an

empty FIFO will still be clocked through to the output register based on RCLK,
regardless of the state of

RCS. The RCS pin must also be active (LOW) in order

to perform a Retransmit. See figure 12 for Read Cycle and Read Chip Select
Timing (IDT Standard Mode). See figure 15 for Read Cycle and Read Chip
Select Timing (First Word Fall Through Mode).

LOAD (

LD )

This is a dual purpose pin. During Master Reset, the state of the

LD input,

along with FSEL0 and FSEL1, determines one of eight default offset values for
the

PAE and PAF flags, along with the method by which these offset registers

can be programmed, parallel or serial (see Table 2). After Master Reset,

enables write operations to and read operations from the offset registers. Only
the offset loading method currently selected can be used to write to the registers.
Offset registers can be read only in parallel.

After Master Reset, the

LD pin is used to activate the programming process

of the flag offset values

PAE and PAF. Pulling LD LOW will begin a serial loading

or parallel load or read of these offset values.

BUS-MATCHING (BM, IW, OW)

The pins BM, IW and OW are used to define the input and output bus widths.

During Master Reset, the state of these pins is used to configure the device bus
sizes. See Table 1 for control settings. All flags will operate on the word/byte
size boundary as defined by the selection of bus width. See Figure 4 for Bus-
Matching Byte Arrangement.

BIG-ENDIAN/LITTLE-ENDIAN (

BE )

During Master Reset, a LOW on

BE will select Big-Endian operation. A

HIGH on

BE during Master Reset will select Little-Endian format. This function

is useful when the following input to output bus widths are implemented: x72 to
x36, x72 to x18, x36 to x72 and x18 to x72. If Big-Endian mode is selected,
then the most significant byte (word) of the long word written into the FIFO will
be read out of the FIFO first, followed by the least significant long word. If Little-
Endian format is selected, then the least significant word of the long word written
into the FIFO will be read out first, followed by the most significant word. The
mode desired is configured during master reset by the state of the Big-Endian
(

BE) pin. See Figure 4 for Bus-Matching Byte Arrangement.

PROGRAMMABLE FLAG MODE (PFM)

During Master Reset, a LOW on PFM will select Asynchronous Program-

mable flag timing mode. A HIGH on PFM will select Synchronous Programmable

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

flag timing mode. If asynchronous

PAF/PAE configuration is selected (PFM,

LOW during

MRS), the PAE is asserted LOW on the LOW-to-HIGH transition

of RCLK.

PAE is reset to HIGH on the LOW-to-HIGH transition of WCLK.

Similarly, the

PAF is asserted LOW on the LOW-to-HIGH transition of WCLK and

PAF is reset to HIGH on the LOW-to-HIGH transition of RCLK.

If synchronous

PAE/PAF configuration is selected (PFM, HIGH during

MRS) , the

PAE is asserted and updated on the rising edge of RCLK only and

not WCLK. Similarly,

PAF is asserted and updated on the rising edge of WCLK

only and not RCLK. The mode desired is configured during master reset by
the state of the Programmable Flag Mode (PFM) pin.

INTERSPERSED PARITY (IP)

During Master Reset, a LOW on IP will select Non-Interspersed Parity mode.

A HIGH will select Interspersed Parity mode. The IP bit function allows the user
to select the parity bit in the long word loaded into the parallel port (D

-Dn) when

programming the flag offsets. If Interspersed Parity mode is selected, then the
FIFO will assume that the parity bits are located in bit position D

, D

35,

, D

and D

during the parallel programming of the flag offsets. If

Non-Interspersed Parity mode is selected, then D

, D

and D

are is assumed

to be valid bits and D

, D

66,

, D

and D

are ignored.

IP mode is selected during Master Reset by the state of the IP input pin.

OUTPUTS:

FULL FLAG (

FF/IR )

This is a dual purpose pin. In IDT Standard mode, the Full Flag (

FF) function

is selected. When the FIFO is full,

FF will go LOW, inhibiting further write

operations. When

FF is HIGH, the FIFO is not full. If no reads are performed

after a reset (either

MRS or PRS), FF will go LOW after D writes to the FIFO

(D = 512 for the IDT72V7230, 1,024 for the IDT72V7240, 2,048 for the
IDT72V7250, 4,096 for the IDT72V7260, 8,192 for the IDT72V7270, 16,384
for the IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the
IDT72V72100). See Figure10, Write Cycle and Full Flag Timing (IDT
Standard Mode), for the relevant timing information.

In FWFT mode, the Input Ready (

IR) function is selected. IR goes LOW

when memory space is available for writing in data. When there is no longer
any free space left,

IR goes HIGH, inhibiting further write operations. If no reads

are performed after a reset (either

MRS or PRS), IR will go HIGH after D writes

to the FIFO (D = 513 for the IDT72V7230, 1,025 for the IDT72V7240, 2,049
for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for the IDT72V7270,
16,385 for the IDT72V7280, 32,769 for the IDT72V7290 and 65,537 for the
IDT72V72100). See Figure 13, Write Timing (FWFT Mode), for the relevant
timing information.

