SPEC NO: DSAD1385
REV NO: V.1
DATE:MAR/30/2003
PAGE: 1 OF 3
APPROVED: J. Lu
CHECKED: Allen Liu
DRAWN:D.L.HUANG
SUBMINIATURE SOLID STATE LAMP
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
Features
SUBMINIATURE PACKAGE.
WIDE VIEWING ANGLE.
RIGHT ANGLE BEND.
LONG LIFE SOLID STATE RELIABILITY.
LOW PACKAGE PROFILE.
Package Dimensions
AM27SRD10 SUPER BRIGHT RED
Description
The Super Bright Red source color devices are made
with Gallium Aluminum Arsenide Red Light Emitting
Diode.
SPEC NO: DSAD1385
REV NO: V.1
DATE:MAR/30/2003
PAGE: 2 OF 3
APPROVED: J. Lu
CHECKED: Allen Liu
DRAWN:D.L.HUANG
Selection Guide
Note:
1
. 1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Absolute Maximum Ratings at T
A
=25
C
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
