KING BILLION ELECTRONICS CO., LTD
HE83R142
HE80000 SERIES
1
V1.01E
A.HE83R142 Introduction
HE83R142
is a member of 8-bit Micro-controller series developed by King Billion Electronics Ltd
.
Users can chose any one of combination among 1024 dots LCD Driver + 16 Bit I/O Port...896 dots
LCD Driver + 24 Bit I/O Portetc. The built-in OP comparator can be used with (lightvoice
temperaturehumility) sensor and used as battery low detection. The 7-bit current-type D/A converter and
PWM device provide the complete speech output mechanism. The 256K ROM Size can be used in the
storage of speechgraphictext etc.. . It can be applicable to the medium systems such as Small-Scale
Dictionary, Data Bank, Educational Toy, Digital Voice Recording System etc. It also can be connected to
SRAM or Flash RAM for recording function.
The instruction set of HE83R142 are quite easy to learn and simple to use. Only about thirty instructions
with four-type addressing mode are provided. Most of instructions take only 3 oscillator clocks (machine
cycles). The processing power is enough to most of battery operation system.
B.HE83R142 Features
Operation Voltage
2.4V 5.5V
System Clock
DC ~ 8MHz @ 5.0V
DC
~
4MHz
@
2.4V
Internal ROM
256K
Bytes
Internal RAM
4K
Bytes
Dual Clock System
Normal (Fast) clock 32.768K ~ 8MHz
Slow
clock
32.768KHz
Operation Mode DUALFASTSLOWIDLESLEEP Mode.
With WDT (WATCH DOG TIMER) to prevent deadlock condition.
16~24 bit Bi-directional I/O port.
Mask Option can select PUSH-PULL or OPEN DRAIN
output mode for each I/O pin. 8 of them are shared with LCD segment pins.
One built-in OP comparator.
1024~896 dots LCD driver (B TYPE selectable).
(No LCD contrast control function)
Build in LCD Voltage Regulator.
One 7-bit current-type DAC output.
PWM device.
Two external interrupts and three internal timer interrupts.
Two 16-bit timers and one Time-Base timer.
Instruction set 32 instructions, 4 addressing mode. 12-bit DATA POINTER for RAM and
18-bit TABLE POINTER for ROM.