The

IR status not only measures the contents of the FIFO memory, but also

counts the presence of a word in the output register. Thus, in FWFT mode, the
total number of writes necessary to deassert

IR is one greater than needed to

assert

FF in IDT Standard mode.

FF/IR is synchronous and updated on the rising edge of WCLK. FF/IR are

double register-buffered outputs.

EMPTY FLAG (

EF/OR )

This is a dual purpose pin. In the IDT Standard mode, the Empty Flag (

EF)

function is selected. When the FIFO is empty,

EF will go LOW, inhibiting further

read operations. When

EF is HIGH, the FIFO is not empty. See Figure 11,

Read Cycle, Output Enable, Empty Flag and First Word Latency Timing (IDT
Standard Mode), for the relevant timing information.

In FWFT mode, the Output Ready (

OR) function is selected. OR goes LOW

at the same time that the first word written to an empty FIFO appears valid on

the outputs.

OR stays LOW after the RCLK LOW to HIGH transition that shifts

the last word from the FIFO memory to the outputs.

OR goes HIGH only with

a true read (RCLK with

REN = LOW). The previous data stays at the outputs,

indicating the last word was read. Further data reads are inhibited until

OR goes

LOW again. See Figure 10, Read Timing (FWFT Mode), for the relevant timing
information.

EF/OR is synchronous and updated on the rising edge of RCLK.

In IDT Standard mode,

EF is a double register-buffered output. In FWFT

mode,

OR is a triple register-buffered output.

PROGRAMMABLE ALMOST-FULL FLAG (

PAF )

The Programmable Almost-Full flag (

PAF) will go LOW when the FIFO

reaches the almost-full condition. In IDT Standard mode, if no reads are
performed after reset (

MRS), PAF will go LOW after (D - m) words are written

to the FIFO. The

PAF will go LOW after (512-m) writes for the IDT72V7230,

(1,024-m) writes for the IDT72V7240, (2,048-m) writes for the IDT72V7250,
(4,096-m) writes for the IDT72V7260, (8,192-m) writes for the IDT72V7270,
(16,384-m) writes for the IDT72V7280, (32,768-m) writes for the IDT72V7290,
and (65,536-m) writes for the IDT72V72100. The offset "m" is the full offset value.
The default setting for this value is stated in the footnote of Table 1.

In FWFT mode, the

PAF will go LOW after (513-m) writes for the IDT72V7230,

(1,025-m) writes for the IDT72V7240, (2,049-m) writes for the IDT72V7250,
(4,097-m) writes for the IDT72V7260 and (8,193-m) writes for the IDT72V7270,
(16,385-m) writes for the IDT72V7280, (32,769-m) writes for the IDT72V7290
and (65,537-m) writes for the IDT72V72100, where "m" is the full offset value.
The default setting for this value is stated in Table 2.

See Figure 23, Synchronous Programmable Almost-Full Flag Timing (IDT

Standard and FWFT Modes), for the relevant timing information.

If asynchronous

PAF configuration is selected, the PAF is asserted LOW

on the LOW-to-HIGH transition of the Write Clock (WCLK).

PAF is reset to HIGH

on the LOW-to-HIGH transition of the Read Clock (RCLK). If synchronous

PAF

configuration is selected, the

PAF is updated on the rising edge of WCLK. See

Figure 25, Asynchronous Almost-Full Flag Timing (IDT Standard and FWFT
Modes).

PROGRAMMABLE ALMOST-EMPTY FLAG (

PAE )

The Programmable Almost-Empty flag (

PAE) will go LOW when the FIFO

reaches the almost-empty condition. In IDT Standard mode,

PAE will go LOW

when there are n words or less in the FIFO. The offset "n" is the empty offset
value. The default setting for this value is stated in the footnote of Table 1.

In FWFT mode, the

PAE will go LOW when there are n+1 words or less

in the FIFO. The default setting for this value is stated in Table 2.

See Figure 24, Synchronous Programmable Almost-Empty Flag Timing

(IDT Standard and FWFT Modes), for the relevant timing information.

If asynchronous

PAE configuration is selected, the PAE is asserted LOW

on the LOW-to-HIGH transition of the Read Clock (RCLK).

PAE is reset to HIGH

on the LOW-to-HIGH transition of the Write Clock (WCLK). If synchronous

PAE

configuration is selected, the

PAE is updated on the rising edge of RCLK. See

Figure 26, Asynchronous Programmable Almost-Empty Flag Timing (IDT
Standard and FWFT Modes).

