SPEC NO: DSAB2992
REV NO: V.3
DATE:DEC/09/2002
PAGE: 1 OF 5
APPROVED : J. Lu
CHECKED :Joe Lee
DRAWN:D.L.HUANG
SURFACE MOUNT DISPLAY
APCA03-41SYKWA SUPER BIRHGT YELLOW
Package Dimensions
& Internal Circuit Diagram
Features
!
0.3INCH DIGIT HEIGHT.
!
LOW CURRENT OPERATION.
!
EXCELLENT CHARACTER APPEARANCE.
!
I.C. COMPATIBLE.
!
MECHANICALLY RUGGED.
!
GRAY FACE,WHITE SEGMENT.
!
PACKAGE : 800PCS / REEL.
Description
The Super Bright Yellow source color devices are
made with DH InGaAlP on GaAs substrate Light
Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches), Tolerance is
0.25(0.01")unless otherwise noted.
2. Specifications are subject to change whitout notice.
