Intel
82443MX PCIset
Specification Update
April 2001
Notice: The Intel 82443MX PCIset may contain design defects or errors known as
errata which may cause the product to deviate from published specifications. Current
characterized errata are documented in this Specification Update.
R
Intel
82443MX PCIset
2
Specification
Update
R
Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual
property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability
whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness
for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in
medical, life saving, or life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future
definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The Intel 82443MX PCIset may contain design defects or errors known as errata which may cause the product to deviate from published specifications.
Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained by calling
1-800-548-4725 or by visiting Intel's website at
http://www.intel.com
.
Intel is a registered trademark of Intel corporation and its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright Intel Corporation 2001
R
Intel
82443MX PCIset
Specification Update
3
Contents
Revision History ........................................................................................................................... 4
Preface......................................................................................................................................... 5
Identification Information.............................................................................................................. 9
Specification Changes ............................................................................................................... 10
Errata ......................................................................................................................................... 11
Specification Clarifications ......................................................................................................... 29
Documentation Changes ........................................................................................................... 30
Intel
82443MX PCIset
4
Specification
Update
R
Revision History
Date of Revision
Revision
Description
6/22/99
-001
Document includes all known specifications to date (original
version).
9/18/99 -002
Added
Erratum
#32
Added workarounds to Errata #30 and #31
01/18/99 -003
Added
Erratum
#33
Added Document Changes #1, #2 and #3
08/18/00
-004
Added Erratum #34 and #35
03/06/2001 -005
Added
Erratum
#36
Updated Errata #33 - Removed workaround option #3
(Option #3 will be revised in Q2 2001 release of 440MX
Specification Update for USB high-speed device compatibility.)
R
Intel
82443MX PCIset
Specification Update
5
Preface
This document is an update to the specifications contained in the Intel
82443MX PCIset Datasheet and
other documents related to the 82443MX PCIset. It is intended for hardware system manufacturers. It
contains Specification Changes, Errata, Specification Clarifications, and Documentation Changes.
Nomenclature
Specification Changes are modifications to the current published specifications. These changes will be
incorporated in the next release of the specifications.
Errata are design defects or errors. Errata may cause the Intel 82443MX PCIset behavior to deviate
from published specifications. Hardware and software designed to be used with any given stepping must
assume that all errata documented for that stepping are present on all devices.
Specification Clarifications describe a specification in greater detail or further highlight a
specification's impact to a complex design situation. These clarifications will be incorporated in the next
release of the specifications.
Documentation Changes include typos, errors, or omissions from the current published specifications.
These changes will be incorporated in the next release of the specifications.
Note: Errata remain in the specification update throughout the product's lifecycle or until a particular stepping
is no longer commercially available. Under these circumstances, errata removed from the specification
update are archived and available upon request. Specification changes, specification clarifications, and
documentation changes are removed from the specification update when the appropriate changes are
made to the appropriate product specification or documentation.