HALF-FULL FLAG (

HF )

This output indicates a half-full FIFO. The rising WCLK edge that fills the FIFO

beyond half-full sets

HF LOW. The flag remains LOW until the difference between

the write and read pointers becomes less than or equal to half of the total depth
of the device; the rising RCLK edge that accomplishes this condition sets

HIGH.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

JTAG INTERFACE

Five additional pins (TDI, TDO, TMS, TCK and

TRST) are provided to

support the JTAG boundary scan interface. The IDT72V7230/72V7240/
72V7250/72V7260/72V7270/72V7280/72V7290/72V72100 incorporates
the necessary tap controller and modified pad cells to implement the JTAG facility.

Note that IDT provides appropriate Boundary Scan Description Language

program files for these devices.

The Standard JTAG interface consists of four basic elements:

·
·
·
·
·

Test Access Port (TAP)

·
·
·
·
·

TAP controller

·
·
·
·
·

Instruction Register (IR)

·
·
·
·
·

Data Register Port (DR)

The following sections provide a brief description of each element. For a

complete description refer to the IEEE Standard Test Access Port Specification
(IEEE Std. 1149.1-1990).

The Figure below shows the standard Boundary-Scan Architecture

TAP

Cont-
roller

Mux

DeviceID Reg.

Boundary Scan Reg.

Bypass Reg.

clkDR, ShiftDR

UpdateDR

TDO
TDI

TMS
TCLK
TRST

clklR, ShiftlR

UpdatelR

Instruction Register

Instruction Decode

Control Signals

4680 drw11

Figure 6. Boundary Scan Architecture

TEST ACCESS PORT (TAP)

The Tap interface is a general-purpose port that provides access to the

internal of the processor. It consists of four input ports (TCLK, TMS, TDI,

TRST)

and one output port (TDO).

THE TAP CONTROLLER

The Tap controller is a synchronous finite state machine that responds to

TMS and TCLK signals to generate clock and control signals to the Instruction
and Data Registers for capture and update of data.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

Test-Logic
Reset

Run-Test/
Idle

Select-
DR-Scan

Select-
IR-Scan

Capture-IR

Capture-DR

EXit1-DR

Pause-DR

Exit2-DR

Update-DR

Exit1-IR

Exit2-IR

Update-IR

4680 drw12

Shift-DR

Shift-IR

Pause-IR

Input = TMS

Figure 7. TAP Controller State Diagram

Refer to the IEEE Standard Test Access Port Specification (IEEE Std.

1149.1) for the full state diagram

All state transitions within the TAP controller occur at the rising edge of the

TCLK pulse. The TMS signal level (0 or 1) determines the state progression
that occurs on each TCLK rising edge. The TAP controller takes precedence
over the FIFO memory and must be reset after power up of the device. See
TRST description for more details on TAP controller reset.

CAPTURE-DR

Data is loaded from the parallel input pins or core outputs into the Data

SHIFT-DR

The previously captured data is shifted in serially, LSB first at the rising edge

of TCLK in the TDI/TDO path and shifted out serially, LSB first at the falling edge
of TCLK towards the output.

UPDATE-DR

The shifting process has been completed. The data is latched into their

parallel outputs in this state to be accessed through the internal bus.

EXIT1-DR / EXIT2-DR

This is a temporary controller state. If TMS is held high, a rising edge applied

to TCK while in this state causes the controller to enter the Update-DR state. This
terminates the scanning process. All test data registers selected by the current
instruction retain their previous state unchanged.

PAUSE-DR

This controller state allows shifting of the test data register in the serial path

between TDI and TDO to be temporarily halted. All test data registers selected
by the current instruction retain their previous state unchanged.

Capture-IR, Shift-IR and Update-IR, Exit-IR and Pause-IR are

similar to Data registers. These instructions operate on the instruction registers.

NOTES:
1. Five consecutive TCK cycles with TMS = 1 will reset the TAP.
2. TAP controller does not automatically reset upon power-up. The user must provide a reset to the TAP controller (either by

TRST or TMS).

3. TAP controller must be reset before normal FIFO operations can begin.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

THE INSTRUCTION REGISTER

The Instruction register allows an instruction to be shifted in serially into the

processor at the rising edge of TCLK.

The Instruction is used to select the test to be performed, or the test data

register to be accessed, or both. The instruction shifted into the register is latched
at the completion of the shifting process when the TAP controller is at Update-
IR state.

The instruction register must contain 4 bit instruction register-based cells

which can hold instruction data. These mandatory cells are located nearest the
serial outputs they are the least significant bits.

TEST DATA REGISTER

The Test Data register contains three test data registers: the Bypass, the

Boundary Scan register and Device ID register.

These registers are connected in parallel between a common serial input

and a common serial data output.

The following sections provide a brief description of each element. For a

complete description, refer to the IEEE Standard Test Access Port Specification
(IEEE Std. 1149.1-1990).

TEST BYPASS REGISTER

The register is used to allow test data to flow through the device from TDI

to TDO. It contains a single stage shift register for a minimum length in serial path.
When the bypass register is selected by an instruction, the shift register stage
is set to a logic zero on the rising edge of TCLK when the TAP controller is in
the Capture-DR state.

