SPEC NO: DSAD1891
REV NO: V.1
DATE:APR/13/2003 PAGE: 1 OF 3
APPROVED: J.LU
CHECKED: Allen Liu
DRAWN:L.ZHANG
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
Package Dimensions
2x5mm RECTANGULAR LED LAMP
Features
!
LOW POWER CONSUMPTION.
!
RELIABLE AND RUGGED.
!
EXCELLENT UNIFORMITY OF LIGHT OUTPUT.
!
SUITABLE FOR LEVEL INDICATOR.
!
LONG LIFE - SOLID STATE RELIABILITY.
W113HDT BRIGHT RED
Description
The Bright Red source color devices are made with
Gallium Phosphide Red Light Emitting Diode.
SPEC NO: DSAD1891
