RURP8120
8A, 1200V Ultrafast Diode
The RURP8120 is an ultrafast diode with soft recovery
characteristics (t
rr
< 100ns). It has low forward voltage drop
and is of silicon nitride passivated ion-implanted epitaxial
planar construction.
This device is intended for use as a freewheeling/clamping
diode and rectifier in a variety of switching power supplies
and other power switching applications. Its low stored charge
and ultrafast soft recovery minimize ringing and electrical
noise in many power switching circuits, thus reducing power
loss in the switching transistors.
Formerly developmental type TA49095.
Symbol
Features
Ultrafast with Soft Recovery . . . . . . . . . . . . . . . . . . <100ns
Operating Temperature. . . . . . . . . . . . . . . . . . . . . . .175
o
C
Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . .1200V
Avalanche Energy Rated
Planar Construction
Applications
Switching Power Supplies
Power Switching Circuits
General Purpose
Packaging
JEDEC TO-220AC
Ordering Information
PART NUMBER
PACKAGE
BRAND
RURP8120
TO-220AC
RURP8120
NOTE: When ordering, use the entire part number.
K
A
CATHODE
ANODE
CATHODE
(FLANGE)
Absolute Maximum Ratings
T
C
= 25
o
C, Unless Otherwise Specified
RURP8120
UNITS
Peak Repetitive Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
RRM
1200
V
Working Peak Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
RWM
1200
V
DC Blocking Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .V
R
1200
V
Average Rectified Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
F(AV)
(T
C
= 144
o
C)
8
A
Repetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
FRM
(Square Wave, 20kHz)
16
A
Nonrepetitive Peak Surge Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I
FSM
(Halfwave, 1 Phase, 60Hz)
100
A
Maximum Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P
D
75
W
Avalanche Energy (See Figure 10 and Figure 11). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E
AVL
20
mJ
Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .T
STG
, T
J
-65 to 175
o
C
Data Sheet
January 2000
2
Electrical Specifications
T
C
= 25
o
C, Unless Otherwise Specified
SYMBOL
TEST CONDITION
MIN
TYP
MAX
UNITS
V
F
I
F
= 8A
-
-
2.1
V
I
F
= 8A, T
C
= 150
o
C
-
-
1.9
V
I
R
V
R
= 1200V
-
-
100
A
V
R
= 1200V, T
C
= 150
o
C
-
-
500
A
t
rr
I
F
= 1A, dI
F
/dt = 100A/
s
-
-
100
ns
I
F
= 8A, dI
F
/dt = 100A/
s
-
-
110
ns
t
a
I
F
= 8A, dI
F
/dt = 100A/
s
-
60
-
ns
t
b
I
F
= 8A, dI
F
/dt = 100A/
s
-
40
-
ns
Q
RR
I
F
= 8A, dI
F
/dt = 100A/
s
-
380
-
nC
C
J
V
R
= 10V, I
F
= 0A
-
25
-
pF
R
JC
-
-
2
o
C/W
DEFINITIONS
V
F
= Instantaneous forward voltage (pw = 300
s, D = 2%).
I
R
= Instantaneous reverse current.
t
rr
= Reverse recovery time (See Figure 9), summation of t
a
+ t
b
.
t
a
= Time to reach peak reverse current (See Figure 9).
t
b
= Time from peak I
RM
to projected zero crossing of I
RM
based on a straight line from peak I
RM
through 25% of I
RM
(See Figure 9).
R
JC
= Thermal resistance junction to case.
Q
RR
= Reverse Recovery Charge.
C
J
= Junction Capacitance.
pw = pulse width.
D = duty cycle.
Typical Performance Curves
FIGURE 1. FORWARD CURRENT vs FORWARD VOLTAGE
FIGURE 2. REVERSE CURRENT vs REVERSE VOLTAGE
V
F
, FORWARD VOLTAGE (V)
I
F
, FOR
W
ARD CURRENT (A)
1
40
0.5
10
0
0.5
1
1.5
2
2.5
3
25
o
C
100
o
C
175
o
C
V
R
, REVERSE VOLTAGE (V)
0
400
800
1200
600
1000
500
0.01
0.1
1
10
I
R
, REVERSE CURRENT (
A)
200
0.001
175
o
C
25
o
C
100
o
C
100
RURP8120
3
FIGURE 3. t
rr
, t
a
AND t
b
CURVES vs FORWARD CURRENT
FIGURE 4. t
rr
, t
a
AND t
b
CURVES vs FORWARD CURRENT
FIGURE 5. t
rr
, t
a
AND t
b
CURVES vs FORWARD CURRENT
FIGURE 6. CURRENT DERATING CURVE
FIGURE 7. JUNCTION CAPACITANCE vs REVERSE VOLTAGE
Typical Performance Curves
(Continued)
I
F
, FORWARD CURRENT (A)
0.5
0
75
50
25
8
1
trr
100
125
t
,
RECO
VER
Y TIMES (ns)
ta
tb
4
T
C
= 25
o
C, dI
F
/dt = 100A/
s
50
100
150
t
,
RECO
VER
Y TIMES (ns)
I
F
, FORWARD CURRENT (A)
0.5
0
8
1
4
200
T
C
= 100
o
C, dI
F
/dt = 100A/
s
tb
ta
trr
100
trr
200
300
t
,
RECO
VER
Y TIMES (ns)
I
F
, FORWARD CURRENT (A)
0.5
0
8
1
4
ta
tb
T
C
= 175
o
C, dI
F
/dt = 100A/
s
10
2
0
100
115
145
175
160
4
6
8
T
C
, CASE TEMPERATURE (
o
C)
I
F(A
V)
, A
VERA
GE FOR
W
ARD CURRENT (A)
130
DC
SQ. WAVE
V
R
, REVERSE VOLTAGE (V)
20
100
0
40
0
50
100
150
200
80
60
C
J
, JUNCTION CAP
A
CIT
ANCE (pF)
RURP8120
4
