SPEC NO: DSAD0865
REV NO: V.1
DATE: APR/05/2003
PAGE: 1 OF 3
APPROVED: J. Lu
CHECKED: Allen Liu
DRAWN: K.ZHANG
2.4mm FLAT TOP LED LAMP
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
0.25(0.01") unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
Features
!
LOW POWER CONSUMPTION.
!
I.C. COMPTATIBLE.
!
LONG LIFE-SOLID STATE RELIABILITY.
!
FITS 2.4mm HOLE IN PANEL UP TO 4mm THICK.
Package Dimensions
W443HDT BRIGHT RED
Description
The Bright Red source color devices are made with
Gallium Phosphide Red Light Emitting Diode.