The operation of the bypass register should not have any effect on the

operation of the device in response to the BYPASS instruction.

THE BOUNDARY-SCAN REGISTER

The Boundary Scan Register allows serial data TDI be loaded in to or read

out of the processor input/output ports. The Boundary Scan Register is a part
of the IEEE 1149.1-1990 Standard JTAG Implementation.

THE DEVICE IDENTIFICATION REGISTER

The Device Identification Register is a Read Only 32-bit register used to

specify the manufacturer, part number and version of the processor to be
determined through the TAP in response to the IDCODE instruction.

IDT JEDEC ID number is 0xB3. This translates to 0x33 when the parity

is dropped in the 11-bit Manufacturer ID field.

For the IDT72V7230/72V7240/72V7250/72V7260/72V7270/72V7280/

72V7290/72V72100, the Part Number field contains the following values:

Device

Part# Field

IDT72V7230

0x57

IDT72V7240

0x51

IDT72V7250

0x52

IDT72V7260

0x53

IDT72V7270

0x54

IDT72V7280

0x55

IDT72V7290

0x56

IDT72V72100

0x50

IDT72V7230/40/50/60/70/80/90/100

JTAG DEVICE IDENTIFICATION REGISTER

31(MSB)

28 27

12 11

1 0(LSB)

Version (4 bits)

Part Number (16-bit) Manufacturer ID (11-bit)

0X0

0X33

JTAG INSTRUCTION REGISTER

The Instruction register allows instruction to be serially input into the device

when the TAP controller is in the Shift-IR state. The instruction is decoded to
perform the following:

·
·
·
·
·

Select test data registers that may operate while the instruction is
current. The other test data registers should not interfere with chip
operation and the selected data register.

·
·
·
·
·

Define the serial test data register path that is used to shift data between
TDI and TDO during data register scanning.

The Instruction Register is a 4 bit field (i.e.IR3, IR2, IR1, IR0) to decode 16

different possible instructions. Instructions are decoded as follows.

JTAG INSTRUCTION REGISTER DECODING

Hex

Instruction

Function

Value
0x00

EXTEST

Select Boundary Scan Register

0x02

IDCODE

Select Chip Identification data register

0x01

SAMPLE/PRELOAD

Select Boundary Scan Register

0x03

HI-Z

JTAG

0x0F

BYPASS

Select Bypass Register

The following sections provide a brief description of each instruction. For

a complete description refer to the IEEE Standard Test Access Port Specification
(IEEE Std. 1149.1-1990).

EXTEST

The mandatory EXTEST instruction is provided for external circuity and

board level interconnection check.

IDCODE

This instruction is provided to select Device Identification Register to read

out manufacture's identity, part number and version number.

SAMPLE/PRELOAD

The mandatory SAMPLE/PRELOAD instruction allows data values to be

loaded onto the latched parallel outputs of the boundary-scan shift register prior
to selection of the boundary-scan test instruction. The SAMPLE instruction
allows a snapshot of data flowing from the system pins to the on-chip logic or
vice versa.

HIGH Z

This instruction places all the output pins on the device into a high impedance

state.

BYPASS

The Bypass instruction contains a single shift-register stage and is set to

provide a minimum-length serial path between the TDI and the TDO pins of the
device when no test operation of the device is required.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

- D

WEN

RCLK

REN

ENH

- Q

DATA READ

NEXT DATA READ

SKEW1

(1)

4680 drw15

WCLK

NO WRITE

WFF

ENS

(1)

CLK

CLKH

RCS

RCSS

RCSLZ

WFF

SKEW1

CLKL

X+1

WFF

NO OPERATION

RCLK

REN

4680 drw16

CLK

CLKH

CLKL

ENH

REF

OLZ

Q0 - Qn

WCLK

(1)

SKEW1

WEN

D0 - Dn

ENS

ENH

OLZ

NO OPERATION

LAST WORD

ENS

ENH

OHZ

LAST WORD

REF

ENH

ENS

REF

ENS

ENH

Figure 11. Read Cycle, Output Enable, Empty Flag and First Data Word Latency Timing (IDT Standard Mode)

NOTES:
1. t

SKEW1

is the minimum time between a rising WCLK edge and a rising RCLK edge to guarantee that

EF will go HIGH (after one RCLK cycle plus t

REF

). If the time between the

rising edge of WCLK and the rising edge of RCLK is less than t

SKEW1

, then

EF deassertion may be delayed one extra RCLK cycle.

LD = HIGH.

3. First data word latency = t

SKEW1

+ 1*T

RCLK

+ t

REF.

RCS is LOW.

NOTES:
1. t

SKEW1

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

FF will go HIGH (after one WCLK cycle pus t

WFF

). If the time between the

rising edge of the RCLK and the rising edge of the WCLK is less than t

SKEW1

, then the

FF deassertion may be delayed one extra WCLK cycle.

