DFM600LXS18-A000
FEATURES
s
Low Reverse Recovery Charge
s
High Switching Speed
s
Low Forward Voltage Drop
s
Isolated Base
APPLICATIONS
s
Brake Chopper Diode
s
Boost and Buck Converters
s
Free-wheel Circuits
s
Motor Drives
s
Resonant Converters
s
Induction Heating
s
Multi-level Switch Inverters
The DFM600LXS18-A000 is a single 1800 volt fast
recovery diode (FRD) module. Designed for low power
loss, the module is suitable for a variety of high voltage
applications in motor drives and power conversion.
Fast switching times and low reverse recovery losses
allow high frequency operation making the device suitable
for the latest drive designs employing PWM and high
frequency switching.
These modules incorporate electrically isolated base
plates and low inductance construction enabling circuit
designers to optimise circuit layouts and utilise grounded
heat sinks for safety.
ORDERING INFORMATION
Order As:
DFM600LXS18-A000
Note: When ordering, please use the complete part number.
DFM600LXS18-A000
Fast Recovery Diode Module
Preliminary Information
DS5430-1.4 April 2001
KEY PARAMETERS
V
RRM
1800V
V
F
(typ)
2.0V
I
F
(max)
600A
I
FM
(max)
1200A
Fig. 1 Circuit diagram
Fig. 2 Electrical connections - (not to scale)
Outline type code: L
(See package details for further information)
1
2
1
2
DFM600LXS18-A000
2/7
www.dynexsemi.com
Units
V
A
A
kA
2
s
W
kV
pC
ABSOLUTE MAXIMUM RATINGS
Stresses above those listed under 'Absolute Maximum Ratings' may cause permanent damage to the device. In extreme
conditions, as with all semiconductors, this may include potentially hazardous rupture of the package. Appropriate safety
precautions should always be followed. Exposure to Absolute Maximum Ratings may affect device reliability.
T
case
= 25C unless stated otherwise
Symbol
V
RRM
I
F
I
FM
I
2
t
P
max
V
isol
Q
pd
Test Conditions
T
vj
= 25C
DC, T
case
= 65C
T
case
= 110C, t
p
= 1ms
V
R
= 0, t
p
= 10ms, T
vj
= 125C
T
case
= 25C, T
vj
= 125C
Commoned terminals to base plate. AC RMS, 1 min, 50Hz
IEC1287. V
1
= 1500V, V
2
= 1100V, 50Hz RMS
Max.
1800
600
1200
120
2080
4.0
10
Parameter
Repetitive peak reverse voltage
Forward current
Max. forward current
I
2
t value fuse current rating
Maximum power dissipation
Isolation voltage
Partial discharge
Test Conditions
Continuous dissipation -
junction to case
Mounting torque 5Nm
(with mounting grease)
-
-
Mounting - M6
Electrical connections - M6
Parameter
Thermal resistance - diode
Thermal resistance - case to heatsink
(per module)
Junction temperature
Storage temperature range
Screw torque
THERMAL AND MECHANICAL RATINGS
Symbol
R
th(j-c)
R
th(c-h)
T
j
T
stg
-
Units
C/kW
C/kW
C
C
Nm
Nm
Max.
48
15
125
125
5
5
Typ.
-
-
-
-
-
-
Min.
-
-
-
40
-
-
Internal insulation:
Al
2
O
3
Baseplate material:
Cu
Creepage distance:
22mm
Clearance:
12mm
CTI (Critical Tracking Index): 175
3/7
www.dynexsemi.com
DFM600LXS18-A000
Test Conditions
I
F
= 600A,
dI
F
/dt = 4000A/
s,
V
R
= 900V
Test Conditions
V
R
= 1800V, T
vj
= 125C
I
F
= 600A
I
F
= 600A, T
vj
= 125C
-
Parameter
Peak reverse current
Forward voltage
Module inductance
STATIC ELECTRICAL CHARACTERISTICS
T
vj
= 25C unless stated otherwise.
Symbol
I
RM
V
F
L
M
Units
mA
V
V
nH
Max.
10
2.3
2.3
-
Typ.
-
2.0
2.0
15
Min.
-
-
-
-
Parameter
Peak reverse recovery current
Reverse recovery charge
Reverse recovery energy
Symbol
I
rr
Q
rr
E
rec
Units
A
C
mJ
Max.
-
-
-
Typ.
440
160
120
Min.
-
-
-
DYNAMIC ELECTRICAL CHARACTERISTICS
T
vj
= 25C unless stated otherwise.
T
vj
= 125C unless stated otherwise.
Test Conditions
I
F
= 600A,
dI
F
/dt = 4000A/
s,
V
R
= 900V
Parameter
Peak reverse recovery current
Reverse recovery charge
Reverse recovery energy
Symbol
I
rr
Q
rr
E
rec
Units
A
C
mJ
Max.
-
-
-
Typ.
510
270
180
Min.
-
-
-
DFM600LXS18-A000
4/7
www.dynexsemi.com
TYPICAL CHARACTERISTICS
Fig. 2 Diode typical forward characteristics
Fig. 4 Transient thermal impedance
Fig. 5 Power dissipation
Fig. 6 DC current rating vs case temperature
0
100
100
300
400
500
600
700
800
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
Foward voltage, V
F
- (V)
Foward current, I
F
- (A)
T
j
= 125C
T
j
= 25C
1
10
100
0.001
0.01
1
0.1
10
Pulse width, t
p
- (s)
Transient thermal impedance, Z
th (j-c)
- (
C/kW )
R
i
(C/KW)
i
(ms)
1
2.8086
0.006863
2
10.5142
1.8477
3
16.6906
14.6244
4
66.004
76.68
0
1000
2000
3000
0
20
40
60
80
100
120
140
160
Case temperature, T
case
- (C)
Power dissipation, P
tot
- (W)
0
200
400
600
800
1000
1200
0
20
40
60
80
100
120
140
160
Case temperature, T
case
- (C)
DC forward current, I
F
- (A)
5/7
www.dynexsemi.com
DFM600LXS18-A000
Fig. 7 RBSOA
0
100
200
300
400
500
600
700
800
0
400
800
1200
1600
2000
Reverse voltage, V
R
- (V)
Reverse recovery current, I
rr
- (A)
T
j
= 125C
