2004 IXYS All rights reserved
1 - 1
427
DSSK 80-006BR
IXYS reserves the right to change limits, test conditions and dimensions.
Advanced Technical Information
I
FAV
= 2x40 A
V
RRM
= 60 V
V
F
= 0.51 V
Symbol
Conditions
Maximum Ratings
I
FRMS
70
A
I
FAV
T
C
= 120C; rectangular, d = 0.5
40
A
I
FAV
T
C
= 120C; rectangular, d = 0.5; per device
80
A
I
FSM
T
VJ
= 45C; t
p
= 10 ms (50 Hz), sine
600
A
E
AS
I
AS
= 20 A; L = 100 H; T
VJ
= 25C; non repetitive
20
mJ
I
AR
V
A
=1.5 V
RRM
typ.; f=10 kHz; repetitive
2
A
(dv/dt)
cr
tbd
V/s
T
VJ
-55...+150
C
T
VJM
150
C
T
stg
-55...+150
C
P
tot
T
C
= 25C
155
W
F
C
mounting force with clip
20...120
N
V
ISOL
50/60 Hz, RMS, t = 1 minute, leads-to-tab
2500
V~
Weight
typical
6
g
V
RSM
V
RRM
Type
V
V
60
60
DSSK 80-006BR
Symbol
Conditions
Characteristic Values
typ.
max.
I
R
V
R
= V
RRM
; T
VJ
= 25C
22
mA
V
R
= V
RRM
; T
VJ
= 100C
200
mA
V
F
I
F
= 40 A;
T
VJ
= 125C
0.51
V
I
F
= 40 A;
T
VJ
= 25C
0.55
V
I
F
= 80 A;
T
VJ
= 125C
0.74
V
R
thJC
0.8
K/W
R
thCH
0.25
K/W
Pulse test:
Pulse Width = 5 ms, Duty Cycle < 2.0 %
Data according to IEC 60747 and per diode unless otherwise specified
Power Schottky Rectifier
with common cathode
Features
International standard package
Very low V
F
Extremely low switching losses
Low I
RM
-values
Isolated and UL registered E153432
Applications
Rectifiers in switch mode power
supplies (SMPS)
Free wheeling diode in low voltage
converters
Advantages
High reliability circuit operation
Low voltage peaks for reduced
protection circuits
Low noise switching
Low losses
Dimensions see Outlines.pdf
C = Cathode, A = Anode
ISOPLUS 247
TM
A
A
C
Isolated
back surface *
A
C
A