LD = HIGH, OE = LOW, EF = HIGH

Figure 10. Write Cycle and Full Flag Timing (IDT Standard Mode)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

[n +2]

[D-m-1]

[D-m-2]

[D-1]

[n+3]

[n+4]

[D-m]

[D-m+1]

WCLK

WEN

- D

RCLK

SKEW1

(1)

REN

- Q

PAF

PAE

SKEW2

REF

PAES

PAFS

WFF

[D-m+2]

ENH

4680 drw 18

PREVIOUS DATA IN OUTPUT REGISTER

(2)

D-1

]

[

D-1

]

[

D-1

]

[

ENS

RCS

RCSS

RCSLZ

Figure 13. Write Timing (First Word Fall Through Mode)

NOTES:

SKEW1

is the minimum time between a rising WCLK edge and a rising RCLK edge to guarantee that

will go LOW after two RCLK cycles plus t

REF

. If the time between the rising edge of WCLK and the rising edge of RCLK

is less than t

SKEW1

, then

assertion may be delayed one extra RCLK cycle.

SKEW2

is the minimum time between a rising WCLK edge and a rising RCLK edge to guarantee that

PAE

will go HIGH after one RCLK cycle plus t

PAES

. If the time between the rising edge of WCLK and the rising edge of RCLK

is less than t

SKEW2

, then the

PAE

deassertion may be delayed one extra RCLK cycle.

= HIGH,

= LOW

n =

PAE

offset, m =

PAF

offset and D = maximum FIFO depth.

5. D = 513 for IDT72V7230, 1,025 for IDT72V7240, 2,049 for IDT72V7250, 4,097 for IDT72V7260, 8,193 for IDT72V7270, 16,385 for

the IDT72V7280, 32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

First data word latency = t

SKEW1

+ 2*T

RCLK

+ t

REF.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WCLK

WEN

- D

RCLK

ENS

REN

- Q

PAF

PAE

m+2

[m+3]

OHZ

SKEW1

ENH

PAFS

WFF

ENS

SKEW2

4680 drw 19

PAES

[D-n]

[D-n-1]

REF

[D-1]

[D-n+1]

[m+4]

[D-n+2]

(1)

(2)

ENS

D-1

]

[

D-1

]

[

Figure 14. Read Timing (First Word Fall Through Mode)

NOTES:

1. t

SKEW1

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

will go LOW after one WCLK cycle plus t

WFF

. If the time between the rising edge of RCLK and the rising edge of WCLK

is less than t

SKEW1

, then the

assertion may be delayed one extra WCLK cycle.

SKEW2

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

PAF

will go HIGH after one WCLK cycle plus t

PAFS

. If the time between the rising edge of RCLK and the rising edge of WCLK

is less than t

SKEW2

, then the

PAF

deassertion may be delayed one extra WCLK cycle.

= HIGH.

n
=

PAE

Offset, m =

PAF

offset and D = maximum FIFO depth.

D = 513 for IDT72V7230, 1,025 for IDT72V7240, 2,049 for IDT72V7250, 4,097 for IDT72V7260, 8,193 for IDT72V7270, 16,385 for th

e IDT72V7280, 32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

RCS

= LOW.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WCLK

WEN

- D

RCLK

REN

- Q

PAF

PAE

m+2

[m+3]

RCSHZ

SKEW1

ENH

PAFS

WFF

ENS

RCS

SKEW2

4680 drw 20

PAES

[D-n]

[D-n-1]

[D-1]

[D-n+1]

[m+4]

[D-n+2]

(1)

(2)

ENS

RCSS

RCSLZ

ENS

REF

D-1

]

[

D-1

]

[

RCSH

Figure 15. Read Cycle and Read Chip Select Timing (First Word Fall Through Mode)

NOTES:

1. t

SKEW1

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

will go LOW after one WCLK cycle plus t

WFF

. If the time between the rising edge of RCLK and the rising edge of WCLK

is less than t

SKEW1

, then the

assertion may be delayed one extra WCLK cycle.

SKEW2

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

PAF

will go HIGH after one WCLK cycle plus t

PAFS

. If the time between the rising edge of RCLK and the rising edge of WCLK

is less than t

SKEW2

, then the

PAF

deassertion may be delayed one extra WCLK cycle.

= HIGH.

n
=

PAE

Offset, m =

PAF

offset and D = maximum FIFO depth.

