D4
Symbol
Test Conditions
Maximum Ratings
I
FRMS
35
A
I
FAV
T
C
= 165
C; rectangular, d = 0.5
8
A
I
FAV
T
C
= 165
C; rectangular, d = 0.5; per device
16
A
I
FSM
T
VJ
= 45C; t
p
= 10 ms (50 Hz), sine
120
A
E
AS
I
AS
= 8 A; L = 180 H; T
VJ
= 25C; non repetitive
tbd
mJ
I
AR
V
A
=1.5 V
RRM
typ.; f=10 kHz; repetitive
tbd
A
(dv/dt)
cr
5000
V/s
T
VJ
-55...+175
C
T
VJM
175
C
T
stg
-55...+150
C
P
tot
T
C
= 25
C
90
W
M
d
mounting torque
0.4...0.6
Nm
Weight
typical
2
g
I
FAV
= 2x8 A
V
RRM
= 100 V
V
F
= 0.62 V
204
DSSK 16-01C
V
RSM
V
RRM
Type
V
V
100
100
DSSK 16-01C
Symbol
Test Conditions
Characteristic Values
typ.
max.
I
R
T
VJ
= 25C; V
R
= V
RRM
0.3
mA
T
VJ
= 125C; V
R
= V
RRM
20
mA
V
F
I
F
= 8 A;
T
VJ
= 125C
0.62
V
I
F
= 8 A;
T
VJ
=
25C
0.79
V
I
F
= 16 A;
T
VJ
= 125 C
0.73
V
R
thJC
1.7
K/W
R
thCH
0.5
K/W
Pulse test:
Pulse Width = 5 ms, Duty Cycle < 2.0 %
Data according to IEC 60747 and per diode unless otherwise specified
Power Schottky Rectifier
with common cathode
Preliminary Data
Features
International standard package
Very low V
F
Extremely low switching losses
Low I
RM
-values
Epoxy meets UL 94V-0
Applications
Rectifiers in switch mode power
supplies (SMPS)
Free wheeling diode in low voltage
converters
Advantages
High reliability circuit operation
Low voltage peaks for reduced
protection circuits
Low noise switching
Low losses
Dimensions see IXYS Databook 2001
A
C
A
TO-220 AB
A = Anode, C = Cathode , TAB = Cathode
C (TAB)
A
C
A