D = 513 for IDT72V7230, 1,025 for IDT72V7240, 2,049 for IDT72V7250, 4,097 for IDT72V7260, 8,193 for IDT72V7270, 16,385 for th

e IDT72V7280, 32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

= LOW.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

RTS

ENH

4680 drw24

ENS

WCLK

RCLK

REN

PAF

PAE

- Q

SKEW2

PAFS

PAES

x+1

WEN

ENS

(4)

ENH

(4)

SCLK

SEN

4680 drw25

ENH

ENS

LDS

BIT 0

EMPTY OFFSET

BIT X

BIT 0

FULL OFFSET

(1)

ENH

BIT X

(1)

LDH

Figure 20. Serial Loading of Programmable Flag Registers (IDT Standard and FWFT Modes)

NOTE:
1. X = 9 for the IDT72V7230, X= 10 for the IDT72V7240, X = 11 for the IDT72V7250, X = 12 for the IDT72V7260, X = 13 for the IDT72V7270, X = 14 for the IDT72V7280,

X = 15 for the IDT72V7290 and X = 16 for the IDT72V72100.

NOTES:
1. If the part is empty at the point of Retransmit, the output ready flag (

OR) will be updated based on RCLK (Retransmit clock cycle), valid data will also appear on the output.

2. No more than D - 2 words may be written to the FIFO between Reset (Master or Partial) and Retransmit setup. Therefore,

IR will be LOW throughout the Retransmit setup procedure.

D = 513 for the IDT72V7230, 1,025 for the IDT72V7240, 2,049 for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for the IDT72V7270, 16,385 for the IDT72V7280, 32,769 for
the IDT72V7290 and 65,537 for the IDT72V72100.

OE = LOW; RCS = LOW.

4. W

, W

= first, second and third words written to the FIFO after Master Reset.

5. There must be at least two words written to the FIFO before a Retransmit operation can be invoked.
6. RM is set LOW during MRS.

Figure 19. Zero Latency Retransmit Timing (FWFT Mode)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WCLK

WEN

- D

4680 drw26

LDS

ENS

PAE

OFFSET

PAF

OFFSET

LDH

ENH

CLK

LDH

ENH

CLKH

CLKL

RCLK

REN

- Q

LDH

LDS

ENS

DATA IN OUTPUT REGISTER

PAE OFFSET

PAF OFFSET

ENH

LDH

4680 drw27

CLK

CLKH

CLKL

WCLK

WEN

PAF

RCLK

(3)

PAFS

REN

4680 drw 28

D - (m+1) words in FIFO

(2)

D - m words in FIFO

(2)

D-(m+1) words

in FIFO

(2)

PAFS

ENH

ENS

SKEW2

ENH

ENS

CLKL

NOTES:
1. m =

PAF offset.

2. D = maximum FIFO depth.

In IDT Standard mode: D = 512 for the IDT72V7230, 1,024 for the IDT72V7240, 2,048 for the IDT72V7250, 4,096 for the IDT72V7260 and 8,192 for the IDT72V7270, 16,384 for
the IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the IDT72V72100.
In FWFT mode: D = 513 for the IDT72V7230, 1,025 for the IDT72V7240, 2,049 for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for the IDT72V7270, 16,385 for the IDT72V7280,
32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

3. t

SKEW2

is the minimum time between a rising RCLK edge and a rising WCLK edge to guarantee that

PAF will go HIGH (after one WCLK cycle plus t

PAFS

). If the time between the

rising edge of RCLK and the rising edge of WCLK is less than t

SKEW2

, then the

PAF deassertion time may be delayed one extra WCLK cycle.

PAF is asserted and updated on the rising edge of WCLK only.

5. Select this mode by setting PFM HIGH during Master Reset.

Figure 23. Synchronous Programmable Almost-Full Flag Timing (IDT Standard and FWFT Modes)

NOTES:
1.

OE = LOW; RCS = LOW.

Figure 22. Parallel Read of Programmable Flag Registers (IDT Standard and FWFT Modes)

Figure 21. Parallel Loading of Programmable Flag Registers (IDT Standard and FWFT Modes)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WCLK

ENH

CLKH

CLKL

WEN

PAE

RCLK

ENS

n words in FIFO

(2)

n+1 words in FIFO

(3)

PAES

SKEW2

PAES

(4)

REN

4680 drw29

ENS

ENH

n+1 words in FIFO

(2)

n+2 words in FIFO

(3)

n words in FIFO

(2)

n+1 words in FIFO

(3)

WCLK

CLKH

CLKL

ENS

ENH

WEN

PAF

ENS

PAFA

D - (m + 1) words

in FIFO

RCLK

PAFA

REN

4680 drw30

D - m words

in FIFO

D - (m + 1) words in FIFO

NOTES:
1. n =

PAE offset.

2. For IDT Standard mode
3. For FWFT mode.
4. t

SKEW2

is the minimum time between a rising WCLK edge and a rising RCLK edge to guarantee that

PAE will go HIGH (after one RCLK cycle plus t

PAES

). If the time between the

rising edge of WCLK and the rising edge of RCLK is less than t

SKEW2

, then the

PAE deassertion may be delayed one extra RCLK cycle.

PAE is asserted and updated on the rising edge of WCLK only.

6. Select this mode by setting PFM HIGH during Master Reset.
7.

RCS is LOW.

Figure 24. Synchronous Programmable Almost-Empty Flag Timing (IDT Standard and FWFT Modes)

NOTES:
1. m =

PAF offset.

2. D = maximum FIFO Depth.

In IDT Standard Mode: D = 512 for the IDT72V7230, 1,024 for the IDT72V7240, 2,048 for the IDT72V7250, 4,096 for the IDT72V7260, 8,192 for the IDT72V7270, 16,384 for the
IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the IDT72V72100.
In FWFT Mode: D = 513 for the IDT72V7230, 1,025 for the IDT72V7240, 2,049 for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for the IDT72V7270, 16,385 for the IDT72V7280,
32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

PAF is asserted to LOW on WCLK transition and reset to HIGH on RCLK transition.

4. Select this mode by setting PFM LOW during Master Reset.

Figure 25. Asynchronous Programmable Almost-Full Flag Timing (IDT Standard and FWFT Modes)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WCLK

CLKH

CLKL

ENS

ENH

WEN

PAE

ENS

PAEA

n + 1 words in FIFO

(2),

n + 2 words in FIFO

(3)

n words in FIFO

(2),

n + 1 words in FIFO

(3)

RCLK

PAEA

REN

4680 drw 31

n words in FIFO

(2),

n + 1 words in FIFO

(3)

WCLK

ENS

ENH

WEN

ENS

RCLK

REN

4680 drw32

CLKL

CLKH

D/2 words in FIFO

(1)

[

+ 1

]

words in FIFO

(2)

D-1

D/2 + 1 words in FIFO

(1)

[

+ 2

]

words in FIFO

(2)

D/2 words in FIFO

(1)

[

+ 1

]

words in FIFO

(2)

D-1

NOTES:
1. n =

PAE offset.

2. For IDT Standard Mode.
3. For FWFT Mode.
4.

PAE is asserted LOW on RCLK transition and reset to HIGH on WCLK transition.

5. Select this mode by setting PFM LOW during Master Reset.

NOTES:
1. In IDT Standard mode: D = maximum FIFO depth. D = 512 for the IDT72V7230, 1,024 for the IDT72V7240, 2,048 for the IDT72V7250, 4,096 for the IDT72V7260, 8,192 for the

IDT72V7270, 16,384 for the IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the IDT72V72100.

2. In FWFT mode: D = maximum FIFO depth. D = 513 for the IDT72V7230, 1,025 for the IDT72V7240, 2,049 for the IDT72V7250, 4,097 for the IDT72V7260, 8,193 for the IDT72V7270,

16,385 for the IDT72V7280, 32,769 for the IDT72V7290 and 65,537 for the IDT72V72100.

Figure 27. Half-Full Flag Timing (IDT Standard and FWFT Modes)

Figure 26. Asynchronous Programmable Almost-Empty Flag Timing (IDT Standard and FWFT Modes)

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

WRITE CLOCK (WCLK)

m + n

MASTER RESET (

MRS)

READ CLOCK (RCLK)

DATA OUT

m + n

WRITE ENABLE (

WEN)

FULL FLAG/INPUT READY (

FF/IR)

PROGRAMMABLE (

PAF)

PROGRAMMABLE (

PAE)

EMPTY FLAG/OUTPUT READY (

EF/OR) #2

OUTPUT ENABLE (

OE)

READ ENABLE (

REN)

LOAD (

LD)

EMPTY FLAG/OUTPUT READY (

EF/OR) #1

PARTIAL RESET (

PRS)

4680 drw 33

FULL FLAG/INPUT READY (

FF/IR) #2

HALF-FULL FLAG (

HF)

FIRST WORD FALL THROUGH/

SERIAL INPUT (FWFT/SI)

RETRANSMIT (

RT)

FIFO

GATE

(1)

GATE

(1)

- Dm

DATA IN

- Dn

- Qn

FIFO

IDT

72V7230
72V7240
72V7250
72V7260
72V7270
72V7280
72V7290

72V72100

IDT

72V7230
72V7240
72V7250
72V7260
72V7270
72V7280
72V7290

72V72100

READ SHIP SELECT (

RCS)

NOTES:
1. Use an AND gate in IDT Standard mode, an OR gate in FWFT mode.
2. Do not connect any output control signals directly together.
3. FIFO #1 and FIFO #2 must be the same depth, but may be different word widths.

OPTIONAL CONFIGURATIONS

WIDTH EXPANSION CONFIGURATION

Word width may be increased simply by connecting together the control

signals of multiple devices. Status flags can be detected from any one device.
The exceptions are the

EF and FF functions in IDT Standard mode and the IR

and

OR functions in FWFT mode. Because of variations in skew between RCLK

and WCLK, it is possible for

EF/FF deassertion and IR/OR assertion to vary

by one cycle between FIFOs. In IDT Standard mode, such problems can be

Figure 28. Block Diagram of 512 x 144, 1,024 x 144, 2,048 x 144, 4,096 x 144, 8,192 x 144, 16,384 x 144, 32,768 x 144 and 65,536 x 144 Width Expansion

avoided by creating composite flags, that is, ANDing

EF of every FIFO, and

separately ANDing

FF of every FIFO. In FWFT mode, composite flags can be

created by ORing

OR of every FIFO, and separately ORing IR of every FIFO.

Figure 28 demonstrates a width expansion using two IDT72V7230/

72V7240/72V7250/72V7260/72V7270/72V7280/72V7290/72V72100 de-
vices. D

- D

from each device form a 144-bit wide input bus and Q

-Q

from each device form a 144-bit wide output bus. Any word width can be attained
by adding additional IDT72V7230/72V7240/72V7250/72V7260/72V7270/
72V7280/72V7290/72V72100 devices.

COMMERCIAL TEMPERATURE RANGE

IDT72V7230/7240/7250/7260/7270/7280/7290/72100 3.3V HIGH DENSITY SUPERSYNC II

FIFO

512 x 72, 1K x 72, 2K x 72, 4K x 72, 8K x 36, 16K x 72, 32K x 72, 64K x 72

INPUT READY

WRITE ENABLE

WRITE CLOCK

WEN

WCLK

DATA IN

RCLK

READ CLOCK

RCLK

REN

OUTPUT ENABLE

OUTPUT READY

GND

WEN

WCLK

REN

READ ENABLE

DATA OUT

TRANSFER CLOCK

4680 drw34

FWFT/SI

IDT

72V7230
72V7240
72V7250
72V7260
72V7270
72V7280
72V7290

72V72100

IDT

72V7230
72V7240
72V7250
72V7260
72V7270
72V7280
72V7290

72V72100

READ CIP SELECT

RCS

Figure 29. Block Diagram of 1,024 x 72, 2,048 x 72, 4,096 x 72, 8,192 x 72, 16,384 x 72, 32,768 x 72, 65,572 x 72 and 131,072 x 72 Depth Expansion

DEPTH EXPANSION CONFIGURATION (FWFT MODE ONLY)

The IDT72V7230 can easily be adapted to applications requiring depths

greater than 512, 1,024 for the IDT72V7240, , 2,048 for the IDT72V7250,
4,096 for the IDT72V7260, 8,192 for the IDT72V7270, 16,384 for the
IDT72V7280, 32,768 for the IDT72V7290 and 65,536 for the IDT72V72100
with an 72-bit bus width. In FWFT mode, the FIFOs can be connected in series
(the data outputs of one FIFO connected to the data inputs of the next) with no
external logic necessary. The resulting configuration provides a total depth
equivalent to the sum of the depths associated with each single FIFO. Figure
29 shows a depth expansion using two IDT72V7230/72V7240/72V7250/
72V7260/72V7270/72V7280/72V7290/72V72100 devices.

Care should be taken to select FWFT mode during Master Reset for all FIFOs

in the depth expansion configuration. The first word written to an empty
configuration will pass from one FIFO to the next ("ripple down") until it finally
appears at the outputs of the last FIFO in the chain no read operation is
necessary but the RCLK of each FIFO must be free-running. Each time the
data word appears at the outputs of one FIFO, that device's

OR line goes LOW,

enabling a write to the next FIFO in line.

For an empty expansion configuration, the amount of time it takes for

OR of

the last FIFO in the chain to go LOW (i.e. valid data to appear on the last FIFO's
outputs) after a word has been written to the first FIFO is the sum of the delays
for each individual FIFO:

(N 1)*(4*transfer clock) + 3*T

RCLK

where N is the number of FIFOs in the expansion and T

RCLK

is the RCLK

period. Note that extra cycles should be added for the possibility that the t

SKEW1

specification is not met between WCLK and transfer clock, or RCLK and transfer
clock, for the

OR flag.

The "ripple down" delay is only noticeable for the first word written to an empty

depth expansion configuration. There will be no delay evident for subsequent
words written to the configuration.

The first free location created by reading from a full depth expansion

configuration will "bubble up" from the last FIFO to the previous one until it finally
moves into the first FIFO of the chain. Each time a free location is created in one
FIFO of the chain, that FIFO's

IR line goes LOW, enabling the preceding FIFO

to write a word to fill it.

For a full expansion configuration, the amount of time it takes for

IR of the first

FIFO in the chain to go LOW after a word has been read from the last FIFO is
the sum of the delays for each individual FIFO:

(N 1)*(3*transfer clock) + 2 T

WCLK

where N is the number of FIFOs in the expansion and T

WCLK

is the WCLK

period. Note that extra cycles should be added for the possibility that the t

SKEW1

specification is not met between RCLK and transfer clock, or WCLK and transfer
clock, for the

IR flag.

The Transfer Clock line should be tied to either WCLK or RCLK, whichever

is faster. Both these actions result in data moving, as quickly as possible, to the
end of the chain and free locations to the beginning of the chain.
